Oldal 1/3
- With 6 PoE+ and 2 PoE++ ports, transfers data and power on one single cable
- Working with IEEE 802.3af/at/bt compliant PDs, expands your network
- Supports PoE power up to 60 W for PoE++ port and 30 W for each PoE+ port
- Supports PoE power up to 123 W* for all PoE ports
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications
- Isolation Mode allows one-click client trac separation for higher security and performance
- Up to 250 m data and power transmission under Extend Mode** specially designed for surveillance
system
- With PoE Auto Recovery, the switch will automatically reboot your dropped or unresponsive
PoE-powered devices connected to port 1–8
- Requires no conguration and installation
- Fanless Design
- Supports desktop and wall mountable installation methods
Highlights
10-Port Gigabit Desktop Switch
with 6-Port PoE+ and 2-Port PoE++
Overview
TL-SG1210PP is an unmanaged switch with 10 Gigabit ports that requires no conguration and
provides 8 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE
802.3af/at/bt compliant Powered Devices (PDs) at port 1-2 and IEEE 802.3af/at compliant Powered
Devices (PDs) at port 3-8. In this situation, the electrical power is transmitted along with data in one
single cable allowing you to expand your network to where there are no power lines or outlets, where
you wish to x devices such as APs, IP Cameras or IP Phones, etc.
Power Over Ethernet
8 RJ45 ports (port 1 to port 8) of the switch support Power over Ethernet (PoE) function. They can
automatically detect and supply power with those IEEE 802.3af/at/bt compliant Powered Devices (PDs)
at port 1-2 and IEEE 802.3af/at compliant Powered Devices (PDs) at port 3-8.
Overload Arrangement
TL-SG1210PP has the priority function which will help protect the system when the system power is
overloaded. If all PoE PDs power consumption is ≥ 123 W*, a priority will be arranged among the PoE
ports, then the system will cut o the power of the lowest-priority port.
Intelligent Power Management
Priority (port 1 > port 2 ……> port 8): This function will help protect the system when the system power
is overloaded. For example, port 3, 4, 5 and 6 is using 25 W respectively (maximum power per port is 30
W); the system power is 100 W in total. If there is an additional PD inserted to port 1 with 35 W, and then
the system will cut o the power of port 6 because of the overloaded power, this means port 3, 4 and 5
will use 25 W respectively and port 1 will use 35 W, no power will be supplied to port 6.
Highlight Performance
• Up to 250 m PoE power supply and data transmission under Extend Mode** for port 1-4.
• Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications
• Isolation Mode allows one-click client trac separation for higher security and performance
• With PoE Auto Recovery, the switch will constantly detect the data transmission with PoE-powered
devices (PD) for port 1-8. When the switch nds that a PD stops sending data packets to the switch
for a long period, the switch will reboot it automatically.
TL-SG1210PP is easy to install and use. It requires no conguration and installation. With desktop and
wall mountable design, outstanding performance and quality, the TP-Link 10-Port Gigabit Desktop
Switch with 8-Port PoE+ and 2-Port PoE++ TL-SG1210PP is a great selection for expanding your
network.
Easy to Use
Hardware Features & Performance
Specications
www.tp-link.com
Specications are subject to change without notice. All brands and product names are trademarks or registered trademarks of their respective holders. © 2023 TP-Link
Note:
* PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will
vary as a result of client limitations and environmental factors.
**The speed of the ports which are under extend mode will be downgraded to 10Mbps. Actual transmission
distance may vary from the quality of the cables.
Product Picture
Model TL-SG1210PP
Standards IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Network Ports 10 10/100/1000 Mbps RJ45 Ports;
Network Media ( e)Cabl
10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m);
EIA/TIA STP (maximum 100 m)-568 100Ω
100BASE-TX: UTP category 5, 5e cable (maximum 100 m);
EIA/TIA STP (maximum 100 m)-568 100Ω
1000BASE-T: UTP category 5e cable or above (maximum 100 m);
EIA/TIA STP (maximum 100 m)-568 100Ω
PoE
PoE Standard: IEEE 802.3af/at/bt for ports 1-2, IEEE 802.3af/at for ports 3-8
PoE Port 1-2: up to 60 W per port
PoE Port 3–8: up to 30 W per port
PoE Power Budget: 123 W*
Auto-Negotiation YES
Auto MDI/MDIX YES
PoE Power on RJ45
Port 1-2:
P er+: pin 3 & pin 6ow
P er -: pin 1 & pin 2ow
P er+: pin 4 & pin 5ow
P er -: pin 7 & pin 8ow
Port 3-8:
P er+: pin 3 & pin 6ow
P er -: pin 1 & pin 2ow
Max P er ow Consumption 8.7 W (220 V/50 Hz no PD connected)
144.1 W (220 V/50 Hz with 123 W* PD connected)
Max Heat Dissipation 29.67 BTU/h (220 V/50 Hz no PD connected)
491.38 BTU/h (220 V/50 Hz with 123 W* PD connected)
Forwarding Mode Store and Forward
Swit ty 20 Gbpsch Capaci
MA Address Table 4K, Auto-learning, Auto-agingC
Extend Mode YES (for Ports 1–4)
PoE Auto Rec ery YES (for Ports 1-8)ov
Isolation Mode YES (for Ports 1-4/5-8)
Priority Mode YES (for Ports 1-2)
Flow Conrol YES
Fanless YES
LED P er, Link/Acow t, PoE Status, PoE MAX
Dimensions 8.2x5.0x1.0in (209x126x26 mm)
C CCE, F
Environment
Operating Temperature t to 104°F): 0°C o 40°C (32°F
Storage Temperature t to 158°F): -40°C o 70°C (-40°F
Operating Humidity: 10% to 90% RH, non-condensing
Storage Humidity: 5% to 90% RH, non-condensing
