Használati útmutató Alogic P10QC10P18

Alogic power bank P10QC10P18

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Alogic P10QC10P18 (2 oldal) a power bank kategóriában. Ezt az útmutatót 3 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/2
Model: P10QC10P18-BK, P10QC10P18-WH
Battery Type: Lithium-Polymer
Capacity: 10,000mAh
Input: USB-C
Output 1: USB-C: Up to 15W (Power Delivery)
Output 2: USB-A: Up to 12W (Fast Charge)
Output 3: 10W (Wireless Charging)
LED: Wireless Charging Indicator
LCD: Numerical Battery Charge Indicator Display
Output Voltage Selection: Automatic
Dimension HxWxL(mm): 145 x 70 x 45
USB-C 10,000mAh Power Bank
Ultimate with Fast Charging
User Manual
Packaging Includes:
Power On: Red and blue LED light flashes
for three times
Charging: Breathing blue LED lights
Standby: Solid blue LED light
Fully charged phone: Slow breathing blue LED light
Foreign object detected: Flashing red LED light
LED Light Meaning:
Quick Start Guide
Numerical
LED Display
LED Indicator
Output 3
Power Button
Input
Output 1
Output 2
How to Use
Charging the Power Bank
1) Before using the ALOGIC 10,000mAh USB-C Power Bank Ultimate for the first time, fully charge the
device by using a USB-C cable and a compatible wall charger (Wall charger not included)
The LCD display will flash and show the battery capacity to indicate charging.
Charging Wirelessly
Understanding LED lights
2) Activate the power bank’s wireless charging by
pressing the power button twice. The wireless LED
indicator will flash blue and red three times to
indicate that the wireless charger is on.
3) Place you Qi-enabled device on the printed Qi logo.
Ensure that the centre of your device is aligned with
the logo.
Standby: Solid blue LED light
Charging: Breathing blue LED light
Fully Charged Phone: Slow breathing, blue LED light
Foreign Object Detected: Flashing red LED light
Charging via cable
4) Connect an existing USB-A cable between your
device and the power bank’s USB-A output. Press
the power button, the LCD display will turn on to
indicate that your device is successfully being
charged.
5) Connect an existing USB-C cable between your
device and the power bank’s USB-C output. Press
the power button, the LCD display will turn on to
indicate that your device is successfully being
charged.
6) To check the battery status of the power banks,
press the power button.
Power Button

Termékspecifikációk

Márka: Alogic
Kategória: power bank
Modell: P10QC10P18
