Oldal 1/24

EnglishDeutschFrançaisEspañol

Português

ItalianoРусский

日本語

Owner’s Manual

Bedienungsanleitung

Mode d’emploi

Manual de instrucciones

Manual do Proprietário

Manuale di istruzioni

Руководство пользователя

取扱説明書

SPEAKER SYSTEM

XS3SB

XS3SW

CMA3SB

CMA3SW

SPEAKER ACCESSORY

⭞䈪᱄Ҝ

ѣᮽ

2VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

PLEASE READ CAREFULLY BEFORE

PROCEEDING

Please keep this manual in a safe place for

future reference.

WARNING

Always follow the basic precautions listed

below to avoid the possibility of serious

injury or even death from electrical shock,

short-circuiting, damages, fire or other

hazards. These precautions include, but are

not limited to, the following:

Do not open

• This device contains no user-serviceable

parts. Do not open the device or attempt

to disassemble the internal parts or modify

them in any way. If it should appear to be

malfunctioning, discontinue use immediately

and have it inspected by qualiﬁed Yamaha

service personnel.

Water warning

• Do not expose the device to rain, use it

near water or in damp or wet conditions.

If any liquid such as water seeps into the

device, turn off the power of the ampliﬁer

immediately. Then have the device inspected

by qualiﬁed Yamaha service personnel.

Hearing loss

• When turning on the AC power in your audio

system, always turn on the power ampliﬁer

LAST, to avoid hearing loss and speaker

damage. When turning the power off, the

power ampliﬁer should be turned off FIRST

for the same reason.

Fire warning

• Do not place any burning items or open

ﬂames near the device, since they may

cause a ﬁre.

If you notice any abnormality

• If any of the following problems occur,

immediately turn off the power of the

ampliﬁer.

- Unusual smells or smoke are emitted.

- Some object has been dropped into the

device.

- There is a sudden loss of sound during use

of the device.

- Cracks or other visible damage appear on

the device.

Then have the device inspected or repaired

by qualiﬁed Yamaha service personnel.

CAUTION

Always follow the basic precautions listed

below to avoid the possibility of physical

injury to you or others, or damage to the

device or other property. These precautions

include, but are not limited to, the following:

Location

• Do not place the device in an unstable

position where it might accidentally fall over

and cause injuries.

• Do not place the device in a location where it

PRECAUTIONS

may come into contact with corrosive gases

or salt air. Doing so may result in malfunction.

• Avoid being near the device during a

disaster, such as an earthquake. Since the

device may fall and cause injury, stay away

from the device quickly and move to a safe

place.

• Before moving the device, remove all

connected cables.

• Be sure to contact a professional installer, if

the speaker installation requires construction

work, and make sure to observe the following

precautions.

- Choose mounting hardware and an

installation location that can support the

weight of the device.

- Avoid locations that are exposed to

constant vibration.

- Use the required tools to install the device.

- Inspect the device periodically.

Connections

• Use only speaker cables for connecting

speakers to the speaker jacks. Use of other

types of cables may result in ﬁre.

Handling caution

• Do not place heavy objects on it. Avoid

applying excessive force to the buttons,

switches or connectors to prevent injuries.

• Do not operate the device if the sound is

distorting. Prolonged use in this condition

could cause overheating and result in ﬁre.

PA-8 1/2

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

PRECAUTIONS

• Do not input excessively loud signals that

may result in clipping in the ampliﬁer or

cause the following:

- Feedback, when using a microphone

- Continuous and extremely loud sound from

a musical instrument, etc.

- Continuous and excessively loud distorted

sound

- Noise caused by plugging/unplugging the

cable while the ampliﬁer is turned on

Even if the output power of the ampliﬁer

is lower than the power capacity of this

device (program), damage to the device,

malfunction or ﬁre may occur.

• When choosing a power ampliﬁer for use

with this device, make sure that the output

power of the ampliﬁer is lower than the power

capacity of this device (see Owner’s Manual).

