Oldal 1/128
2004 Sony Corporation
KDE-37XS955
KDE-42XS955
KDE-50XS955
Flat Panel Color TV
Operating Instructions
2-583-350-11 (2)
Flat Panel Color TV KDE-37XS955/KDE-42XS955/KDE-50XS955
Printed in U.S.A.
Owner’s Record
The model and serial numbers are located at the rear of the TV. Record
these numbers in the spaces provided below. Refer to them whenever
you call upon your Sony dealer regarding this product.
Model No.
Serial No.
Contacting Sony
If, after reading these operating instructions, you have additional
questions related to the use of your Sony television, please call our
Customer Information Services Center at 1-800-222-SONY (7669)
(US residents only) or 1-877-899-SONY (7669) (Canadian residents
only).
1
WARNING
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
This symbol is intended to
alert the user to the presence
of uninsulated “dangerous
voltage” within the
product’s enclosure that
may be of sufficient
magnitude to constitute a
risk of electric shock to
persons.
This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the
appliance.
CAUTION
To prevent electric shock, do not use this
polarized AC plug with an extension cord,
receptacle or other outlet unless the blades can
be fully inserted to prevent blade exposure.
Note on Caption Vision
This television receiver provides display of
television closed captioning in accordance with
§15.119 of the FCC rules.
Note to CATV System Installer
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the National Electrical Code (NEC) that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall
be connected to the grounding system of the
building, as close to the point of cable entry as
practical.
Use of this television receiver for other than
private viewing of programs broadcast on UHF
or VHF or transmitted by cable companies for
the use of the general public may require
authorization from the broadcaster/cable
company and/or program owner.
NOTIFICATION
This equipment has been tested and found to
comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference with radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
sReorient or relocate the receiving
antennas.
sIncrease the separation between the
equipment and receiver.
sConnect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
sConsult the dealer or an experienced
radio/TV technician for help.
Safety
sOperate the TV only on 120 V AC.
sThe plug is designed, for safety purposes,
to fit into the wall outlet only one way. If
you are unable to insert the plug fully into
the outlet, contact your dealer.
sIf any liquid or solid object should fall
inside the cabinet, unplug the TV
immediately and have it checked by
qualified service personnel before
operating it further.
sIf you will not be using the TV for several
days, disconnect the power by pulling the
plug itself. Never pull on the cord.
sFor details concerning safety precautions,
see “Important Safeguards” on page 2.
Important Notice
sWhen used at an altitude of greater than
1,900m or 6,248feet (air pressure less than
800hPa), this Plasma Display Panel may
generate a low buzzing sound as a result
of the difference between the interior and
exterior air pressure of the panels. This is
not considered a defect and is not covered
under by the Limited Warranty.
Installing
sTo prevent internal heat buildup, do not
block the ventilation openings.
sDo not install the TV in a hot or humid
place, or in a place subject to excessive
dust or mechanical vibration.
sAvoid operating the TV at temperatures
below 5°C (41°F).
sIf the TV is transported directly from a
cold to a warm location, or if the room
temperature changes suddenly, the picture
may be blurred or show poor color due to
moisture condensation. In this case,
please wait a few hours to let the moisture
evaporate before turning on the TV.
sTo obtain the best picture, do not expose
the screen to direct illumination or direct
sunlight. It is recommended to use spot
lighting directed down from the ceiling or
to cover the windows that face the screen
with opaque drapery. It is desirable to
install the TV in a room where the floor
and walls are not of a reflective material.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
NO ABRIR
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
CAUTION
Bright, stationary images, such as TV station
logos, displayed on your TV can become
permanently imprinted onto the screen.
Theses types of imprints are known as
“Image Retention.” Please take the following
steps to reduce the risk of causing image
retention:
View a variety of program sources or
programming material. Changing the
program material viewed reduces the
possibility that a single image will become
imprinted on the TV screen.
When using video games, computers, and
similar products with your TV, or viewing a
TV station whose logo always stays on the
screen, keep the “Brightness” and “Picture”
functions at low settings. (See page 92 for
instructions on adjusting picture quality.)
This TV was designed primarily for viewing
TV broadcasts in wide screen mode (16:9
aspect ratio). Therefore, when viewing
conventional (4:3) aspect ratio TV programs,
select “Wide Zoom” or “Full” in the Wide
Screen Mode, or “4:3 Default” in the Screen
menu (see pages 97-98).
IMAGE RETENTION IS NOT COVERED
BY YOUR WARRANTY.
(Continued)
2
CAUTION
Use the following SONY appliance(s) only with the following
WALL-MOUNT BRACKET. Use with other WALL-MOUNT
BRACKET may cause instability and result in possible injury.
SONY APPLIANCE MODEL NO.
KDE-37XS955
KDE-42XS955
KDE-50XS955
SONY WALL-MOUNT BRACKET MODEL NO.
SU-PW3M
SONY FLOATING STAND MODEL NO.
SU-PF3L (for KDE-50XS955)
SU-PF3M (for KDE-37/42XS955)
To Customers
Sufficient expertise is required for installing the specified product. Be sure
to subcontract the installation to Sony dealers or contractors and pay
adequate attention to safety during the installation.
To Sony Dealers
For installation of SONY WALL-MOUNT BRACKET, or SONY
FLOATING STAND, be sure to read and follow the instructions supplied
with those optional products.
Trademark Information
TruSurround, SRS and the symbol are trademarks of SRS Labs, Inc.
TruSurround technology is incorporated under license from SRS Labs, Inc.
Licensed by BBE Sound, Inc. under USP4638258, 4482866. “BBE” and
BBE symbol are trademarks of BBE Sound, Inc.
Steady Sound, Digital Reality Creation, CineMotion, Memory Stick, and
Twin View are registered trademarks of Sony Corporation. BN Smoother
is trademark of Sony Corporation.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
This TV incorporates High-Definition
Multimedia Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
CableCARD™ is a trademark of Cable Television Laboratories, Inc.
This digital television is capable of receiving analog basic, digital basic and
digital premium cable television programming by direct connection to a
cable system providing such programming.
A security card provided by your cable operator is required to view
encrypted digital programming.
Certain advanced and interactive digital cable services such as
video-on-demand, a cable operator's enhanced program guide and
data-enhanced television services may require the use of a set-top box. For
more information call your local cable operator.
Important
Safeguards
Before using your TV, please read these instructions completely, and keep
this manual for future reference.
Carefully observe and comply with all warnings, cautions and instructions
placed on the unit or described in the operating instructions or service
manual.
WARNING
To guard against injury, the following basic safety precautions should be
observed in the installation, use and servicing of the unit.
Use
Power Sources
This unit should be operated only from the type of
power source indicated on the serial/model plate.
If you are not sure of the type of electrical power
supplied to your home, consult your dealer or local
power company. For those sets designed to operate
from battery power, refer to the operating
instructions.
Grounding or Polarization
This unit is equipped with a polarized AC power cord plug (a plug having
one blade wider than the other), or with a three-wire grounding type plug
(a plug having a third pin for grounding). Follow the instructions below:
For the unit with a polarized AC power cord plug
This plug will fit into the power outlet only
one way. This is a safety feature. If you are
unable to insert the plug fully into the
outlet, try reversing the plug.
If the plug still fails to fit, contact your
electrician to have a suitable outlet installed. Do not defeat the safety
purpose of the polarized plug by forcing it in.
Wall outlet
Do not use a poor fitting outlet.
Insert the plug fully into the outlet. If it is loose, it
may cause arcing and result in fire.
Contact your electrician to have the outlet changed.
Wiring
For your safety, unplug the AC power cord when wiring cables.
Moisture
Do not touch the AC power cord or the unit with a
wet hand.
If you plug/unplug the AC power cord from the unit
with a wet hand, it may cause electric shock.
3
Cleaning
Clean the AC power plug regularly.
If the plug is covered with dust and it picks up
moisture, its insulation may deteriorate and result in
fire. Unplug the AC power plug and clean it
regularly.
For the unit with a three-wire grounding type AC
plug
This plug will only fit into a grounding-type power
outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician
to have a suitable outlet installed. Do not defeat the
safety purpose of the grounding plug.
Overloading
Do not overload wall outlets, extension cords or
convenience receptacles beyond their capacity, since
this can result in fire or electric shock.
Always turn the unit off when it is not being used.
When the unit is left unattended and unused for
long periods of time, unplug it from the wall outlet
as a precaution against the possibility of an internal
malfunction that could create a fire hazard.
If a snapping or popping sound from a TV unit is
continuous or frequent while the TV is operating,
unplug the TV and consult your dealer or service
technician. It is normal for some TV sets to make
occasional snapping or popping sounds, particularly
when being turned on or off.
AC power cord
If you damage the AC power cord, it may result in fire or electric shock.
sDo not pinch, bend, or twist the cord excessively. The core lines may
be bared and cut, and cause short-circuit, resulting in fire or electric
shock.
sDo not convert or damage the AC power cord or display interface
cable.
sDo not put anything heavy on the AC power cord. Do not pull the
AC power cord.
sKeep the AC power cord away from heat sources.
sBe sure to grasp the plug when disconnecting the AC power cord.
If the AC power cord is damaged, stop using it and ask your dealer or Sony
service center to exchange it.
Batteries
Do not dispose of batteries in fire.
Do not short circuit, disassemble or overheat the batteries.
Object and Liquid Entry
Never push objects of any kind into the unit through
the cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the
unit.
Do not place any objects on the unit.
The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
Ventilation holes
Do not insert anything in the ventilation holes. If metal
or something flammable enters, it may result in fire or
electric shock.
Cleaning
Unplug the AC power cord when cleaning this unit.
If not, it may result in electric shock.
Clean the cabinet of the TV with a dry soft cloth. To
remove dust from the screen, wipe it gently with a
soft cloth. Stubborn stains may be removed with a
cloth slightly dampened with a solution of mild soap and warm water.
Never use strong solvents such as thinner or benzine for cleaning.
If the picture becomes dark after using the TV for a long period of time, it
may be necessary to clean the inside of the TV. Consult qualified service
personnel.
Attachments
Do not use attachments not recommended by the
manufacturer, as they may cause hazards.
Medical institution
Do not place this unit in a place where medical
equipment is in use.
It may cause malfunction of medical instruments.
Moisture and flammable objects
sDo not use power-line operated sets near
water — for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
It may result in fire or electric shock.
sDo not let this unit get wet. Never spill liquid
of any kind on the unit. If any liquid or solid
object does fall through, do not operate the
unit. It may result in electric shock or damage
to the unit. Have it checked immediately by
qualified personnel.
sTo prevent fire, keep inflammable objects or naked lights (e.g.
candles) away from the unit.
Accessories
Do not place the unit on an unstable cart, stand, table or
shelf. The unit may fall, causing serious injury to a child
or an adult and serious damage to the unit. Use only a
cart or stand recommended by Sony for the specific
model of TV. No part of the TV unit should overhang
any edge of the TV cart or stand; any overhanging edge
is a safety hazard. An appliance and cart combination
should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the appliance and
cart combination to overturn.
