Oldal 1/2
Windows 7, Windows 8, Windows 10
Product name
Key switch
N-key rollover
Interface
Cable length
Material
PURI TKL Gaming Keyboard
Cherry MX mechanical switch
Yes ( USB mode support )
Polling rate 1000Hz
Full key backlight Yes
USB plug
1.8m
Dimension 150(L) X 370(W) X 40(H) mm
Steel / Plastic
Weight 1.2kg
The above specifications may vary by country or region
ENGLISH
● COMPACT AND STURDY DESIGN
Solid and stable, Puri's minimalist design brings you
all the key features of a pro gaming keyboard without
burdening you with extras you don't need. Quality
and strength meet in this superb gaming tool.
● CHERRY MX MECHANICAL SWITCHES
The original mechanical switches from Germany are
also the best on the market. With 50 million clicks per
switch of guaranteed flawless performance, Cherry
switches bring you the response and reliability you want.
● BACKLIGHT EFFECTS (20 PRESET + 10 CUSTOMIZABLE)
Simple and elegant, Puri's backlight functionality gives
you all you need. Start enjoying 20 preset modes that
cover the most commonly needed patterns (uniform,
wave, breathing, etc.) and 10 modes for you to customize!
● MAGNETIC PROTECTIVE COVER
No cloth or mesh pouches here: to truly protect your
keyboard both at home and on the go, you need
(and we are happy to give you!) a solid cover. Puri's
magnetically attached cover will protect it from water
spills, bread crumbs or pressure when traveling.
COUGAR PURI TKL Gaming Keyboard
User Manual
Backlight 1 : Press the Fn key + 1
Backlight 2 : Press the Fn key + 2
Backlight 3 : Press the Fn key + 3
Backlight 4 : Press the Fn key + 4
Backlight 5 : Press the Fn key + 5
● Depends on diverse languages and regions, the keyboard layout will be different.
● When the brightness reaches its maximum or
minimum, the CAPS Lock, Scroll Lock
and Windows Key lock will start blinking.
PORTUGUÊS
● MAGNÉTICO CAPA PROTETORA
● CABO DESTACÁVEL
● 20 EFEITOS DE LUZ DE FUNDO
● TECLADOS MECÂNICOS CHERRY MX
● N-KEY ROLLOVER
● 1000 Hz POLLING RATE / 1MS RESPONSE TIME
한국어
●
자기보호 커버
●
탈착식 케이블
●
20 가지 백라이트 효과
●
CHERRY MX 기계식 키
●
N-KEY ROLLOVER
●
1000 Hz POLLING RATE / 1MS 응답속도
日本語
● 磁気保護カバー
● 取り外し可能なケーブル
● 20パターンLEDバックライトモード
● CHERRY MXメカニカル・スイッチ使用
● Ｎキーロールオーバー対応
● 1000Hzレポートレート/1MS応答速度
● HOUSSE DE PROTECTION MAGNÉTIQUE
● CÂBLE DÉTACHABLE
● 20 EFFETS DE RÉTROÉCLAIRAGE
● SWITCHS MÉCANIQUES CHERRY MX
● N-KEY ROLLOVER
● TEMPS DE RÉPONSE 1MS/ FRÉQUENCE 1000Hz
FRANÇAIS
ESPAÑOL
● MAGNÉTICO TAPA PROTECTORA
● CABLE DETACHABLE
● 20 EFECTOS DE RETROILUMINACIÓN
● TECLADOS MECÁNICO CHERRY MX
● N-KEY ROLLOVER
● 1000 Hz POLLING RATE / 1MS RESPONSE TIME
中 文
● 磁铁保护防尘盖
● 分离式线材
● 20种背光效果
● CHERRY MX 机械式开关
● N-KEY ROLLOVER / 100%无冲突按键
● 1000 Hz轮询速率 / 1MS响应时间
РУССКИЙ
● COPERTURA PROTETTIVA MAGNETICA
● CAVO STACCABILE
● 20 EFFETTI DI RETROILLUMINAZIONE
● CHERRY MX SWITCH MECCANICI
● N-KEY ROLLOVER IN MODALITA' USB
● 1000Hz POLLING RATE / 1MS RESPONSE TIME
ITALIANO
●
MÁGNESES PROTEKTOR FEDÉL
●
LEVEHET KÁBELŐ
●
20 PROGRAMOZOTT FÉNYHATÁS
●
CHERRY MX MECHANIKUS KAPCSOLÓK
●
N-KARAKTERES PUFFER USB ÜZEMMÓDBAN
(N-KEY ROLLOVER)
●
1000Hz-ES MINTAVÉTELEZÉS / 1MS-OS VÁLASZIDŐ
HUNGARIAN
● OS ONA OCHRONNA Ł
● OD CZANY KABEL ŁĄ
● 20 EFEKTÓW POD WIETLENIAŚ
● MECHANICZNE PRZE CZNIKI CHERRY MXŁĄ
● N-KEY ROLLOVER W TRYBIE USB
● RAPORTOWANIE 1000Hz / CZAS REAKCJI 1MS
POLISH
● ÌÀÃÍÈÒÍÛÅÇÀÙÈÒÍÀß ÊÐÛØÊÀ
● ÑÚÅÌÍÛÉ ÊÀÁÅËÜ
● 20 ÝÔÔÅÊÒ ÏÎÄÑÂÅÒÊÈ
● ÌÅÕÀÍÈ×ÅÑÊÈÅ ÊËÀÂÈØÈ CHERRY MX
● N-KEY ROLLOVER
● 1000 Hz POLLING RATE / 1MS RESPONSE TIME
DEUTSCH
● SCHÜTZENDE ABDECKUNG MIT MAGNETHALTER
● ABNNEHMBARES KABEL
● 20 BELEUCHTUNGS-EFFEKTE
● CHERRY MECHANISCHE SWITCHES
● N-KEY ROLLOVER IM USB-BETRIEB
● RUTSCHFESTE GUMMI-FÜSSE
●
When the speed reaches its maximum or minimum,
the CAPS Lock, Scroll Lock and
Windows Key lock will start blinking.
●
N-KEY ROLLOVER IN USB MODE
N-KEY directly in USB mode, without need for a USB
to PS/2 adapter.
Unlimited simultaneous key presses.
●
FUNCTION KEY SHORTCUTS
FN key combos allow you to quickly access multimedia
functions and lock the WIN & application key.
●
1000 Hz POLLING RATE / 1 ms RESPONSE TIME
●
DEDICATED MULTIMEDIA FUNCTION KEYS
●
3-STEP HEIGHT AND ANGLE ADJUSTMENT
●
CABLE MANAGEMENT SYSTEM
●
BRAIDED CABLE & GOLDEN-PLATED CONNECTOR
●
WINDOWS & APPLICATION KEY LOCK
Avoid kicking yourself out of games by locking the
Windows key in-game with an easy shortcut.
●
DRIVER-FREE
Plug and Play. No need to bother installing or
configuring anything, no driver conflicts, no updates.
Just you and the game.
Brightness
adjustment
There are 10 custom lighting effects in total.
Step 1 : Press the Fn key + 1~0
Step 2 : Press the Fn key + END key
Step 3 : Press the key you want to light up.
Then, you can continue to set other keys.
When you finish all settings, press the Fn key + END key again to store it.
Brightness
adjustment
Press the Fn key + INS key to change
different backlight effects.
Press the Fn key + HOME key to change
different backlight effects.
Press the Fn key + PgUp key to change
different backlight effects.
Press the Fn key + DEL key to change
different backlight effects.
Press the Fn key + PgDn key to change
different backlight effects.
Brightness
adjustment
Backlight
effects direction
Backlight
effects speed
Brightness
adjustment
Backlight
effects direction
Backlight
effects speed
Brightness
adjustment
Backlight
effects direction
Backlight
effects speed
Brightness
adjustment
Backlight
effects direction
Backlight
effects speed
Brightness
adjustment
Backlight
effects direction
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
Brightness
adjustment
Backlight
effects speed
DISCLAIMERS
●
COUGAR product is not authorized for use as critical components in life support device or for incorrect application
software or malfunction of the product.
●
COUGAR is not liable for the death or damage of person or loss of property when product is using as, including but not
limited to, medical equipment, military equipment, traffic equipment and disaster prevention system.
●
COUGAR's warranty liability is limited to repair, replacement.
●
COUGAR is not liable for any damages, expenses, lost data, lost revenues, lost savings, lost profits, or any incidental
or consequential damages due to using defect product of COUGAR.
If you have any question about the warranty, please feel free to contact us.
Customer support: service@cougargaming.com
WARRANTY AGREEMENT
●
If the product has defects in material or manufacture, COUGAR will provide product repair and replacement service
within the warranty period.
●
Our warranty service is based on the date of the invoice or warranty card (must be affixed with the store stamp).
If you lose the aforementioned evidence, we will apply the original shipping date of the product as the beginning date
of warranty period. The shipping date will be identified by the product serial number(S/N).
CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED
●
Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc).
●
Any fault or damage caused by accidental factors and man-made reasons (including hit, scrape, crash, moving,
compression, stain, corrosion, use of incurred on unsuitable voltage, computer virus, riot, misuse, malicious damage, etc).
●
Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).
●
Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still within the
warranty period and the shipping date of the product is out of warranty.
●
The warranty card or product serial number has been altered or its number is hard to identify.
●
The warranty period has expired.
●
Any fault or damage caused by non-compliance with regulations stated on the user manual or improper, rough and
careless treatment.
●
Any fault or damage caused by use of parts not certified by COUGAR original manufacturer.
●
The problem is caused by improper repair or adjustment by the buyer or any manufacturer without authorization
from COUGAR.
●
The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.
●
Paper carton, instruction and other accessories are not warranted.
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR PURI TKL gaming keyboard
Warranty : 1 Year
This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.
This manual was created by Compucase Enterprise and may not be completely or partially copied, passed on, distributed
or stored without written consent by Compucase Enterprise.
COUGAR® is a registered brand of Compucase Enterprise Other product and company names mentioned in this
documentation may be brands or trademarks of their respective owners.
Compucase Enterprise reserves the right to make changes concerning the contents of the manual and the technical data
of the product without previous announcement.
Al l ot h er r eg is t er ed trad e marks b e lo ng
to th e ir re spe ct iv e c ompa n ie s.
MSIP-REI-CEE-
COUGAR PURI TKL
D63088
RoHS
Compucase Enterprise Co.,Ltd.
All rights reserved.More information you will find at cougargaming.com Made in China
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год, последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
● Например, AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
1 3 4 5 6 8 9 02 7
A
B
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail:service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/

