Használati útmutató Lexon Luma M

Lexon rádió Luma M

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Lexon Luma M (5 oldal) a rádió kategóriában. Ezt az útmutatót 3 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/5
Design by Manuela Simonelli & Andrea Quaglio
LH87
LUMA M
2
35
4
1
6
7
IN THE BOX
1x 1x Luma M USB Type-C charging cable User manual1x
PRODUCT OVERVIEW
1. Touch area (Lighting function) Receiver for wireless charging5.
2. 6. Lamp LED indicator (battery & charging status)
3. BT Button (connection between Luma M lamps) USB Type-C charging port7.
4. Reset key
FEATURES
• LED technology with 9 colors (warm white, cold white, blue, yello , green, red, purple, light pink & light blue)w
• Dimmable LED lights with memory system
• Interconnectable LED lamp (Bluetooth mesh network)
• Suitable for outdoor use (IPX4)
• Rechargeable via wireless charging or USB Type-C
CHARGING
We recommend you to fully charge the battery before using Luma M for the first time.
The initial full charge should take approximately 3 hours via USB charging and 4 hours via wireless charging.
LED information
Operation mode LED status (Red LED)
Charging LED indicator remains ON
In use LED indicator remains OFF
Fully charged LED indicator remains OFF
Charge with USB cable
1. Plug the provided USB Type-C cable into the charging port of Luma M.
2. Plug the USB end of the cable into any computer or any DC 5V power supply charger.
Charge with Wireless Charger
Luma M has a built-in wireless charging receiver. You can charge the battery by using a wireless charger.
1. Place Luma M at the center of the wireless charger.
2. Disconnect the device once the battery has been fully charged
OPERATING INSTRUCTIONS
Setting up one Luma M lamp
• Touch the top of the lamp to turn it ON.
• There are 9 colors options you can select by simply touching the top of the lamp.
• To adjust brightness, touch the top area until you reached the desired brightness then release.
• To turn OFF the light, wait 3 seconds after the color selection then touch again.
The last color set will be remembered for next time.
Note: If you want to set Luma M in cool and warm light mode only, quickly tap 3 times on the top area. To return to full set lighting
mode, repeat the procedure.
Pairing several Luma M lamps (Interconnection network)
Pairing Luma M with one or multiple Luma M lamps does not require any third-party software/device.
To enjoy the multiple bulbs synchronization feature, follow below instructions:
1. Press and hold the BT button at the bottom of each lamp for 3 seconds to turn ON the communication module.
The Blue LED will start flashing.
2. Select one of the lamps and press the BT button twice to initiate the multi-pairing procedure.
Once procedure is complete, all lamps will be on the same color setting.
The lamp used for connection is now identified a MASTER in the its LED will keep flashing while others are turnedsystem,
OFF
You can now interact from any lamp the change the color, adjust brightness or turn ON & OFF all lamps at once.
Important note: Bluetooth will automatically turn off after the lamp has been off for 60 minutes.
If network, pairing, you enable the Bluetooth® on one of your lamps to connect it to the but do not complete the the lamp's
Bluetooth mode will turn off after 3 minutes automatically
Add one or more Luma M lamps to the network
1. To add one or more Luma M lamps to the simply to it (them) ON by pressing and holding the BT button on each unitnetwork,
for 3 seconds.
2. Press once on the pairing button of any lamp from the existing network (repeat the procedure with any new device).
Exclusive LOCK NETWORK feature
Luma M is equipped with a unique locking system allowing only One lamp to control all preventing any change of colorothers, ,
brightness or even turn ON/OFF to be made from any other lamp in the network. The main lamp (MASTER) is the only one to control
the network. All other lamps are becoming SLAVES.
To enable LOCK function, take the MASTER units and follow below instructions:
1. Press 5 times on the B MASTER device button, it will send signal toT ALL other lamps to LOCK.
2. In LOCK mode, only MASTER interact with other lamps. Its LED is double flashing every 3 seconds.
3. Network can be unlocked by quickly pressing 5 times on the BT button from the MASTER lamp
To change the MASTER device
1. Make sure the network is UNLOCKED
2. Quickly Press the B button on any device for 10 times, this device will become the new MASTER device.T
You can now LOCK and UNLOCK the network from this new device.
Important note: In LOCKED/UNLOCKED mode, network it is strongly recommended to always keep the MASTER device in
charge or fully charged to get the best experience and avoid loss of control of the entire network.
Other working operations:
• To turn OFF ALL the lamps when the network is locked, double tap on the top of the MASTER device.
You’ll need to tap on the MASTER again to turn all lamps back ON.
• To turn OFF only one lamp when the network is long press on the BT button from more than 15 seconds until the lamplocked,
turns OFF. (This will remove the lamp from the network. Repeat the pairing procedure above to bring it back to the network)
• To reset the lamp, insert a thin object into the hole (4) under the lamp and press the key inside.
A manual reset allows you to reboot your device and correct miscellaneous bugs (unrecognized unstable Bluetoothdevice,
connection...).
LED Information
Operation mode LED status (Blue LED)
Ready to pair Blinking quickly
Master device Blinking twice every 3 seconds
Locked devices Off
SAFETY PRECAUTIONS
• IPX4 water resistant device, resistant to rain, splash, and spray water.
• circuit, overheating, fire, Never immerse your device in water to avoid internal short deformation or even explosion of the
battery.
• Do not store your device in very hot or cold areas. It is recommended to use your device at room temperatures.
• Do not attempt to service, repair or disassemble the device yourself.
• Make sure to respect the technical specifications for charging and never use a power adapter delivering more voltage output
than the one indicated to avoid any irreversible damage to the internal circuit (DC Input: 5V)
• materials, magnets, Do not place the Luma M case on the wireless charger when conductive such as metal objects and are
placed between the Luma M case and the wireless charger.
Use only certified wireless chargers.
PRODUCT SPECIFICATIONS
Material: SBA/muinimulA 10mBluetooth® range:
Weight: Frequency range: 0.34 lbs / 153 g 2402M-2480MHZ
Dimensions:
Max lumen output: nput port: 45 lm I DC 5V
Color temperature: Wireless input: 5W
W Li-polymerarm white: 3000-3500 Battery type:
Cold white: 6800-7200 900 mA Battery capacity:
Color temperature: Charging system: 3000- 7200k USB Type-C or Supports wireless charging
Battery voltage:
Normal usage time Charging time (wirelessly): approx. 4 hours
Lamp ON not connected to network: Up to 24h (Brightness at 50%) Operating temperature: -10°C - +50°C
Lamp ON connected to network: Up to 12h (Brightness at 50%) nternational warranty: 1 year
