Oldal 1/24
6 720 888 207 (2018/10) DIV
Operating instructions
Kullanma kılavuzu
RDE1518407, RDE2124407
Table of Contents
6 720 888 207 (2018/10)
2
Table of Contents 1 Important safety information
This appliance is intended for domestic use and the
household environment only.
Please read these instructions carefully, then act
accordingly! Store for future reference. These
instructions must be included when transferring
this appliance to a new owner.
WARNING:
Risk of electric shock!
▶Switch off the mains voltage supply immediately
if a fault occurs. Immediately shut off the cold
water supply to the appliance should it leak.
These installation instructions are intended for
plumbers, heating engineers and electricians. All
instructions must be observed. Failure to comply with
instructions may result in material damage and
personal injury, including possible loss of life.
▶ Read the installation instructions (heat source,
heating controller, etc.).
▶ Observe the safety instructions and warnings.
▶ Observe national and regional regulations,
technical rules and guidelines.
• The installation and initial start-up must be
undertaken by a specialist who complies with the
enclosed installation instructions. The safety
information in the installation instructions must be
observed. We do not accept liability for damage
resulting from failure to heed these instructions and
the installation instructions.
• If the output temperature of the water leaving the
tap is higher than the set temperature, then this is
because the supply water temperature from the
domestic system is too hot, e. g. due to its being
heated by a solar energy unit.
• The mixer and the warm water pipe may be hot.
Please inform and instruct children appropriately.
• Do not use aggressive or abrasive cleaning
detergents!
• Do not use a steam cleaner.
• The appliance is only to be descaled by a suitably
qualified specialist.
• Repairs must only be carried out by an authorised
technician. Improper repairs can lead to risk of
serious injury to the user.
1 Important safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Getting to know your appliance. . . . . . . . . . . . . . . . . . . . 3
2.2 Operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.1 Switching the appliance on and off. . . . . . . . . . . . . . . . . 3
3.2 Setting the water temperature . . . . . . . . . . . . . . . . . . . . 3
3.3 Status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.4 Startup after power failure . . . . . . . . . . . . . . . . . . . . . . . 3
3.5 Using the appliance after switching
off the water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.6 Saving energy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.7 Winter operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6 Environmental protection/disposal. . . . . . . . . . . . . . . . . . . . . . 4
7 A fault, what to do? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7.1 Faults that the customer can troubleshoot himself . . . . . 5
7.2 Faults that the customer service
specialist should troubleshoot . . . . . . . . . . . . . . . . . . . . 5
7.3 Faults that are automatically remedied. . . . . . . . . . . . . . 5
8 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating instructions
3
6 720 888 207 (2018/10)
Safety of electrical devices for domestic use and
similar purposes
The following requirements apply in accordance with
EN 60335-2-35 in order to prevent hazards from
occurring when using electrical appliances:
“This appliance can be used by children of 3 years and
older, as well as by people with reduced physical,
sensory or mental capabilities or lacking in experience
and knowledge, if they are supervised and have been
given instruction in the safe use of the appliance and
understand the resulting dangers. Children shall not
play with the appliance. Cleaning and user
maintenance must not be performed by children
without supervision.”
“If the power cable is damaged, it must be replaced by
the manufacturer, its customer service department or
a similarly qualified person, so that risks are avoided.”
Congratulations on purchasing this BOSCH appliance.
You have acquired a top-quality product, which will
give you a lot of enjoyment.
2 Operating instructions
2.1 Getting to know your appliance
This appliance is an electronically-regulated, pressurized continuous-
flow heater for decentrally supplying hot water.
The electronic continuous-flow heater heats the water as it flows through
the appliance. One or more taps can be supplied with warm water.
2.2 Operating elements
1Rotary selector switch
2Status display
3 Operating the appliance
3.1 Switching the appliance on and off
The continuous-flow heater switches on and heats the water when the
warm water tap is opened. It switches off again if the water tap is closed.
3.2 Setting the water temperature
• Turn the rotary selector switch.
Use the continuously-variable switch to set the desired temperature for.
Note: If a thermostatic-regulating mixer tap is used for high
temperatures or for large water volumes, then it is recommended
that the setting “Bathing” or “Rinsing” be selected.
Increasing the water temperature
If a higher temperature is not obtained when the warm water tap is fully
opened, then this is because more water is flowing than the continuous-
flow heater’s power capacity can heat.
• If this happens, then slightly close the warm water tap.
Decreasing the water temperature
• Turn the rotary selector switch to a lower level e. g. “Washing hands” .
Note: If the temperature of the water supplying the appliance changes,
then the output temperature of the water leaving the tap also changes
correspondingly.
3.3 Status display
3.4 Startup after power failure
• Open the warm water tap fully and allow water to flow until it is warm.
3.5 Using the appliance after switching
off the water supply
• Switch off the appliance (unscrew the fuse in the fusebox).
• Open the warm water tap and keep it open until the air has
been completely forced out of the water pipe.
• Switch the fuse back on again.
• Open the warm water tap fully and allow water to flow for at least
one minute.
Only then (for safety reasons) will the appliance begin to heat.
The appliance is now ready to operate.
3.6 Saving energy
• Set the desired water temperature directly on the appliance.
The appliance is operated economically when set to approximately
40 °C (rotary selector switch: “Showering” ).
Washing hands Showering
Bathing Rinsing
LED Appliance status
Off Off
Lights green On
Flashes green (1/s) The set temperature is not obtained; the rate
of water flow is too high for appliance rating
(the appliance has reached the power limit).
See “ A fault, what to do?”
Flashes green (2/s) Cold-water rinse-through phase
Flashes red See “ A fault, what to do?”
