Instruction Manual
V1.0
4040 CD
CD Player
WWW.CREEKAUDIO.COM
ENGLISH
USER MANUAL FOR 4040 CD PLAYER
OVERVIEW
COMPACT DISCS may be a 20th century legacy format, but most people still have a perfectly good collection of CDs
that may be collecting dust somewhere. Your CD music is wholly owned by you and not borrowed from the cloud.
So, why not exploit what is yours?
SIZE
The diminutive 4040 CD’s case, with its extruded aluminium front panel, matches the 4040 A integrated amplifier.
Technical advances and circuit miniaturisation over the last 40 years no longer require heavy casework and massive
power supplies to play digital music accurately from CD.
DIGITAL OUTPUTS
The 4040 CD oers three types of digital outputs for the discerning audiophile, including transformer-isolated SPDIF
(via coaxial RCA), professional balanced AES-EBU (via XLR), and optical TOSLINK.
DAC
The 4040 CD provides a useful built-in DAC for convenient stand-alone analogue audio output, via a pair of RCA
sockets. However, to ensure the highest quality audio reproduction, Creek recommends connecting the 4040 A by
SPDIF coaxial or optical digital output, to benefit from the amplifier’s excellent ES9018K2M ESS Sabre32 Reference
DAC.
POWER SUPPLY
An important feature of any high-end audio product is its power supply. The 4040 CD Player’s impressive
performance and small size is thanks to its eicient and rock-steady external DC power supply. The CREEK multi-
region 12 Volt power supply adapter provides a stable DC voltage to the 4040 CD’s circuitry, independent of mains
quality and stability. Multiple linear voltage stabilisers then power every part of its circuitry.
STANDBY
Audio signal sensing circuitry enables the 4040 CD to reduce overall power consumption by powering down non-
essential circuitry when not required to less than 0.5W.
CD QUALITY
Properly recorded and well-maintained CDs can still provide resolution equal to most streamed music. The Compact
Disc’s native 16 bit 44.1kHz format is adequate for most music replay and is not compressed. By comparison, a lot of
streamed music undergoes some form of compression to shrink its file size, with consequent losses. As a bonus, CDs
provide a positive tactile experience and provides helpful and informative artist and title notes.
2
Page:
FRONT PANEL CONTROLS AND DISPLAY
POWER ON Press MENU once to wake-up from Standby.
POWER OFF Press MENU for 1 second to enter Standby.
Insert a Compact Disc into the slot and it will automatically load.
The display will indicate ‘Loading’ while the mechanism reads the Table of Contents (TOC).
It will then show the number of tracks, the total time of the CD, and automatically play the
first track.
If a Compact Disc is already inside the 4040 CD, when it is woken-up from standby it will read
the TOC and show the number of tracks and total time of the CD. If there is no disc loaded
the 4040 CD will display ‘No Disc’.
PLAY / PAUSE Press >II to PLAY the first track. Press >II to PAUSE.
STOP Press to STOP playing but leave the disc inside.
TRACK FORWARD Press >>I to move the disc forward to the next track.
TRACK BACKWARD Press I<< to move the disc backward to the last track.
EJECT Press to stop play and EJECT the disc.
MENU Press briefly to select the SETUP MENU, then press >>I or I<< to select options and then
press MENU again to confirm selection.
DIMMER Press once to enter. Press >>I to select display Always ON or Auto OFF.
BRIGHTNESS Display brightness has 7 levels of adjustment.
AUTO STANDBY Auto Standby time can be set for: 30 mins, 60 mins, or 120 mins without a signal. Always On,
means it will not automatically power down without a signal.
INFO Soware revision V1.0 confirms the initial release number and may be updated in future if
necessary. CD Servo soware revision V1.0 is also the initial release number.
BACK Press to exit SETUP MENU or wait for 10 seconds to automatically exit.
