model / 型号 KDS250
KDS350
Display Chiller/冷冻陈列柜/Peti Pendingin
Instruction Manual / Buku Panduan说明指示书/
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / Mustahak重要/
P/N : 40-51280-01
1. Do not open the door frequently and too long to save energy.
2. Never leave heavy or hot objects on top panel or the showcase to avoid deforming.
3. Cut o the power before cleaning.
4. To clean the showcase, please use soft cloth dampened in some moderate detergent. After cleaning, wipe in
dry, never use all kinds of detergent and hot water.
5. Use warm water to clean oil fruit juice stain on the magnetic gasket in order to keep its elasticity.
6. The showcase should not be left unused for a long time. To stop using the showcase, disconnect the main
power rst, then clean the inside and leave the door open for 2-3 days to dry it.
Safety Precaution Information
!
1
Safety & warning information
Cleaning & Maintenance
1. All repairs, disassembly and modications must be performed by qualied technicians. Attempting to perform
these operations by yourself can result in re, mal-function and injury.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
3. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
4. Do not splash water directly onto unit or wash unit with water. These actions can result in short circuit or
electrical leakage.
5. Do not put inammable liquids or volatile substances into unit. Fire or explosion may occur.
6. Do not modify, damage, excessively bend, strain, twist or bundle power cord.
7. Do not place heavy objects on power cord.
8. This unit is intended to cool or store bottled water or canned beverages. Do not use this unit for other purposes
as it can adversely aect performance.
9. Do not attempt to insert ngers or objects into air suction compartment.
10. Do not place objects or items containing water on top of unit.
11. If gas leakage is detected near or around unit, do not touch or open unit's door. Open windows or door to
ventilate air. Find gas and plug leakage before operating the unit.
12. Should the unit need to be placed in temporary storage, ensure that the location is not accessible to children.
And lock or tape the door from opening. This will minimize risk of children trapped in the air tight compartment.
13. When moving unit to another location, always unplug from mains.
14. Do not place more than 20 kg on top of each shelf.
15. Connecting the power to check the showcase before using. The showcase can be used when the temperature
decreases obviously after 30 minutes.
16. If power cut-ois needed, you should wait for at least 5 min before plugging in again to avoid damage to the
compressor.
17. Adjust the dial according to the real room temperature, the quantity of the foodstu stored.
18. Hot food should be stored only after it is completely cold.
19. Packing foods with plastic bag to avoid tastes mixing and frost.
20. WARNING: Keep ventilation opens, in the appliance enclosure or in the built-in strutre, clear of obstruction.
21. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
22. WARNING: Do not damage the refrigerant circuit.
23. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they
are of type recommended by the manufacturer.
Product Identication
Specications
*Pictures are for illustration purpose only.
0
1
2
3
4
5
6
7
ON OFF
ON OFF
Display Light Box
1
Key Lock
2
Handle
3
4 Door
5Door Pad
6 Wheel
7Adjustable Foot Screw
8Evaporator Fan
9Thermostat Box Knob
10 Display Light Box Button
11 Compartment Light Button
8
9
10
11
1
3
4
5
6
KDS250
220-240V~ 50Hz
220W
5W + 5W
1.4A
250L
R134a(110g)
4
Manual
0-10°C
Yes
60.4kg
64.9kg
545 x 620 x 1727mm
585 x 630 x 1756mm
Model
Voltage
Power
Lamp Power
Current
Capacity
Refrigerant
Number of Shelves
Temperature Controller Type
Inner Temperature Range
Lock & Key
Net Weight
Gross Weight
Product Dimension (LxWxH)
Box Dimension (LxWxH)
KDS350
220-240V ~ 50Hz
230W
5W + 5W
1.45A
350L
R134a(127g)
5
Manual
0-10°C
Yes
71.4kg
76.4kg
600 x 675 x 1877mm
645 x 675 x 1916mm
* Specications are subject to change without prior notice.
