WARNING: Read all safety warnings and instructions before use. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury. Save these instructions for future reference.
09/16
DEMOLITION
HAMMER KIT
ORIGINAL INSTRUCTIONS
2
Power: 1500W
Input: 230-240V ~ 50Hz
Impact Energy: 32J
Impact Frequency: 1900/min
Breaking Capacity: 38mm
Accessory Fitment: SDS Max
Weight: 10.8kg
SPECIFICATIONS - MODEL NO. FBT-1100U
KNOW YOUR PRODUCT
1. Accessory Holder
2. Accessory Locking Sleeve
3. Accessory Rotation Lock
4. Side Handle
5. Power Cord
6. On/Off Trigger
7. Lock-On Button
8. Anti-Vibration Rear Handle
1
2
3
4 5
6
7
8
4
Congratulations on purchasing your Full Boar demolition
hammer kit. It has been designed for rapid breaking and
chipping of concrete, block and masonry products.
Read and understand the instruction manual before
operating the demolition hammer. Failure to do so could
result in personal injury or equipment damage.
INTRODUCTION
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency,
before operating the tool. Save these instructions and other documents supplied with this tool for
future reference. The manufacturer cannot accept any liability for damage or accidents which arise
due to a failure to follow these instructions and the safety information.
Before you connect the equipment to the mains supply make sure that the data on the rating plate is
identical to the mains data.
This tool is double insulated therefore no earth wire is required.
The power supply for this product should be protected by a residual current device (rated at 30mA or
less). A residual current device reduces the risk of electric shock.
If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord
available through the service organisation.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool. The insulation system is for added protection against injury resulting from a possible electrical
insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or
defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead
not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire
and electric shock.
ELECTRICAL SAFETY
