Oldal 1/12

Manual Revision: 01/30/2019

For the latest information, technical specications, and support for

this product, please visit www.startech.com/PEXM2SAT32N1.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

PEXM2SAT32N1

3-Port M.2 NGFF SSD Adapter Card - 1 x PCIe

M.2, 2 x SATA III M.2 - PCIe 3.0

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Introduction ............................................................................................1

Packaging contents 1 ..................................................................................................................................

System requirements 1 ...............................................................................................................................

Product diagram ....................................................................................2

Top view 2 .......................................................................................................................................................

Bottom view 2 ................................................................................................................................................

Mounting hardware 2 .................................................................................................................................

LED indicators .........................................................................................3

LED diagram 3 ................................................................................................................................................

Hardware installation ............................................................................4

Install a drive on the PCIe card 4 .............................................................................................................

SATA M.2 drive-installation diagram (top side) 4 ..............................................................................

PCIe M.2 drive-installation diagram (bottom side) 5 .......................................................................

Install the low-prole bracket 5 ...............................................................................................................

Install the PCIe card 5 ..................................................................................................................................

Initialize a drive ......................................................................................6
