90W 2-Port Industrial 2.5G PoE++ Injector
TI-IG290 (v2.0R)
2 x 2.5G PoE++ ports (Data + PoE out)
2 x 2.5G ports (Data in)
180W PoE power budget
Supports PoE (15.4W), PoE+ (30W), and PoE++ (95W)
devices
Uses IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt industry
PoE standards for greater device interoperability
Network a PoE device located up to 100m (328 ft.) away
Fanless design eliminates operating noise and lowers energy
consumption
Extreme operating temperature range -40 to 75 °C (-40 to
167 °F)
Redundant power inputs with overload current protection
Includes DIN-Rail mount and wall mount
Power supply sold separately (model TI-S24048)
NDAA / TAA compliant (U.S. and Canada only)
TRENDnet’s 90W 2-Port Industrial 2.5G PoE++ Injector, model TI-IG290, allows users to add PoE++ power to a non-PoE 2.5G
switch. Connect the 2-port industrial 2.5G PoE++ injector to a non-PoE 2.5G switch, and then run Ethernet cables up to 100 meters
(328 ft.) to network two PoE/PoE++ devices. This multi-port industrial 2.5G PoE++ injector supplies up to 90W of power to two PoE
devices with a total PoE budget of 180W. The fanless design conveniently eliminates operating noise and lowers unnecessary
energy consumption. The dual port industrial 2.5G PoE++ injector is equipped with an IP30 rated metal enclosure, designed to
withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° – 70° C (-40° – 158° F) for
harsh industrial environments.
TI-IG290
2-Port PoE
This multi-port 2.5G PoE++ injector
supplies up to 90W of power to two PoE
devices with a total PoE budget of 180W.
2.5G Ports
Features two high-speed 2.5G ports
(data in) and two high-speed 2.5G PoE++
ports (data + PoE out).
Industrial Design
IP30 rated metal enclosure with a high
degree of vibration and shock resistance,
and a wide operating temperature range
of -4– 70° C (-40° – 158° F).
NETWORKING SOLUTION
TI-IG290
FEATURES
2-Port PoE++
The 2-port industrial 802.3 bt
PoE++ injector supplies up to 90W
of power to two PoE (IEEE
802.3af), PoE+ (IEEE 802.3at), or
PoE++ (IEEE 802.3bt) devices
Industrial Design
Equipped with an IP30 rated metal
enclosure, designed to withstand a
high degree of vibration and shock,
while operating within a wide
temperature range of -40° – 70° C
(-40° – 158° F) for industrial
environments
2.5G Ports
2 x 2.5G ports (data in) and 2 x
2.5G PoE++ ports (data + PoE out)
PoE Distance
Provides two PoE network
connections up to 100m (328 ft.)
away from the 2-port industrial
802.3bt PoE++ adapter
LED Indicators
LEDs indicate PoE connectivity and
power status
Shock and Vibration Resistant
Rated for shock (EN 60068-2-27),
freefall (EN 60068-2-32), and
vibration (EN 60068-2-6)
Grounding Point
Grounding point protects equipment
from external electrical surges
Fanless Design
Fanless design on the 2-port
industrial 2.5G PoE++ injector
conveniently eliminates operating
noise and lowers unnecessary
energy consumption
TI-IG290

Termékspecifikációk

Márka: TRENDnet
Kategória: nincs kategorizálva
Modell: TI-IG290
