ThermoLux heating mats are made of
water-proof and rot-proof materials, are
absolutely watertight, and can be used
without any danger in freshwater. They
oer maximum safety due to the built-in,
full-surface protective conductor. Always
remove the plug from the power socket
before cleaning the mat or working on
the aquarium, to prevent danger of
electric shocks.
The mats are connected by means of the
plug direct to the 230V power supply, and
at an ambient temperature of 20 °C, and
without a cover, reach a maximum surface
temperature of approx. 42 °C.
The heating of the mat depends however
on the undersurface, the ambient
temperature and the amount of substrate to
be heated (sand, mulch, water etc.) and
can take from several hours to days.
When used without temperature limitation,
take care to of theavoid overheating
ThermoLux heating mat, since the mat can
reach a temperature of over 100 °C if
placed between dry substrates!
Please note the following safety
instructions:
-Please note the specic usage
instructions on the mat, the packaging
and the following pages!
-Ensure that the cable does not
become trapped or disconnected.
-Do not use the mat any longer if it or
the cable are damaged!
24 month warranty for defects:
We oer our customers a guarantee of 24
months. The guarantee does not however
apply in cases where damage due to
overheating, or injury due to electric shock,
is caused by improper use of the
equipment by the customer (failure to
observe the safety and usage instructions,
improper use, use for other purposes,
continued use of damaged mats).
Use as a terrarium underlay
Note:
The mat must not be placed in the
terrarium, since animals may crawl under
it, or it may be damaged by animals with
sharp claws.
The mat must not be placed between two
layers of insulating material (e.g.
styropor, wood shavings, other substrate
material). This could lead to a build-up of
heat, and damage to the terrarium or
heating mat (see General Instructions)!
The mat should be placed under the
terrarium so as not to cover the whole of
the terrarium area, so that the reptiles are
also left with cooler areas. In order to avoid
heat loss, the ThermoLux heating mat
should be placed on a sheet of styropor.
To avoid damaging the terrarium base by
thermal and mechanical stresses, do not
place the terrarium directly on the mat.
Spacers (e.g. wooden slats) should be laid
along the whole length of the terrarium
base between the mat and the terrarium
base, leaving an distance of about 12 mm
between the mat and the terrarium. This
will ensure an even distribution of heat.
Check the temperature change at the
surface of the oor substrate using a
thermometer, and adjust the separating
distance to achieve the required
temperature. Ensure that the humidity is
sucient to prevent the animals suffering
from desiccation.
Use as an underlay for plants
Place the mat on a windowsill or direct in a
hydro-culture vessel or seeding tray. Water
regularly in order to avoid a build-up of heat
and the drying-out of the substrate (earth,
hydro-culture). The temperature of the soil
depends on the volume of the vessel/tray
and the surrounding temperature.
The ThermoLux Temperature Regulator
can be used for controlling the temperature.
The temperature will then automatically be
maintained within the required range. The
temperature regulation is only suciently
accurate within the damp substrate.
ThermoLux Temperature Regulator
(Accessory)
Only for use with damp materials (earth,
gravel, sand etc.) and water.
Control range 18 - 36 °C (tolerance: damp
substrate 3 °C, water: 0.3 °C), power 
supply/consumption 230V~ 400 W.
In combination with a plug rail, several
ThermoLux mats with a consumption of up
to 400 W can be controlled by one
temperature regulator.
Please note the instructions on the
packaging!
The following ThermoLux products are
available:
ThermoLux heating underlays
for animal and plant terraria
Dimensions Supply/consumption Art. No.
17.0 x 17.0 cm 230V~ 6 Watt 461265 + 461267
11.5 x 55.0 cm 230V~ 10 Watt 462265 + 462267
25.0 x 35.0 cm 230V~ 15 Watt 463265 + 463267
30.0 x 50.0 cm 230V~ 30 Watt 464265 + 464267
30.0 x 70.0 cm 230V~ 35 Watt 465265 + 465267
45.0 x 65.0 cm 230V~ 40 Watt 466265 + 466267
ThermoLux foot-warming mat
Dimensions Supply/consumption Art. No.
42.0 x 65.0 cm 230V~ 70 Watt 473291
Accessory:
ThermoLux Temperature regulator
Switching capacity Art.No.
230V~ 400 Watt 467061
Switching temperature, adjustable 18° - 36°C
Witte + Sutor GmbH
Steinberger Strasse 6 D-71540 Murrhardt
Tel.: +49(0)7192/9292-0 Fax: 9292-50
www.acculux.de * e-mail: info@acculux.de
ThermoLux
Heating Mats
Operating Instructions:
