Használati útmutató B-tech BT9925

B-tech nincs kategorizálva BT9925

Olvassa el alább 📖 a magyar nyelvű használati útmutatót B-tech BT9925 (1 oldal) a nincs kategorizálva kategóriában. Ezt az útmutatót 7 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF

Oldal 1/1

1500mm

59.06in

600mm

23.62in

1200mm

47.24in

1000mm

39.37in

182mm

7.17in

164.9mm

6.49in

8.2mm

0.32in

164.9mm

6.49in

82mm

3.23in

10.4mm

0.41in

705mm

27.76in

(Including End Cap)

Closed

113.8mm - 128.8mm

4.48in - 5.07in

(Tolerance +/- 1mm)

62mm

2.44in

6mm

0.24in

51.5mm

2.03in

Open

266.8mm - 281.8mm

10.5in - 11.1in

(Tolerance +/- 1mm)

1 0.5

406mm

15.98in

500mm

19.69in

100mm

3.94in

500mm

19.69in

406mm

15.98in

8.5mm

0.33in

300mm

11.81in

300mm

11.81in

600mm

23.62in

8.5mm

0.33in

ISOMETRIC VIEW

B-Tech International Design & Manufacturing Limited

Soft-Open Full Service Portrait Wall Mount for XXL Displays

BT9925

R00

B-Tech No:

Title:

Revision:

The information contained in this drawing is the sole property of B-Tech International Design and Manufacturing Limited, any reproduction in part or whole without the written permission of B-Tech International Design and Manufacturing Limited is prohibited.

Sheet:

1 of 1

File Name: BTD-BT9925

Date:

03/07/2023

1:10

Scale:

Size:

Part of the B-Tech International Group

UNLESS

OTHERWISE

SPECIFIED

DIMENSIONS ARE

IN MILLIMETERS

B-Tech International Design and Manufacturing Limited makes no representation or warranties, express or implied, with respect to the reuse of the data provided herewith,

regardless of its format or the means of its transmission. B-Tech International Design and Manufacturing Limited makes every effort to provide accurate information, however

there is no guarantee or representation to the user as to the accuracy, currency, suitability or reliability of this data. The user assumes all risks associated with its use. B-Tech

International Design and Manufacturing Limited assumes no responsibility for actual or consequential damage incurred as a result of any user's reliance on this data.
