Oldal 1/2
LOCATION OF PARTS
AND CONTROLS
LITHIUM-ION BATTERY
WARNINGS
This device contains a non-removable
lithium-ion battery. The battery must be
recycled or disposed of properly.
Contact your local waste management
office for information on battery
recycling or disposal.
FCC INFORMATION
This equipment has been tested
and found to comply with the
limits for a Class B Digital Device,
pursuant to Part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used
in accordance with the instructions,
may cause harmful interference to
radio communications. However, there
is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
• Reorient or relocate the
receiving antenna.
• Increase the distance between
the equipment and receiver.
• Connect the equipment to an outlet
on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an
experienced radio/TV technician
for help.
This equipment complies with
Part 15 of the FCC Rules.
Operation is subject to the
following two conditions:
1. This equipment may not cause
harmful interference.
2. This equipment must accept any
interference received, including
interference that may cause
undesired operation.
Modifications not authorized by the
manufacturer may void the user’s
authority to operate this device.
1. Dust Cover
2. Charging LED indicator
3. Micro USB Port
4. Volume Down Button
5. Volume Up Button
6. Play/Pause Button
7. LEDs indicator
8. Micro USB Charging
Cable (not shown)
4 5
7
6
Aviator Mini Wireless
Speaker
BIG SOUND TO GO
1
Fold Fold Fold Fold
3.
The speaker will wait for a
connection in pairing mode for
30 minutes. If it does not pair with
a device, it will power off.
4. Once the speaker is in pairing
mode and your device is ready
to pair, select “Jet speaker”.
If prompted, use 0000 as a PIN
for the pairing code. Once the
speaker is selected, the LEDs
Indicator will flash slowly and
beeps will sound to confirm
pairing complete.
PAIRING YOUR DEVICE
1. Prepare your device to pair using
Bluetooth® technology, making sure
you are within 33 feet of the speaker.
Refer to your device’s owners
manual for details if necessary.
2. Press and hold the ' ' button until
the speaker power on enter auto-
pairing mode. The LEDs Indicator
light will flash quickly and the
speaker will sound beeps.
2
3
Fold Fold Fold
1. Play your audio device as you
normally would,
2. Volume may be adjusted on your
audio device or by a single press
the ' ' or ' ' buttons on the
speaker .
3. Press and hold the' ' or ' ' button
will advance to the next track or go
back to the previous track.
LISTENING TO YOUR
AUDIO DEVICE
SPECIFICATIONS
Power Supply: 5V, 500mA
Total Output: 3W
Range: Class 2, up to 33 ft (10 m)
Li-ion Rechargeable Battery: 300mAh
Speaker: 1.23 inch, 4 Ohm
Charging Time: Approx. 1 hours
Battery Life: Approx. 6 hours
Compatibility: Bluetooth® 2.0 or above
device with A2DP/AVRCP
The Bluetooth® word mark and logos
are registered trademarks owned of
Bluetooth SIG, Inc. and any use
of such marks by Brookstone is under
license.
CARE AND STORAGE
1. Store the speaker in its compact
form in a cool, dry place.
CHARGING THE SPEAKER
1. Connect the USB Cable
(included) to the Micro USB
Port on the speaker.
2. Plug the other end of the USB
Cable into a USB Port on your
computer or USB wall adapter.
3. The charging LED Indicator will
illuminate red while charging,
and the light will change to blue
when the speaker is fully charged.
Charges in approximately 1 hours
for up to 6 hours of listening
enjoyment.
4. To pause audio, press the ' '
button on the speaker. To
resume audio playback press
the ' ' button again.
5. Press and hold the ' ' button to
power the speaker off .The speaker
will sound beeps and the LEDs will
go out.
897763; 897764; 897765
Merrimack, New Hampshire, USA 03054
800-846-3000 • Brookstone.com
