WARNING
• Read and understand product
labels and all instructions in
this manual and in your vehicle
owner’s manual before installing
or using this car seat.
• Failure to properly install or
use this car seat or follow these
warnings and those on this car
seat’s labels can result in serious
injury or death to the child
in a sharp turn, sudden stop
or crash.
C01-0602-E1-CA January 2017
Foonf 2017 Instruction Manual
This car seat is designed for use either Rear-Facing or Forward-Facing by children who meet
all of the following requirements:
HEIGHT WEIGHT AGE
64 – 110 cm
25 – 43 in.
6.4 – 18 kg
14 – 40 lb
Able to sit
upright alone
HEIGHT WEIGHT AGE
76 – 124 cm
30 – 49 in.
10 – 29.5 kg
22 – 65 lb
2+ years
recommended
(1 year min)
FO17CA
i
Checklist for Proper Use
IMPORTANT: This is only a checklist — you Must read and understand all of the warnings and
instructions on this car seat’s labels and in this manual before installing or using this car seat.
When Using This Car Seat in Rear-Facing Mode
√ Child weighs between 6.4 and 18 kg (14 and 40 lb), height is between 64 and 110 cm (25
and 43 in.) and able to sit upright alone.
√ Car seat is securely installed in a vehicle rear seat using Rear-Facing Base and Anti-
Rebound Bar.
– If car seat must be installed in a front seat, the front air bag for that position is
deactivated and the vehicle owner’s manual states that this is an acceptable position to
install a Rear-Facing child restraint.
√ UAS Belt or vehicle belt is correctly routed under Seat Cushion in the Rear-Facing belt path
and there is no slack in the UAS Belt or the vehicle belt.
√ Car seat is installed using a Rear-Facing recline position and reclined so that the Rear-
Facing Reference Line appropriate for the child’s weight is parallel to the ground.
√ The top of the child’s head is at least 2.5 cm (1 in.) below the top of the car seat Headrest.
√ Shoulder Harness Straps are through Shoulder Harness Slots closest to and at or below the
shoulder of the child.
√ Bottom of Headrest is at or above the Shoulder Harness Slots in use.
√ Crotch Strap is through the inner Crotch Strap Slot
√ Harness is snugly adjusted on child and buckled.
ii
When Using This Car Seat in Forward-Facing Mode
√ Child weighs between 10 and 29.5 kg (22 and 65 lb), height is between 76 and 124 cm
(30 and 49 in.) and is at least 1 year of age.
√ Car seat is securely installed in a vehicle rear seat without the Rear-Facing Base or the
Anti-Rebound Bar.
– If car seat must be installed in a front seat, the front air bag for that position is
deactivated, check the vehicle owner’s manual for proper use of a child restraint in
that position.
√ Car seat is correctly attached to the vehicle using either the Rigid UAS Connectors and
Top Tether; the vehicle belt and Top Tether; or the rigid UAS
Connectors, the vehicle belt and the Top Tether.
– If child weighs more than 21.8 kg (48 lb) or the weight
limit specified for UAS use in your vehicle owner’s
manual, this car seat must be installed with the vehicle
belt and Top Tether; or with the Rigid UAS Connectors,
vehicle belt, and Top Tether..
√ Car seat is in a Forward-Facing recline position.
√ The top of the child’s ears are at or below the top of the
car seat Headrest.
√ Shoulder Harness Straps must be through Shoulder Harness
Slots closest to and at or above shoulders of child.
√ Bottom of Headrest is at or above the Shoulder Harness
Slots in use.
√ Crotch Strap is through the outer Crotch Strap Slot and
adjusted to the longer length.
√ Harness is snugly adjusted on child and buckled.
For concerns related
to parts or the use and
maintenance of this
product, please contact
us at:
Clek Inc.
Attn: Customer Service
226 Lesmill Road
Toronto, ON
Canada
M3B 2T5
1-866-656-2462
www.clekinc.ca
