Gigabyte Server Management

Installation and Conguration Guide

Rev. 1.0

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specifications and features in this manual may be made by GIGABYTE

without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

Documentation Classications

In order to assist in the use of this product, GIGABYTE provides the following types of documentations:

 For detailed product information, carefully read the User's Guide.

For more information, visit our website at:

http://b2b.gigabyte.com

Active GIGABYTE distributors and resellers: Access a comprehensive source of sales,

marketing & technical materials at:

http://reseller.b2b.gigabyte.com

Please contact your sales representative to register.

https://www.facebook.com/gigabyteserver

- 3 -

Table of Contents

Chapter 1 Getting Started 5 ...............................................................................................

1-1 Using Your Gigabyte Server Management 5 .......................................................

1-2 Hardware Requirement 5 ....................................................................................

1-3 Software Requirement 5 .....................................................................................

1-3-1 Prerequisites on remote management server 5 ..........................................................

1-4 Installing Gigabyte Server Management (Windows) 6 ........................................

1-4-1 Installation Procedure 6 ...............................................................................................

1-5 Installing Gigabyte Server Management (Linux) 10 ............................................

1-5-1 Tomcat Installation Procedure 10 ................................................................................

1-5-2 PostgreSQL Installation Procedure 10 ........................................................................

1-5-3 Restore dbGSMv0XX.backup .................................................................................11

1-5-4 pgadminIII Installation Procedure (Optional) 13 ..........................................................

1-5-5 Login Gigabyte Server Management 14 ......................................................................

Chapter 2 Gigabyte Server Management 15 .....................................................................

2-1 Overview ........................................................................................................ 15

2-2 Enter Gigabyte Server Management 16 .............................................................

2-2-1 System Manager 18 ....................................................................................................

2-2-1-1 Information ..............................................................................................................19

2-2-1-2 Monitoring ...............................................................................................................20

2-2-1-3 Remote Access .......................................................................................................21

2-2-1-4 NetworkConguraiton ............................................................................................26

2-2-1-5 Event Log 27 ...............................................................................................................

2-2-1-6 Alert Management 28 ..................................................................................................

2-2-1-7 Updates ..................................................................................................................30

2-2-2 Group Manager 32 ......................................................................................................

2-2-3 Alert ........................................................................................................................34

2-2-4 Account ...................................................................................................................35

2-2-5 Preference ..............................................................................................................36

2-2-5-1 IP Range 37 .................................................................................................................

2-2-5-2 Event Log 38 ...............................................................................................................

2-2-5-3 Alert Management 39 ..................................................................................................

2-2-5-4 Database ................................................................................................................42

2-2-5-5 Properties ...............................................................................................................43

2-2-5-6 Update ....................................................................................................................44

2-2-6 Help ........................................................................................................................45

Chapter 3 Appendix 46 ......................................................................................................

3-1 Event Log List 46 ................................................................................................

- 4 -

- 5 - Gigabyte Server Management

1-1 Using Your Gigabyte Server Management

Gigabyte Server management has a user-friendly Graphics User Interface (GUI) called the

Gigabyte Server management GUI. It is designed to be easy to use. It has a low learning curve

because it uses a standard Internet browser. You can expect to be up and running in less than

veminutes.ThischapterallowsyoutobecomefamiliarwiththeGigabyteServermanagement

GUI’s various functions. Each function is described in detail.

1-2 Hardware Requirement

Before using Gigabyte Server Management , please check your system for the following required

congurationrequirements:

• SystemProcessor:2GHzandabove

• SystemMemory:Minimum4GBRAM

• FreeDiskSpace:1000GBatleast

• Nodeservers:255maximum

1-3 Software Requirement

1-3-1 Prerequisites on remote management server

Supported Browsers:

• Internet Explorer 9 or later

• Google Chrome 39.0.2171.65 m or later

• MozillaFirefox33.1.1

Operating System:

• Windows 2008 & 2012 R2

• Redhat/CentOS 6.3 or later

Chapter 1 Getting Started

Gigabyte Server Management - 6 -

1-4 Installing Gigabyte Server Management (Windows)

1-4-1 Installation Procedure

1. .UnziptheleandrunGSM_Setup.exe

2. Then,aseriesofinstallationwizardsappear.

3. Click .Next

4. Click to start the nstallation.Install

- 7 - Gigabyte Server Management

5. Installingpreparationles.

CAUTION! Please make sure you have enough space on your hard drive for the program.