If the output power is higher than the power

capacity, malfunction or ﬁre may occur.

Yamaha cannot be held responsible for

damage caused by improper use or

modifications to the device.

PA-8 2/2

NOTICE

To avoid the possibility of malfunction/ damage

to the product, or damage to other property,

follow the notices below.

Handling and maintenance

When using a high-impedance speaker

connection, make sure the audio signal is

passed through an 60 Hz or above high-pass

filter before being input to the speakers.

Do not install the device to excessive dust or

vibration, or extreme cold or heat (such as in

direct sunlight, near a heater, or in a car during

the day), in order to prevent the possibility

of panel disfiguration, unstable operation, or

damage to the internal components.

Do not place vinyl, plastic or rubber objects on

the device, since this might discolor the device.

When cleaning the device, use a dry and soft

cloth. Do not use paint thinners, solvents,

cleaning fluids, or chemical-impregnated

wiping cloths.

Be sure to observe the amplifier’s rated load

impedance (see Owner’s Manual), particularly

when connecting speakers in parallel.

Connecting an impedance load outside

the amplifier’s rated range can damage the

amplifier.

Protection Circuit

This speaker system has an internal protection

circuit that shuts off the speaker unit when an

excessive input signal is applied. If the speaker

unit emits no sound, reduce the volume level of

the amplifier immediately. The sound will return

automatically in several seconds.

Do not place the speaker face down with the

grille attached, as deformation of the grille may

result.

When placing the speaker face down, always

place it on a flat surface.

Avoid touching or allowing objects to come in

contact with the speaker diaphragms.

Information

About this manual

The illustrations as shown in this manual are for

instructional purposes only.

The company names and product names in

this manual are the trademarks or registered

trademarks of their respective companies.

Regarding disposal

This product contains recyclable components.

When disposing of this product, please contact

the appropriate local authorities.

4VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

 

NOTICE ...................................................................................... 3

Information ............................................................................... 3

 

 

Main features .......................................................................... 4

Included accessories ........................................................... 5

Optional accessories ........................................................... 5

 

Connect the power amplier and the VXS3S ............. 6

Set the line voltage/impedance and power ................. 6

Connecting satellites ........................................................... 7

 

Speaker orientation .............................................................. 9

Pre-installation (cable preparation) ...............................10





Painting the grille ................................................................16

Painting the speaker enclosure .....................................16

Painting the ceiling mount adaptor ..............................17





Contents Introduction

Thank you for purchasing a YAMAHA VXS3SB or VXS3SW (hereafter

"VXS3S") speaker system. This product is a subwoofer designed

for playing background music in a retail or commercial setting. This

manual explains to the installer how to install the product. Additionally,

the product can be installed in a ceiling using an optional CMA3SB

or CMA3SW (hereafter "CMA3S"). To obtain maximum performance

from your YAMAHA speaker system, we recommend that you read this

Owner’s Manual thoroughly before use. Keep this manual in a safe place

for future reference.

Main features

Uses Yamaha's unique SR-Bass™ technology* to provide realistic sound

and amazing energy in a small speaker.

• Supports both low-impedance and high-impedance connection in a

single speaker.

• Features connection terminals for satellite speakers, allowing you to

keep the number of power amplifier channels used to a minimum.

* SR-Bass™ represents the evolution of passive-type diaphragm technology. It

is Yamaha's unique bass reproduction technology that efficiently converts the

energy inside the speaker cabinet into low-frequency sound.

* The contents of this manual apply to the latest specifications as of the publishing

date. To obtain the latest manual, access the Yamaha website then download the

manual file.

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Introduction

Included accessories

VXS3S

Speaker ×1 Grille ×1

Safety wire ×1 Mounting bracket ×1 Spacer ×3

Machine screw (M4×16) ×2 Masking sheet ×2 Owner's Manual

(this document)

Optional accessories

Ceiling mount adaptor CMA3S

Ceiling mount adaptor ×1 Square ring ×1

Safety wire ×1 Terminal cover ×1 Tapping screw (4×12) ×8

Tapping screw (4×8) ×2 Hole cover sheet ×4 Cutout template ×1

Tile rails ×2 Masking sheet ×1

6VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Connections

Set the line voltage/impedance and power

Select the line voltage/impedance (100V/70V/8

Ω) and input wattage

power tap when using a 100V/70V line distributed system.