(Continued)(Continued)
4
Dispose of used batteries
To preserve our environment, dispose the used batteries according to your
local laws or regulations.
Damage requiring service
If the surface of the TV cracks, do not touch it until you unplug the AC
power cord.
Otherwise electric shock may result.
Broken pieces
Do not throw anything at the unit.
The screen glass may break by the impact and cause serious injury.
Cable wiring
Take care not to catch your feet on the cables. It may damage the unit.
Heat
Do not touch the surface of the TV.
It remains hot, even for some time after the TV is turned off.
Volume adjustment
Adjust the volume so as not to trouble your neighbors. Sound carries very
easily at night time. Therefore, closing the windows or using headphones
is suggested.
When using headphones, adjust the volume so as to avoid excessive levels,
as hearing damage may result.
Installation and moving
Installation
When installing or removing the TV on the
wall, be sure to use qualified contractors.
Wall mount installation requires the use of a
wall-mount bracket. If the TV is installed or
removed from the wall by a person other than
a qualified contractor, the unit may fall and
cause serious injury if the unit is not installed
securely.
Placement for viewing
It is recommended to watch the TV at a distance of 3-7 times that of the
screen, and in moderate brightness. Watching the TV for too long or in a
dark room will cause eye fatigue.
Optional accessories
Observe the following when installing the TV using a
stand or wall-mount bracket. If the TV is not secured
properly, it may fall and cause injury.
sBe sure to follow the operating instructions
supplied with your stand or wall-mount bracket
when installing the unit.
sBe sure to attach the brackets supplied with your stand or
wall-mount bracket.
Protruding location
Do not install the TV in protruding locations. If you install the unit in the
following locations, injury may result.
sDo not install the unit in a location where the unit protrudes, such as
pillars.
sDo not install the unit in a location that may cause facial injury.
Oils
Do not install this unit in restaurants where oily vapors occur. Dust
absorbing oil may enter into the unit and damage the unit.
Corrosion
Use of this set near the seashore may subject the set to excessive salt,
corrosion and internal damage and result in deterioration of the set’s
performance. If the set will be subjected to these conditions, steps should
be taken to reduce the humidity and temperature of the area where the set
is located.
Ventilation
The slots and openings in the TV are provided for necessary ventilation. To
ensure reliable operation of the unit, and to protect it from overheating,
these slots and openings must never be blocked or covered.
Unless proper ventilation is provided, the unit may
gather dust and get dirty. For proper ventilation,
Observe the following:
sDo not install the unit turned backward or
sideways.
sDo not install the unit turned over or upside
down.
sNever cover the slots and openings with a
cloth or other materials.
sNever block the slots and openings by
placing the unit on a bed, sofa, rug or other
similar surface.
sNever place the unit in a confined space, such as
a bookcase or built-in cabinet, unless proper
ventilation is provided.
sDo not place the unit near or over a radiator or
heat register, or where it is exposed to direct
sunlight.
Carry the TV in the specified manner
Carrying the TV requires at least two people.
If you carry the TV in a manner other than that specified and without
the specified number of persons, it may drop and a serious injury may
result. Be sure to follow the instructions given below.
sCarry the TV with the specified number of
persons.
sCarry the TV holding the upper and bottom
frames of the TV as illustrated. Do not carry
by the clear plastic front panel.
sHold the TV securely when carrying it.
sAs the glass surface of the TV has a special coating, be careful to
avoid touching the glass surface as far as possible.
sWhen transporting, do not subject the unit to shocks or vibration, or
excessive force.
6
Antenna Grounding According to the National
Electrical Code, ANSI/NFPA 70
Lightning
For added protection for this TV receiver during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna. This will prevent damage to the
receiver due to lightning and power-line surges.
Service
Damage Requiring Service
Unplug the unit from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
sWhen the power cord or plug is damaged
or frayed.
sIf liquid has been spilled into the unit.
sIf the unit has been exposed to rain or water.
sIf the unit has been subject to excessive shock
by being dropped, or the cabinet has been
damaged.
sIf the unit does not operate normally when
following the operating instructions. Adjust only
those controls that are specified in the operating
instructions. Improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the unit to normal operation.
sWhen the unit exhibits a distinct change in
performance, it indicates a need for service.
Servicing
Do not attempt to service the unit yourself since opening
the cabinet may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
Replacement Parts
When replacement parts are required, be sure the service
technician certifies in writing that he/she has used
replacement parts specified by the manufacturer that
have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric
shock or other hazards.
Safety Check
Upon completion of any service or repairs to the unit,
ask the service technician to perform routine safety
checks (as specified by the manufacturer) to determine
that the unit is in safe operating condition, and to so
certify. When the unit reaches the end of its useful life,
improper disposal could result in a picture tube
implosion. Ask a qualified service technician to dispose
of the unit.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
Antenna lead-in wire
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Ground clamps
Power service grounding
electrode system
(NEC Art 250 Part H)
Ground clamps
Electric service
equipment
NEC: National Electrical Code
7
Contents
Introducing the TV
Welcome...............................................................................................11
Package Contents..........................................................................11
Features .........................................................................................12
Setting Up the TV
Overview ..............................................................................................15
TV Controls and Connectors..............................................................16
Front panel .....................................................................................16
Side panel ......................................................................................17
Rear panel......................................................................................18
Connecting the Power Cord ...............................................................20
Preventing the TV from Toppling Over...........................................21
Bundling the Connecting Cables....................................................22
Basic Connections: Connecting a Cable or Antenna ......................23
Cable or Antenna ...........................................................................24
Cable Box and Antenna .................................................................25
Cable Box.......................................................................................26
Connecting Optional Equipment .......................................................28
Making Video Connections ............................................................28
About Using S VIDEO ....................................................................29
VCR and Cable ..............................................................................30
VCR and Cable Box .......................................................................32
Two VCRs for Tape Editing............................................................34
Satellite Receiver ...........................................................................36
Satellite Receiver and VCR............................................................38
DVD Player with Component Video Connectors............................41
DVD Player with S VIDEO and Audio Connectors.........................43
Digital Satellite Receiver with HDMI Connector .............................44
DVD Player or Digital Satellite Receiver via AV Receiver with
CENTER SPEAKER IN Terminals..........................................46
Camcorder .....................................................................................48
Audio Receiver...............................................................................49
Sub Woofer ....................................................................................49
Device with an Optical (Digital Audio) Connector ..........................50
Using the CONTROL S Feature.....................................................50
Using CableCARD™............................................................................51
Activating CableCARD™ Service ...................................................51
Removing the CableCARD™..........................................................52
Setting Up the Channel List ...............................................................53
Using Auto Setup ...........................................................................53
8
Using the Remote Control
Overview ..............................................................................................55
Inserting Batteries...............................................................................55
Button Descriptions ............................................................................56
Programming the Remote Control.....................................................58
Using Other Equipment with Your Remote Control.........................60
Operating a Cable Box...................................................................60
Operating a Satellite Receiver .......................................................60
Operating a VCR............................................................................61
Operating a DVD Player or DVD Changer .....................................61
Operating a 5.1ch DVD AV System (Sony DAV) ...........................62
Operating a DVD/VCR Combo Unit ...............................................62
Operating an AV Receiver .............................................................62
Using the Features
Overview ..............................................................................................63
Watching TV.........................................................................................64
Using the Program Guide ...................................................................65
Displaying the Program Guide .......................................................65
Using Additional Program Guide Options ......................................66
Using Wide Screen Mode ...................................................................67
Using Twin View ..................................................................................69
Displaying Twin Pictures ................................................................69
Activating the Picture .....................................................................70
Changing the Picture Size..............................................................71
Using Favorite Channels ....................................................................72
Using the Channel Menu................................................................72
Using the Favorite Channels Guide ...............................................73
9
Using the Memory Stick Viewer
About Memory Stick............................................................................75
Features .........................................................................................75
Memory Stick Compatibility............................................................76
Memory Stick Functionality ............................................................76
File Compatibility............................................................................77
Trademark Information...................................................................77
Inserting and Removing a Memory Stick ..........................................78
Inserting a Memory Stick................................................................78
Inserting the Memory Stick DUO....................................................79
Removing a Memory Stick .............................................................80
Using the Memory Stick Index ...........................................................81
Using the Memory Stick Index .......................................................82
Viewing Photos....................................................................................83
Photo Controls ...............................................................................83
Photo Menu Bar Options................................................................84
Using Zoom and Pan .....................................................................85
Using Rotate ..................................................................................85
Playing Movies ....................................................................................86
Movie Controls ...............................................................................86
Movie Menu Bar Options................................................................87
Memory Stick Index Menu Bar Options.............................................88
Slide Show Menu Options..............................................................88
Contents Menu Options .................................................................89
Memory Stick Menu .......................................................................89
Notes on Using Memory Stick Media ................................................90
About DCF File Names ..................................................................90
Memory Stick Precautions .............................................................90
Using the Menus
Overview ..............................................................................................91
Navigating Through Menus ................................................................91
Using the Video Menu.........................................................................92
Selecting Video Options.................................................................92
Using the Audio Menu ........................................................................95
Selecting Audio Options.................................................................95
Using the Screen Menu.......................................................................97
Selecting Screen Options...............................................................97
Using the Channel Menu ....................................................................99
Selecting Channel Options.............................................................99
Using the Parental Lock Menu .........................................................101
Selecting Parental Lock Options ..................................................101
US Models: Selecting Custom Rating Options.............................102
Viewing Blocked Programs ..........................................................102
Canadian Models: Selecting Custom Rating Options ..................103
Viewing Blocked Programs ..........................................................103
Using the Setup Menu.......................................................................104
Selecting Setup Options...............................................................104
Programming Caption Vision .......................................................106
Using the Applications Menu ...........................................................107
Selecting Applications Options.....................................................107
10
Other Information
Overview ............................................................................................109
Glossary .............................................................................................110
Contacting Sony................................................................................111
Troubleshooting ................................................................................111
Twin View.....................................................................................111
Remote Control ............................................................................112
CableCARD™...............................................................................112
Channels ......................................................................................113
Memory Stick ...............................................................................114
Audio ............................................................................................115
Video ............................................................................................116
General ........................................................................................117
Specifications ....................................................................................118
Optional Accessories........................................................................120
Index ...................................................................................................121
11
Introducing the TV
Welcome
Thank you for purchasing the Sony Flat Panel Color TV. This manual is to
be used with the following models:
sKDE-37XS955
sKDE-42XS955
sKDE-50XS955
Package Contents The package contains the following:
sFlat panel color TV
sRemote control (RM-Y1004) and two size AA batteries
sAC power cord
sAC plug holder
sCable band (1)
sCable band screw (1)
sAC cord clamp
sCleaning cloth
sOperating Instructions
sQuick Setup Guide
sWarranty Card
These items are all you need to set up and operate the TV in its basic
configuration.
Most components (VCRs, DVD players, etc.) come with the necessary
cables to connect them. If you want to set up a complex system, you may
need to buy extra cables, connectors, etc. Be sure to have these on hand
before you start to connect your system.
(Continued)
12
Welcome
Features Some of the features that you will enjoy with your new TV include:
sIntegrated HDTV: You can watch digital television programs and
enjoy the improved audio/video quality offered by these programs.
sCableCARD™ slot: Provides cable subscribers with access to digitally
encrypted cable channels — without the need for a set-top box — that
will enable you to receive not only standard definition but also high
definition television. The CableCARD™, which is provided by your
cable TV company, is inserted into the TV’s rear panel CableCARD™
slot. After the service is activated with your cable TV company, the card
replaces the need for a separate set-top box. (Check with your cable TV
company about CableCARD™ service details, limitations, pricing, and
availability. For more information about CableCARD™ in this manual,
see pages 18 and 51.)
sWEGA Engine™: Delivers superb picture quality from any video
source by minimizing the signal deterioration caused by digital-to-
analog conversion and stabilizing the signal processing. The WEGA
engine features unique Sony technology, including:
• The first step in the digital processing system, Composite
Component Processor2 (CCP2), which enhances input signal to
noise ratio by chroma decoder digital processing;
•DRC (Digital Reality Creation®) MultiFunction 2 circuitry:
Enables the digital mapping of any NTSC source (DVD, VHS, DBS,
Cable, etc.), to create a picture that is precise and finer in detail,
rivaling high definition resolution. Incoming HD signals (1080i) are
also bitmapped, utilizing Sony’s proprietary algorithm to provide a
crisp and clear picture;
•IFP (Image Format Processor): The Digital Texture Enhancer
function of this chip provides the optimal contrast by utilizing a wide
dynamic range. This chip also reduces signal noise, by using an
improved motion vector algorithm, while maintaining image
sharpness.
•New Panel Driver LSI: This drive provides a more realistic color
expression by improving the color space of the original signal and
color gradation.
sS-master Full Digital Amplifier: Delivers superb clear dialog and
reproduces the original sound quality while minimizing any sound
fragmentation or jitter noise.
sBN Smoother™: Reduces the block noise caused by digital video
encoding and decoding process.
sCineMotion®: Provides an optimized display by automatically
detecting film content and applying a reverse 3/2 pulldown process.
Moving pictures will appear clearer and more natural-looking.
13
Welcome
sWide Screen Mode: Watch conventional 4:3 aspect ratio broadcasts in
wide screen (16:9) mode.
sFavorite Channels: Allows you to preview and select from 16 of your
favorite channels.
sSteady Sound®: Equalizes volume levels so there is consistent output
between programs and commercials.
sMemory Stick® Viewer: Allows you to view on your TV screen digital
images (JPEG) and movies (MPEG1) with background music (MP3)
that are stored on Memory Stick media.
sComponent Video Inputs: Offers the best video quality for DVD (480p
and 480i), and digital set-top box (1080i, 720p, 480p and 480i)
connections.
sParental Control: V-Chip technology allows parents to block
unsuitable programming from younger viewers.
sHDMI (High-Definition Multimedia Interface): Provides an
uncompressed, all-digital audio/video interface between this TV and
any HDMI-equipped audio/video component, such as a set-top box,
DVD player, and A/V receiver. HDMI supports enhanced, or high-
definition video, plus two-channel digital audio.
15
Setting Up the TV
Overview
This chapter includes illustrated instructions for setting up your TV.
Topic Page(s)
TV Controls and Connectors 16-19
Connecting the Power Cord 20-22
Basic Connections: Connecting a Cable or Antenna 23-27
Connecting Optional Equipment
Making Video Connections
About Using S VIDEO
VCR and Cable
VCR and Cable Box
Two VCRs for Tape Editing
Satellite Receiver
Satellite Receiver and VCR
DVD Player with Component Video Connectors
DVD Player with S VIDEO and Audio Connectors
Digital Satellite Receiver with HDMI Connector
DVD Player or Digital Satellite Receiver via AV Receiver with
CENTER SPEAKER IN Terminals
Camcorder
Audio Receiver
Sub Woofer
Device with an Optical (Digital Audio) Connector
Using the CONTROL S Feature
28
29
30
32
34
36
38
41
43
44
46
48
49
49
50
50
Using CableCARD™51
Setting Up the Channel List 53
16
Setup
TV Controls and Connectors
Front panel
Item Description
1Speakers
(Left/Right)
Outputs audio signal.
2PICTURE OFF
LED
When lit, indicates that the Picture Off feature is activated.
For details, see page 56.
3TIMER LED When lit, indicates one of the timers is set. When the timer
is set, this LED will remain lit even if the TV set is turned
off. For details, see page 107.
4STANDBY LED When in standby mode, the LED lights up in red.
5POWER LED Lights up in green when the TV set is turned on. The LED
does not light up when the main power is turned off. If the
LED blinks in red continuously, this may indicate the
display unit needs servicing (see “Contacting Sony” on
page 111).
6(IR) Infrared
Receiver
Receives IR signals from the remote control.
PICTURE OFF TIMER STANDBY POWER
17
Setup
Side panel
PRO
STD/DUO
S
VIDEOLR
VIDEO
VIDEO 2 IN
AUDIO
(MONO)
POWER
TV/VIDEO
VOLUME
CHANNEL
Left side
Right side
Item Description
1Memory Stick
indicator
When lit, indicates that the Memory Stick is being read.
(Do not remove the Memory Stick when the indicator is lit.)
2Memory Stick
slot
Memory Stick insertion slot. For details, see “Inserting and
Removing a Memory Stick” on page 78.
3VIDEO 2 IN
S VIDEO
Connects to the S VIDEO OUT jack on your camcorder or
other video equipment that has S VIDEO. Provides better
picture quality than composite video (4).
4VIDEO 2 IN
VIDEO/
L (MONO)-
AUDIO-R
Connects to the composite A/V output jacks on your
camcorder or other video equipment.
5Main POWER Press to turn on and off the main power of the TV.
6+ CHANNEL – Press to scan through channels. To scan quickly through
channels, press and hold down either CHANNEL.
7+ VOLUME – Press to adjust the volume.
8TV/VIDEO Press repeatedly to cycle through the video equipment
connected to the TV’s video inputs.
18
Setup
Rear panel
CABLE
CableCARD
CableCARD
R-AUDIO -L
R-AUDIO -L
R-AUDIO -L R-AUDIO -L
VIDEO
S
VIDEO
CENTER SPEAKER IN
CONTROL S
IN
OUT
VIDEO IN 1
6
3
4
(MONO)
HD/DVD IN
(1080i/720p/480p/480i)(VAR/FIX)
180W ( 6
)MAX
AUDIO OUT
(VAR)
SUBWOOFER OUT
5
OPTICAL OUT
AC IN
YPBPR
VHF/UHF
For KDE-50XS955
Jack Description
1AC IN Connects the supplied AC power cord.
2DIGITAL AUDIO
(OPTICAL) OUT
(PCM/DOLBY*
DIGITAL)
Connect to the optical audio input of a digital audio component that is PCM/Dolby Digital
compatible.
3CableCARD™ slot CableCARD™ provides cable subscribers with access to secure, digitally encrypted cable
channels–without the need for a set-top-box–that will enable you to receive not only
standard definition but also high definition television. For more information, see page 51.
19
Setup
4VIDEO 6 IN
HDMI IN/R-AUDIO-L
HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-digital
audio/video interface between this TV and any HDMI-equipped audio/video component,
such as a set-top box, DVD player, and A/V receiver. HDMI supports enhanced, or high-
definition video, plus two-channel digital audio.
5VIDEO 1/3 IN
VIDEO/
R-AUDIO-L (MONO)
Connect to the composite A/V output jacks on your VCR or other video component. A third
composite A/V input jack (VIDEO 2) is located on the left side panel of the TV.
6HD/DVD 4/5 IN
(1080i/720p/480p/
480i)
Connect to your DVD player’s or digital set-top box’s component video (Y, PB, PR) and
audio (L/R) jacks. Component video provides better picture quality than the S VIDEO (9)
or the composite video (5) connections.
7CABLE RF input that connects to your cable signal.
8VHF/UHF RF input that connects to your VHF/UHF antenna or cable box.
9VIDEO 1/3 IN
S VIDEO
Connects to the S VIDEO OUT jack of your VCR or other video equipment that has
S VIDEO. S VIDEO provides better picture quality than the composite video (5).
0CENTER SPEAKER
IN 180W (6Ω) MAX
Connect the center output terminals of Dolby Pro Logic* system decoder amplifier. You can
use the TV speakers as a center speaker.
qa CONTROL S
IN/OUT
Allows the TV to receive (IN) and send (OUT) remote control signals to other Sony
infrared-controlled audio or video equipment that has the CONTROL S function.
qs SUBWOOFER OUT
(VAR)
Connects to the input jack of your woofer.
qd AUDIO OUT
(VAR/FIX/R/L)
Connects to the left and right audio input jacks of your audio or video equipment. You can
use these outputs to listen to your TV’s audio through your stereo system.
* “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories.
Jack Description
21
Setup
Preventing the TV
from Toppling Over
Prepare a commercially available strong rope or chain and wall anchor
bracket beforehand.
After connections with antennas and other equipment are completed, be sure
to attach a sturdy strong rope or chain securely to each clamp screw, and
attach it to a wall or pillar.
WARNING
Be sure to take measures to prevent stand from toppling over.
If you fail to do so, the TV may topple over and cause injury. Anchor the
TV to a wall, pillar, etc., to prevent it from toppling over.
Rear of TV
Clamp screw
22
Setup
Bundling the
Connecting Cables
You can bundle the connecting cables using the supplied cord clamp with a
cable band at the rear of the TV.
1Bundle the connecting cables.
2Attach the supplied cord clamp for the AC power cord.
3Remove the cable cover.
One side of the cable cover is secured by screws.
4Store the connecting cables.
5Secure the cord clamp and replace the cable cover.
Cord clamp
Rear of TV
Cable band
23
Setup
Basic Connections: Connecting a Cable or Antenna
The way in which you will connect your TV varies, depending on how your
home receives a signal (cable, cable box, antenna) and whether or not you
plan to connect a VCR.
If you are connecting a VCR
sSee the connections described on pages 30 and 32.
If You Are Connecting See Page
Cable or Antenna
sNo cable box or VCR
24
Cable Box and Antenna
sCable box unscrambles only some channels
(usually premium channels)
sNo VCR
25
Cable Box
sCable box unscrambles all channels
sNo VCR
26
24
Setup
Cable or Antenna For best results, use this connection if you are connecting a cable or an
antenna and you:
sDo not need a cable box to unscramble channels. (If you have a cable
box, see page 26.)
sDo not intend to connect a VCR. (If you have a VCR, see pages 30 and
32.)
For antenna connection, use the 75-ohm coaxial cable (not supplied).
Note on Using This Connection
Cable Type Connect As Shown
VHF Only or
combined
VHF/UHF
Cable
When using an indoor antenna, such as rabbit-ear or dipole-
antenna, keep the antenna away from the display unit. If not,
noise may appear on the screen.
VHF/UHF
75-ohm
coaxial
cable
CABLE
75-ohm
coaxial
cable
To Do This ... Do This ...
