Oldal 1/22
0906941
Single and Multi-Channel
EGT, CHT, Carb Temp and OAT Instruments
Operating and Installation Instructions
OII 0906941 9/6/94
Electronics International Inc. ®
63296 Powell Butte Hwy Bend, OR 97701 (541) 318-6060 Buy-EI.com
(This manual covers 25 instruments and remote switches)
(Supersedes OI 070781, II 070781, OI 040831 and II 070781-1)
(FAA Approved)
S/N:_____________________
You must read this manual before installing or operating the instrument. This
manual contains warranty and other information that may affect your decision
to install this product and/or the safety of your aircraft.
Important Installation Information
0720921
1. Leave slack in the cable to allow
for engine movement and vibration.
All steps must be read before installing a probe.
FE
2. Do Not Overtighten.
Over time, tight wire
wraps will cause the wire
to break.
Hose Clamp.
4. The tab inside the male connector must be centered (not
bent up or down) to mate properly. Check each connector
before installation. Two drops of oil on the connector will
protect it from corrosion for many years.
5. If you remove a connector, double over the wire
before installing it into a new connector. Each connec-
tor must be double crimped very tightly.
Male Conn.
6. If connectors have been disconnected several times the female connector may become
loose. If this happens use a pair of needle nose pliers to retighten the female recep-
tacle then mate the connectors.
S.S. Washer.
3. Both clip rings must be on
the inside of the hose clamp.
The rubber band is used to hold
the washer on during shipping.
Important Notice
***** MUST READ *****
If you think it is not important to read this manual, you're wrong! This manual
contains important installation information that may affect the safety of your air-
craft, delay your installation or affect the operation of your instrument. You Must
read this manual prior to installing your instrument. Any deviation from these
installation instructions is the sole responsibility of the installer/pilot and may
render the STC invalid.
Read the Warranty / Agreement. There is information in the Warranty / Agreement that may alter
your decision to install this product. If you do not accept the terms of the Warranty / Agreement, do not
install this product. This product may be returned for a refund. Contact Electronics International inc. for
details.
Check that the instrument make and model marked on the side of the instrument and on the invoice are
correct before starting the installation.
It is possible for any instrument to fail thereby displaying inaccurate high, low or jumpy readings.
Therefore, you must be able to recognize an instrument failure and you must be proficient in operating your
aircraft safely in spite of an instrument failure. If you do not have this knowledge, contact the FAA or a
local flight instructor for training.
The pilot must understand the operation of this product before flying the aircraft. Do not allow anyone
to operate the aircraft that does not know the operation of this product. Keep the Operating Manual in the
aircraft at all times.