Satellite speakers (NONE)

Satellite speakers (×4)

Satellite speakers (×2)

NOTICE

• When connecting speakers with high impedance, check the tap selector switch

settings indicated around the switch, and then set the tap according to the number of

satellite speaker connections (NONE/×2/×4) and the output (W).

Make sure that the input total of each speaker does not exceed the rated output of the

power ampliﬁer.

• Do not set the tap selector switch to the "X" position.

• When using a low impedance connection, set the tap selector switch to the “8

Ω”

position.

If the setting is incorrect, it may cause malfunction of the speaker and ampliﬁer.

• Make sure the ampliﬁer is switched off before operating the tap selector switch.

Connect the power ampliﬁer and the VXS3S

Connect the OUTPUT of the power amplifier to the INPUT of the

subwoofer.

＋

－

Power amplifier

INPUT

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Connections

Connecting satellites

This product features built-in output terminals for connecting satellite

speakers. You can connect full-range speakers to the satellite terminals

and use them as mid and high-range speakers.

NOTICE

• We recommend the use of 2 or 4 satellite speakers.

• Use caution when mixing 2- and 4-speaker satellite systems, as there may be

differences in volume.

VXS3S+VXS1ML (×4) low impedance connection

This is a basic system.

＋

－

＋

－

＋

－

＋

－

＋

－

Power amplifier

INPUT

ST1 ST2

ST3 ST4

VXS3S+VXS1ML (×2) low impedance connection

Connect the speakers as shown below when using only 2 satellite

speakers.

＋

－

＋

－

＋

－

Power amplifier

INPUT

ST1 ST2

NOTICE

When connecting satellites at low impedance, the combined impedance is 4

Ω (when

connecting 4 satellites) or 3.5Ω (when connecting 2 satellites).

Make sure than the power ampliﬁer is compatible with these impedances. If the power

ampliﬁer is not compatible, the power ampliﬁer may malfunction.

8VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Connections

VXS3S+VXS1ML high impedance connection

This is an example of a system where multiple subwoofers are connected using high impedence connections. Additionally, multiple satellite systems can

be connected using just one of the power amplifier's channels.

Set the tap selector switch of the VXS3S according to the number of satellite speaker connections (NONE/×2/×4) and output (W) while referring to the

selector switch inscription. For details, refer to page 6.

＋

－

＋

－

＋

－

＋

－

Power amplifier

Hi-z

INPUT

Hi-z Hi-z

THRU

THRU INPUT

THRU

ST1 ST2

ST3 ST4

ST1 ST2

ST3 ST4

additional systems

NOTICE

• When connecting speakers with high impedance, be sure that the rated output of the power ampliﬁer exceeds the input total of each speaker.

For details, refer to the explanation of high-impedance connection at the following URL.

Yamaha Pro Audio site, "Better Sound for Commercial Installation"

http://www.yamahaproaudio.com/global/en/training_support/better_sound/

• When installing speakers, make sure the power ampliﬁer is turned off.

• When connecting at high impedance, the signals inputted into the speaker should be sent through a high-pass ﬁlter set to 60Hz or greater.

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Installing on a wall or ceiling

You can use the included mounting bracket to install the speaker on a

wall or ceiling. Before installation, make sure the installation area can

support the weight of the speaker.

NOTICE

When installing speakers, make sure the power ampliﬁer is turned off.

NOTE

If you will paint the speaker, refer to "Painting" on page 16.

Speaker orientation

Install the speaker so that the r mark on the mounting bracket is facing

the r mark on the speaker.