Switch the TV’s input between
the cable and antenna
Press ANT to switch back and forth between the TV’s VHF/UHF and CABLE
inputs.
26
Setup
Cable Box For best results, use this connection if:
sYour cable company scrambles all channels, which requires you to use a
cable box.
sYou do not have a VCR. (If you have a VCR, see pages 30 and 32.)
With this connection you can:
sUse the remote control to change channels coming through the cable
box to the TV’s VHF/UHF jack. (You must first program the remote
control for your specific cable box, see page 58.)
To connect the cable box
1Connect the CATV cable to the cable box’s input jack.
2Use the 75-ohm coaxial cable (not supplied) to connect the cable box’s
output jack to the TV’s VHF/UHF jack.
3Run the Auto Setup program, as described in “Setting Up the Channel
List” on page 53.
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, all channels come into the TV through your cable box and
only one unscrambled signal is sent to the TV, so you cannot use the dual picture
features. If some of your channels are scrambled, but others are not, consider using
the “Cable Box and Antenna” connection on page 25 instead.
zBefore connecting a
cable box, See “Using
CableCARD™” on
page 51.
VHF/UHF
75-ohm coaxial cable
OUT
IN
Cable Box
CATV
cable
Rear of TV
27
Setup
Notes on Using This Connection
To Do This ... Do This ...
Use the cable box Tune the TV to the channel the cable box is set to (usually channel 3 or 4) and then
use the cable box to switch channels.
Set up the remote control to
operate the cable box
Program the remote control. See “Programming the Remote Control” on page 58.
Activate the remote control to
operate the cable box
Press SAT/CABLE (FUNCTION).
Prevent the accidental switching
of TV channels
When using the cable box, you need the TV to stay on the channel the cable box is
set to (usually channel 3 or 4). You can use the TV’s Channel Fix feature to lock in a
specific channel. For details, see “Using the Channel Menu” on page 99.
Do not leave the display indication of the cable box turned on.
29
Setup
About Using
S VIDEO
If the optional equipment you are connecting has an S VIDEO jack
(shown at left), you can use an S VIDEO cable for improved picture
quality (compared to an A/V cable). Because S VIDEO carries only
the video signal, you also need to connect audio cables for sound, as
shown below.
Example of an S VIDEO Connection
R-AUDIO -L VIDEO
S
VIDEO
(MONO)
VIDEO IN 1
3
S VIDEO
cable
Audio cable
Rear of TV
Equipment with S VIDEO
30
Setup
VCR and Cable For best results, use this connection if:
sYour cable company does not require you to use a cable box.
To connect the VCR and cable
1Connect the CATV cable to the single (input) jack of the splitter.
2Using the 75-ohm coaxial cable (not supplied), connect one of the
output jack of the splitter to the TV’s CABLE jack.
3Using a coaxial cable, connect the splitter’s other output jack to the
VCR’s input jack.
4Use an A/V cable to connect the VCR’s A/V output jacks to the TV’s
A/V input jacks (VIDEO 1 or 3).
5Run the Auto Program function, as described in “Setting Up the
Channel List” on page 53.
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, you can use all the dual picture features.
Using S VIDEO jacks? See page 29.
CABLE
R-AUDIO -L VIDEO
S
VIDEO
VIDEO IN 1
3
(MONO)
Rear of TV
A/V cable
75-ohm
coaxial cable
VCR
Coaxial cable
Splitter
CATV
cable
31
Setup
Notes on Using This Connection
To Do This ... Do This ...
Watch the VCR Press TV/VIDEO repeatedly to select the VCR input (VIDEO 1 in the illustration).
Watch cable channels Press TV/VIDEO repeatedly to select the cable input (CABLE in the illustration).
Set up the remote control to
operate the VCR
If you have a non-Sony VCR, you must program the remote control. See
“Programming the Remote Control” on page 58.
Activate the remote control to
operate the VCR
Press DVD/VCR (FUNCTION).
Control VCR functions with the
remote control
See “Operating a VCR” on page 61.
Label video inputs to easily
identify equipment connected to
the TV
See the instructions for setting up Video Labels on page 105.
Do not leave the display indication of the VCR turned on.
32
Setup
VCR and Cable Box For best results, use this connection if:
sYour cable company scrambles some channels, such as premium
channels (which requires you to use a cable box), but does not scramble
all channels.
With this connection you can:
sUse the remote control to change channels coming through the cable
box. You must first program the remote control for your specific cable
box; see “Programming the Remote Control” on page 58.
sUse the remote control to change channels coming directly into the TV’s
CABLE input jack. (The TV’s tuner provides a better signal than the
cable box.)
sRecord channels coming through the cable box and channels coming
directly into the TV.
To connect a VCR and cable box, you need:
sA splitter, which is a small, inexpensive device that you can purchase at
your local electronics store.
sFour coaxial cables.
sTwo A/V cable or two S VIDEO cable with audio cables.
To connect the VCR and cable box
1Connect the CATV cable to the single (input) jack of the splitter.
2Use a coaxial cable to connect one of the splitter’s two output jacks to
the TV’s CABLE input jack.
3Use a coaxial cable to connect the splitter’s other output jack to the
cable box’s input jack.
4Use a coaxial cable to connect the cable box’s output jack to the VCR’s
RF input jack.
5Use an A/V cable to connect the cable box’s A/V output jacks to the
TV’s A/V input jacks.
6Use an A/V cable to connect the VCR’s A/V output jacks to the TV’s
A/V input jacks (VIDEO 1 or 3).
7Run the Auto Setup program, as described in “Setting Up the Channel
List” on page 53.
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, you can use all the dual picture features.
Using S VIDEO jacks? See page 29.
zBefore connecting a
cable box, See “Using
CableCARD™” on
page 51.
34
Setup
Two VCRs for Tape
Editing
Connecting two VCRs lets you record from one VCR to the other. By
connecting them as shown below, you can view (monitor) what is being
recorded.
To connect two VCRs for tape editing
1Use an A/V cable to connect the playback VCR’s A/V output jacks to
the recording VCR’s A/V input jacks.
2Use an A/V cable to connect the recording VCR’s A/V output jacks to
the TV’s A/V input jacks (VIDEO 1 or 3).
Using S VIDEO jacks? See page 29.
R-AUDIO -L VIDEO
(MONO)
S
VIDEO
VIDEO IN 1
3
Rear of TV
Recording VCR
A/V cable
Playback VCR
A/V cable
When connecting two VCRs for tape editing;
– you cannot edit a tape with copy protection.
– do not connect the TV’s A/V input jack and output jack to
your VCRs at the same time to avoid looping the signal.
35
Setup
Notes on Using This Connection
To Do This ... Do This ...
View (monitor) what is being
recorded
Press TV/VIDEO repeatedly to select the VCR input (VIDEO 1 in the illustration).
Set up the remote control to
operate the VCR(s)
If you have a non-Sony VCR, you must program the remote control. See
“Programming the Remote Control” on page 58.
Activate the remote control to
operate the VCR(s)
Press DVD/VCR (FUNCTION).
Control VCR functions with the
remote control
See “Operating a VCR” on page 61.
Label video inputs to easily
identify equipment connected to
the TV
See the instructions for setting up Video Labels on page 105.
36
Setup
Satellite Receiver To connect a satellite receiver
1Connect the satellite antenna cable to the satellite receiver’s satellite
input jack.
2Use an A/V cable to connect the satellite receiver’s A/V output jacks to
the TV’s A/V input jacks (VIDEO 1 or 3).
3Connect the 75-ohm coaxial cable (not supplied) from your cable or
antenna to the TV’s CABLE or VHF/UHF input jack.
4Run the Auto Setup program, as described in “Setting Up the Channel
List” on page 53.
Using S VIDEO jacks? See page 29.
VHF/UHF
CABLE
R-AUDIO -L VIDEO
VIDEO IN 1
3
(MONO)
S
VIDEO
S
VIDEO
Rear of TV
A/V cable
Satellite Receiver
CATV
cable
75-ohm
coaxial
cable
Satellite
antenna
cable
37
Setup
Notes on Using This Connection
To Do This ... Do This ...
Watch the satellite receiver Press TV/VIDEO repeatedly to select the satellite receiver input
(VIDEO 1 in the illustration).
Set up the remote control to operate the satellite
receiver
If you have a non-Sony satellite receiver, you must program the
remote control. See “Programming the Remote Control” on page 58.
Activate the remote control to operate the
satellite receiver
Press SAT/CABLE (FUNCTION).
Control satellite receiver functions with the
remote control
See “Operating a Satellite Receiver” on page 60.
Label video inputs to easily identify equipment
connected to the TV
See the instructions for setting up Video Labels on page 105.
Do not leave the Electronic Program Guide and display
indication turned on.
39
Setup
R-AUDIO -L VIDEO
(MONO)
CABLE
VIDEO IN 1
3
S
VIDEO
S
VIDEO
A/V cable
Satellite Receiver
75-ohm
coaxial cable
Satellite
antenna
cable
CATV
cable
A/V cable
VCR
Rear of TV
Splitter
75-ohm
coaxial cable
75-ohm
coaxial
cable
(Continued)
40
Setup
Notes on Using This Connection
To Do This ... Do This ...
Watch the satellite receiver Press TV/VIDEO repeatedly to select the VCR input (VIDEO 1 in the illustration).
The VCR may need to be turned on and set to the satellite receiver input.
Watch the VCR Press TV/VIDEO repeatedly to select the input to which the VCR is connected
(VIDEO 1 in the illustration).
Set up the remote control to
operate the satellite receiver or
VCR
If you have a non-Sony VCR or satellite receiver, you must program the remote
control. See “Programming the Remote Control” on page 58.
Activate the remote control to
operate the satellite receiver or
VCR
For the satellite receiver, press SAT/CABLE (FUNCTION). For the VCR, press
DVD/VCR (FUNCTION).
Control satellite receiver and
VCR functions with the remote
control
See “Operating a Satellite Receiver” on page 60 and “Operating a VCR” on page 61.
Label video inputs to easily
identify equipment connected to
the TV
See the instructions for setting up Video Labels on page 105.
Do not leave the Electronic Program Guide and display
indication turned on.
41
Setup
DVD Player with
Component
Video Connectors
For best results, use this connection if your DVD player has component
video (Y, PB, PR) jacks.
To connect a DVD player with component video connectors
1Use a component video cable to connect the DVD player’s Y, PB and PR
output jacks to the Y, PB and PR input jacks (VIDEO 4 or 5) on the TV.
2Use an audio cable to connect the DVD player’s audio output jacks to
the TV’s VIDEO 4 or 5 audio input jacks.
The Y, PB and PR jacks on your DVD player are sometimes
labeled Y, CB and CR, or Y, B-Y and R-Y. If so, connect the
cables to their matching color jacks.
YPBPR
4
HD/DVD IN
(1080i/720p/480p/480i)
5
R-AUDIO -L
Rear of TV
DVD Player
Component video cable
Audio cable
(Continued)
42
Setup
Notes on Using This Connection
To Do This ... Do This ...
