MODEL: MBH522
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
OWNER'S MANUAL
WIRELESS
EARPHONES
GENERAL SPECIFICATIONS:
BT(Bluetooth) Pairing:
For first time use or re-pairing the unit to a new BT Device, pairing it as below:
1. Press and holding the Button on the unit approximately 6 seconds until the
Red and Blue Indicators on the unit illuminate and blink.
2. Power on the external BT Device and enter to BT searching mode. Start
pairing following the on screen instructions from the external BT Device. When
paired, the Red LED Indicator will turn off and the Blue LED Indicator will
become slow blinking.
3. If pairing is complete you may now play music and answer the phone with
your external BT Device.
4. During playback:
Press the Button to pause press again to resume normal playback.；
Press and release the or Buttons to adjust volume level as desired.
Press and holding the or Buttons to skip tracks.
5. If the unit is paired to a Cell Phone and a call is incoming during an active music
session:
Press the Button then speak to the Microphone to answer the call. When
your call is complete, press the Button to disconnect or end the call and
resume to music playback.
Or, press and holding the Button approximately 1 second to decline the
incoming phone then resume to music playback.
6. To shut off the unit, press and holding the Button approximately 3 seconds
until the Red and Blue Indicators is illuminate and blink then release the button.
Notes:
When the external BT Device searched the unit, our model number “MBH522”
will appear on the display of external BT Device.
If while pairing you are asked for a code please try "0000" or "1234".
Normal operation after paired:
1. Power on the external BT Device and enter to BT mode.
2. Press and holding the Button on the unit approximately 1 second until the
Blue Indicators on the unit illuminate and blink then release the button.
3. Wait a few seconds until the unit automatically pair to the BT Device. The Red
LED Indicator will turn off and the Blue LED Indicator will become slow blinking.
4. If pairing is complete you may now play music and answer the phone with your
external BT Device.
1
2
3
5 4
6
7
1. Button
2. Button
3. Button
4.LED Indicators
5.Microphone
6.Rubber Cover
7.Micro USB Port (For Charging only)
Reduce the volume level by press
the Button on the unit
The unit has a built-in Li-ion rechargeable battery, charge it before first timeuse or
when it is drained as follows:
1. Open the Rubber Cover on the unit.
2. Connect the small plug from the supplied USB Connection Cable to the Micro
USB Port.
3. Connect the full size USB Plug from the supplied USB Connection Cable to the
USB Port on the Personal Computer or USB Charger (Computer and USB
Charger not included).
4. When charging, the Red Charging Indicator on the small plug from the unit then
close unit will illuminate.
5. When charging is complete, the Red Indicator will turn off and the Blue Indicator
will illuminate.
6. After charging, disconnect the small plug from the unit then
close the rubber Cover.
NOTES:
Your battery will last longer if you following these simple guidelines for
caring and storing:
A. Before first time use, recharge the unit approximately 4 hours until the unitis
fully charged.
B. Charge and store the unit within the temperature range
of 5°C - 35°C (40°F - 95°F).
C. Do not overcharge (longer than 24 hours). Excessive charging or running the
unit until battery fully drains will damage battery. Battery life will be extended if
you keep the battery fully charged.
D. Battery life naturally shortens slowly over time.
E. The rechargeable battery incorporated in this product is not user replaceable.
Check the following before requesting service:
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
Can’t power
on
No sound
or sound
weak
Sound
distortion
BT not
functioning
Built-in batterydrained
Volume level too high
Volume level of the
paireddevice too high
The external BT Device
had NOT paired to the unit
The external BT device too
far from the unit
Pair the external BT Device to
the unit as page 4
Place the external BT device
close to the unit
Reduce the volume level of the
paired device
Volume of the unit was set
to minimum position
Volume level of paired
device is in low level
Rise the volume level of the
paired device
Increase the volume by press the
Button on the unit
Recharge the battery as page 3
GENERAL SPECIFICATIONS:
PACKAGE INCLUDES:
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE
Power source: Built-in DC 3.7V, 60mAh (0.22 WH) rechargeable Li-ion
Battery, Recharge by DC 5V through the Micro USB Port
Impedance of the Earbuds: 16 Ω per Channel
Audio power: 5 mW per Channel (Total 10 mW)
BT Version: V4.1
BT Operation Distance: 32 Feet in open area
1 x Owner’s Manual
1 x USB Connection Cable (For Charging only)
