ASSEMBLY INSTRUCTION MODEL# ROS-A1006-CH-CL-MWP
LIGHTING THE WAY FOR SIXTY YEARS
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
WARNING:
Electrical Danger Turn Power Off
R
CUL
You will need 5-Candelabra Base Bulb
40 Watts Recommended 60 Watts Max
USE LED BULBS FOR EXTENDED USE
How to Install
Crystal Sets
WARNING: This product can expose you to Lead,
which is known to the State of California to cause cancer
and/or birth defects or reproductive harm. For more
information go to www.P65Warnings.ca.gov
DETAILED ILLUSTRATION
36Sets. (1)22mm Square
A. 15Sets. (1)22mm Square
B. 28Sets.
(1)10mm+(3)12mm+(2)14mm+(1)16mm+(1)18mm
(1)20mm+(1)22mm+(1)24mm
F.
15Sets. (1)22mm Square
C. 36Sets (1)20mm+(1)18mm+(1)50mm Baguette
+(1)12mm+(1)10mm
D.
E
1Piece AS8-30mm
1. Attach the top rod kit onto the coupler on the top of wiring box.
2. Attach the bottom rod kit onto the coupler on the bottom of wiring box.
3. Do not install the glass dish before the crystal strands "C" are dressed.
4. After safety attaching fixture into outlet box, install bulbs (not included)
and proceed to connecting the power.
5. Dress the crystal sets on the frame. Please hang the crystal strand "B"
before crystal " A".
6. Place the glass dish and small metal dish over the threaded pipe,
secure it with ball finial.
7. Hang the bottom crystal ball "D" on the finial.
The fixture is dry rated
B
PART NUMBER # ROS-A1006-CH-CL-MWP
LIGHTING THE WAY FOR SIXTY YEARS
A
C
E
F
G
H
I
J
D
OUTLET BOX
K
Part Number
Part Numbers
B.
.
.
.. (1)-Mounting Bar
C (2)-Outlet Box Screws
.
.
.
..
D.
.
.
.. (1)-Lock Washer
E.
.
.
.. (1)-Hex Nut
F.
.
.
.. (1)-Nipple
G (1)-Canopy; w5" x h1.25" (
.
.
.
.. XFB1006CHCAN5IN)
H.
.
.
.. (1)-Collar Ring
I.
.
.
.. (1)-Collar Loop
J.
.
.
.. (1)-Chain; 72", 4mm (XFB1006CHCHA5MM)
K.
.
.
..
(1)-Top Band Ring
L.
.
.
..
(1)-Top Stem; 14", 12MM thickness (XFB1006CHTOPSTEM14IN)
M.
.
.
..
A (2)-Wire Connector
.
.
.
..
N.
.
.
..
O.
.
.
..
(1)-Band Ring
(1)-Bottom Stem; 2.75", 10MM thickness (XFB1006CHBOSTEM2.75IN)
P.
.
.
..
R.
.
.
..
Q.
.
.
.. (1)-Glass Dish; Ø4", 11mm hole (XFB1006DIBOB4IN)
S.
.
.
..
(1)-Small Metal Dish
(1)-Finial (XFB1006CHFIN)
(1)-Ground Wire
(1)-Metal Plate
L
P
Q
R
S
PART BAG : Includes Parts A, CⅠ
PART BAG : Includes Parts B, D, E, F, H, IⅡ