Horizontal installation Vertical installation

r mark

r mark r mark

CAUTION

When installing the speaker in a vertical orientation, if the r mark on

the mounting bracket is pointing down, the speaker cannot be se-

cured to the mounting bracket and it may fall. Do not install the speak-

er so that the r mark points down.

10 VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Installing on a wall or ceiling

Pre-installation (cable preparation)

Strip the cable insulation as shown in the figure and connect the cables.

Compatible cable: AWG12 (max. 3.5 sq)

7–8mm

NOTE

• Do not use solder to plate stranded wires, as this may cause the wires to break.

• Run the speaker cables to the installation area before installing the speaker.

1 Attaching the mounting bracket to the wall or ceiling

1-1 Determine the speaker installation location.

1-2 Refer to the ﬁgure below and determine where the mounting

bracket will be installed and where the cables will be fed.

110

3040

Wall or ceiling

175 or more 175 or more

90 or more 90 or more

Wall or ceiling

Recommended area

for pulling out cables

Unit:mm

1-3 If you want to add space between the wall and the speaker,

attach spacers to the mounting bracket.

When securing at 4 points When securing at 1 point (center)

1-4 Attach the mounting bracket to the wall or ceiling.

The 4 slots are for M6 screws, and the center hole's diameter is

11 mm.

1-5 Feed the cables from the wall or ceiling.

2 Attaching the safety wire

2-1 Attach the safety wire to the wall or ceiling.

CAUTION

• Use the included safety wire.

• Attach safety wire high enough so that there is not too much

slack in the wire.

• If the included safety wire is not long enough, consider the

weight of the speaker and the installation conditions, and pro-

cure an appropriate safety wire.

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Installing on a wall or ceiling

2-2 Attach the safety wire to the speaker.

Attach the safety wire so that its clasp ﬁts inside the groove on

the speaker.

3 Connecting the cables

3-1 Use a Phillips screwdriver to loosen the screws on the barrier

strip, insert the cables, and then tighten the screws. For

information about connecting the cables, refer to "Connections"

on page 6. Make sure the cables are secure and cannot be

pulled out.

4 Secure the speaker to the mounting bracket

4-1 Remove the grille.

4-2 Attach the speaker so that the r mark on the mounting bracket

is facing the r mark on the speaker.

r mark

12 VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Installing on a wall or ceiling

4-3 Slide the speaker about 10mm in the direction shown to tempo-

rarily secure the speaker.

About 10mm

4-4 Use the supplied two screws to secure the speaker.

CAUTION

Make sure you tighten the screws.

NOTICE

When installing the speaker, make sure you do not touch the ﬂaps or subject the

speaker to strong shocks. If the ﬂaps become indented, the sound may become

distorted.

Flaps

5 Setting the line voltage/impedance and power

5-1 Set the line voltage/impedance (100V/70V/8

Ω) and input wattage

when using a 100V/70V line distributed system. For details, refer

to page 6.

6 Attach the grille

6-1 Align the grille to the front of the cabinet and attach the grille.

CAUTION

If the grille is not attached properly, it may fall off after the speaker is

installed.

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Installing in a ceiling (using the CMA3S)

You can use the optional VXS3S ceiling mount adaptor to install the

speaker in a ceiling.

1 Cut a hole in the ceiling

1-1 Use the included cutout template (350mm×210mm) to mark the

outline of the hole on the ceiling.

NOTE

Make sure to use the included cutout template; if the hole size is not correct, you

will not be able to install the speaker.

1-2 Cut along the outline and cut the hole.

When cutting the hole, be careful to prevent debris or dust from

entering your eyes.

2 Attach the square ring and rails to the inside

surface of the ceiling.

2-1 Insert the two tile rails through the cut hole and place them on the

ceiling surface within your reach. Be sure that each tile rails are

oriented as shown in the illustration.

2-2 Insert the square-ring through the cut hole.

2-3 Secure the square-ring and tile rails with supplied two screws

through either slot of both square-ring brackets.

