Oldal 1/2
Protocol manuals for developers: available for download at
https://github.com/velbus
Features
suitable for:
single push button with screw connection terminals: NIKO® ref. 170-00000
dual push button with screw connection terminals: NIKO® ref. 170-05000
NOT suitable for: NIKO® ref. 170-00005 and 170-05005 (with plug-in
connection terminals)
backlight of the buttons:
switchable, on or off
brightness adjustable
feedback on the buttons:
switchable, on or off
brightness adjustable
flashing mode on or off
status feedback of a contact (open or closed)
configuration:
only configurable via Velbus pc interface (VMB1USB, VMB1RS or VMBRSUSB)
and the Velbuslink software
software addressing (up to 250 adresses possible)
push button settings:
> response time for each push button adjustable between 0, 1, 2 or 3 seconds
> normally open or normally closed type
> double-channel push button (short or long push)
> multichannel push button (each push selects the next channel)
> lock or unlock
> suppress
timer functions:
> to simulate a push button operation at a certain time
> daily, weekly, monthly or yearly program
> choose between 3 program groups (ex. summer, winter, or holiday program)
> push button lock or unlock can be added to the program
> two different alarm wake-up and bed times that can be used as references
in the program
> sunset/sunrise linked programs
functions via external Velbus push buttons:
> lock or unlock
> activate/deactivate switching programs and timers
VMB2PBN-R datasheet
Push-button interface for NIKO® single
or dual push-button, with blue feedback
LEDs
Also available with amber LEDs as the VMB2PBAN-R.
VELBUS VMB2PBN-R
Legen Heirweg 33 9890 Gavere Belgium• •
velbus.eu
1
Protocol manuals for developers: available for download at
https://github.com/velbus
Specifications
power supply 15±3VDC
consumption 20 mA
dimension (WxLxH) 33 x 40 x 32 mm / 1.3 x 1.57 x 1.26”
VMB2PBN-R datasheet
Push-button interface for NIKO® single
or dual push-button, with blue feedback
LEDs
Also available with amber LEDs as the VMB2PBAN-R.
VELBUS VMB2PBN-R
Legen Heirweg 33 9890 Gavere Belgium• •
velbus.eu
2
