FCC Informaon and Copyright
This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon
against harmful interference in a residenal installaon. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons. There is no guarantee that interference
will not occur in a parcular installaon.
The vendor makes no representaons or warranes with respect to the contents here and
specially disclaims any implied warranes of merchantability or tness for any purpose. Further
the vendor reserves the right to revise this publicaon and to make changes to the contents here
without obligaon to nofy any party beforehand.
Duplicaon of this publicaon, in part or in whole, is not allowed without rst obtaining the
vendor’s approval in wring.
The content of this user’s manual is subject to be changed without noce and we will not be
responsible for any mistakes found in this user’s manual. All the brand and product names are
trademarks of their respecve companies.
Dichiarazione di conformità sintetica
Ai sensi dell’art. 2 comma 3 del D.M. 275
del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specied
by the directives
2004/108/CE, 2006/95/CE and 1999/05/
CE
whenever these laws may be applied
The terms HDMI and HDMI High-Denion Mulmedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
2 | Table Of Contents
Table Of Contents
FCC Informaon and Copyright ������������������������������������������������������������������������������� 1
Chapter 1: Introducon ������������������������������������������������������������������������������������������� 3
1.1 Before You Start .................................................................................................................. 3
1.2 Package Checklist 3 ................................................................................................................
1.3 Specicaons ...................................................................................................................... 4
1.4 Rear Panel Connectors 5 ........................................................................................................
1.5 Motherboard Layout .......................................................................................................... 6
Chapter 2: Hardware installaon ����������������������������������������������������������������������������� 7
2.1 Install Central Processing Unit (CPU) .................................................................................. 7
2.2 Install a Heatsink 9 .................................................................................................................
2.3 Connect Cooling Fans 10 .......................................................................................................
2.4 Install System Memory ..................................................................................................... 11
2.5 Expansion Slots ................................................................................................................. 12
2.6 Jumper & Switch Seng ................................................................................................... 15
2.7 Headers & Connectors 16 ......................................................................................................
2.8 LEDs .................................................................................................................................. 20
Chapter 3: UEFI BIOS & Soware 21 ���������������������������������������������������������������������������
3.1 UEFI BIOS Setup ................................................................................................................ 21
3.2 BIOS Update ...................................................................................................................... 21
3.3 Soware ............................................................................................................................ 26
Chapter 4: Useful help 27�������������������������������������������������������������������������������������������
4.1 Driver Installaon ............................................................................................................. 27
4.2 AMI BIOS Beep Code......................................................................................................... 28
4.3 AMI BIOS post code .......................................................................................................... 28
4.4 Troubleshoong ................................................................................................................ 30
APPENDIX: Specicaons in Other Languages ������������������������������������������������������� 31
Arabic 31 ......................................................................................................................................
German 32 ...................................................................................................................................
Spanish ................................................................................................................................... 33
Thai 34 ........................................................................................................................................
Japan 35 .......................................................................................................................................
Chapter 1: Introducon | 3
B760MX-E | B760MX2-E |
Chapter 1: Introducon
1�1 Before You Start
Thank you for choosing our product. Before you start installing the motherboard, please make
sure you follow the instrucons below:
•  Prepare a dry and stable working environment with sucient lighng.
•  Always disconnect the computer from power outlet before operaon.
•  Before you take the motherboard out from an-stac bag, ground yourself properly
by touching any safely grounded appliance, or use grounded wrist strap to remove the
stac charge.
•  Avoid touching the components on motherboard or the rear side of the board unless
necessary. Hold the board on the edge, do not try to bend or ex the board.
•  Do not leave any unfastened small parts inside the case aer installaon. Loose parts
will cause short circuits which may damage the equipment.
•  Keep the computer from dangerous area, such as heat source, humid air and water.
•  The operang temperatures of the computer should be 0 to 45 degrees Celsius.
•  To avoid injury, be careful of:
Sharp pins on headers and connectors
Rough edges and sharp corners on the chassis
Damage to wires that could cause a short circuit
1.2 Package Checklist
•  Serial ATA Cable x2
•  Rear I/O Panel for ATX Case p3-x1
•  WIFI antenna accessories x1
•  Quick Installaon Guide x1
•  Fully Setup Driver DVD x1
•  M.2 Anchor x1
Note
» 
»The package contents may be dierent due to the sales region or models in which it was sold. For 
more informaon about the standard package in your region, please contact your dealer or sales 
representave.