6. Installing Java JDK, this may take few mintues to complete installation.

Gigabyte Server Management - 8 -

7. Installing Visual C++.

8. Installing PostgreSQ.

9. Setting Database of PostgreSQL.

- 9 - Gigabyte Server Management

10. Insatalltion completed, click .Finish

Gigabyte Server Management - 10 -

1-5 Installing Gigabyte Server Management (Linux)

1-5-1 Tomcat Installation Procedure

1-5-2 PostgreSQL Installation Procedure

1. Unzipapache-tomcat-7.0.47.tar.gz

 tar-zxvfapache-tomcat-7.0.47.tar.gz

2. Move apache-tomcat-7.0.47 to /root/tomcat7

mv apache-tomcat-7.0.47 /root/tomcat7

3. Move GSM.war to /root/tomcat7/webapps

mv GSM.war /root/tomcat7/webapps

4. Execute startup.sh

cd /root/tomcat7/bin

./startup.sh

[Ubuntu]

1. Install default-jre

apt-get install default-jre

2. Install PostgreSQL

apt-get install postgresql postgresql-contrib

3. Openuppostgresql.confleinyourfavoriteeditor

vi /etc/postgresql/9.3/main/postgresql.conf

4. Alterthelisten_addressesasbelow:

listen_addresses = '*'

[Cent OS/RedHat]

1. Remove the old PostgreSQL package.

yum remove postgresql*

2. Locateandedityourdistributions.repole,located:

[CentOS] vi /etc/yum.repos.d/CentOS-Base.repo ([base] and [updates] sections)

[Red Hat] vi /etc/yum/pluginconf.d/rhnplugin.conf ([main] section)

3. Tothesection(s)identiedabove,youneedtoappendaline:

exclude=postgresql*

- 11 - Gigabyte Server Management

4. DownloadPGDGRPMle

[CentOS] curl -O

 http://yum.postgresql.org/9.3/redhat/rhel-6-x86_64/pgdg-centos93-9.3-1.noarch.rpm

[Red Hat] curl -O

 http://yum.postgresql.org/9.3/redhat/rhel-6-x86_64/pgdg-redhat93-9.3-1.noarch.rpm

5. InstallPGDGRPMle

[CentOS] rpm -ivh pgdg-centos93-9.3-1.noarch.rpm

[Red Hat] rpm -ivh pgdg-redhat93-9.3-1.noarch.rpm

6. Install PostgreSQL

yum install postgresql93-server

7. Initialize

service postgresql-9.3 initdb

8. Startup

 chkcongpostgresql-9.3on

1-5-3 Restore dbGSMv0XX.backup

1. Modifypg_hba.confle

[Ubuntu]

vi /etc/postgresql/9.3/main/pg_hba.conf

[CentOS / Red Hat]

vi /var/lib/pgsql/9.3/data/pg_hba.conf

2. Edit

TYPE DATABASE USER ADDRESS METHOD

Local all all→postgres peer→trust

host all 127.0.0.1/32all→postgres indent→trust

host all all→postgres ::1/128 indent→trust

:wqtosaveeditedle.

3. Start service

[Ubuntu]

service postgresql restart

Gigabyte Server Management - 12 -

[CentOS / Red Hat]

service postgresql-9.3 start

4. Create database

createdb -U postgres dbGSM

5. Restore dbGSMv0XX.backup to database

pg_restore -h 127.0.0.1 -p 5432 -U postgres -d dbGSM -v " dbGSMv0XX.backup"

- 13 - Gigabyte Server Management

1-5-4 pgadminIII Installation Procedure (Optional)

[CentOS]

1. Install pgadmin3

yum install pgadmin3_93

2. Execute pgadmin3

pgadmin3 &

3. File -> Add server

[Redhat]

1. Get wxBase

curl -O

http://yum.postgresql.org/9.2/redhat/rhel-6.5-x86_64/wxBase-2.8.12-1.el6.x86_64.rpm

