Oldal 1/4

DGS Retail Ltd • Maylands Avenue • Hemel Hempstead •

Herts • HP2 7TG • England

GB-4 GB-5

Visit Partmaster.co.uk today for the easiest way to

buy electrical spares and accessories. With over 1

million spares and accessories available we can

deliver direct to your door the very next day. Visit

www.partmaster.co.uk or call 0870 6001 338 (UK customers only) Calls charged at

National Rate.

This symbol on the product or in the instructions means that your electrical

and electronic equipment should be disposed at the end of its life

separately from your household waste. There are separate collection systems

for recycling in the EU. For more information, please contact the local

authority or your retailer where you purchased the product.

SPECIFICATIONS

Supply voltage: 230-240V~50Hz

Power input: 1200-1400W (1600 MAX)

Dust capacity: 2.5L

We continually strive to improve our products, specications may change without prior

notice.

SAFETY FIRST!

For your continued safety and to reduce the risk of injury or electric shock, please

follow all the safety precautions listed below.

• Read all the instructions carefully before using the appliance and keep them for

future reference.

• Retain the manual. If you pass the appliance onto a third party make sure to include

this manual.

• Check that the voltage marked on the rating label matches your mains voltage.

• Consult your dealer if you are ever in doubt about the installation, operation or

safety of your appliance.

• Do not remove any xed cover as this may expose dangerous voltages.

• Do not allow any electrical appliance to be exposed to dripping or splashing.

• To protect against electrical shock, do not immerse mains cable, mains plug, or any

part of the appliance in water or other liquids.

• Make sure the dust bin is properly installed before use.

• Never vacuum up water or any other liquids. Never vacuum up ammable

substances and do not vacuum up ashes until they are cold.

• Never use the appliance without the motor protection lter. This damages the motor

and shortens the life of the appliance.

• If a blockage is found in the brushes, hoses or tubes, it should be removed before

use.

• Store and use the appliance well away from heat sources such as radiators or gas /

electric res.

• Do not run over the mains cable with the appliance.

• Close supervision is necessary when any appliance is used by or near children.

• This appliance is not intended for use by persons (including children) with reduced

sensory or mental capabilities, or lack of experience and knowledge unless they

have been given supervision or instructions concerning the use of the appliance by

a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Do not point the hose, tube or any other accessory at the eyes, ears or mouth during

operation.

• Unplug the appliance from the mains socket when it is not in use and before

replacing lter.

• Allow the appliance to cool completely before cleaning or storing.

• Do not use the appliance for other uses than its intended use.

• The use of accessories not recommended by the appliance manufacturer may cause

injuries.

• Do not use the appliance outdoors.

• Do not operate an appliance with a damaged mains cable or mains plug, or in an

abnormal state. If the mains cable is damaged it must be replaced by the

manufacturer, its service agent, or similarly qualied persons in order to avoid a

hazard.

• Do not continue to operate the appliance if you are in any doubt about it working

normally (e.g. abnormal noise, smell, smoke), or if it is damaged in any way - switch

oﬀ, withdraw the mains plug and consult your dealer.

• Any maintenance and repair must be handled by a professional technician. Do not

try to repair by yourself.

Bagless Cylinder

Vacuum Cleaner

Instruction Manual

L16VB10

Congratulations on the purchase of your new Logik

Vacuum Cleaner.

We recommend that you spend some time reading this instruction

manual in order to fully understand all the operational features it

offers.

Read all the safety instructions carefully before use and keep this

instruction manual for future reference.

FIRST TIME USE

1. To connect the hose, insert the hose connector into the hose connection opening

until you hear ‘click’ sound (Fig 1).

2. To connect the telescopic tubes to the handgrip of the hose, insert the narrow

section into the wider section while turning a little (Fig 2).

3. Extend the telescopic tube to a length you nd the most comfortable by pressing the

button located on the telescopic tube (Fig 3).

4. Connect a nozzle/brush suitable to the oor type to be cleaned. The hard oor brush

can be used with brush strips lowered or raised (Fig 4). You may also connect the

combination nozzle to vacuum corners, slots or grooves. It can also be used as a

brush nozzle by turning the strips out in the direction of the arrow.

GB-1 GB-2 GB-3

UNPACKING

Remove all packaging from the vacuum cleaner. Retain the packaging. If you dispose of

it please do so according to local regulations.

