Használati útmutató Magnavox MMA3632

Magnavox hangszóró MMA3632

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Magnavox MMA3632 (1 oldal) a hangszóró kategóriában. Ezt az útmutatót 2 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/1
1 x AC/DC Adapter (Input: AC 100-240 V~, 50/60 Hz, 0.5 A Max.; Output: DC 9V, 2A， )
4. To shut off the unit, press and hold the Button for approximate 3 seconds until the Indicator light turns off.
1 2 3 4 5 6 7 8 9 10 1211
AC/USB Adaptor
Battery Recharging:
IMPORTANT:
NOTES:
Top View: Side View:
1. Open the rubber cover on the right side of the unit as the illustrated or right.
Prior to first use, fully charge the built-in Li-ion rechargeable battery.
To charge your battery follow the following steps:
3. Connect the AC/DC Adapter to a wall outlet as the illustrated on right.
2. Connect the plug from the supplied AC/DC Adapter to the DC (in) Jack.
4. The red charging indicator light will illuminate while charging. When
charging is complete, the indicator will turn green.
• The rubber cover is for water and dust resistance; always make sure it is completely closed after open.
•This AC/DC Adapter is not meant to be mounted to a ceiling, or downward facing outlet.
•To save energy, unplug the AC/DC Adapter while not in use.
•You can play and listen music while charging.
Your battery will last longer if you following these guidelines for charging and storing.
A. Before first use, fully charge the unit for about 4 hours.
B. Charge and store the unit within the temperature range of 5°C - 35°C (40°F - 95°F).
C. Do not overcharge the battery (longer than 24 hours). Excessive charging or draining will
affect the battery life.
D. Battery life naturally shortens slowly over time.
E. The rechargeable battery in this product is not replaceable.
8. Charging Indicators
9. USB Port (For charging external USB device)
10. AUX (in) Jack
11. Carry Handle
12. Rubber Cover (This cover is for water and
dust resistance; always make sure it is
completely closed)
1. Indicators
2. Button
3. Button
4. + Button
5. – Button
6. Built-in Microphone
7. DC (in) Jack (for charging the built-in battery)
CHARGING VIA THE USB PORT
TROUBLESHOOTING
SPECIFICATIONS:
PACKAGE INCLUDES:
NORMAL OPERATION AFTER PAIRED:
IMPORATANT:
Device not working properly? Try the following easy solutions:
NOTES:
OPERATION
IMPORTANT SAFETY INSTRUCTIONS BT (Bluetooth):
BT PAIRING:
To pair the device for the first time, follow the steps below:
1. Power on the unit by press and hold the Button on the top of unit approximate 1 second. The unit will enter to BT
mode automatically and the Blue Indicator on the top of unit will illuminate and blink.
2. Power on the BT Device you would like to pair and enter BT search mode. Follow the on screen prompts from your
BT Device. Once pairing is complete, the Blue Indicator will stop blinking.
3. Plays the music in the paired BT Device as usual.
4. During playback:
Press and release the Button to pause: press again to resume normal playback.
Press and hold the + or - Buttons to adjust the volume.
Press the + or - Buttons repeatedly to skip tracks.
5. To answer a call while listening to music; press and release the Button to pause music playback and answer the call.
When your call is complete, press and releases the Button to resume music playback.
6. To turn off the unit, press and hold the Button for approximately 3 seconds until the Indicator turns off.
When connecting to a BT Device our model number "MMA3632" will appear on the display of BT Device.
If asked for a Pairing code enter "0000”or“1234”when prompted.
1. Power on the unit by pressing and holding the Button for approximately 1 second. The unit will enter BT mode
automatically. The Blue Indicator on the top of unit will illuminate and blink.
2. Wait a few seconds until the unit automatically pairs to the external BT Device.
(The Blue Indicator will stop blinking once paired).
3. Plays the music in the paired BT Device as usual.
AUX IN:
To play music via the 3.5mm audio out jack:
1. Power on the unit by pressing and holding the Button for approximately 1 second.
The unit will enter to BT mode automatically.
The Blue Indicator on the top of unit will illuminate and blink when done.
2. Connect the supplied Auxiliary Audio Cable to the headphone; line out; AUX out jack on the external audio player.
3. Open the rubber cover on the right of unit.
4. Connect the other end of the Auxiliary Audio Cable to the AUX (in) Jack.
5. Press the Button on the top of unit to enter to AUX (in) mode, the color of the Indicator will
turns green.
6. Play music on the external Audio Player as usual. (Make sure the audio out of the external player
is set to high to enjoy full audio clarity).
7. During playback, press and hold the + or - Buttons on the unit to adjust the volume.
8. To shut off the unit, press and hold the Button for approximate 3 seconds until the Indicator
turns off.
The on board Full-Sized USB port can be used to charge an external USB device.
To charge an external device:
2. Connect a USB Connection Cable (Not included) to the charging port on the external
USB device you wants to charge as illustrated below:
3. Charging will automatically start.
A. Ensure the unit is fully charged before charging an external USB device.
If the power of the unit is too low, it cannot charge an external device.
B. The power of the built-in battery is 16.28 WH. Devices with a higher capacity battery will not
receive a full charge.