2. Install wxBase

rpm -ivh wxBase-2.8.12-1.el6.x86_64.rpm

3. Get wxGTK

curl -O

 http://yum.postgresql.org/9.2/redhat/rhel-6.5-x86_64/wxGTK-2.8.12-1.el6.x86_64.rpm

4. Install wxGTK

rpm -ivh wxGTK-2.8.12-1.el6.x86_64.rpm

5. Get PgAdmin3

curl -O

 http://yum.postgresql.org/9.3/redhat/rhel-6.5-x86_64/pgadmin3_93-1.18.1-2.rhel6.x86_64.

rpm

6. Install PgAdmin3

rpm -ivh pgadmin3_93-1.18.1-2.rhel6.x86_64.rpm

7. Execute pgadmin3

pgadmin3 &

8. File -> Add server

Gigabyte Server Management - 14 -

1-5-5 Login Gigabyte Server Management

1. Open a browser and enter URL

 http://localhost:8080/GSM/

2. Enter Database User Name

postgres

• This utility supported CentOS 6.3 or later version.

• PostgreSQL must be execute in root authority.

• In Fedora 19, you have to install package in the following:

 Locateandedityourdistributions.repole,located:

vi /etc/yum.repos.d/fedora.repo and /etc/yum.repos.d/fedora-updates.repo

([fedora] sections)

 InstallPGDGRPMle:

curl -O

http://yum.postgresql.org/9.3/redhat/rhel-6-x86_64/pgdg-centos93-9.3-1.noarch.

rpm

Initialize:

/usr/pgsql-9.3/postgresql93-setup initdb

- 15 - Gigabyte Server Management

2-1 Overview

Chapter 2 Gigabyte Server Management

1. Openaweb browserandtype inyouridentied IP.TheIPaddresscanbe found

using your DHCP server.

2. Enterthefollowingvalues:

• Username:admin

• Password:password

• The default user name and password are in lower-case characters.

• When you log in using the root user name and password, you have full administrative

powers. It is advised that once you log in, you change the root password.

Gigabyte Server Management - 16 -

2-2 Enter Gigabyte Server Management

After you successfully log into your Gigabyte Server Management, the Remote

Management GUI appears. Click Node Status imageforadvancedconguration.

- 17 - Gigabyte Server Management

After you entering into your Management Console, the Management Console GUI

appears.

Management Console Information shows the general system health status of the current remote

node.Thenodehealthstatuswillappearontheleftsidewithdifferentcolor,eachcolordenition

willbedescribedinthefollowing:

Icon Decription/Resulting Action

Normal:Allnodesandsensorarenormaland

there’s no sensor that has any alert.

Warning:There’satleastonenode/sensorthathaswarningalert.

Unknown:There'snotcriticalalertornon-

criticalalertclassedasunknownstatus.

Critical:There’satleastonenode/sensorthathascriticalalert.

Non-connected:Thisindicatesthe

identiednodeisnotconnected.

Gigabyte Server Management - 18 -

2-2-1 System Manager

System Manager provides the function of List all connected node systems. Click the

drop-downlisttolterandselectspecicnodegroup.

Andtheclickhedrop-downlistforadvancedconguration.

- 19 - Gigabyte Server Management

2-2-1-1 Information

The Information is a display page for basic system health information, such as FRU

information, hardware information, and software information. Items on this window are

non-congurable.

Gigabyte Server Management - 20 -

2-2-1-2 Monitoring

The Monitoring displays a real-time record of the node system fan and voltage

information.Itemsonthiswindowarenon-congurable.

- 21 - Gigabyte Server Management

2-2-1-3 Remote Access

The Remote Accessprovidesthefollowingremotefunctions:

• PowerControlConguration

• Chassis Identify

• Boot Option

• Launch iKVM

• Reboot BMC

• Restore BIOS default settings

• Mount/Unmount Virtual Media

• NetworkTimeProtocolConguration

• BMCAccountConguration

Gigabyte Server Management - 22 -

Icon Decription/Resulting Action

Power on system.

Power off system.

Power cycle system.

Hard reset system.

Power Control

User can power on/off/cycle/and hard reset the remote host system in . power control

- 23 - Gigabyte Server Management

Chassis Identify

Boot Option

iKVM

Reboot BMC

Restore BIOS default settings

Parameter Decription/Resulting Action

Chassis Identify Denethechassislightingtime.

