Usage of DIY Stickers: Tear apart the film. Apply the patterned side to the
desired position and use wet tissues or a piece of damp cloth to gently tap the
sticker. 5 to 10 seconds later, peel up one corner of the sticker to see if the
pattern has been printed. If so, rip the whole piece of the sticker.
ACCESSORIES
DRONE applies 2.4G remote control system to allow for multiple players
compete without interference and functions such as forward and backward,
left and right, left sideward and right sideward, left rotation and right rotation,
and 360 degree flips and rolls etc.
3
2
Protective Guard
Upper Casing
Lower Casing
Propeller
Motor
Bottom Base
1
6
5
4
1
23
4
5
6
KNOW YOUR
DRONE
1.Propeller Installation
A corresponds to A
B corresponds to B
B
BA
A
Front
②Depress the propellers
until fixed.
①Align the propellers to
the motor shaft with the
propellers and the shaft
aligned correctly.
Notes:
When installing or dismantling the propeller, please do not force on the
propeller to avoid distortion.
2.Propeller Replacement
Please replace with new propellers once the
propellers are damaged due to crashes or
collisions. Each propeller is marked with A or B.
When installing, make sure that A corresponds
to A and B to B, otherwise the drone cannot
perform functions such as takeoff, rotation or
throw-to-fly.
ACCESSORY ASSEMBLY
3.Prop Guard Installation
When installing or dismantling the propeller, please do not force on the
propeller to avoid distortion.
Propellers vary from one to another！
Notes:
①Use scissors to pry the
propellers that needs to
be replaced.
②Install the propellers in
order of A to A and B to
B. Hold the propellers,
align to the crankshaft
and depress until fixed.
B A
①Align the protective
guard to the three holes.
②Depress the protective
guard until fixed.
A.Remove the battery from
the bottom of the drone.
B.Connect USB charger with
the battery. (Do not charge
the battery until the water
stains on it have been
vaporized.)
4.Battery Charging for Drone
Notes：
The LED light turns on during charging and turns off when the charging
completes. It takes about 65 minutes to fully charge and gives about 5-6
minutes of running time when fully charged.
!BATTERY INSTRUCTIONS
There is a certain risk when using battery. It may cause fire, body injury or
property loss. Users must be aware of the risks and take full responsibility of
using battery improperly.
If battery leakage occurs, please avoid contacting your eyes or skin with
electrolyte. Once it happens, please wash your eyes with clean water and
seek medical care immediately.
Please remove the plug immediately if you sense any peculiar smell, noise
or smog.
Battery Charging
Please use the original charger to ensure safe use.
Do not charge dilatant or outworn battery.
Do not over charge battery. Please unplug the charger once fully charged.
Do not charge the battery next to inflammables, such as carpet, timber floor
or wood furniture or on the surface of electro-conductive objects. Please
always keep an eye on the battery when charging.
Do not charge battery which not cool down yet.
The charging temperature should be between 0 to 40 .℃ ℃
Battery Recycling
Do not dispose the battery as daily rubbish. Please familiarize yourself with
the local garbage disposal method and dispose it according to the special
requirement.
The flight mode will be turned on by default at startup. The light turns red on
flight mode, turns green when you switch it to ground mode and turns blue
when you switch it to water mode.
Notes:
2
3
4
5
1
7
8
9
10
6
Speed Mode
Indicator Light
Throttle Joystick
Flight Mode/Ground
Mode/Water Mode
Short Press for Headless
Mode/Long Press for
Return to Home
Flips and Rolls (This
Button Works as
One-key Rotation
on Ground Mode)
Forward/Backward
Fine-tuning
Rudder Joystick
Left/Right Sideward
Fine-tuning
Power Switch
1.Protective Guard the Parts Name of the Remote Control
KNOW YOUR REMOTE CONTROL
4
5
6
7
8
9
10
1
2
3
②Assemble the Battery
Open the battery compartment cover, insert two AA batteries (not included) with
the two poles aligned correctly.
1.5V AA“ ”
1.5V AA“ ”
Open the battery compartment cover with a philips screwdriver.
2.Remote Control Battery Installation
①Open the Remote Control Battery Cover
Notes：
1. Ensure the polarity symbols on the batteries match the symbols inside the
battery compartment.
2. Do not mix new and old batteries.
3. Do not mix different types of batteries.
PRE-FLIGHT PREPARATION
1.Flight Environment
Please keep the drone in sight during the flight and keep it away from barriers,
high-tension cables, trees and crowds.
Do not fly in extreme environment, such as hotness, coldness, strong wind or
heavy rain.
Indoor: Spacious spaces away from barriers, crowds or pets are preferred.
Outdoor: Sunny, windless and breezy weathers are preferred.
3.Pairing Remote Control with Drone
①Turn on the power of the drone; put the drone on
plain ground; check whether the indicator lights of
remote control and LED lights of drone flash.
②Push the throttle joystick to the top and then pull
back to the bottom. After the sounds of beep, the
flash of indicator lights of remote control and LED
lights of drone will turn to constant lights, which
means the pairing completes.
Please Check the Followings Before Flying:
①If the drone and the remote controller are fully charged.
②If the propellers have been correctly installed and in good condition.
③If the propellers work well after startup.
④If the surrounding conditions are ideal for a safe flight.
2.Pre-flight Inspection Left Joystick
4.Calibration
If the drone fails to ascend vertically, please
proceed to the calibration process. Toggle the
throttle joystick and the rudder stick towards
toe-out at the same time. When the drone’s
indicator light turns from quick blinking to solid
light, the process of calibration completes.
