Használati útmutató Golden Lighting Torbellino 8106-10 CDB
Golden Lighting
Lampa
Torbellino 8106-10 CDB
Olvassa el alább 📖 a magyar nyelvű használati útmutatót Golden Lighting Torbellino 8106-10 CDB (3 oldal) a Lampa kategóriában. Ezt az útmutatót 9 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra
Oldal 1/3
Canopy
1ea
Mounting
Screws 2ea Cap 1ea
Chain
2ea 10ft
Nipple 1ea Deco Nut 1ea
Chain connector 4ea Wire connectors 2ea
Mounting Strap 1ea Hex Nut 1ea
Part Needed Quantity
Part Needed Quantity
Reason why ( missing, scratched, broken glass, bent, bad nish)
Comments
F A IIXTURE SSEMBLY NSTRUCTIONS
For Customer Service, contact the place of purchase to arrange for replacement parts.
NOTE: INSTALL THE GLASS ASSEMBLY
AFTER THE FIXTURE IS HUNG.
1. By measuring determine correct number of links
needed for proper hanging height. Use a pair of
pliers to open one link of the Chain (J) then remove
the excess chain (J) and discard it.
2. Use Chain connector (R) to attach the Top loop
(K) to one end of chain (J) and close the connector
as shown. (disregard if the Top loop is already
attached to one end of chain)
3. Attach a Chain connector (R) to the top end of
the Chain (J). Repeat steps 1thru 3 for the second
chain.
8106-10 CDB
Read and review installation instruction sheet before
assembling the xture.
Fig 1
Notice: Please review the parts listing and check for all parts before assembling the xture. If any parts are
missing or damaged, please note onthis sheet and contact the place of purchase to arrange for
replacement parts.
PARTS LIST Company Name:_______________________Co. Account #:_____________
to be lled out by retailer
PARTS & ASSEMBLY SHEET
This xture assembled PO:__________ Date: ________
Fixture Name: Torbellino 8106-10 CDB
For Customer Service, contact the place of purchase to arrange for replacement parts.
Note: Complete these remaining steps after the
xture is hung.
7. Place the Glass Shade (N) over the Threaded
Socket (M),place the Socket washer (O) over the
threaded socket (M) then secure the Glass Shade
(N) by threading by the Socket Ring (P) until tight.
8. Install the light bulbs in accordance with the
xture's specications.
(DO NOT EXCEED THE MAXIMUM WATTAGE RATING)
Fig 3
4. Slip the Top Loop (K) over top curve of the xture
Frame (L). Lace the xture’s wire through the Top
loop (K) and the chain links (J) (every three links)
and pull until taut.
5. Use Chain connector (R) to attach the top of
Chain (J) to the Canopy loop (I) and close the chain
connector as shown.
6. Make sure the weight of the chandelier is
supported by the chain-not the electrical wire.
* You may now install the xture.
Fig 2
PARTS & ASSEMBLY SHEET
Fixture Name: Torbellino 8106-10 CDB
INSTALLATION INSTRUCTIONS
Fixture Name: Torbellino 8106-10 CDB
For Chandelier Light Fixture
FINISHING THE INSTALLATION (Fig.3)
11. Place the xture canopy (F), over the threaded rod (D), so
it protrudes through the hole in the Canopy (J). Thread the Cap
(G) and Deco Nut (H) onto the threaded rod and continue
turning until the Canopy (F) is snug against the ceiling.
12. Install the light bulbs and glass shade as per the xture
assembly sheet.
YOUR INSTALLATION IS NOW COMPLETE. RETURN
POWER TO THE JUNCTION BOX AND TEST THE FIXTURE.
Fig. 3
For Customer Service, contact the place of purchase to arrange for replacement parts.
6. Assemble the xture and have an assistant or secure support
hold the weight of the xture while you complete the wiring
connections.
7.Thread the xture wires and ground wire of the assembled
xture through the canopy loop and into the outlet box.
WARNING ! SHUT OFF POWER AT FUSE OR CIRCUIT BREAKER.
HANGING THE FIXTURE (Fig.1)
1. Carefully remove the new xture from the carton and the
yellow bag that holds all parts. Check that all parts are included
as shown in the illustration and parts list.
2. Shut o the power at the circuit breaker and remove old
xture from ceiling, including the old mounting strap.
3.Thread the Nipple (D) into the Mounting Strap (C). Place Lock
Washer (B) over end of Nipple (D) protruding through Mounting
Strap (C) and thread Hex Nuts (A) onto Nipple until tight.
4. The Mounting Strap (C) contains several pairs of threaded
holes, nd the pair of holes that match the holes spacing in your
xture Canopy (F) and thread the two Mounting Screws (E) half
way into the Mounting Strap (C).
5. Place the Mounting Strap (C)over the Junction Box so the
Mounting Screws (E) are vertical or horizontal, as required by
xture type and fasten using the two mounting screws (B).
Tighten the screws (B) securely with screw driver.
Fig. 1
CONNECTING THE WIRES (Fig 2)
8. Attach the power supply wires to the xture lead wires by
connecting BLACK to BLACK (or SMOOTH) and WHITE to
WHITE (or RIBBED).
9. Attach the GROUND wire(GREEN or COPPER) from the
Junction Box and the xture Ground wire to the green Ground
Screw on the Mounting Bracket (C) or connect both wires
together using the correct size of wire connectors.
NOTE: Twist the wires together in the same direction you twist
the wire connector onto the wires.
10. Tuck these wire connections neatly into the Junction Box.
Fig. 2
A
E
C
JUNCTION BOX
(CEILING)
D
G
H
F
A
B
R
J
A
E
C
D
G
H
F
R
J