Watch the DVD player Press TV/VIDEO repeatedly to select the DVD input (VIDEO 4 in the illustration).
Set up the remote control to
operate the DVD player
If you have a non-Sony DVD player, you must program the remote control. See
“Programming the Remote Control” on page 58.
Activate the remote control to
operate the DVD player
Press DVD/VCR (FUNCTION).
Control DVD functions with the
remote control
See “Operating a DVD Player or DVD Changer” on page 61.
Label video inputs to easily
identify equipment connected to
the TV
See the instructions for setting up Video Labels on page 105.
You cannot record the signal from any equipment connected
into the Y, PB, PR jacks.
Do not leave a still image, such as the DVD menu, displayed on
the screen.
43
Setup
DVD Player with
S VIDEO and Audio
Connectors
Use this connection if your DVD player does not have component video (Y,
PB, PR) jacks.
To connect a DVD player with A/V connectors
1Use an S VIDEO cable to connect the DVD player’s S VIDEO jack to
the TV’s S VIDEO input jack (VIDEO 1 or 3).
2Use an audio cable to connect the DVD player’s audio output jacks to
the TV’s VIDEO 1 or 3 audio input jacks.
Notes on Using This Connection
R-AUDIO -L VIDEO
S
VIDEO
(MONO)
VIDEO IN 1
3
Rear of TV
DVD Player
Audio cable
S VIDEO cable
To Do This ... Do This ...
Watch the DVD player Press TV/VIDEO repeatedly to select the DVD input (VIDEO 1 in the illustration).
Set up the remote control to
operate the DVD player
If you have a non-Sony DVD player, you must program the remote control. See
“Programming the Remote Control” on page 58.
Activate the remote control to
operate the DVD player
Press DVD/VCR (FUNCTION).
Control DVD functions with the
remote control
See “Operating a DVD Player or DVD Changer” on page 61.
Label video inputs to easily
identify equipment connected to
the TV
See the instructions for setting up Video Labels on page 105.
Do not leave a still image, such as the DVD menu, displayed on
the screen.
44
Setup
Digital Satellite
Receiver with HDMI
Connector
To connect a Digital Satellite Receiver with HDMI connector
1Use a HDMI cable to connect the Digital Satellite Receiver’s HDMI
output connector to the TV’s HDMI IN connector (VIDEO 6).
To connect a Digital satellite receiver with DVI-HDTV connector
If the Digital Satellite Receiver does not have an HDMI connector, you can
connect the TV’s HDMI IN connector to the Digital Satellite Receiver’s
DVI-HDTV OUT connector using the HDMI cable (not supplied).
1Use a HDMI to DVI-HDTV adapter or cable (not supplied) to connect
the Digital Satellite Receiver’s DVI-HDTV OUT connector to the TV’s
HDMI IN connector (VIDEO 6).
HDMI cables transmit both audio and video signals. (Separate
audio cables are not necessary.) You can purchase HDMI
cables at your local electronics store.
R-AUDIO -L
6
Rear of TV
Digital Satellite Receiver
HDMI cable
The DVI-HDTV VIDEO connector does not provide audio, so
audio cables must be connected to provide sound when an
HDMI to DVI-HDTV adapter is used.
45
Setup
2Use an Audio cable to connect the Digital Satellite Receiver’s AUDIO
OUT jacks to the TV’s AUDIO IN jacks (VIDEO 6).
Notes on Using This Connection
R-AUDIO -L
6
Digital Satellite Receiver
HDMI to DVI-HDTV
adapter or cable
(not supplied)
Audio cable (not supplied)
Rear of TV
To Do This ... Do This ...
Watch the digital satellite
receiver
Press TV/VIDEO repeatedly to select the digital satellite receiver input (VIDEO 6 in
the illustration).
Label video inputs to easily
identify equipment connected
to the TV
See the instructions for setting up Video Labels on page 105.
Do not leave the Electronic Program Guide and display
indication turned on.
Do not connect to a PC to the TV with the DVI cable.
47
Setup
When using the TV’s speakers as the center speaker
Using Center Speaker In in the AUDIO menu, select the video input for
which you want to use the TV’s speakers as the center speaker, and set to
On.
4
HD/DVD IN
(1080i/720p/480p/480i)
5
R-AUDIO -L
YP
B
P
R
CENTER SPEAKER IN
180W ( 6
)MAX
AM
COAXIAL
FM
75
VIDEO OUTAUDIO OUT
SCAN SELECT
SELECTABLE
INTERLACE
VIDEO INAUDIO IN
RL
R
P
B
/C
B
P
R
/C
R
Y
L
VIDEO 2
VIDEO 2
MONITOR OUT
VIDEO 1
COMPONENT VIDEO OUT
SPEAKER
COMPONENT
VIDEO OUT
VIDEO IN
VIDEO
OPTICAL
DIGITAL
IN
S VIDEO
AUDIO IN
RL
CENTER FRONT LFRONT R
SURR LSURR R
SUB
WOOFER
AUDIO
OUT
Rear of TV
Component
video cable
Audio cable
SPEAKER cord
DVD Player or
Digital Satellite Receiver
AV Receiver
Optical digital cable
48
Setup
Camcorder For easy connection of a camcorder, the TV has front A/V input jacks. If you
prefer, you can connect the camcorder to the TV’s rear A/V input jacks.
To connect a camcorder
Use an A/V cable to connect the camcorder’s A/V output jacks to the TV’s
A/V input jacks (VIDEO 2).
Notes on Using This Connection
Using S VIDEO jacks? See page 29.
LR
VIDEOAUDIO
(MONO)
A/V cable
Left side of TV
Camcorder
To A/V output
To Do This ... Do This ...
Watch the camcorder Press TV/VIDEO repeatedly to select the camcorder input (VIDEO 2 in the
illustration).
Label video inputs to easily
identify equipment connected to
the TV
See the instructions for setting up Video Labels on page 105.
Do not leave a still image of the camcorder or digital camera
displayed on the screen.
49
Setup
Audio Receiver For improved sound quality, you may want to play the TV’s audio through
your stereo system.
To connect an audio system
1Use an audio cable to connect the TV’s AUDIO OUT jacks to the audio
receiver’s line input jacks.
2Using the TV’s Audio menu, set the Speaker option to Off. Then set the
Audio Out option to Fixed or Variable, depending on how you want to
control the volume. For details, see “Using the Audio Menu” on page
95.
3Turn on the audio receiver, and then set the audio receiver’s line input to
the jack into which you connected the TV.
Sub Woofer Use a monaural audio cable to connect the TV’s SUBWOOFER OUT jack to
the sub woofer’s input jack.
R-AUDIO -L
(VAR/FIX)
AUDIO OUT
Rear of TV
Audio cable
Audio Receiver
To line input
(VAR)
SUBWOOFER OUT
Rear of TV
Sub Woofer
Monaural audio
cable (not supplied)
Sub woofer input
50
Setup
Device with an
Optical (Digital
Audio) Connector
You can use the TV’s digital audio output jack (OPTICAL OUT) to connect
a digital audio device that is PCM/Dolby Digital compatible, such as an
audio amplifier.
sUsing an optical cable, connect the device’s OPTICAL IN jack to the
TV’s OPTICAL OUT jack.
Using the CONTROL
S Feature
CONTROL S allows you to control your system and other Sony equipment
with a single remote control. In addition, the CONTROL S feature allows
you to always point your remote control at your TV, instead of having to
point it at the other equipment, which might be hidden or out of direct line of
sight.
Use CONTROL S IN to send signals to the TV.
Use CONTROL S OUT to send signals to connected equipment.
OPTICAL OUT
OPTICAL
IN
LINE
OUT
LINE
IN
L AUDIO R
Rear of TV
Optical cable
Audio Amplifier
CONTROL S
IN
OUT
Rear of TV
52
Setup
KDE-50XS955
CAUTION: Inserting the CableCARD™ incorrectly may result in permanent
damage to the card and the TV.
2Gently push the card into the slot until it locks into place.
3The CableCARD™ setup screen is displayed. This screen includes
information your cable TV company will request before they can
activate your service.
4Follow the displayed instructions: Phone your cable TV company. A
representative will guide you through the activation process.
5After your CableCARD™ is activated, your cable TV company will
download the service information, including the channel list, to the
CableCARD™.
After the CableCARD™ has acquired channels from your cable TV
company, the TV tunes to the lowest available channel.
Removing the
CableCARD™In the event you want to cancel your service, contact your cable TV
company.
1Push the eject button on the TV’s CableCARD™ slot to release the card.
2Pull the CableCARD™ straight out of the slot to remove it.
To install a different CableCARD™, follow the instructions in “Activating
CableCARD™ Service” on page 51.
CableCARD
zYou can also access
information about your
CableCARD™ in the
Applications Menu (see
page 108).
Once the CableCARD™ is removed, your TV will no longer
decrypt digital cable TV programming services that require
CableCARD™.
Eject button
53
Setup
Setting Up the Channel List
After you finish connecting your TV, you need to run Initial Setup, which
automatically sets up available analog and digital channels. The Initial Setup
screen appears when you turn on your TV for the first time after hooking it
up. If you do not want to set up the channels at this time, you can do it later
by selecting the Auto Program option in the Channel menu (see page 99).
Using Auto Setup To run Initial Setup the first time you turn on your TV
1Press POWER to turn on the TV.
The Initial Setup screen appears.
2Press V or v to select the on-screen display language. Then press .
The message “Start auto program now?” appears.
3Press V or v to select “Yes”, then press .
Auto Program automatically creates a list of receivable channels. When
finished, the lowest numbered channel is displayed.
To run Auto Program again at a later time
sUse the Auto Program feature as described on page 99.
To add individual digital channels
sUse the Digital Channels feature as described on page 99.
The Auto Program feature does not apply for installations that
use a cable box for all channel selection.
Auto Program may take up to 50 minutes or more to complete.
A progress bar is displayed while the channel list is being
created.
55
Using the Remote Control
Overview
This chapter describes how to set up, program, and use the remote control.
Inserting Batteries
Insert two size AA batteries (supplied) by matching the e and E on the
batteries to the diagram inside the remote control’s battery compartment.
Topic Page
Inserting Batteries 55
Button Descriptions 56
Programming the Remote Control 58
Using Other Equipment with Your Remote Control 60
Remove the batteries to avoid damage from possible battery
leakage whenever you anticipate that the remote control will
not be used for an extended period.
Handle the remote control with care. Avoid dropping it, getting
it wet, or placing it in direct sunlight, near a heater or where the
humidity is high.
The supplied remote control can be programmed to operate
most video equipment (see “Programming the Remote
Control” on page 58).
56
Remote Control
Button Descriptions
Button Description
1DVD/VCR,
SAT/CABLE
Power Buttons
Press to turn on and off the equipment you have programmed
into the remote control. For details, see “Programming the
Remote Control” on page 58.
DVD/VCR: Press to turn on and off the video equipment.
SAT/CABLE: Press to turn on and off the satellite receiver or
cable box.
2MUTING Press to mute the sound. Press again or press VOL+ to restore
the sound.
