33Activating the keyboard
1. Leave your computer on.
2. On the keyboard, slide the power switch to
the ON position.
3. On your computer open the application for wireless
connections using Bluetooth® technology. This is usually
found in Control Panel or the Start menu.
Example:
For computers running Windows® 7:
Start > Control Panel > Devices and Printers > Add a device
For computers running Vista®:
Start > Control Panel > Hardware and Sound >Wireless Devices using
Bluetooth® technology
For computers running Windows® XP:
Start > Control Panel > Printers and Other Hardware > Wireless Devices
using Bluetooth® technology
In the wireless devices with Bluetooth® technology programme, select the
option to add a new device and follow the instructions on the screen. If
you are prompted for a Password, type it using the keyboard, then press
enter.
4. Press the Connect button on the back of the keyboard to allow the
keyboard to be discovered by your computer.
22Installing the Batteries
Connect Button
ON/OFF Switch
CONNE CT
OFFON
Quick Start Guide
Wireless Keyboard with
Bluetooth® Technology
LKBUBT13
11Unp cka ing
Remove all packaging from the unit. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0844 800 3456 for assistance.
Keyboard
2x AAA Batteries
(Use a paperclip to help pry open the battery compartment cover
if necessary.)
* Images are for indication only. Please refer to your individual item
for details.
Press ENTER after typing the password on each device. Setup
your device is complete.
Please ensure the battery’s polarities(+/—) match the battery
compartment’s polarities.
44Function Key Access 55Troubleshooting
Keyboard Not Working :
1. Keep other electrical devices at least 8 inches (20cm) away from the
keyboard.
2. Re-connect the keyboard.
3. Ensure your device’s wireless function has been activated, so you
can connect using Bluetooth® technology.
77Specications
Supply voltage: 2xAAA Batteries (3.0V)
Dimension (approx.): 287 x 135 x 18 mm
Operating system: Windows® XP/ Vista®/ 7/ 8/ Mac OS10.6/
Android 3.0/ IOS 5.0, 6.0+
66Safety Warnings
• Don’t disassemble the keyboard or remove any parts.
• Don’t put the keyboard into water or any liquid.
• Don’t use the keyboard close to heat sources or expose to high
temperatures.
• Don’t use the keyboard where strong electromagnetic waves are
present. Strong electromagnetic waves will cause damage to
the keyboard.
• Keep the keyboard away from direct sunlight, moisture, dirt or abrasive
chemical products (cleaning products etc).
Wireless Devices :
Before boarding any aircraft or packing a wireless device in luggage that
will be checked in, remove the batteries from the wireless device.
Wireless devices can transmit radio frequency (RF) energy, whenever
batteries are installed and the wireless device is turned on.
66Safety Warnings (Cont.)
Battery-Powered Devices :
Improper use of batteries may result in battery uid leakage, overheating,
or explosion. Released battery uid is corrosive and may be toxic. It can
cause skin and eye burns, and is harmful if swallowed.
To reduce the risk of injury :
• Keep batteries out of the reach of children.
• Do not heat, open, puncture, mutilate, or dispose of batteries in re.
• Do not mix new and old batteries or batteries of different types.
• Do not allow metal objects to touch the battery terminals on the
device; they can become hot and cause burns.
Key Primaray Function Secondary Function
Backwards/skip music/media; hold to search
Play/Pause music/media
Fowards/skip music/media; hold to search
Share (Windows® 8 only)
Escape: Cancel current command
Settings (Windows® 8 only)
Decrease volume
Increase volume
Show virtual keyboard
Search the web
Open Browser Home Page (Windows® only) and Home (Mac OS only)
Menu
N/A
Home-Go to begining of line in some applications
End-Go to end of line in some applications
Move backwards/left one cursor or space
Move forwards/right one cursor or space
Mute Sound
Device (Windows® 8 only)
F7- Access Spell Check for some applications
F8- Access various functions in some applications
F9-Access various functions in some applications
N/A
F4- Access various functions in some applications
F5-Access various functions in some applications
F11-Access “Full screen” functions in some applications
F12-Access “Save as” functions in some applications
N/A
N/A
N/A
F10-Access various functions in some applications
F6-Access various functions in some applications
Features and specications are subject to change without prior notice.
Windows is a registered trademark of Microsoft Corporation in the United States and
other countries.
DSG International Sourcing declares that the keyboard complies with the essential
requirements and other relevant provisions of R&TTE Directive 1999/5/EC.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by DSG Retail Limited is as an Aliate under the
License held by DSG International Sourcing Ltd. Other trademarks and trade names
are those of their respective owners and all rights are acknowledged.
(QSG-LKBUBT13-130523V1)
DSG Retail Ltd. (co. no. 504877)
Maylands Avenue, Hemel Hempstead, Hertfordshire, HP2 7TG, UK
This symbol on the product or in the instructions means that your electrical and
electronic equipment should be disposed at the end of its life separately from your
household waste. There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where you
purchased the product.
Visit Partmaster.co.uk today for the easiest way to buy electrical
spares and accessories. With over 1 million spares and
accessories available we can deliver direct to your door the very
next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK customers only) Calls charged
at National Rate.
Part Number
There are 17 shortcut function keys*.
Access primary functions by pressing the keys. Access secondary
functions (different colour text), press Fn and the desired key togther.
* Not all functions are available, depending on your operating system
