Oldal 1/2
How to Install
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
ASSEMBLY INSTRUCTION
®
MODEL #CLO-8890-AG
1.Put the check ring over the hex nut on top of wiring box
O:
2.Thread Rod onto the nipple
3.Place the top metal plate over the Rods and secure
it with hex nuts
4.Pull the wire from center stem through the hickey until
taut and put the top cap over it and secure with
xture loop
L:
5.Insert each long threaded crystal ball through the
bottom of the ring,then secure it from the top with
the crystal ball (without nipple).
39.3″
32.5″
27.7″
Installation of safety cable
4.Continue to run safety cable through the top of outlet box and
secure it to the ceiling joist.
3.Feed safety cable through the cable lock and coil it around the
hickey twice.Then feed the cable through the lock again and
tighten it with lock screw.
2.Feed wires and safety cable up through chain and the
hole of screw collar loop.Have the wires and safety
cable exit through the side of hickey
1.Pass the long threaded pipe on the hickey through the
center of outlet box.Attach it to the ceiling joist and
secure it with nuts.
CRYSTAL SETS:
O:Ø16mmx19,Ø60mmx1
L:Ø30mmx120,Crystal ball with long thread
Ø30mmx120,Crystal ball
WARNING: This product can expose you to Lead,
which is known to the State of California to cause cancer
and/or birth defects or reproductive harm. For more
information go to www.P65Warnings.ca.gov
PART NUMBER
Part Number
Part Numbers
MODEL #CLO-8890-AG
A.Mounting Hardware
(3)Wire Nut
(1)Hickey
(2)1/4" IP NIPPLE
(4)Nut
(4)Flat Washer
(4)Spring Washer
B.(1)Canopy;Ø5.5″x0.98″h;XMO8890AGCAN5.5IN
A
B
D
E
D.(1)Chain;72″Lx Ø5.0mmT;XMO8890AGCHA5.0MM
E.(1)Top Loop
F
F.Assembly Hardware
(1)Top Cap
(1)Top Metal Plate
(4)Hex Nut
G
G.(4)Rod;Ø0.5″x12″h;XMO8890AGROD12IN
H.(1)Center Stem;Ø0.75″x12.3″h;XMO8890AGROD12.3IN
I
L
M
K
J
N
O
I.Assembly Hardware
(1)Wiring Box
(4)Check Ring
(4)Hex Nut
J.(1)Top Ring
K.(4)Arm;Ø0.5″
L.(240)Crystal Ball;Ø1.18″
M.(24)Candle Sleeve; 1 x2.8 h;XMO8890AGCDL2.8INØ″ ″
N.(1)Bottom Ring
O.(1)Strand Crystal
H
C
C.(2)Quick Link
x3
Wire Nut
