Audio-Technica Limited, Old Lane, Leeds LS11 8AG England
Audio-Technica SAS, 28 rue Godefroy-Cavaignac, 75011 Paris, France
Audio-Technica Niederlassung Deutschland, Stiftstrasse 18, D-65183 Wiesbaden, Germany
©2010 Audio-Technica, www.audio-technica.com
AT33EV
AT33EV
Elliptical 1/2 inch Standard Mount Cartridge
The original model of this stereo cartridge is the AT33ANV, which was available
as a special release to celebrate our 45th anniversary. The A33ANV was the
first in the AN33 series to feature a Duralumin cantilever, which received wide
acclaim for its sound quality.
Retaining the basic specification, we present a further improved and evolved
model.
The A33EV is a ½ inch, standard mount 0.3 x 0.7 mm elliptical cartridge
featuring a tapered Duralumin cantilever which reduces the effective mass of
the cartridge, resulting in a more durable cantilever. The Dual Moving Coil
cartridge design increases channel separation and extends the frequency
response range delivering extraordinary audio quality. Internally constructed
with a neodymium magnet enhances magnetic energy and PCOCC wire for
pure audio transmission.
Elliptical stylus chip and durable duralumin tapered pipe cantilever.
10Ωmid impedance specifications.
Dramatically increased magnetism with neodymium magnets and PCOCC as
the coil.
High separation, wide-response dual moving coil.
VC Mold eliminates unnecessary vibrations.
“Hanenite” anti-vibration rubber eliminates unwanted vibrations.
RRP ex VAT 499,00
RRP inc. VAT £529.00
Ean code: T4961310103972
Specifications*:
Type: MC-type
Playback frequency range: 15-50,000Hz
Output voltage: 0.3mV (1kHz and 3.54cm/sec.)
Channel separation: 30dB (1kHz)
Output balance: 0.5dB (1kHz)
Stylus pressure: 1.8-2.2g (2.0g standard)
Coil impedance: 10 Ω(1kHz)
DC resistance: 10 Ω
Load resistance: More than 100 Ω(when head amp connected)
Coil inductance: 22µH (1kHz)
Static compliance: 40×10-6cm/dyne
Dynamic compliance: 10×10-6cm/dyne (100Hz)
Stylus needle shape: oval (0.3×0.7mil)
Cantilever: Duralumin tapered pipe
Vertical tracking angle: 23°
Dimensions: H16×W16.D26.5mm
Weight: 6.9g
Accessories: Non-magnetic screwdriver × 1, Washer × 2, Protector × 1,
Cartridge installation screws 13 mm × 2 and 19 mm × 2,
Nut × 2, Brush × 1, PCOCC lead set × 1
* Specifications are subject to change without notice.
PCOCC = Pure Copper by Ohno Continuous Casting process