3PICTURE Press repeatedly to cycle through the available video picture
modes: Vivid, Standard, Pro. The video picture modes can be
also accessed in the Video menu. For details, see “Using the
Video Menu” on page 92.
4WIDE Press repeatedly to step through the Wide Screen Mode
settings: Wide Zoom, Normal, Full, Zoom. The Wide Screen
Mode settings can be also accessed in the Screen menu. For
details, see pages 67 and 68.
5Use with 0-9 and ENT buttons to select digital channels (for
example, 2.1). For more details, see “Watching TV” on
page 64.
6GUIDE Press to display the program guide.
When FUNCTION is switched on DVD/VCR
TOP MENU Press to display the top menu of your DVD/VCR.
7FAVORITES Press to display the Favorite Channels list. For details, see
page 72.
8FUNCTION
Buttons
Press to have the remote control operate the equipment you
want. For details, see “Programming the Remote Control” on
page 58.
9DVD/VCR
Operating
Buttons
When FUNCTION is switched on DVD/VCR, these buttons
operate the video equipment you have programmed into the
remote control. For details, see “Using Other Equipment with
Your Remote Control” on page 60.
m Rewind
N Play
M Fast forward
X Pause
x Stop
z Record
q; POWER
SAVING
Press repeatedly to cycle through the power saving modes:
Standard, Reduced, Picture Off. For more details, see
“Selecting Setup Options” on page 105.
qa SOUND
MODE
Press repeatedly to cycle through the sound modes: Dynamic,
Clear Voice, Custom. For more details, see “Selecting Audio
Options” on page 95.
qs VOL +/– Press to adjust the volume.
MUTING
PICTURE WIDE
FAVORITES
POWER
SAVING SOUND
MODE
/TV/SAT ANT
MENU
DISPLAY
TV/
VIDEO
MODE
SAT/
CABLE
POWER
GUIDE
TOP MENU
RESET JUMPMTS/SAP
DVD/
VCR
GUIDE
57
Remote Control
qd RESET Press to reset the settings to the factory defaults. See pages 92
and 95. Also used to clear Label Channels.
qf (Twin View) Press to turn on and off Twin View. For details, see page 69.
qg POWER Press to turn on and off the TV.
qh TV/VIDEO Press repeatedly to cycle through the video equipments
connected to the TV’s video inputs.
qj DISPLAY Press once to display the current channel number, and channel
label. If set, the current channel number will display for 10
seconds.
qk 0 - 9 ENT Press 0 - 9 to select a channel; the channel changes after 2
seconds. Press ENT to change channels immediately.
ql MENU Press to display the menu. Press again to exit from the menu.
For details, see page 91.
w; V/v/B/b Press V/v/B/b to move the on-screen cursor. To select an item,
press .
wa F1 Press to select the function of your video equipment which is
programmed on the TV’s remote control.
When FUNCTION is switched on TV
Press to display the Memory Stick menu. For more details, see
“Using the Memory Stick Viewer” on page 75.
ws F2 Press to select the function of your video equipment which is
programmed on the TV’s remote control.
wd ANT Press to switch between the sources connected to the TV’s
VHF/UHF and CABLE inputs.
When FUNCTION is switched on SAT/CABLE
GUIDE Press to display the program guide of your satellite program
provider.
wf Press to select the sound effect modes: TruSurround,
Simulated, Off. The sound effect modes can be also accessed
in the Audio menu. For more details, see “Selecting Audio
Options” on page 95.
When FUNCTION is switched on SAT/CABLE
TV/SAT Press to switch between the TV and the satellite receiver.
wg CH +/– Press to scan through channels. To scan quickly through
channels, press and hold down either CH.
wh JUMP Press to jump back and forth between two channels. The TV
alternates between the current channel and the last channel
that was selected.
wj MTS/SAP Press repeatedly to cycle through the Multi-channel TV Sound
(MTS) options: Stereo, Auto SAP (Second Audio Program),
and Mono. The MTS setting can be also accessed in the Audio
menu. For more details, see “Selecting Audio Options” on
page 95.
Button Description
58
Remote Control
Programming the Remote Control
The remote control is preset to operate Sony brand video equipment.
If you have video equipment other than Sony brand that you want to control
with the TV’s remote control, use the following procedures to program the
remote control.
From the “Manufacturer’s Codes” listed on page 59, select the three-digit
code number for the manufacturer’s code of your equipment. If more than
one code number is listed, try entering them one by one until you come to the
correct code for your equipment. Use the code number to complete the
following procedure.
1Press the DVD/VCR (FUNCTION) and RESET buttons
simultaneously, or press the SAT/CABLE (FUNCTION) and RESET
buttons simultaneously. DVD/VCR and SAT/CABLE buttons flash.
2Press the function button you want to program.
To program a cable box or a satellite receiver
Press SAT/CABLE (FUNCTION).
To program video equipment
Press DVD/VCR (FUNCTION).
3Enter the three-digit manufacturer’s code number using the 0-9 buttons.
4Press ENT.
5To check if the code number works, aim the TV’s remote control at the
equipment and press DVD/VCR and/or SAT/CABLE (POWER) that
corresponds with that equipment. If it responds, the programming is
completed. If not, try using the other codes listed for that manufacturer.
Sony Equipment Programmable Code Number
DVD/VCR 601 (Sony Dream System)
SAT/Cable 801 (Sony Satellite Receiver)
The equipment must have infrared (IR) remote capability in
order to be used with this remote control.
If you enter a new code number, the code number you
previously entered at that setting is erased.
In some rare cases, you may not be able to operate your
equipment with the Sony remote control. In this case, use the
equipment’s own remote control unit.
MUTING
PICTURE WIDE
FAVORITES
POWER
SAVING SOUND
MODE
/TV/SAT ANT
MENU
DISPLAY
TV/
VIDEO
MODE
SAT/
CABLE
POWER
GUIDE
TOP MENU
RESET JUMPMTS/SAP
DVD/
VCR
GUIDE
5
3
4
1, 2
1
59
Remote Control
Manufacturer’s Codes
DVD Players
DVD Changers
DVD/VCR Combo Units
HDD/DVD Combo Units
5.1ch DVD AV System
AV Receivers
VCRs
Manufacturer Code
Sony 751
General Electric 755
Hitachi 758
JVC 756
Magnavox 757
Mitsubishi 761
Panasonic 753
Philips 757
Pioneer 752
RCA/PROSCAN 755
Samsung 758
Toshiba 754
Zenith 760
Manufacturer Code
Sony 765
Panasonic 766
Manufacturer Code
Sony 767
Zenith 768
Toshiba 773
Samsung 774
JVC 775
Broksonic 776
Panasonic 777
Manufacturer Code
Sony 770, 771, 772
Manufacturer Code
Sony (DAV) 601, 602, 603,
604
Manufacturer Code
Sony 764
Manufacturer Code
Sony 301, 302, 303
Admiral
(M. Ward)
327
Aiwa* 338, 344
Audio Dynamic 314, 337
Broksonic 319, 317
Canon 309, 308
Citizen 332
Craig 302, 332
Curtis Mathes 304, 338, 309
Daewoo 341, 312, 309
DBX 314, 336, 337
Dimensia 304
Emerson 319, 320, 316,
317, 318, 341
Fisher 330, 335
Funai 338
General Electric 329, 304, 309
Go Video 322, 339, 340
Goldstar 332
Hitachi 306, 304, 305, 338
Instant Replay 309, 308
JC Penney 309, 305, 304,
330, 314, 336, 337
JVC 314, 336, 337,
345, 346, 347
Kenwood 314, 336, 332, 337
LG 332
LXI (SEARS) 332, 305, 330,
335, 338
Magnavox 308, 309, 310
Marantz 314, 336, 337
Marta 332
Memorex 309, 335
Minolta 305, 304
Mitsubishi/
MGA
323, 324, 325, 326
Multitech 325, 338, 321
NEC 314, 336, 337
Olympic 309, 308
Optimus 327
Orion 317
Panasonic 308, 309, 306, 307
Pentax 305, 304
Philco 308, 309
Philips 308, 309, 310
Pioneer 308
Quasar 308, 309, 306
RCA/
PROSCAN
304, 305, 308,
309, 311, 312,
313, 310, 329
Realistic 309, 330, 328,
335, 324, 338
Sansui 314
Samsung 322, 313, 321
Sanyo 330, 335
Manufacturer Code
Cable Boxes
Satellite Receivers
*If an Aiwa VCR does not work
even though you enter the code
for Aiwa, enter the code for
Sony instead.
Scott 312, 313, 321,
335, 323, 324,
325, 326
Sharp 327, 328
Signature 2000
(M. Ward)
338, 327
SV2000 338
Sylvania 308, 309, 338, 310
Symphonic 338
Tashiro 332
Tatung 314, 336, 337
Teac 314, 336, 338, 337
Technics 309, 308
Toshiba 312, 311
Wards 327, 328, 335,
331, 332
Yamaha 314, 330, 336, 337
Zenith 331
Manufacturer Code
Sony 230
Hamlin/Regal 222, 223, 224,
225, 226
Jerrold/G. I. 201, 202, 203,
204, 205, 206,
207, 208, 218,
222
Oak 227, 228, 229
Panasonic 219, 220, 221
Pioneer 214, 215
Scientific Atlanta 209, 210, 211
Tocom 216, 217
Zenith 212, 213
Manufacturer Code
Sony 801
Dish Network 810
Echostar 810
General Electric 802
Hitachi 805
Hughes 804
Mitsubishi 809
Panasonic 803
RCA/PROSCAN
802, 808
Toshiba 806, 807
Manufacturer Code
60
Remote Control
Using Other Equipment with Your Remote Control
To operate other connected equipment with your TV, first turn to page 59 and
program the necessary code. For operating video equipment, press
TV/VIDEO repeatedly until you see the video input on the screen for your
connected equipment. Remote control operation tips are provided below.
