Quick Start Guide
Before continuing please be sure your devices are fully charged before
continuing on with this guide.
Guide 1 Pairing your devices
The devices should now find each other and pair together. You will know they are paired when both
flashing blue lights go to a slow blue flashing state. Anytime you turn on both devices they will
automatically connect. If they do not, please refer to steps 3–6. Please see further instructions on
page 2 for connecting your transmitter to your television.
AUX
SPDIF TX SPDIF RX
1
A
You can find the
MicroUSB port
on the back of your TV
HearGear transmitter.
A
2
Plug MicroUSB cable
(included) into MicroUSB
port on the back of TV
HearGear transmitter.
3
Make sure the switch
on the side of the
transmitter is set to the
“TX” setting.
4
Hold the power
button for 2 seconds
to turn transmitter on.
5
Press the pairing button
on the transmitter until you
see a quick flashing blue light.
Note: that if you see a blue and red
alternating light on the transmitter, you
are in the RX setting and you should go
back to Step 3.
6
Press and hold the
power button on the
Earphone for 3 seconds
or until you see a quick
flashing blue light.
B
B
TX RX
TX RX
A
A
B
B
C
C
D
D
To pair a second set of earphones, for dual listening capabilities,
please repeat steps 5 and 6 using a second earphone device.
Light on front of transmitter will be solid green when
connected to 2 devices. D
With first set
already paired,
repeat steps 5
and 6 on second
set of earphones.
Guide 2 Connecting your transmitter to your television
Note: Every television is different and you will need to refer to the television manual for specific
instructions on how to set up the audio outputs on your TV. Not every TV has the same outputs so
please refer to the back of your TV to see which connection you need to follow.
AUX
SPDIF TX SPDIF RX
Choose your type of connection
Enjoy your new TV HearGear TV Streaming system and listen to your television at
your own volume, without disturbing others!
For further information or technical assistance please visit www.heargear.com
Connect optical cable* (included) ** to
your HearGear transmitter and television.
* Cable has 2 white protective plastic covers on the tips. You will need
to remove these for connecting to your television.
** Be sure to insert the connector in the correct direction.
L R
OPTICAL
AUDIO OUT
3.5 mm
AUDIO
TELEVISION
Your TV HearGear
transmitter can connect to
your television in 3 different
types of connections.
Choose one.
• 3.5 mm Audio
• RCA Audio
• Optical Audio
Optical Audio Connection
AUX
SPDIF TX SPDIF RX
Connect optical cable* (included) ** to
your HearGear transmitter and television.
* Cable has 2 white protective plastic covers on the tips. You will need
to remove these for connecting to your television.
** Be sure to insert the connector in the correct direction.
TV HEARGEAR TRANSMITTER
A A
AUX
SPDIF TX SPDIF RX
Connect 3.5 mm audio cable* (included)
** to your HearGear transmitter and television.
* Cable looks like standard 3.5 mm headphone cable
TV HEARGEAR TRANSMITTER
B B
3.5 mm Audio Connection (Standard Headphone Jack)
OR
AUX
SPDIF TX SPDIF RX
Connect 3.5 mm audio cable to
RCA Audio cable (included)
TV HEARGEAR TRANSMITTER
C C
Traditional RCA Connection
OR
D
D
TELEVISION TV HEARGEAR TRANSMITTER
3.5 mm
AUDIO
3.5 mm
AUDIO OPTICAL
AUDIO OUT
L RL R
TELEVISION
3.5 mm
AUDIO
3.5 mm
AUDIO OPTICAL
AUDIO OUT
L RL R
TELEVISION
3.5 mm
AUDIO
3.5 mm
AUDIO OPTICAL
AUDIO OUT
L RL R
TELEVISION
Plug the RCA connectors to Red/White RCA
output ports on your television. Plug other end of
connected cables (3.5 mm plug) to TV HearGear transmitter.
9
8
7