C. The unit has a built-in overload/overheat protection system. If the output from the charger is overloads, or short
circuits, the charger will automatiacally shut off.
Y PTO PO IBLE CAU E PO IBLE OLUTION
Can’t power on
Follow the charging instructions on page 3
Unit volume set too low
Increase the volume by pressing and
holding the + Button
Volume level of paired/
connected device is too low
Rise the volume level of
the paired/connected device
No sound or sound
Sound distortion Volume level too high Reduce the volume level by pressing
and holding the - Button
Rechargeable battery drained
Volume level of the connected/paired
device too high
Reduce the volume level of the
connected/paired device
BT not functioning The external BT Device had NOT
paired to the unit
Follow the BT pairing
instructions on page 4
The Device is placed too far from
the unit
Move the external BT Device
closer to the unit
4 5 6
Power source: Built-in 2 x DC 3.7 V, 2200 mAh (Total 16.28 WH) rechargeable Li-ion
Dust/water resistance level: IP56
Output from the built-in USB Charger: DC 5 V, 1 A
Impedance of Speakers: 2 x 10 W; 4 ohm
Audio power: 2 x 8 W (Total 16 W, RMS)
BT Version: 4.0
BT Operation Distance: 32 Feet in open area
1 x User’s Manual
1. Open the rubber cover on the right side of the unit.
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT
REMOVE THE COVER (OR BACK). NO USER
SERVICEABLE PART INSIDE, REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lighting flash with arrowhead symbol ,within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’
enclosure, that maybe of sufficient magnitude to constitute
a risk of electric.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
1 Read these instructions .
All the safety and operating instructions should be read
before the appliance is operated.
2 Keep these instructions .
The safety and operating instructions should be kept for
future reference.
3 Heed all warnings.
All warnings on the appliance and in the operating
instructions should be adhered to.
4.Follow all instructions
All operation and use instructions should be followed.
5.Do not use this apparatus near water
The appliance should not be used near water; for example,
near a bath tub, washbowl, kitchen sink, laundry tub, in
awet basement, or near a swimming pool.
6.Clean only with dry cloth
The appliance should be cleaned only as recommended by
the manufacturer.
7.Do not block any ventilation openings. Install in
accordance with the manufacturer’ instructions.
Slots and openings in the cabinet and in the back or bottom
are provided for ventilation, to ensure reliable operation of
the product and to protect it from overheating. These
openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed,
sofa, rug, or similar surface. This product should never be
placed near or over a radiator or heat source. This product
should not be placed in a built-in installation, such as a
bookcase or rack unless proper ventilation is provided or
the manufacturer’ instructions have been adhered to.
8.Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9.Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10.Product the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11.Only use attachments / accessories specified by the manufacturer.
12.Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer,
or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
An appliance and cart combination should be moved
with care. Quick stop, excessive force and uneven
surfaces may cause the appliance and cart
combination to overturn.
13.Unplug this apparatus during lightning
storms or when unused for long periods of time.
To protect your product from a lightning storm, or
when it is left unattended and unused for long periods
of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage
to the product due to lightning and power-line surges.
14.Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15.Power source
This product should be operated only from the type of
power source indicated on the marking label. If you
are not sure of the type of power supply to your
home, consult your appliance dealer or local power
company. For products intended to operate from
battery power, or other source, refer to the operation
instructions.
16.Power lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact
with them might be fatal.
17.Overloading
Do not overload wall outlets and extension cords as
this can result in a risk of fire or electric shock.
18.Object and liquid entry
Never push objects of any kind into the product
through openings as they may touch dangerous
voltage points or short out parts that could result in
fire or electric shock. Never spill or spray any type of
liquid on the product.
19.Outdoor antenna grounding
If an outside antenna is connected
to the product, be sure the antenna
system is grounded so as to provide
some protection against voltage surges
and built up static charges. Section 810
of the National Electric Code ANSI/ NFPA 70 provides
information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-
in wire to an antenna discharge product, size of
grounding conductors, location of antenna-
discharge product, connection to grounding
electrodes and requirements for the grounding
electrodes.
20.Service
Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
21.Replacement parts
When replacement parts are required, be sure the
service technician uses replacement parts specified
