In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
LED MAGNETIC TABLE LAMP
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-10116
SKU 23412, 23413
SOLAR PANEL 5V, 210mA-1W
RATED INPUT 5V
LUMENS 400 Lm
BEAM ANGLE 60°
CRI ≥80
DIMMABLE 10-100%
LIFE SPAN 20,000 Hours
MATERIAL Metal+ABC+PC
DIMENSION 352x120mm
BATTERY CHARGING TIME WORKING TIME
3600 mAh
Li-ion Battery 3-4 Hours Maximum Light >5 Hours
Minimum Dark > 24 Hours
Magnetic ball head
Solar Panel
Metal bracket
On/O
Dimming Touch Switch
PRODUCT STRUCTURE
WARNING
1. Please make sure to turn o the power
before starting the installation.
2. The light source of this luminaire is not
replaceable, when the light source reaches
its end of life the whole luminaire should be
replaced.
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
PACKAGE CONTENTS
OPERATION CAUTIONS
1. Don’t connect with dimming sensing device
2. Don’t use the lamp in a humid or flammable environment.
3. Don’t pull the power plug when your hands are wet to prevent electric shock
4. Don’t cover the lamp with objects to prevent the lamp from being damaged
or causing danger.
Continuously touch the key, the main light changes in turn” on -> low -> medium -> high
-> o” cycle selection.
Power hint: red light when charging, green light when full.
INSTALLATION INSTRUCTION
1. Strong magnetic ball head design (adjust
more angles, illuminate more places)
. 2 Screw the metal
bracket into the base
Table Lamp
LED Lamp Metal
Bracket Instruction
SOLAR PANEL MAINTENANCE & WARNING
• Do not use solvents, petrol, etc. Otherwise the light will be damaged.
• Clean the light with a dry, lint-free cloth.
• Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
flawless function of the product.
• Especially during the winter, keep the product free from snow and ice.
• Confirm installation direction is correct (solar panel should be at top).
• Confirm no objects blocking the solar panel to receive sunlight.
• Keep away from the fire.
• Don’t immerse in the water.