Please calibrate the drone on a level surface
as to ensure the calibration can be successful.
FLY WITH REMOTE CONTROL
1.Flying
The left joystick is used to control flying height and left and right turning, while
the right joystick is used to control forward, backward and sideward flights.
Right Joystick
Ascend
Descend
Turn Left
Turn Right
Forward
Backward
Left
Sideward
Right
Sideward
①Forward Fine-tuning
②Backward Fine-tuning
③Left Sideward Fine-tuning
④Right Sideward Fine-tuning
①
③
②
④
2.Fine-tuning
Gradually push the throttle joystick to make
the drone ascend. Fine-tune the direction
when the drone rolls or yaws.
1
2
3
4
If you want to control the speed of the
drone, press the Speed Mode button “ ”
to control it to fly at the speed of 30%,
60% and 100% out of the full speed.
3.Speed Mode
Speed
Mode
Put the drone with its front being your
front. Pair the drone with the remote
controller before its takeoff. Then short
press the Headless Mode button to “ ”
let it enter the headless mode. To exit,
press the Headless Mode button again.“ ”
4.Headless Mode
Headless Mode
Long press the One-key Return button to return the drone automatically. After “ ”
the drone has returned to home point, toggle the front joystick or press the
“ ”One-key Return button to exit the auto return mode. The drone’s light will then
turn solid.
5.One-key Return
Home Point
Finishing Point
One-key Return
Front Flips
and Rolls
Back Flips
and Rolls
Right Joystick
6.Flips and Rolls
Till the drone ascends to the altitude of 3 meters, press the button of flips and
rolls and move the right joystick to certain direction to finalize flips and rolls.
7.Ground Mode/Water Mode
Rotate the accessory part (close to the projections on the tail) on the drone’s
back as shown in figure , and install the drone onto the bottom base as ①
shown in figure . It has been completely set up and ready for takeoff or ②
cruising as shown in figure . (Please wipe off the drone with a piece of dry ③
cloth after water mode.)
② ③①
Doll
Place a doll (not included)
on the brick.
8.Separation of the Drone and the Bottom Base
Put your hands at the tail of the drone and push it forward to
take it apart from the bottom base.
FAQ
PROBLEMS CAUSES SOLUTIONS
Control
failure
Not connect with the drone battery.
Too strong wind force.
Connect the drone battery in
right way.
Fail to
ascend
The wind can affect the drone’s
flight. Therefore, do not fly it in
strong wind conditions.
The rotation speed of main blades
is too slow.
The battery of the drone is not fully
charged.
Push up the throttle joystick.
Please fully charge the battery.
Landing
too soon
The throttle joystick is pulled down
too fast.
Pull down the throttle joystick
slowly to perform a smooth
landing.
Out of
control Beyond the effective controlling
distance.
Ensure that the flying distance
is within 20 meters.
Motor
cannot
rotate
Dust or other objects has been
gathered on the motor.
Clean the dust or remove
other objects on or around
the motor.
Bottom Base x1 Propeller x4
DRONE
x1
(Battery Included)
Remote Control x1
USB Charger x1 User Manual x1Phillips
Screwdriver x1
AGE 14+
VIHICLE X DRONE X HOVERCRAFT 3 IN 1
DRONE
*Please read this manual carefully before operation and keep it properly for
future reference.
3IN1 RC MODEL
Item No.: 25307 / 25308
INSTRUCTION MANUAL
Amewi Trade e.K.
Nikolaus-Otto-Str. 18
D-33178 Borchen
MAXIMUM TRANSMITTING POWER
Operation frequency: 2.405 ~ 2.476 MHz
Maximum Radio frequency power: maximum peak power: 2 dBm
8+
Termékspecifikációk
| Márka: | Amewi |
| Kategória: | drón |
| Modell: | Trix 25307 |
Szüksége van segítségre?
Ha segítségre van szüksége Amewi Trix 25307, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók drón Amewi
27 Augusztus 2024
27 Augusztus 2024
27 Augusztus 2024
Útmutatók drón
- drón Carrera
- drón Xiaomi
- drón Prixton
- drón Reely
- drón Hama
- drón GPX
- drón Parrot
- drón Carson
- drón Dahua Technology
- drón Denver
- drón DJI
- drón Autel
- drón Revell
- drón Syma
- drón Overmax
- drón Kogan
- drón Manta
- drón Blaupunkt
- drón Hubsan
- drón SereneLife
- drón Joby
- drón Hobbywing
- drón Swann
- drón DF-Models
- drón Emax
- drón AEE
- drón Brigmton
- drón Steren
- drón Blade
- drón Ninco
- drón FIMI
- drón Yuneec
- drón Kaiser Baas
- drón Robbe
- drón Odyssey
- drón XTIM
- drón Jamara
- drón LUXWALLET
- drón WLtoys
- drón Dromida
- drón Quadrone
- drón UGo
- drón Zero-X
- drón Estes
- drón Air Wars
- drón Zero Zero Robotics
- drón CHASING
- drón EHang
- drón Ryze
- drón SwellPro
- drón 3DR
- drón Extreme Fliers
- drón Snaptain
- drón Hobby Zone
- drón PowerVision
- drón Holy Stone
- drón Sky Rider
- drón SkyRider
Legújabb útmutatók drón
11 December 2024
7 Október 2024
2 Október 2024
28 Szeptember 2024
26 Szeptember 2024
24 Szeptember 2024
20 Szeptember 2024
18 Szeptember 2024
17 Szeptember 2024
17 Szeptember 2024