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Installing in a ceiling (using the CMA3S)

6 Secure the speaker to the ceiling

6-1 Push the speaker into the ceiling, taking care not to pinch the cables.

NOTICE

When installing the speaker, make sure you do not touch the ﬂaps or subject the

speaker to strong shocks. If the ﬂaps become indented, the sound may become

distorted.

Flaps

6-2 While lifting the speaker up slightly, use a Phillips screwdriver to

turn the screws clockwise and tighten the attachments screws.

The clamp opens when you begin turning the screw. As you

continue to turn the screw, the clamp slides down and pulls the

speaker into the ceiling.

NOTE

If the clamp is difﬁcult to open, turn the screw counter-clockwise one-half revolu-

tion; this will make it easier to open.

Clamp

Attachment

screw

CAUTION

• To prevent stripping the screws, do not overtighten the screws.

• Do not turn any screws other than the attachment screws. This

may cause the speaker to fall or malfunction.

7 Setting the line voltage/impedance and power

7-1 Refer to page 6.

8 Attach the hole cover sheets

8-1 Attach the included hole cover sheets to the screw holes.

9 Attach the grille

9-1 Align the grille to the front of the cabinet and attach the grille.

CAUTION

If the grille is not attached properly, it may fall off after the speaker

is installed.

16 VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Painting

When painting the VXS3S, we recommend using acrylic lacquer paint.

Refer to the paint's instructions for details on how to apply the paint.

CAUTION

Work in an area that has adequate ventilation.

NOTICE

• Painting procedures often require the use of volatile solvents that can cause ﬁre. Follow

all necessary safety precautions to avoid any risk of a ﬁre or accident.

• Yamaha cannot be held responsible for any damage to the speaker as a result of

painting.

Painting the grille

1 Remove the grille from the speaker, taking care not to scratch it.

2 Remove the emblem on the front of the grille.

The emblem is attached by adhesive tape.

3 Tuck the included masking sheet under the crosspiece on the back

of the grille and insert the masking sheet.

NOTE

Make sure the areas shown below are covered.

4 Apply the paint to the grille.

NOTE

Make sure the holes in the grille do not become clogged with paint.

If the holes become clogged with paint, sound quality may be affected.

5 When the paint is completely dry, remove the masking sheet and

attach the emblem to the grille.

Make sure the emblem is attached in the correct position.

6 Attach the grille to the speaker.

Painting the speaker enclosure

1 Remove any dust or dirt with a lint-free cloth.

Do not sand the enclosure.

2 Use spray paint to paint the enclosure.

Cover the bafﬂe and connectors using masking materials to avoid

paint contact.

3 Allow the paint to dry completely.

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Painting

Painting the ceiling mount adaptor

1 Wipe off any dirt from the ceiling mount adapter before painting it.

Do not ﬁle it down.

2 Align the included masking sheet with the posts of the ceiling mount

adaptor and insert the masking sheet.

3 Use masking tape to cover the posts and the screw heads (8 loca-

tions total).

NOTE

Use masking tape as necessary to mask other areas.

4 Spray the paint onto the ceiling mount adaptor and the hole cover

sheets.

5 When the paint is completely dry, remove the masking sheet.

151

VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Speciﬁcations

Model VXS3SB VXS3SW

Type SR-Bass™ type Subwoofer

Component 3.5" (9cm) Cone

Nominal impedance

Lo-Z: 8Ω

Hi-Z:

4 Satellites or None

15W 7.5W 3.8W 1.9W

100V 670Ω1.3kΩ2.7kΩ-

70V 330Ω670 Ω1.3kΩ2.7kΩ

2 Satellites

15W 7.5W 3.8W

100V 1.3kΩ2.7kΩ-

70V 670Ω1.3kΩ2.7kΩ

Satellite impedance 8Ω (Load per satellite output recommended)

Power rating

NOISE 20W

PGM 40W

MAX 80W

Sensitivity (1W, 1m)*1 79dB SPL

Maximum SPL

(Calculated,1m)*2 98dB SPL

Frequency range (-10dB) 65Hz - 180Hz

Connector

TERMINAL BLOCKS(4pin) Input:

+/-, Loop-thru: +/-

TERMINAL BLOCKS(8pin) Satellite output:

+/- (ST1~ST4)

Max. wire size AWG 12(3.5sq)

Transformer

Taps

70V line 15W, 7.5W, 3.8W, 1.9W

100V line 15W, 7.5W, 3.8W

Overload protection Full-range power limiting to protecting

network and transducers

Model VXS3SB VXS3SW

Magnetically shielded No

Enclosure

Cabinet

Material ABS (V-0) 5mm Black ABS (V-0) 5mm White

Bafﬂe

Material ABS (V-0) 3.5mm Black

Grille

Material Powder coated perforated steel (t=0.6mm)

Grille Frame: ABS (V-0)

Finish

Black painting

(approximate value:

Munsell N3)

White painting

(approximate value:

Munsell N9)

Aperture

ratio 55% 55%

Dimension (Speaker only) W322 × H162 × D118mm

(12 5/8" × 6 3/8" × 4 5/8")

Net Weight (Speaker only) 2.7 kg (6.0 lbs)

Packaging Packaged in 1pc

*1 : Full-space (4π)

*2 : Calculated based on power rating and sensitivity, exclusive of power

compression.

Model CMA3SB CMA3SW

Enclosure

ABS (V-0) 3.0mm

Black

ABS (V-0) 3.0mm

White

Dimensions

(Adapter only)

W386 × D233 × H90mm

(15 1/4" × 9 1/4" × 3 1/2")

Net Weght 0.44 kg (0.97 lbs)

Cutout size 350mm × 210mm (13 3/4" × 8 1/4")

152 VXS3SB / VXS3SW / CMA3SB / CMA3SW Owner's Manual

Dimensions

VXS3SB/VXS3SW CMA3SB/CMA3SW (OPTION)

■ ANCHOR BRACKET AND SQUARE RING

■ TILE RAIL

■ SQUARE RING

644

608 28

118

322

162

277

262

206

346

402

277

262

206

402

346

154

5 55

■ WALL BRACKET

117

φ11

386

233

Unit: mm

Termékspecifikációk

Márka:	Yamaha
Kategória:	hangszóró
Modell:	CMA3SB

Szüksége van segítségre?

Ha segítségre van szüksége Yamaha CMA3SB, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek

Az Ön neve*

Az Ön e-mail címe*

Írja ide kérdését

Útmutatók hangszóró Yamaha

Yamaha WX-010 Útmutató

15 Január 2025

Yamaha DXR15 MKII Útmutató

14 Január 2025

Yamaha NS-F 51 Útmutató

13 Január 2025

Yamaha CMA3SW Útmutató

10 Január 2025

Yamaha IF2112/64 Útmutató

10 Január 2025

Yamaha IF2115/99 Útmutató

10 Január 2025

Yamaha VXC2FB Útmutató

10 Január 2025

Yamaha VXC6W Útmutató

10 Január 2025

Yamaha VXC2P Útmutató

10 Január 2025

Yamaha VXC8-VA Útmutató

10 Január 2025

Útmutatók hangszóró

Legújabb útmutatók hangszóró

Focal K2 Power M FRAK Útmutató

5 Április 2025

Match UP C42BMW-FRT.3 Útmutató

3 Április 2025

Turbosound PQ12-SB Útmutató

3 Április 2025

Trust Tytan GXT 658 Útmutató

3 Április 2025

Turbosound PQ15-YB Útmutató

3 Április 2025

Klipsch Synergy KSB-S1 Útmutató

3 Április 2025

Klipsch Synergy KSF-10.5 Útmutató

3 Április 2025

Klipsch kO-R1 Útmutató

3 Április 2025

Klipsch Synergy SB-1 Útmutató

3 Április 2025

Klipsch Reference RB-5 II Útmutató

3 Április 2025