Termékspecifikációk

Márka: Cougar
Kategória: billentyűzet
Modell: Puri TKL

Szüksége van segítségre?

Ha segítségre van szüksége Cougar Puri TKL, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek


Útmutatók billentyűzet Cougar

Cougar

Cougar Vantar MX Útmutató

30 Augusztus 2024
Cougar

Cougar Attack X3 RGB Speedy Útmutató

19 Augusztus 2024
Cougar

Cougar Puri TKL Útmutató

19 Augusztus 2024
Cougar

Cougar 500K Útmutató

18 Augusztus 2024
Cougar

Cougar Core EX Útmutató

18 Augusztus 2024
Cougar

Cougar Puri Útmutató

18 Augusztus 2024
Cougar

Cougar 700K EVO Útmutató

18 Augusztus 2024
Cougar

Cougar Core Útmutató

18 Augusztus 2024
Cougar

Cougar 700K Útmutató

18 Augusztus 2024
Cougar

Cougar Ultimus RGB Útmutató

18 Augusztus 2024

Útmutatók billentyűzet

Legújabb útmutatók billentyűzet

Trust

Trust Callaz GXT 834 Útmutató

30 Március 2025
Krom

Krom Kunai Útmutató

30 Március 2025
Savio

Savio Blackout X2 Útmutató

30 Március 2025
Evga

Evga Z10 Útmutató

30 Március 2025
X9 Performance

X9 Performance X9WWKEYHUB Útmutató

30 Március 2025
Trust

Trust Acira GXT 867 Útmutató

30 Március 2025
Trust

Trust Ody II 25011 Útmutató

30 Március 2025
Erica Synths

Erica Synths Bullfrog XL Útmutató

30 Március 2025
Tiptop Audio

Tiptop Audio 257t Útmutató

30 Március 2025
Tiptop Audio

Tiptop Audio 245t Útmutató

30 Március 2025
