MPN: SP-HD20-1X44K
4K HDMI 1x4 Splitter with HDCP2.2
1x4 HDMI DA w/ HDCP2.2, 4K Cinema resolutions & Smart EDID Control
FEATURES
• Distribute True 4K HDMI video and audio
signals to four HD 4K displays
• True 4K@60Hz UHD, 1080p & 3D resolutions
• 4Kx2K @30Hz with 24bit RGB, YCBCR 4:4:4
& YCBCR 4:2:2
• 4Kx2K @60Hz with 12bit YCBCR 4:2:0
• Conforms to High Speed HDMI specifications:
SPECIFICATIONS
Signal Input/Outputs:
• Input DDC Signal: 5 Volts p-p (TTL)
• Input & Output Signal: High Speed HDMI
Spec 2.0a
Input Ports: 1 x HDMI (Female)
Output Port: 4 x HDMI (Female)
Operating Frequency: Vertical Frequency
Range: 50/60Hz
Supported Resolutions:
• 480i ~1080p50/60, 4Kx2K@24/30
• 4Kx2K@60Hz with 12bit YCBCR 4:2:0
• VGA~UXGA
Power Requirements:
• Power Consumption: 2W
• External Power Supply: 5V, 1A DC
Regulatory Approvals:
• Converter Unit: FCC, Ce, UL
• Power Supply: UL, Ce, FCC
Environment Operating Temperature:
• Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
• Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
Dimensions: 2.52” (W) × 6.10” (D) × .67” (H)
Weight: 6.35 oz. (180g)
Package Contents:
• HDMI 1X4 Splitter
• 5V, 2A Power Supply
• Operation Manual
The KanexPro SP-HD20-1X44K is
an one input, four output HDMI
Distribution Amplifier engineered
to split 4K quality videos or high
res images from one source
to four HD 4K displays with
resolutions up to 4K@60Hz and
HDCP2.2 specifications. Built-
in EDID management allows
optimal resolution to be selected
and properly outputted to avoid
response time and delays.
The conforming outputs also
have the ability of buffering and
amplifying all the HDMI signals.
It can achieve long distance
transmission of HDMI signals up
to 50 feet (15 meters) or can be
combined with our HDBaseT™
Extenders to route distances up to
330 feet (100 meters).
• (Deep color, HD lossless audio formats & Lip Sync)
• HDCP 2.2 compliant
• EDID Selector for optimal resolutions
• Built-in Smart EDID Control
• Front-panel LED’s for input/ output signal presence
• Includes 5V DC external power supply
ABOUT KANEXPRO
KanexPro carries a broad selection of A/V connectivity products by leveraging the core strength in professional systems enabling you to broadcast, convert, extend, split, or
multiply HD signal transmissions; simply and cost-effectively. KanexPro is a trademark. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC in the United States and/or other countries. All other product or service names are the property of their respective owners.
