Oldal 1/84

Table of Contents

Introduction 4 ............................................................................................................................................................................................

1. Getting Started 5 ..................................................................................................................................................................................

1.1 System Requirements ..............................................................................................................................................................5

1.2 Registration ..................................................................................................................................................................................5

1.3 Software Installation 6 .................................................................................................................................................................

1.4 Licenses 6 .........................................................................................................................................................................................

2. Hardware 7 .............................................................................................................................................................................................

3. Suggested Uses And Congurations .........................................................................................................................................9

3.1 One Computer with a DiGiGrid IOS-XL ..............................................................................................................................9

3.2 Adding More I/Os to Your System 10 ......................................................................................................................................

3.3 Multiple Computers with a Single DiGiGrid IOS-XL 11 .....................................................................................................

3.4 Advanced Network: Multiple Computers and Multiple I/Os 12 ....................................................................................

4. Software Setup And Controls 14 .....................................................................................................................................................

4.1 Device Firmware 17 .......................................................................................................................................................................

4.1.1 Resetting the Unit 17 .........................................................................................................................................................

4.2 Identifying a Device from the SoundGrid Studio Device Rack 17 ................................................................................

5. Control Panel 18 ....................................................................................................................................................................................

5.1 Controls Page 20 ............................................................................................................................................................................

5.1.1 Top Bar............................................................................................................................................................................... 21

IOS-XL-XL

IOS-XL

5.1.2 Analog Section 21 ...............................................................................................................................................................

5.1.3 Digital Section 24 ................................................................................................................................................................

5.1.4 Clip Indication and Small Meters 25 .............................................................................................................................

5.2 Clock Page 26 ..................................................................................................................................................................................

6. IOS-XL Server 28 ....................................................................................................................................................................................

6.1 Applications of an IOS-XL Server 29 .......................................................................................................................................

6.1.1 eMotion ST mixer 29 ..........................................................................................................................................................

6.1.2 StudioRack 30 .......................................................................................................................................................................

7. Moving Audio in a Soundgrid Network 31 ..................................................................................................................................

7.1 Using an I/O Device with a DAW 32 ........................................................................................................................................

7.2 Patching I/O to Driver and Driver to I/O 33 .........................................................................................................................

7.3 eMotion ST Mixer Patching 36 ..................................................................................................................................................

7.4 Device-to-Device Patching 37 ...................................................................................................................................................

7.5 Headphone Patching 38 ..............................................................................................................................................................

8. Using the IOS-XL with Midi.......................................................................................................................................................... 39

9. Technical Specications ................................................................................................................................................................ 40

9.1 Installation Notes 42 .....................................................................................................................................................................

IOS-XL

INTRODUCTION

Thank you for choosing the DiGiGrid IOS-XL interface for SoundGrid systems. In order to get the most out of your product,

please take some time to read this manual. We also suggest that you become familiar with our support sites, www.digigrid.net

and www.waves.com/support, where you will nd an extensive answer base, the latest tech specs, detailed installation guides,

software updates, and current information about licensing and registration.

About SoundGrid and DiGiGrid IOS-XL

SoundGrid is a scalable infrastructure that provides a variety of cost-eective, high-quality solutions for studio production. It can be

congured in many ways, with many hardware possibilities, to provide a very exible work environment. This framework is managed

by the SoundGrid Studio Application, which congures the network, assigns and manages I/Os, controllers and servers, and patches

audio throughout the system. Any user, anywhere on the SoundGrid network, has access to all available network I/O devices. Adding

a SoundGrid DSP server enables processing, recording, and monitoring.

DiGiGrid IOS-XL is an audio interface for native DAWs and Waves SoundGrid applications that run on a SoundGrid network. It has

eight mic/line inputs and 8 line outs, along with the standard digital ins and outs. Like all DiGiGrid I/O devices, it can be used by

the local host or by a remote audio workstation anywhere on the SoundGrid network. Since all IOS-XL features (even the preamp

settings) are controlled remotely from the host computer, the IOS-XL can be placed in the live room or in the studio.

