Oldal 1/32
GB
Drill Instruction Manual
F
Perceuse Manuel d’instructions
D
Bohrmaschine Betriebsanleitung
I
Trapano Istruzioni per l’uso
NL
Boormachine Gebruiksaanwijzing
E
Taladro Manual de instrucciones
P
Furadeira Manual de instruções
DK
Boremaskine Brugsanvisning
GR Τρυπάνι Οδηγίες χρήσεως
MT605
MT606
MT607
2
1 2
3 4
5
6
4
A
B
3
1
2
3
ENGLISH (Original instructions)
Explanation of general view
1 Switch trigger
2 Lock button
3 Reversing switch lever
4 Chuck key
5 Sleeve
6 Ring
SPECIFICATIONS
Model MT605 MT606 MT607
Capacities
Steel ........................................................................... 10 mm 10 mm 10 mm
Wood ......................................................................... 25 mm 25 mm 25 mm
No load speed (min–1) .................................................. 3,000 0 – 3,000 0 – 3,000
Overall length ............................................................... 229 mm 229 mm 234 mm
Net weight ..................................................................... 1.3 kg 1.3 kg 1.3 kg
Safety class ................................................................... /II /II /II
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE032-1
Intended use
The tool is intended for drilling in wood, metal and plastic.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
GEA010-1
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future refer-
ence.
GEB001-6
DRILL SAFETY WARNINGS
1. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
2. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
3. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
4. Hold the tool firmly.
5. Keep hands away from rotating parts.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Do not touch the drill bit or the workpiece imme-
diately after operation; they may be extremely
hot and could burn your skin.
8. Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation
and skin contact. Follow material supplier safety
data.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this instruc-
tion manual may cause serious personal injury.
FUNCTIONAL DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and
unplugged before adjusting or checking function on the
tool.
Switch action (Fig. 1)
CAUTION:
• Before plugging in the tool, always check to see the
switch trigger actuates properly and returns to the
“OFF” position when released.
For MT605
To start the tool, simply pull the switch trigger. Release
the switch trigger to stop.
For continuous operation, pull the switch trigger and then
push in the lock button.
To stop the tool from the locked position, pull the switch
trigger fully, then release it.
For MT606, MT607
To start the tool, simply pull the switch trigger. Tool speed
is increased by increasing pressure on the switch trigger.
Release the switch trigger to stop.
For continuous operation, pull the switch trigger and then
push in the lock button.
To stop the tool from the locked position, pull the switch
trigger fully, then release it.