by the manufacturer or those that have the same
characteristics as the original parts. Unauthorized
substitutions may result in fire or electric shock or
other hazards.
22.Safety check
Upon completion of any service or repairs to this
product, ask the service technician to perform safety
checks to determine that the product is in proper
operating condition.
23.Wall or ceiling mounting
The product should be mounted to a wall or ceiling
only as recommended by the manufacturer.
24.Damage requiring service
Unplug this product from the wall outlet and refer
service to qualified service personnel under the
following conditions.
A. When the power- supply cord or plug is damaged.
B. If liquid has been spilled or objects have fallen into
the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as an adjustment of other controls
may result in damage and will require extensive
work by a qualified technician to restore the
product to its normal operation.
E. If the product has been dropped or the cabinet has
been damaged.
F. When the product exhibits a distinct change in
performance- this indicates a need for service.
25.Note to CATV system installer
This reminder is provided to call the CATV system
installer' attention to Article 820- 40 of the NEC
that provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
WARNING: USE UNDER SUPERVISION OF AN ADULT
DUE TO LONG CORD
This unit has a long cord that can be easily tripped on
or pulled on, causing injury. Please make sure it is
arranged so that it will not drape over a tabletop, etc.
Where it can be pulled on by children or tripped over
accidentally.
FCC NOTICE:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation. The antenna(s) used for this
transmitter must be installed to provide a
separation distance of at least 20 cm from all
persons and must not be co-located or operating
in conjunction with any other antenna or
transmitter.
FCC WARNING:
To assure continued operation, follow the attached
installation instructions and use only shield cables
when connecting to other devices. Changes or
modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
Battery,
Recharge by DC 9 V, 2 A, through DC (in) Jack
4. When finished charging, unplug the USB Cable from both units.
NOTE: Refer all servicing to qualified service personnel.
Servicing is required when the unit has been damaged in
any way such as the following: the power-supply cord or
plug has been damaged, liquid has been spilled into unit,
the unit has been exposed to rain or moisture, the unit has
been dropped or the unit does not operate normally. 1 x 3.5mm Stereo AUX Cable
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
To external USB device
Before using the unit, be sure to read all operating
instruction carefully, please note that these are general
precautions and may not pertain to your unit. For example,
this unit may not have the capability to be connected to an
outdoor antenna.
MODEL: MMA3632
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
OWNER'S MANUAL
WATERPROOF
PORTABLE SPEAKER
with Bluetooth® Wireless Technology
Printed in China MMA3632_WC_E0HZ1_B0WU
LIMITED WARRANTY
Craig Electronics warrants this product to be free from manufacturing defects in
material and workmanship under normal use for a period of 180 days from date of
purchase. If service is required, please return the product to the store where it was
purchased for exchange; or, pack the unit in the original packing material with all
accessories if applicable, a copy of your sales receipt and a Cashier’s check or Money
Order for $15 (to cover shipping and handling costs) payable to Craig Electronics Inc.
For consumers in Canada, please make sure that the cashier check or money order is
redeemable through a U.S. bank. Ship your product freight pre-paid. our unit will be Y
repaired, replaced or if the unit can not be repaired or replaced, a refund will be
forwarded to you within four weeks of receipt of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a commercial application or
rental. b) Damaged through misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d) Damaged because it is
improperly connected to any other equipment.
Note: This warranty does not cover: a) Ordinary adjustments as outlined in the Owner’s
Manual which can be performed by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping the product for repair. d)
Damage to the product not used in the USA.
This warranty is not transferable and only applies to the original purchase. Any implied
warranties, including the warranty of merchantabilit , are limited in duration to the period y
of this expressed warranty and no warranty whether expressed or implied shall apply to
the product thereafter.
Under no circumstance shall Craig be liable for any loss or consequential damage arising
out of the use of this product. This warranty gives specific legal rights. However, you may
have other rights which may vary from state to state. Some states do not allow limitations
on implied warranties or exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
This product has been manufactured by and is sold under the responsibility of Craig
Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMAR . VER SMAR are registered trademarks of Koninklijke Philips T Y T
N.V. and are used under license from Koninklijke Philips N. .V
To Obtain Service on your Product
email:service@craigelectronics.com
s
s
s
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE WITHOUT NOTICE
s