Operating a Cable
Box
Operating a Satellite
Receiver
To Do This ... Press
Activate the remote control to
operate the cable box
SAT/CABLE (FUNCTION)
Turn on/off SAT/CABLE
Select a channel 0-9, ENT
Change channels CH +/–
Back to previous channel JUMP
To Do This ... Press
Activate the remote control to
operate the satellite receiver
SAT/CABLE (FUNCTION)
Turn on/off SAT/CABLE (POWER)
Select a channel 0-9, ENT
Change channels CH +/–
Back to previous channel JUMP
Display channel number DISPLAY
Display SAT Guide GUIDE
Display SAT Menu MENU
Move highlight (cursor) V v B b
Select item
61
Remote Control
Operating a VCR
Operating a DVD
Player or DVD
Changer
To Do This ... Press
Activate the remote control to
operate the VCR
DVD/VCR (FUNCTION)
Turn on/off DVD/VCR (POWER)
Change channels CH +/–
Record N and z simultaneously
Play N
Stop x
Fast forward M
Rewind the tape m
Pause X (press again to resume normal playback)
Search the picture forward or
backward
M or m during playback
(release to resume normal playback)
To Do This ... Press
Activate the remote control to
operate the DVD
DVD/VCR (FUNCTION)
Turn on/off DVD/VCR (POWER)
If you have a DVD changer,
to skip disk
F1
Play N
Stop x
Pause X (press again to resume normal playback)
Step through different
tracks of the disc
M to step forward or m to step backward
Step through different chapters
of the disc
CH+ to step forward or CH– to step backward
Select a track directly 0-9, ENT
Display the menu (setup) MENU
Display the top menu TOP MENU
Operate the DVD menu V v B b,
62
Remote Control
Operating a 5.1ch
DVD AV System
(Sony DAV)
Operating a
DVD/VCR Combo
Unit
Operating an AV
Receiver
To Do This ... Press
Activate the remote control to
operate the DVD
DVD/VCR (FUNCTION)
Turn on/off DVD/VCR (POWER)
Select other equipment
connected to the DAV
F1
Skip a disk F2
Display the DVD menu TOP MENU
Display the menu (setup) MENU
Move highlight (cursor) V v B b
Select item
Change Volume VOL+/–, MUTING
To Do This ... Press
Activate the remote control to
operate the DVD/VCR
DVD/VCR (FUNCTION)
Turn on/off VCR/DVD (POWER)
If you have a DVD/VCR combo component,
Select the DVD
Select the VCR
F1
F2
Display the DVD menu MENU
Play N
Stop x
Pause X
Search the picture forward or
backward
M or m during playback
Move highlight (cursor)
and select (DVD)
V v B b
Record (VCR) N and z simultaneously
Change channels (VCR) CH +/– or 0-9, ENT (using tuner)
Adjust tracking (VCR) CH +/– (during tape playback)
To Do This ... Press
Turn on/off DVD/VCR (POWER)
Change the volume VOL +/–, MUTING
64
Features
Watching TV
z
For a complete list of all
the functions of the
remote control, see page
56.
To Do This ... Do This ...
Activate the remote control to
operate the TV
Press TV (FUNCTION).
Turn on/off the TV Press POWER.
Tune directly to a channel To tune to analog channels, press 0-9 and then
ENT (or wait 3 seconds).
For digital subchannels, press 0-9, , press
0-9 again, and then ENT.
For example, to select subchannel 2.1, press 2,
, 1, and then press ENT.
You can also select channels using
the program guide. See page 65 for
details.
Adjust the volume Press VOL +/–.
Mute the volume Press MUTING (press again or VOL + to
unmute).
Alternate back and forth between
two channels
Press JUMP.
The TV alternates between the current channel
and the last channel tuned.
Display the current channel
number (and other information)
Press DISPLAY once to display the channel
number, current time, wide mode, and channel
label (if set). Press DISPLAY again to turn
Display off.
Switch the TV’s input to the VCR,
DVD player, or other connected
equipment
Press TV/VIDEO repeatedly to cycle through
the video equipment connected to the TV’s
video inputs.
Change video and audio options,
customize the TV’s setup, set
parental controls, and more
Press MENU to display the Menu. For details,
see “Using the Menus” on page 91.
Switch the TV’s input between
sources connected to the TV’s
VHF/UHF and CABLE inputs
Press ANT to alternate between sources
connected to the TV’s VHF/UHF and CABLE
inputs.
65
Features
Using the Program Guide
Displaying the
Program Guide
The program guide lets you review program information and select both
analog and digital channels.
To display the program guide:
Press GUIDE on the remote control. The program guide appears, with the
currently selected program showing in the background.
The Program Guide cannot be displayed when the TV is tuned
to one of the video inputs or if the Channel Fix option is set to
anything other than Off (see page 99).
Make Way for Ducks!
Series follows the aquatic misadventures of Henry and Riley, two
wayward ducks on a unique mission.
Time remaining: 1:26
FAM
TV-G
CC
1 ABC
10 DISC
23.1
FAM
120 HIST
123 TLC
1234 HBO
C23.1
Channel number,
call letters
Program title and
description, program
duration, time remaining,
rating information, closed-
caption availability, format,
resolution (if digital),
aspect ratio
Selectable channel list
Program information in the guide is provided by the
broadcasters. As a result, it may sometimes include only the
channel number, without a program title or description.
To Do This ... Do This ...
Scroll through the channel list Press V or v.
Select the currently displayed
channel and exit the guide
Press .
Display additional options Press b. See “Using Additional Program
Guide Options” on page 66.
Exit the Guide (without changing
channels)
Press GUIDE.
66
Features
Using Additional
Program Guide
Options
Press b while in the program guide’s channel list to display the following
options, which allow you to customize the settings of the program on the
currently tuned channel.
Main
Video 1
Video 2
Video 3
Make Way for Ducks!
Series follows the aquatic misadventures of Henry and Riley, two
wayward ducks on a unique mission.
Time remaining: 1:26
TV-G
CC
1 ABC
10 DISC
23.1
FAM
120 HIST
123 TLC
1234 HBO
Alternate Video
Alternate Audio
FAM
C23.1
Option Description
Alternate
Video
(when available)
Each program has a main video stream (the video that you see
when the channel is first tuned), and may have alternate video
streams. This option allows you to switch among these alternate
video streams.
Alternate
Audio
(when available)
Each program has a main audio stream (the audio that you hear
when the channel is first tuned) and may have alternate audio
streams. This option allows you to switch among these alternate
audio streams (e.g., for different languages).
68
Features
Changing the Wide Screen Mode for 16:9 Source (High definition source)
Example Description
Wide Zoom enlarges the center portion of the picture. The left and right edges
of the picture are stretched to fill the 16:9 screen.
Full displays the picture at its original size.
Zoom enlarges the picture proportionately, both vertically and horizontally.
When the TV receives a 720p or 1080i signal, Normal cannot be
selected.
When TV receives a 720p or 1080i signal that is 4:3 aspect ratio
picture (upconverted to 16:9) with a black bar at each side, Full
returns the picture to its original size.
original source
Upconverted 4:3 Native 16:9
WIDE
Wide Zoom
m
Normal
(This mode is not available.)
m
WIDE
Full
m
WIDE
Zoom
69
Features
Using Twin View
Twin View lets you see two pictures from two sources — from an antenna,
VCR, DVD, etc. — on the screen at the same time. You hear the sound from
only one of the sources at a time, but you can choose which source’s sound is
selected. You can also change the relative size of each of the pictures.
Displaying Twin
Pictures
1Tune the TV to a working channel.
2Press .
A second picture appears.
To cancel Twin View and watch the active picture
sPress or .
Make Way for Ducks!
Series follows the aquatic misadventures of Henry and Riley, two
wayward ducks on a unique mission.
C35.3
WHD-TV
C35.1
0:50 Remaining
TV-G V S L D
1080i 16:9
,
<
Factors Affecting Twin View
sIf you use a cable box to view all channels, the same channel appears in both windows of Twin View
because the cable box unscrambles only one channel at a time.
sIf you use a cable box, you can view the cable box output in one Twin View window and view a
different source (such as a VCR or DVD player) in the second window by using the TV/VIDEO
button. For details, see “Connecting Optional Equipment” on page 28.
sDigital sources, as well as any sources connected to the VIDEO 4, 5, 6 inputs, display in the left
window, but not in the right window.
sIf you are viewing a 4:3 source and a 16:9 enhanced source (such as a DVD) side by side in Twin
View, the 4:3 source appears larger.
sTwin View does not display channels that are blocked by parental settings (see page 102).
70
Features
Activating the
You can use the B and b buttons to activate the left and right pictures while
using Twin View.
Functions Available in the Active (Highlighted) Window
To Do This ... Do This ...
To activate the picture in the right
window
Press b.
To activate the picture in the left
window
Press B.
Modern architectural movement
The city is regarded as a showcase for modern architecture, and is home
to a host of architects who have inspired international architectural styles.
C35.3
WHD-TV
C35.1
0:50 Remaining
TV-G V S L D
1080i 16:9
Make Way for Ducks!
Series follows the aquatic misadventures of Henry and Riley, two
wayward ducks on a unique mission.
C35.3
WHD-TV
C35.1
0:50 Remaining
TV-G V S L D
1080i 16:9
To Do This ... Do This ...
Tune to a channel To tune to analog channels, press 0-9 and then
ENT.
For digital subchannels, press 0-9, , press
0-9 again, and then ENT.
For example, to select subchannel 21.13, press
2+1++1+3, and then press ENT.
Adjust the volume Press VOL +/– .
Mute the sound Press MUTING (press again or VOL + to
unmute).
Switch the TV’s input between
sources connected to the TV’s
VHF/UHF and CABLE inputs
Press ANT.
Switch the TV’s input between
sources connected to the TV’s A/V
inputs
Press TV/VIDEO.
Change the picture size Press V or v. (For details, see “Changing the
Picture Size” on page 71.)
71
Features
Changing the
Picture Size
The zoom feature lets you vary the relative size of the left and right pictures.
To Do This ... Do This ...
Enlarge the active picture
Press V.
Make the active picture smaller
Press v.
When you adjust the picture sizes, the TV memorizes the
change. The next time you use the Twin View function, the
memorized sizes appear.
72
Features
Using Favorite Channels
The Favorite Channels feature lets you select programs from a list of up to
16 favorite channels that you specify. You can create a list using the Favorite
Channels option in the Channel Menu, or by using the Add to Favorites
feature in the Favorite Channels guide.
Using the Channel
Menu
1Press MENU to display the Menu.
2Press V or v to highlight the Channel icon and press .
3Press to select Favorite Channels.
4Use the 0-9 and ENT buttons to enter the channel number that you want
to assign to the Favorite Channel number.
Press to select that channel as a Favorite Channel.
5To add more channels to your favorites list, repeat step 4.
To clear a Favorite Channel, press V or v to highlight the channel you
want to clear. Press and then press RESET.
6Press MENU to exit the Menu.
Digital channels do not display in the preview window.
To enter digital channel numbers in step 4, use the 0-9, ,
press 0-9 again, and ENT buttons.
zFor details on using
the Channel Menu,
see page 99.
73
Features
Using the Favorite
Channels Guide
1Press FAVORITES. The Favorite Channels list appears.
2Press V or v to highlight the channel you want to watch.
To add the current channel to the list of Favorite Channels, highlight
Add to Favorites and press .
3Press to select the channel you want to watch.
To change your Favorite Channels list, highlight Edit Favorites and
press .
Add to Favorites
Favorite Channels
1 8.14 PBS
2 15.8 NBC
3 27 HGTV
4 45.12 TNT
5 98 CNN
6 112.3 ESPN
7 120 NICK
Favorite
Channels
75
Using the Memory Stick Viewer
About Memory Stick
Memory Stick (sold separately) is a compact, portable, and versatile
Integrated Circuit recording medium with a data capacity that makes it
perfect for portable applications, such as digital photography. Memory Stick
is specially designed for sharing digital data among Memory Stick
compatible products such as digital cameras and digital video cameras.
Because it is removable, Memory Stick can also be used for external data
storage.
The Memory Stick Viewer on your TV allows you to view files that are
stored on Memory Stick media. You can view:
sDigital photos (JPEG files)
sMovies (MPEG1 files)
You can also play slide show background music using MP3 files (or m3u
playlists) stored on your Memory Stick.
