Oldal 1/2
Physical Appearance2
Specifications3
Hardware Connection
1
Model GS1026PS2
Network Protocol
PoE Protocol
Optical Media
AC Input Voltage
POE Voltage
Power Pin
Network Medium
Power Socket
PoE or Ethernet Device
(switch, router, etc.)
Wireless AP Smart VoIPIP Camera
Powered Device (PD)
Internet Front board
Back board
10/100/1000Mbps PoE Port SFP Port
Gigabit Ethernet port
IEEE802.3 / IEEE802.3u / IEEE802.3z
IEEE802.3x / IEEE802.3ab / IEEE802.3af/at
IEEE802.3at (30W) and IEEE802.3af (15.4w)
Multimode fiber:50/125,62.5/125,100/140um
Single mode fiber:8/125 8.7/125,9/125,10/125um、
AC100~240V
DC 44-57 V
Power over spare pairs 1/2(+) , 3/6 (-)
10BASE-T: Cat 3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or more UTP (≤100 meter)
1000Base-TX: Cat5 or more UTP/STP(≤100 meter)
NVR Monitor
Router
Power input port
AC INPUT
100V-240V
52V ~ 5.76A
Maximum 280W
320mm×207mm×44mm
56 Gbps
41.644 Mpps
3Mbit
8K
Store-And-Forward
-10~50℃
-40~70℃
10%~90%, non-condensing
5%~95%, non-condensing
Supply Power
POE Power
Dimension(L×W×H)
Bandwidth
Forwarding Rate
Packet Buffer
MAC Address
Transfer Mode
Working Temperature
Storage Temperature
Working humidity
Storage humidity
Q I a Guick nstall tion uide
Model: GS1026PS2
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
directives 2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The original EU declaration of conformity may be
found at http://www.cudy.com/
810600224
LED and Interface Explanation
5
PWR
Mode
1-28 Green
1-24Yellow (POE)
POE MAX (Green)
POE LED Button
DIP Explanation
4
OFF
ON
Standard Switch
Link Extension
(17-24 Port)
Equipment powered on
Equipment power off
Extend on
Extend off
Link connectivity
Data transmission
Link abnormality
POE power supply is normal
POE not powered
Indicates that PoE power usage is less than 90%
Indicates PoE power usage of 90% ≤ P ≤ 95%
Indicates PoE power usage of 95%<P<100%
On
Off
On
Off
On
Flashing
Off
On
Off
Off
Flashing
On
Dual color light selection: default green (link data), switch
yellow light (POE)
Email:
support@cudy.com
Website:
www.cudy.com
All interfaces can communicate with each other, the
transmission distance is less than 100 meters, the
transmission rate is 10/100/1000M adaptive(Disable
POE watchdog)
Link extension mode, 9-16 ports force 10M, link 250M
(enable POE watchdog)