The IOS-XL’s internal DSP server moves plugin processing from the host CPU, greatly increasing the number of plugins that can be

used simultaneously. It also enables recording while monitoring in incredibly low latency.

By combining a DSP server with an I/O, the IOS-XL oers an all-in-one solution to many audio production challenges.

IOS-XL

1. GETTING STARTED

Aside from setting up your microphone preamps, there’s not much you need to know to begin working with your IOS-XL.

1.1 System Requirements

■ SoundGrid Studio runs on Mac and PC (consult Waves website for current OS and DAW compatibility).

■ Compatible native DAW (Logic, Cubase, Nuendo, Ableton, Pro Tools Native, and many more). A list of SoundGrid-compatible

hosts is available at Waves website.

■ IOS-XL / SoundGrid Studio software installed on the host computer.

■ Cat 5e or Cat 6 Ethernet cables.

1.2 Registration

To download IOS-XL software you will need to register your device at www.digigrid.net or www.waves.com. You must know the

serial number of your IOS-XL in order to register it, so sign up before you mount it in a rack. The serial number appears on a label on

the bottom of the unit or on a sticker on the box.

Once you register you will receive two emails:

■ A notication that you can now download the installer.

■ Instructions about authorizing your license.

IOS-XL

1.3 Software Installation

After you register your new IOS-XL, you can download the installer from the Download/Hardware Drivers section of the Waves

website. Since SoundGrid enables you to access an I/O device from any computer in the network, you will need to install the

software on each computer in the network.

The IOS-XL installer consists of:

■ The IOS-XL I/O hardware driver.

■ The SoundGrid ASIO/Core Audio driver, which serves as a bridge between the DAW and the SoundGrid network.

■ The SoundGrid Studio Application, which manages all SoundGrid network resources and assigns devices to computers.

■ StudioRack, a software plugin rack, or chainer, that hosts up to eight plugins and can move their processing from the DAW to the

SoundGrid server.

■ eMotion ST, a software mixer that provides low-latency plugin processing and monitor mixing.

1.4 Licenses

DiGiGrid Native I/O devices do not require a license to operate in a SoundGrid network. However, certain advanced features, such as

using StudioRack and eMotion ST for low-latency recording and monitoring, or ooading processing from the host CPU, require a

server and a SoundGrid license. This license is included with the purchase of IOS-XL.

When you register your device, the relevant licenses are deposited in your Waves account. Use the Waves License Center application

to activate your licenses and install them on your computer or on a USB ash drive.

IOS-XL

2. HARDWARE

IOS-XL is a 2U rack-mounted device. Aside from headphone jacks, all connections are from the rear panel.

IOS-XL Front Panel

Front panel LEDs indicate status regarding essential device functions for each channel.

Input clipping Red = clipping (level can be set through the control panel)

Input signal present Green = signal present

48v phantom power Orange = ON

Network status indicator

Blue: Device recognized by the SoundGrid network

Red: Device not recognized by the SoundGrid network

Yellow: Updating

White: Unit malfunction (e.g., rmware did not load properly, unit did not boot properly)

Cycling through colors: This LED is also used to identify the unit from the control panel.

Power switch/indicator

Two ¼-inch TRS headphone jacks with individual volume control knobs;

8–600 ohms; gain = OFF to +15 dB

IOS-XL

IOS-XL Rear Panel

Mains input: 90–240 V AC 50/60 Hz

Built-in 1GB Ethernet switch, four ports

USB port for server service and upgrades (used for technical support)

Recovery/reset button

MIDI in and out (can be linked to Waves applications and to DAWs)

Digital and clock connections: software selected

Clock in and out (BNC connectors for external Word Clock)

S/PDIF in and out (RCA connectors)

AES in and out (XLR connectors)

Analog connections

8 mic/line inputs (combo XLR/TRS connectors)

8 line out ¼” TRS connectors

Alt line out (DB25 8 channel balanced connector) See connection diagram in IOS-XL specications section.

7 8
