MAKE THE MOST OF YOUR
CARE & USE/INSTALLATION
L 15ICE N
OUTDOOR CLEAR ICE MACHINE
2
CONTENTS
Figure 1
Contents:
Warranty registration ..........................................................2
Safety information ...............................................................3
Unpacking your appliance ..................................................3
Installing your appliance ......................................................4
Installing the drain plumbing ...............................................8
Gravity drain ...................................................................8
Drain pump .....................................................................9
Installing the water supply .................................................10
Drain System est ...............................................................T 11
Ice maker operation ..........................................................12
Product dimensions ..........................................................14
Using your Electronic control ............................................16
Cleaning your ice machine ..............................................17
Care and cleaning .............................................................19
Energy saving tips ............................................................19
Obtaining service .............................................................19
Troubleshooting the ice machine .....................................20
Preparing the ice machine storage ...........................for 22
Drain pump removal .........................................................25
Warranty . ........................................................27
Warranty Registration:
It is important you send in your warranty registration card
immediately after taking delivery of your appliance or you
can register online at:
www.lynxgrills.com/support/registration
The following information will be required when registering
your appliance.
Model Number
Serial Number
Date of Purchase
Dealer’s name and address
The service/model number and serial number can be found
on the serial plate which is located inside the cabinet on the
left side near the top. (See Figure 1).
Greenwood, MS 38930
XXXXXXXXXXX
R600A
Warranty registration ..........................................................2
Door Reversal ...................... ...............................................7
NOTE
NOTE
!CAUTION
Important Safety Instructions
Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situations that
may occur. Common sense, caution, and care must be exercised when installing, maintaining, or operating this appliance.
Recognize Safety Symbols,
Words, and Labels.
CAUTION-Hazards or unsafe practices which could
result in personal injury or property / product damage.
NOTE-Important information to help assure a problem
free installation and operation.
!WARNING
EXCESSIVE WEIGHT HAZARD
Use two or more people to move product.
Failure to do so can result in personal injury.
Remove Interior Packaging
Your appliance has been packed for shipment with all parts
that could be damaged by movement securely fastened.
Remove internal packing materials and any tape holding
internal components in place. The owners manual is
shipped inside the product in a plastic bag along with the
warranty registration card, and other accessory items.
Important
Keep your carton and packaging until your appliance
has been thoroughly inspected and found to be in good
condition. If there is damage, the packaging will be needed
as proof of damage in transit. Afterwards please dispose of
all items responsibly.
Note to Customer
This merchandise was carefully packed and thoroughly
inspected before leaving our plant. Responsibility for its
safe delivery was assumed by the retailer upon acceptance
of the shipment. Claims for loss or damage sustained in
transit must be made to the retailer.
DO NOT RETURN DAMAGED MERCHANDISE TO THE
MANUFACTURER - FILE THE CLAIM WITH THE
RETAILER.
SAFETY INFORMATION AND UNPACKING YOUR APPLIANCE
!WARNING
WARNING - You can be killed or seriously injured
if you do not follow these instructions.
!WARNING
WARNING - Dispose of the plastic bags which can
be a suffocation hazard.
!WARNING
State of California Proposition 65 Warning:
This product contains one or more chemicals known
to the State of California to cause cancer.
!WARNING
State of California Proposition 65 Warning:
This product contains one or more chemicals known
to the State of California to cause birth defects or
other reproductive harm.
If the appliance was shipped, handled, or stored in
other than an upright position for any period of time,
allow the appliance to sit upright for a period of at
least 24 hours before plugging in. This will assure oil
returns to the compressor. Plugging the appliance in
immediately may cause damage to internal parts.
3
