Inverter Air Conditioner
Installation Manual
KSV25CRG, KSV35CRG, KSV70CRG,
KSV25HRG, KSD25HRG, KSV35HRG,
KSD35HRG, KSV50HRG, KSD50HRG,
KSV70HRG, KSD70HRG, KSV80HRG,
KSD80HRG
Congratulations and thank you for choosing our Inverter split
system room air conditioner. We are sure you will find
your new air conditioner a pleasure to use. Before you use the air
conditioner, we recommend that you read through
the entire user manual, which provides the description of
the air conditioner and its functions.
To avoid the risks that are always present when you use an electrical
appliance, it is important that the air conditioner
is installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards.
We recommend that you keep this instruction booklet
for future reference and pass it on to any future owners.
After unpacking the air conditioner please check it is not damaged.
If in doubt, do not use the air conditioner but
contact your local Electrolux Customer Care Centre.
Conditions of use
This appliance is intended to be used in household and similar
applications such as :
• staff kitchen areas in shops, offices and other working
environments.
• farm houses.
• by clients in hotels, motels and other residential type
environments.
• bed and breakfast type environments.
This air conditioner is designed for and intended to be used in
normal domestic applications only.
Record model and serial number here:
Model number: ..................................................................................
Serial number: ...................................................................................
environment
Information on disposal for users
• Most of the packing materials are recyclable.
Please dispose of those materials through your local
recycling depot or by placing them in appropriate collection
containers.
• If you wish to discard this air conditioner, please contact your
local authorities and ask for the correct method
of disposal.
R32 refrigerant warning
This product uses R32 difluoromethane refrigerant, which is
a mildly flammable gas class 2.2 according according to AS
1677 and must be handled by a refrigeration mechanic with
appropriate Australian refrigerant handling licence.
Congratulations Contents
2 Contents Kelvinator Air Conditioning
Important Safety Instructions ................................................. 3
Installation instructions
Choosing a location to mount unit ............................................... 4
Installation drawing ......................................................................... 5
Indoor unit installation
Installation plate mounting ............................................................6
Drilling the wall ................................................................................ 7
Connective pipe installation .......................................................... 7
Drain piping ..................................................................................... 8
Outdoor unit installation
Location of outdoor unit .............................................................. 10
Drain elbow installation ................................................................ 10
Refrigerant pipe connection ........................................................11
Flaring work ...................................................................................12
Test running
Air purging .....................................................................................15
Information servicing
Information servicing .................................................................... 18
Warranty ...................................................................................... 23
Kelvinator Air Conditioning Important safety instructions 3
caution
1 The unit must only be installed by a qualified refrigeration
mechanic and electrical work carried out by a qualified
electrician according to AS/NZS 3000 electrical installation
standard and in accordance with all local and national
regulations.
2 If the installation is not completed by a suitably licensed
person, any faults resulting from poor installation may not be
covered under warranty.
3 Means for disconnection must be provided in the fixed wiring
according to AS/NZS 3000 and local wiring regulations, install
a suitable isolation switch in an accessible location adjacent to
this air conditioner.
4 The temperature of the refrigerant circuit will be high, please
keep the interconnection cable away from the copper tube.
5 This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
warning
Before obtaining access to terminals, all supply circuits must be
disconnected.
Please read this installation manual and the user manual before
installation and carefully store in a handy place for later reference.
Inside you will find many helpful hints on how to install and test the
air conditioner properly.
Incorrect installation due to ignoring this instruction may cause
harm or damage, which may not be covered by warranty.
warning
This symbol indicates information concerning your personal safety
caution
This symbol indicates information on how to avoid damaging
the appliance
important
This symbol indicates tips and information about use of the
appliance
environment
This symbol indicates tips and information about economical and
ecological use of the appliance
caution
• Contact an authorised installer for installation of this unit.
• Contact an authorised service technician for repair or
maintenance of this unit.
• Installation work must be performed in accordance with the
national wiring standards by authorised personnel only.
Important safety instructions Notice for installation