The following items are included:

• One Main Unit • One Hose (P.N.: CH812B-HS)

• One Telescopic Tube (P.N.: CH812B-TB) • One Combination Nozzle (P.N.: CH812B-CN)

• One Hard Floor Brush (P.N.: CH812B-HF) • One Instruction Manual (P.N.: L16VB10-001)

If items are missing, or damaged please contact Partmaster (UK only).

Tel: 0870 6001 338 for assistance.

PRODUCT OVERVIEW OPERATION

1. Hold the mains plug and pull the retractable mains cable out of the vacuum cleaner.

Connect it to the mains socket. The YELLOW mark indicates the ideal length to extend

the cable. Do not extend the mains cable beyond the RED mark which indicates the

maximum length.

2. Press the ON/OFF button on the top of the vacuum cleaner to turn it on.

3. To move the vacuum cleaner from room to room, you can unplug and carry it by

either the handle or the handgrip. Never use the mains cable to pull the vacuum

cleaner.

POWERING OFF AND STORAGE

1. Press the ON/OFF button on the top of the vacuum cleaner to turn it oﬀ and then

remove the mains plug from the mains socket.

2. Press the cord rewind button to rewind the retractable mains cable.

3. Put the vacuum cleaner in an upright position and attach the telescopic tube

to the clip on the vacuum cleaner (Fig 5).

EMPTYING THE BIN

Always unplug the vacuum cleaner from the mains socket before emptying the bin.

1. Remove the hose connector from the cleaner. Unclip the lever clasps and open the

cover

(Fig 6)

2. Use the bin handle to turn the bin anti-clockwise till it stops, then lift the bin up

(Fig 7)

3. To prevent the dust dispersing, lower the bin into your dustbin. Take out the lter unit

to empty the bin.

4. If you nd the lter unit is blocked or dirty, follow the steps in “Cleaning the HEPA

Filter unit”. If not, skip this step.

5. Relocate the lter unit back into the bin and then put them back to the vacuum

cleaner by aligning the tabs at the bottom of the bin with the slots on the vacuum

cleaner. Turn the bin clockwise with the bin handle until it locks in place.

6. Close the cover and clip the lever clasps.

1. Handle

2. Rear wheels

3. Hose connection opening

4. Handgrip of hose

5. Hose connector

6. Hose

7. Telescopic tube

8. Cover

9. Lever clasps

10. Bin

11. Motor Protection Filter

12. HEPA lter unit

13. Bin handle

14. Top

15. Mesh guard

16. HEPA lter

17. Base

18. Combination nozzle

19. Hard oor brush

20. ON/OFF button

21. Exhaust lter

22. Cord rewind button

23. Grill

24. Mains plug

25. Clip

26. Handgrip

27. Wheel

1 2

3 4

5 6

7 8

9 10

11 12

CLEANING THE HEPA FILTER UNIT

Always unplug the vacuum cleaner from the mains socket before cleaning.

1. To take out the lter unit from the bin, tilt it a bit to get the base past the inlet

(Fig 8)

2. Hold the base then untighten the top of the lter unit.

3. Lift the mesh guard from the HEPA lter and shake out the dust accumulated on the

mesh guard gently over your dustbin. You may rinse it gently under a running tap.

4. Shake out the dust accumulated on the HEPA lter. You may soak it in warm soapy

water for a few minutes, and then rinse it under a running tap to remove all traces of

soap. Do not reassemble the lter unit until it is completely dry.

5. To reassemble the lter unit, hold the mesh guard with the arrows pointing up, and

lower it over the HEPA lter

(Fig 9)

6. Fit the top of the lter unit to the top of the HEPA lter, and turn it clockwise. Do not

over-tighten it.

7. Relocate the lter unit back in the bin again, tilt it a bit to get the base past the inlet.

CLEANING THE MOTOR PROTECTION FILTER

The motor protection lter should be cleaned twice a year, or when it appears to be

visibly clogged.

Always unplug the appliance from mains socket before replacing the lter.

1. Unclip the lever clasps and open the cover

(Fig 6)

2. Take out the motor protection lter

(Fig 10)

3. Shake out the dust accumulated on the lter into a dustbin.

4. Relocate the lter back. Close and clip the cover.

CLEANING THE EXHAUST FILTER

Always unplug the appliance from mains socket before replacing the lter.

1. Unclip the grill and take out the exhaust lter (Fig 11 & Fig 12).

2. Shake out the dust accumulated on the lter into a dustbin.

3. Relocate the lter and the grill.
