product specifications 09.25.15369968a
RadioRA 2 C ®• L® Hybrid Keypads
1Technical Support: 1.800.523.9466 (U.S.A)www.lutron.com
RadioRA® 2 C•L Hybrid Keypads function as ®
a dimmer and keypad combined into a single
device. C•L Hybrid Keypads are great for ®
retro-fit applications since they eliminate the
need to install two separate devices.
C•L Hybrid Keypads are neutral-wire controls ®
that can be used with small loads, such as
screw-in CFL/LED lamps. Normal keypad
operation will be available even if the attached
load is not installed or the lamp is burned out.
C•L Hybrid Keypads can be controlled as ®
part of a lighting control system and
incorporate advanced features such as fade
on / fade off and rapid full on.
C•L Hybrid Keypads feature large, ®
easy-to-use buttons, plus a unique backlit
engraving option that makes them readable
any time of the day or night. The C
•L® Hybrid
Keypad buttons are rounded, allowing
engraving to be displayed at an upward angle,
increasing readability. C•L® Hybrid Keypads
include a Front Accessible Service Switch
(FASSTM) for safe lamp replacement.
Use only Lutron or ® Designer (Claro®
SatinColors ) wallplates. The mechanical ®
design of the keypad is compatible with
Lutron® wallplates ONLY and is NOT
compatible with any other manufacturer’s
wallplate. Wallplates are sold separately.
Lutron Claro® ® ® and SatinColors wallplates
snap on with no visible means of attachment.
Replacement Button Kits are available in a
variety of colors and with custom engraving to
identify clearly each button’s function.
C•L Hybrid Keypads are designed for use ®
with permanently installed incandescent,
tungsten halogen, CFL/LED, magnetic
low-voltage, or Lutron® Hi-lume® A-Series LTE
LED drivers only.
RD-RD
RRD-HN5BRL
RRD-HN6BRL
RRD-HN3S RRD-HN4S
RRD-HN3BSRLRRD-HN2RLDRRD-HN1RLD
C•L® Hybrid Keypads
product specifications 09.25.15369968a
RadioRA 2 C ®• L® Hybrid Keypads
2Technical Support: 1.800.523.9466 (U.S.A)www.lutron.com
Model Numbers
RRD-HN1RLD-XX* Dual-Group with Raise/Lower Keypad Neutral-Wire Dimmer. 450 W/450 VA (Incandescent/
Halogen/Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H1RLD-XX*-E Engraved Replacement Button Kit
RRD-HN2RLD-XX* Dual-Group with Dual Raise/Lower Keypad Neutral-Wire Dimmer. 450 W/450 VA (Incandescent/
Halogen/Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H2RLD-XX*-E Engraved Replacement Button Kit
RRD-HN3BSRL-XX* 3-Button with Raise/Lower Keypad Neutral-Wire Dimmer. 450 W/450 VA (Incandescent/Halogen/
Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H3BSRL-XX*-E Engraved Replacement Button Kit
RRD-HN3S-XX* 3-Scene with Raise/Lower Keypad Neutral-Wire Dimmer. 450 W/450 VA (Incandescent/Halogen/
Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H3S-XX*-E Engraved Replacement Button Kit
RRD-HN4S-XX* 4-Scene with Raise/Lower Keypad Neutral Wire Dimmer. 450 W/450 VA (Incandescent/Halogen/
Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H4S-XX*-E Engraved Replacement Button Kit
RRD-HN5BRL-XX* 5-Button with Raise/Lower Keypad Neutral Wire Dimmer. 450 W/450 VA (Incandescent/Halogen/
Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H5BRL-XX*-E Engraved Replacement Button Kit
RRD-HN6BRL-XX* 6-Button with Raise/Lower Keypad Neutral Wire Dimmer. 450 W/450 VA (Incandescent/Halogen/
Magnetic Low Voltage) or 100 W (approved CFL/LED) 120 V~
RKD-H6BRL-XX*-E Engraved Replacement Button Kit
RD-RD-XX* Remote Dimmer for multiple-location installations
* “XX” in the model number represents color/finish code. See Colors and Finishes at end of document.
product specifications 09.25.15369968a
RadioRA 2 C ®• L® Hybrid Keypads
3Technical Support: 1.800.523.9466 (U.S.A)www.lutron.com
Specifications
Model Numbers Keypads: RRD-HN1RLD-XX, RRD-HN2RLD-XX, RRD-HN3BSRL-XX,
RRD-HN3S-XX, RRD-HN4S-XX, RRD-HN5BRL-XX, RRD-HN6BRL-XX
Engraved Replacement Button Kit: RKD-H1RLD-XX-E, RKD-H2RLD-XX-E,
RKD-H3BSRL-XX-E, RKD-H3S-XX-E, RKD-H4S-XX-E, RKD-H5BRL-XX-E,
RKD-H6BRL-XX-E
Remote Dimmer: RD-RD-XX
Power 120 V~ 50 / 60 Hz
Typical Power
Consumption
0.75 W
Test conditions: load is off, all backlights on medium intensity, two LEDs on
(two presets active), keypad powered at 120 V~
Regulatory Approvals UL, cUL, NOM, FCC, IC, COFETEL
Environment Ambient operating temperature: 32 °F to 104 °F (0 °C to 40 °C), 0% to 90%
humidity, non-condensing. Indoor use only.
Communications C•L Hybrid Keypads communicate with the system through Radio ®
Frequency (RF) and must be located within 30 ft (9 m) of a repeater.
Remote dimmers are not required to be within a specific range of a
repeater. System devices operate on frequencies between 431.0 MHz and
437.0 MHz.
ESD Protection Tested to withstand electrostatic discharge without damage or memory
loss, in accordance with IEC 61000-4-2.
Surge Protection Tested to withstand surge voltages without damage or loss of operation, in
accordance with IEEE C62.41-1991 Recommended Practice on Surge
Voltages in Low-Voltage AC Power Circuits.
Power Failure Power failure memory: should power be interrupted, the control will return
to its previous state when power is restored.
Mounting Requires a U.S. wallbox. 3
1⁄ in (89 mm) deep recommended, 221⁄4 in
(57mm) deep minimum. If mounting one control above another, leave at
least 41⁄ in (114 mm) vertical space between them.2
Multiple-Location
Wiring
Uses conventional 3-way and 4-way wiring. RD-RD dimmer needs to be
installed to control from another location.
Warranty www.lutron.com/TechnicalDocumentLibrary/Warranty.pdf
Design Features
• Keypad buttons are programmable to select
scene or room preset levels or positions.
• At the press of a keypad button, lights fade
ON or OFF to desired levels and shades/
draperies open or close to desired positions.
• Adjustable backlight intensity.
• Prepaid engraving included. Redeemable for
one engraved Replacement Button Kit.
• Internal dimmer is assigned to top button
by default. Tap top button to toggle load
ON / OFF.
• Internal dimmer can be assigned to any
button on the C•L Hybrid Keypad and can be ®
programmed to be controlled by any keypad.
• Designed for use with a wide variety of
approved LEDs. Refer to the LED Product
Selection Tool at www.lutron.com/ledtool
• Can be installed in either single location
or multiple-location (with Remote Dimmer)
installations.
