Warranty:
Specifications:
GPM-X2 Series
Brick Battery Charger
INSTRUCTION MANUAL
Core SWX Tel ( ) : 516 575 - 7488
91B Commercial st Fax: (516) 595 - 7492
Plainview, NY 11803 www.coreswx.com
GPM-X2 Series, 2-Channel Simultaneous Charger
SWX
Providing the power to create.
Quick Charge Current: 1.5A Simultaneous
Size: 4.5” x 5.5” x 3”
Weight: 1.0 lbs.
Input Voltage: 90-240VAC 50/60Hz
This product is warranted to the Original Purchaser against all defects in material and or workmanship
for the period herein.
The warranty period shall be, 3 years for parts and labor, unless otherwise noted. Core SWX agrees to
pay equal return freight costs to return the product the same method it was received. In the event of an
issue, purchaser agrees to the below RMA procedure.
Procedure:
1. Go to http://www.coreswx.com/repairsreturns and ll out the online form
2. Print the RMA number conrmation, and ship the product needing service to Core SWX, LLC.
along with RMA number conrmation, and copy of bill of sale.
3. All shipments must be done either through UPS or FEDEX, and insured if necessary
4. Core SWX, LLC. is not responsible for any lost shipments.
Core SWX reserves the right to repair or replace any defective product under warranty after Core SWX
determines which is more practical.
If Core SWX receives defective product for warranty repair and they are found to be defective as a result
of misuse or other damage, not caused by normal wear and tear, Core SWX will notify the customer of an
estimate of repair. Customer will incur costs. There are no further warranties, either expressed or implied,
including warranties of merchantability or tness for a particular purpose that has any bearing upon this
transaction.
Thank you for your choice in purchasing a Core SWX style battery Notes On Use:
charger. The charger is designed to improve and assist you in your
battery charging requirements.
Please read this manual to help you understand and capitalize on the
features of this charger.
Features:
• Rugged, sleekly styled, compact charger chassis.
• Automatic Universal AC input for world-wide use.
• Automatic detection of damaged or misused batteries for
added safety.
Charging Operation:
• Insert the AC power cord into the AC receptacle in the back of
the charger.
• Connect all batteries needing charge into the charger.
• Turn the rear panel power switch to the ON position. At this
time the switch will light and the LED lights on the front panel
of the charger will blink green when charging.
• If the battery does not meet quick charging conditions(i.e.
temperature or deeply discharged) the charger will precharge
the battery and go into a trickle charge mode until it is safe to
enter quick charge mode.
• The LED corresponding with the charging bay will turn solid
green when the battery is fully charged.
• While operating the charger do not place anything on the
charger or block the ventilation slots.
• An increase in temperature is normal during charging.
• Make sure to firmly connect batteries to the charger mounts
and that the contacts are clean.
• The product must be earthed.
• Do not attempt to disassemble the charger, please contact
CoreSWX for any service issues.
• The fuse within the AC receptacle can be replaced only with
one of the same type and rating. (A spare fuse is included for
your convenience)
• Do not operate this device near equipment susceptible to
noise(i.e. TV).
When charging two packs, the charger will charge simultaneously
a
approximately 4hours.
t 1.5A per hour charge rate. 98wh packs will charge in
• This charge is designed for Li-Ion packs solely.
Compatibility outside of Core SWX battery packs
• For V-mount, this charger will charge most V-mount, Lithium
Ion packs on the market.
• For 3-Stud, this charger will only charge Core SWX packs.
