Oldal 1/2
16 "
17.6"
ASSEMBLY INSTRUCTION MODEL #JSP-10533-MT
You will need 3 -Candelabra Base Bulb
40 Watts Recommended 60 Watts Max.
USE LED BULBS FOR EXTENDED USE
12"
108.1”
Wood bead:10mm
Canopy(W4.7",H0.8")
THIS FIXTURE IS DAMP RATED
1 Feed the wire through the chain link and.
rod. Hook the chain link onto the loop of
the rod and the fixture loop. Close the
link using the plier. (To prevent damage
to the paint, please wrap a cloth around
the plier when using).
2. Decide the preferred hanging height and
choose the correct chain length needed.
3 Install the mounting strap onto the outlet .
box.
4. Raise the fixture up to the ceiling, and do
the wire connections. Secure the canopy
to the ceiling with the collar ring.
Crystorama.comCrystorama.com
B
C
D
F
MODEL # JSP-10533-MTPART NUMBER
E
A. (1) - M
B. (1) - Canopy(W4.7”,H0.8”) #XRE10533MTCAN4.7IN
C. (1) - Collar Ring
D. (1) - Collar Loop
E. (2) - Quick Link(4mm)
F. (1) - Hanging Chain(72",3mm) #XRE10533MTCHA3.0MM
G. (1) - Rod #XRE10533MTROD12IN
H. (1) - Chain Link(4mm)
ounting Hardware
A
G
H
Crystorama.comCrystorama.com