For more information about handling Memory Stick media, see “Notes on
Using Memory Stick Media” on page 90.
Features With the Memory Stick Viewer, you can:
sView TV screen digital images (JPEG) and (MPEG1) with background
music (MP3) in a thumbnail index or Slide Show
sSet customized Slide Show options, including transitions and
background audio
sPan, zoom, and rotate photos
sMark photos and set quantities of prints to be output when the Memory
Stick is inserted into your photo printer (not supplied)
sLock (protect) or delete files on the Memory Stick
76
Memory Stick
Memory Stick
Compatibility
This television is compatible with the following Sony brand Memory Stick
media types:
sMemory Stick Media
sMemory Stick DUO and PRO DUO Media (without the Memory Stick
adaptor)
sMemory Stick Media with Memory Select Function
sMemory Stick PRO Media
About Memory Stick PRO Media
Memory Stick PRO media features vary by and are dependent upon the
design of host hardware devices. Memory Stick PRO in this television has
been tested to support up to 1 GB media capacity and does not support high-
speed transfer, MagicGate copyright protection technology, or access control
security features.
Memory Stick
Functionality
Sony cannot guarantee or assure the Memory Stick functionality on this
television in the following cases:
sYou are using non-Sony brand Memory Stick media.
sYou are using video or audio clips that have been processed on a
computer.
sYou are using files that were obtained from the Internet or from a
printed film processing center.
sThe Memory Stick has been formatted on a personal computer.
Sony recommends that you back up all data stored on Memory Stick media
to avoid potential data loss. In the above two cases, in order to avoid
potential data corruption that may occur, be sure to back up data prior to use
with the TV’s Memory Stick Viewer. Sony cannot accept responsibility in
the event that data recorded to Memory Stick media is lost or damaged. For
certain non-Sony brand Memory Stick media, you can view images, but you
cannot rotate, delete or protect/unprotect images on the television. An error
message will occur if you attempt any of these operations. This is a result of
the unique file directory structure on these particular flash memory media
and is not a malfunction of the television.
CAUTION: If you are using a Memory Stick DUO or Memory
Stick PRO DUO with your TV, do not use the Memory Stick
with its adaptor. Remove the adaptor before you insert it
into the TV's Memory Stick slot. Inserting the Memory Stick
into the slot with the adaptor may result in permanent
damage to the Memory Stick and the TV.
!
77
Memory Stick
File Compatibility The Memory Stick Viewer is compatible with JPEG images taken with Sony
digital still cameras and MPEG1* movies taken with Sony digital cameras
and camcorders. In order to be viewable in the Memory Stick Viewer, the
files must have the following file name extensions:
Trademark
Information
Memory Stick, Memory Stick PRO, Memory Stick PRO DUO, and
MagicGate are trademarks of Sony Corporation.
* Some variations of MPEG1 movies may not play back correctly.
File Type Supported File Name Extensions
JPEG .jpg
.jpeg
MPEG1 .mpg
.mpeg
81
Memory Stick
Using the Memory Stick Index
Turn on the TV and insert a Memory Stick that contains the photo or movie
files you want to view. For details, see page 78.
The Memory Stick Index appears, which displays thumbnail images of the
files stored on the Memory Stick.
About the Icons on the Thumbnail Images
If the Memory Stick Index does not appear, press F1 button on
the remote control.
Summer 2004 / DSC0001
Jul 30, 2004 12:59PM 640x480
Slide Show Contents Memory Stick
1 of 25
Thumbnails of photos and
movies
Memory Stick Menu bar
Information about the
highlighted photo or movie
Highlighted thumbnail
Indicates the thumbnail is a movie (MPEG1) file instead of a photo (JPEG)
file.
Indicates the thumbnail is locked. Locked files cannot be changed or
deleted. For details, see “Photo Menu Bar Options” on page 84.
Indicates that the photo is marked to be printed.
Indicates that the photo has an associated voice memo.
82
Memory Stick
Using the Memory
Stick Index
The following describes how to use the Memory Stick Index.
To Do This ... Do This ...
Move the highlight to
a photo, voice memo
( ), or movie ( )
thumbnail
Press V v B b.
Display the
highlighted photo,
voice memo, or movie
file full screen
Press . For details, see “Viewing Photos” on page
83 and “Playing Movies” on page 86.
Display the next page
of thumbnails
1Press v to select V.
2Press v to display the next page of thumbnails.
Display the previous
or next page of
thumbnails
1Press v to select V.
2Press B to select .
3To go to the previous page, press V.
To go to the next page, press v.
Use the Memory Stick
Menu bar to access
additional options
1Press v to select V.
2Press B or b to select Slide Show, Contents, or
Memory Stick.
3Press V or v to select the option you want to
change.
For details on these options, see “Memory Stick Index
Menu Bar Options” on page 88.
Move the highlight
from the Memory
Stick Menu bar back
to the thumbnails
1Press B or b to select V.
2Press V to return to the currently displayed
thumbnails, or v to display the next page of
thumbnails.
Exit Memory Stick
Viewer
Press the F1 button on the remote control.
Y
83
Memory Stick
Viewing Photos
When you select a photo from the Memory Stick Index (described on
page 81), it displays as shown below, with the following controls.
Photo Controls
DSC00012
Jul 30, 2004 12:59PM 640x480 12 of 25
Slide ShowIndex View File
x2
Summer 2004 /
Photo Menu bar
Information about
selected photo
Selected photo
Previous/next buttons
JPEGs captured using a digital video camera may appear to
display motion in full screen. This is a result of the way digital
video cameras record still images, and is not a result of a
malfunction with the TV.
To Do This ... Do This ...
Display the next or previous
file on the Memory Stick
Highlight the (Previous/Next) button.
Then press B to go to the previous file, or b to go to
the next file.
Hide the Photo Menu bar,
displaying only the photo
With the highlight in the Photo Menu bar, press v.
Display the hidden Photo
Menu bar
Press V.
Play the JPEG voice memo
( files only)
Highlight B (Play) and then press . To pause
the voice memo, highlight X (Pause) and then press
.
Display the Memory Stick
Index again
Highlight Index in the Photo Menu bar and press
.
For details on the Memory Stick Index, see page 82.
Access additional options in
the Photo Menu bar
See “Photo Menu Bar Options” on page 84.
Exit Memory Stick Viewer Press the F1 button on the remote control.
zWhen the Menu is
hidden, press B or b to
go to the previous or
next photo.
Termékspecifikációk
| Márka: | Sony |
| Kategória: | televízió |
| Modell: | KDE50XS955 |
Szüksége van segítségre?
Ha segítségre van szüksége Sony KDE50XS955, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók televízió Sony
14 Január 2025
13 Január 2025
23 December 2024
23 December 2024
23 December 2024
19 December 2024
16 Október 2024
14 Október 2024
13 Október 2024
11 Október 2024
Útmutatók televízió
- televízió Samsung
- televízió Beko
- televízió Fujitsu
- televízió Acer
- televízió Nedis
- televízió LG
- televízió Grundig
- televízió Marantz
- televízió Philips
- televízió Pioneer
- televízió SilverCrest
- televízió Panasonic
- televízió JVC
- televízió AEG
- televízió Sharp
- televízió Nokia
- televízió Lenovo
- televízió Casio
- televízió Toshiba
- televízió Oppo
- televízió Hyundai
- televízió Hisense
- televízió BenQ
- televízió SunBriteTV
- televízió Siemens
- televízió Medion
- televízió TCL
- televízió Xiaomi
- televízió GoGen
- televízió Insignia
- televízió Infiniton
- televízió Dell
- televízió Strong
- televízió VOX
- televízió Vivax
- televízió Thomson
- televízió Polaroid
- televízió Aiwa
- televízió Orima
- televízió V7
- televízió Clatronic
- televízió PEAQ
- televízió Qilive
- televízió Haier
- televízió Mitsubishi
- televízió Cecotec
- televízió Sencor
- televízió GPX
- televízió Küppersbusch
- televízió Innoliving
- televízió AOC
- televízió Citizen
- televízió Westinghouse
- televízió Hitachi
- televízió Continental Edison
- televízió Telefunken
- televízió Nevir
- televízió Monster
- televízió Roadstar
- televízió Optoma
- televízió CHiQ
- televízió Viewsonic
- televízió Nextbase
- televízió Denver
- televízió Bush
- televízió Trevi
- televízió Albrecht
- televízió Daewoo
- televízió Funai
- televízió Tesla
- televízió Smart Tech
- televízió Muse
- televízió Energy Sistem
- televízió OK
- televízió SVAN
- televízió Loewe
- televízió RevolutionHD
- televízió Polar
- televízió Manhattan
- televízió Kogan
- televízió Horizon
- televízió Intenso
- televízió Furrion
- televízió Teac
- televízió Aspes
- televízió Digihome
- televízió Manta
- televízió Blaupunkt
- televízió Sagem
- televízió Jay-Tech
- televízió Logik
- televízió Finlux
- televízió Peerless-AV
- televízió Abus
- televízió AG Neovo
- televízió Bang & Olufsen
- televízió Iiyama
- televízió AKAI
- televízió TechniSat
- televízió Seiki
- televízió Jensen
- televízió Pyle
- televízió Emerson
- televízió Sanyo
- televízió Kemo
- televízió Salora
- televízió Lenco
- televízió Schneider
- televízió Philco
- televízió ECG
- televízió Uniden
- televízió Technika
- televízió NEC
- televízió Element
- televízió Soundmaster
- televízió Alphatronics
- televízió AYA
- televízió MBM
- televízió Krüger&Matz
- televízió Dual
- televízió Brandt
- televízió Wharfedale
- televízió Allview
- televízió RCA
- televízió OKI
- televízió Orion
- televízió SereneLife
- televízió Schaub Lorenz
- televízió Luxor
- televízió Metz
- televízió ILive
- televízió Graetz
- televízió Tatung
- televízió Packard Bell
- televízió EasyMaxx
- televízió Orava
- televízió Arçelik
- televízió Planar
- televízió Zenith
- televízió Doffler
- televízió QBell Technology
- televízió SYLVOX
- televízió Majestic
- televízió Reflexion
- televízió FFalcon
- televízió Megasat
- televízió Sogo
- televízió United
- televízió Techwood
- televízió Newstar
- televízió Matsui
- televízió Alden
- televízió Aldi
- televízió Airis
- televízió Aristona
- televízió Apex
- televízió Icy Box
- televízió Lexibook
- televízió Palsonic
- televízió Walker
- televízió Saba
- televízió Antarion
- televízió Kernau
- televízió Tevion
- televízió Proscan
- televízió Vestel
- televízió Tucson
- televízió Sunstech
- televízió Nabo
- televízió Sylvania
- televízió Sunny
- televízió Marquant
- televízió Nordmende
- televízió AudioAffairs
- televízió Magnum
- televízió Audiosonic
- televízió Kubo
- televízió Proline
- televízió Coby
- televízió Seg
- televízió Vivo
- televízió Daitsu
