8.1 CHANNEL CLASS-D
CAR AMPLIFIER
SMART DSP
Installation & Operation Manual / Einbau- & Bedienungsanleitung
A894DSP
– 2 –
SAFETY INSTRUCTIONS
·Keep the product away from children before installation. The inner packaging of the product could pose
a hazard. E.g. due to small parts of the accessories that can be swallowed.
·Depending on their size, polybags inside the packaging must be kept away from small children due to
the possible risk of suffocation.
·This product is designed exclusively for operation with an on-board voltage of 12 V direct current (DC).
If the product is operated with other on-board voltages, this may result in damage to the product or the
vehicle electrical system.
·Follow the manufacturer's instructions in the installation manual. Specific knowledge and tools are required
for installation. Improper installation can lead to damage to the vehicle and the infotainment system.
·Incorrectly installed car audio amplifiers pose a danger to the occupants, as they can come loose in the
event of an accident and injure people.
·Electrically incorrectly connected car audio components pose a short-circuit hazard with possible fire
consequences. Follow the wiring instructions in the installation manual carefully or have the product
installed by a specialist dealer.
·Proper functioning can only be guaranteed if you use the original accessories included in the scope
of delivery.
·The product and the original accessories must not be modified or altered in any way. Improper modifi-
cations can lead to damage to the vehicle and the product.
·Please note that this car audio amplifier generates heat or waste heat during operation and look for a
location for installation and mounting that ensures good ventilation of the product.
·Prolonged listening sessions at high to very high levels at short intervals can lead to permanent hearing loss.
·Road users must be able to hear traffic at all times while driving, e.g. to be able to recognize acoustic
warning signals such as horns or sirens from the police, ambulance, fire department and other emer-
gency services.
·The amplifier must not be opened and/or modified by unauthorized persons. The voltages and currents
inside the device can be life-threatening.
·Do not use the device in places where wireless devices are not permitted.
·AXTON cannot guarantee that accidents or damage will not occur due to improper use of the device.
Use this product with care and at your own risk.
Operating frequency / maximum transmission power
This is a product with an integrated Bluetooth module, class 2.
Bluetooth
Bluetooth standard: 5.0
Transmission frequency band: 2402 MHz ~ 2480 MHz
Bluetooth class: Class 2
Transmission power: 4 dBm / 2.5 mW
Information on radio frequency exposure
This device complies with EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the
general public to electromagnetic fields for the purposes of health protection.
– 4 –
Thank you for purchasing this innovative AXTON amplifier!
To maximize the performance of this amplifier and your complete car audio system installation,
we recommend you acquaint yourself thoroughly with all technical features and controlling op-
tions of this AXTON amplifier. Please read this manual carefully, before attempting the installation.
If, after reading this manual, you still have questions regarding functions or the installation of the
amplifier, we recommend you consult your dealer.
MOUNTING INSTRUCTIONS
1. Before you start with the installation, make sure you know the security code of your headunit
(if applicable).
2. Remove the headunit from the dashboard and disconnect the main wire harness.
3. Find a place for the A894DSP and connect the optionally available car-specific wire harness
to the amp.
4. Run a 16 mm2 power wire from the (+) pole of the battery to the (B+) terminal of the
amplifier. Use a fuse with a value of min. 30A and max. 50 A. The distance between the B+
pole and the fuse holder must be 30 cm or less. Run the minus cable with the same cross
section from the (GND) terminal of the amp to the vehicle chassis ground, but NOT to the
B-pole of the battery. Make sure that the chassis ground contact surface is clean in order to
get best conductance.
5. Optionally: For Hi-Res Sound from your smartphone: Connect the optical and coaxial cables
to the inputs of A894DSP and outputs of the AXTON ABT50. Connect your smartphone
via Bluetooth to the ABT50 for using APTX-HD standard or use the AXTON OTG cable for
absolutely lossless audio transmission: the signal is sent from your smartphone directly to the
amplifier without passing any D/A converter.
6. Optionally: Connect the remote control for convenient operation of the Master Volume, Bass
Extender and Mute function. Recommended when using A894DSP without any headunit.
7. Connect the wire to the headunit.
8. Install the headunit back in the dashboard.
Stand-alone installation
When you intend to use the A894DSP without any headunit, please connect the provided
cable and connect the wires according to the wiring diagram*. Switch (6)* is to be set to
“Remote turn on”.
*see page 6