Whenyounishconguration,clickSubmit.

Boot Option Selectbootoptionbyclickingspecieddevicetab.

iKVM

Click to launch the redirection console Launch

and manage the server remotely.

Please ensure that you have latest version of

JAVA tool to active the Java KVM console.

Reboot BMC Click to restart BMC.RebootBMC

Restore BIOS

default settings

Click Browseandselecttheleonyourlocalsystem

and click to restore BIOS default setting.Restore

Gigabyte Server Management - 24 -

Virtual Media

User can mount an ISO Image via Virtual Media function page.

Follow the instructions below to mount or unmount an ISO image.

1. To mount an ISO image, select the ISO image and click .Mount

2. To unmount an ISO image, select the ISO image and click .Unmount

Network Time Protocol

Network Time Protocol provides Networkconguration. User can view and modify the

network settings on this screen. Select the Operation Mode from the drop-down list.

NOTE! Virtual Media does not support Windows operating system.

Parameter Decription/Resulting Action

Dedicate Mode RequestanimmediateclocksynchronizationwiththeNTPserver;

request will be sent when click the Sync Time Now button.

Daemon Mode

Runs NTP daemon which sends a NTP

request at approximately 5 minute

intervals. Multiple NTP servers may be

speciedtoprovideredundancy.

- 25 - Gigabyte Server Management

BMCAccountConguration

User can configure the adminstrator ID and password in this section. After finish

conguration,clickSumit.

- 27 - Gigabyte Server Management

2-2-1-5 Event Log

Event Log displays the connected Node system event log information.

Click to clear current system event log.Clear

Click to download current system event log.Download

Gigabyte Server Management - 28 -

2-2-1-6 Alert Management

Alert Management SNMP Trap Setting Platform Events containstwocategories: and

Filters (PEF). Each catergory will be described in the following section.

SNMP Trap Setting

In the Trap Settings, user can set the IPv4 and Ipv6 Destination List.

IPv6 and IPv4 are two completely separate protocols. IPv6 is not backwards compatible with

IPv4,andIPv4hostsandrouterswillnotbeabletodealdirectlywithIPv6trafc.

IPv6hasasignicantly largeraddressspacethanIPv4.This resultsfrom theuseofa128-bit

address, whereas IPv4 uses only 32 bits.

Whenyounishtheconguration,click tosaveconguration.Submit

Termékspecifikációk

Márka:	Gigabyte
Kategória:	nincs kategorizálva
Modell:	MD60-SC0

Szüksége van segítségre?

Ha segítségre van szüksége Gigabyte MD60-SC0, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek

Az Ön neve*

Az Ön e-mail címe*

Írja ide kérdését

Útmutatók nincs kategorizálva Gigabyte

Gigabyte AORUS ELITE P1000W 80+ Platinum Modular PCIe 5.0 ICE Útmutató

17 December 2024

Gigabyte MD60-SC0 Útmutató

9 Szeptember 2024

Gigabyte UD850GM-A Útmutató

2 Szeptember 2024

Gigabyte UD750GM-A Útmutató

2 Szeptember 2024

Gigabyte P550SS Útmutató

31 Augusztus 2024

Gigabyte H223-Z10 Útmutató

29 Augusztus 2024

Gigabyte ODIN Plus 600W Útmutató

19 Augusztus 2024

Gigabyte Superb 720 Útmutató

19 Augusztus 2024

Gigabyte Sumo Power Silver 900W Útmutató

19 Augusztus 2024

Gigabyte ODIN Plus 700W Útmutató

19 Augusztus 2024

Útmutatók nincs kategorizálva

Legújabb útmutatók nincs kategorizálva

MOZA SR-P Útmutató

10 Április 2025

Soundstream VRN-64HBL Útmutató

10 Április 2025

Panasonic Lumix DMW-AC11 Útmutató

10 Április 2025

Planet PWR-240-48 Útmutató

9 Április 2025

CaterChef 445001 Útmutató

9 Április 2025

IFM E40581 Útmutató

9 Április 2025

Livn Bolt Útmutató

9 Április 2025

Livn Beats Útmutató

9 Április 2025

Alpine DP2-40C-BC Útmutató

9 Április 2025

IFM O3R252 Útmutató

9 Április 2025
