HDMI to VGA+L/R Audio Converter
INTRODUCTIONS
This product is an HDMI converter. It converts HDMI input to VGA+L/R audio output, allows
users to enjoy their high definition image and sound when watching movies or playing games
on the traditional monitors or projectors which only with VGA inputs.
FEATURES
• Easy to Use: Install in seconds, no need of setting.
• Conversion: It converts complete HDMI into VGA+L/R audio.
•Extra VGA and R/L audio outputs: the outputs could be connected back to PC’s monitor and
speakers
• HDCP pass through
SPECIFICATIONS
Signal Input/Output
Input Video HDMI A female (19PIN)
Output Video VGA, L/R Audio
HDMI input format 480i/576i/480p/576p/1080i/1080p
VGA output format 480i/576i/480p/576p/1080i/1080p
Michanical
Size(W-H-D) 89mm X 29mm X 68mm
Net Weight 99g
Warranty
Limited Warranty 1 Year
Environmental
Operating Temperature 0 to +70
Operating Humidity 10% to 85% RH(No condensation)
Storage Temperature -10 to +80
Storage Humidity 5% to 90% RH(No condensation)
Power Requirement
External Power Supply 5V DC@1A
Regulatory Approvals
Converter Unit FCC,CE
Power Supply FCC,CE,UL
Accessories Adapter
AC Power Adapter US standard,UK standard and so on
User Manual English version
Note: Specifications are subject to change without notice.
PACKAGE CONTENTS
Main unit (HDMI to VGA+L/R Audio Converter)
5V DC Power Supply
User Manual
PANEL DESCRIPTIONS
CONNECTION AND OPERATION
Before installation, please make sure all devices you wish to connect have been turned off.
1, Please connect the VGA source device to the Converter by VGA cable.
2, Please connect the Audio of VGA source device to the Converter by L/R Audio cable.
3, Please connect the HDMI displayer device to the Converter by HDMI cable.