Termékspecifikációk

Márka: Magnavox
Kategória: hangszóró
Modell: MMA3632

Szüksége van segítségre?

Ha segítségre van szüksége Magnavox MMA3632, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek


Útmutatók hangszóró Magnavox

Magnavox

Magnavox MSB2600 Útmutató

8 Január 2025
Magnavox

Magnavox MSB5300 Útmutató

8 Január 2025
Magnavox

Magnavox MSB5305 Útmutató

8 Január 2025
Magnavox

Magnavox MMA3683n Útmutató

8 Január 2025
Magnavox

Magnavox MMA3629 Útmutató

8 Január 2025
Magnavox

Magnavox MD6949 Útmutató

8 Január 2025
Magnavox

Magnavox MMA3680 Útmutató

8 Január 2025
Magnavox

Magnavox MMA3685 Útmutató

8 Január 2025
Magnavox

Magnavox MMA3717 Útmutató

8 Január 2025
Magnavox

Magnavox MMA3679 Útmutató

8 Január 2025

Útmutatók hangszóró

Legújabb útmutatók hangszóró

Yamazen

Yamazen QBU-02 Útmutató

9 Január 2025
Yamazen

Yamazen YTR-D500 Útmutató

9 Január 2025
Sonance

Sonance Visual Performance VP38R Útmutató

9 Január 2025
Duronic

Duronic BX48 Útmutató

9 Január 2025
Sonance

Sonance MAG5.1R Útmutató

9 Január 2025
Sonance

Sonance MAG6R Útmutató

9 Január 2025
Electro-Voice

Electro-Voice XLE191-FG Útmutató

9 Január 2025
Electro-Voice

Electro-Voice Sx600 Útmutató

9 Január 2025
Audibax

Audibax Vegas 10 Útmutató

8 Január 2025
Bazooka

Bazooka BPB24-G3 Útmutató

8 Január 2025
