Got questions or need a repair?
Email help@walrusaudio.com to talk with a real live human about your Walrus gear!
This product comes with a limited lifetime warranty.
Click Here for more info.
Thank you for trusting your instrument’s tuning to the Canvas Tuner!
Out of the box, you’ll find the tuner ready to use in vertical needle mode. Simply connect to a
power source* and your instrument’s cable to the input jack and you’re ready to tune up. Canvas
Tuner has a lot of options to explore including screen orientations, needle or strobe mode,
tuning presets, screen savers and more, so read on to get the most out of your new tuner!
CONTROLS
*Only use a 9 volt DC, Center Negative, 300mA to power the pedal.
The use of an isolated power supply is recommended for powering all Walrus Audio Pedals.
Daisy chain power supplies are not recommended.
MENU BUTTONS:
Up Button - Navigate up in menus.
Menu Button - Access device menu & confirm menu selections.
Down Button - Navigate down in menus.
Stomp Switch - Used as a “back button” when in menu pages.
USB C Jack - USB C port for updating firmware via walrusaudio.io.
MODE: Change between Needle and Strobe tuning modes. Each option
provides distinct visual feedback for a variety of tuning applications.
NEEDLE MODE: The incoming pitch is tracked on the tuning strip at
the top of the display. When an incoming note is flat, the indicator will
appear on the left of the center of the tuning strip and turn red. When
an incoming note is sharp, the indicator will appear on the right of
the center of the tuning strip and turn red. When you are in tune,
the indicator is centered with the arrows on the tuning strip and
the indicator will light up green.
IN TUNEFLAT
BRIGHTNESS
ORIENTATION
COLOR THEME
STANDBY
SCREEN
MENU OPTIONS - DISPLAY
MENU OPTIONS - TUNER
Adjust the screen backlight brightness from 1-10.
Rotate display 360 degrees in 90-degree increments.
Customize the color of the note indicator in Strobe &
Needle modes.
Customize the bypass screen image. Canvas Tuner has
three different standby screen modes to choose from:
1. Canvas - Walrus Audio Canvas color badge.
2. Screensaver - Cute little bouncing Walrus head.
Will it ever hit the corner?
3. Picture Mode - Upload your own image via USB to
be displayed on the bypass screen.
Visit walrusaudio.io for more information.
SHARP
STROBE MODE: The incoming pitch is
tracked by the rotational speed and direction
of the tuning wheel around the target note.
When an incoming note is flat, the tuning wheel
will rotate counterclockwise. When an incoming
note is sharp, the tuning wheel will rotate clockwise.
The more flat or sharp the incoming note is, the faster the
tuning wheel will spin in the respective direction. As the note
becomes more in tune, the rotational speed of the tuning wheel decreases.
When the wheel stops rotating, the incoming note is in tune.
MENU OPTIONS -
TUNER
MENU OPTIONS - TUNER
NOTE: the strobe algorithm is a direct connection to the pitch of
the incoming note. Since the pitch is always moving slightly, the
tuning wheel will never stop for long if at all. Tune until it is as still
as you can make it for hyper-accurate tuning.
CHROMATIC: Tracks and detects the full frequency range of the
guitar signal.
GUITAR STD: Tracks and detects frequencies only in the standard
EADGBE guitar tuning range. When an incoming note is outside
of the tuning preset range, the note will not be tracked.
DROP D: Tracks and detects frequencies only in the standard
DADGBE guitar tuning range. When an incoming note is outside
of the tuning preset range, the note will not be tracked.
BASS STD: Tracks and detects frequencies only in the standard
EADG 4-string bass guitar tuning range. This tuning mode also
supports the lower B string and higher C string included in 5 and
6-string bases. When an incoming note is outside of the tuning
preset range, the note will not be tracked.
TUNING PRESET: Select pitch ranges that the tuner will display
and detect.
F
L
A
T
S
H
A
R
P
