page 1 / 3 sonel.pl/en
Reectometer
TDR-420
index: WMGBTDR420
Product features
• fault location in power and telecommunication cables
• two independent cursors to indicate two fault locations and the distance between them
• fault location in coaxial cables
• fault location in infrastructure cables
• detection of breaks, short-circuits, damage caused by moisture and other changes in cable impedance
• graphic presentation of cable faults with an indication of the distance to the fault on the display
Diagnose faults
with the TDR-420 reectometer
For measurement
of coaxial cables
For measurement
of shielded cables
For measurement
of twisted pairs
For measurement
of multi-conductor cables
For measurement
of pre-insulated pipes
Core identication mode
(TONE)
page 2 / 3 sonel.pl/en
Application
TDR-420 time-domain reflectometer is designed to detect where faults in met-
al wires are. This product is designed for:
• electrical wholesalers and cable dealers,
• electrical installation companies,
• maintenance personnel at manufacturing plants,
• building personnel.
This device meets the expectations of all those who have to accurately locate
a fault and wire end in either power or telecommunications cables.
Easy readout
The TDR-420 reflectometer is equipped with a readable colour display that, due
to its 320 x 240 pixel resolution, allows the fault location to be indicated even
more accurately.
Integrated Help
In the TDR-420 device a handy help function has been added to facilitate the
interpretation of the result obtained during measurement. Thanks to this func-
tion, a user can quickly determine the type of anomaly that is present in the
cable segment which is being examined, by comparing the displayed reflecto-
gram with typical fault shapes.
Durable and practical casing
In response to the customers needs the TDR-420 has been designed to operate
in difcult environmental conditions. A unique casing with the IP67 ingress
protection rating ensures that the device is both waterproof and dustproof. An
additional advantage is the elastomer coating of the casing that prevents the
device from slipping out of the hands and provides protection if it should be
accidently dropped.
Device capabilities
The SONEL reflectometer is distinguished for its long operating range of up
to 6,000 m, very low margin of error in measurement (in the order of 1%) and
the ability to adjust both the velocity of propagation and the impedance of the
cable which is under investigation. By using two cursors there should be no
problem with determining both the distance to two faults and the distance be-
tween them.
page 3 / 3 sonel.pl/en
Technical specication
measuring ranges
20, 45, 90, 180, 360, 750, 1500, 3000,
6000, 10000, 20000 [ft]
7 m, 15 m, 30 m, 60 m, 120 m, 250 m, 500 m,
1 km, 2 km, 3 km, 6 km
accuracy 1% of selected range
resolution approx. 1% of range
minimum cable length 4 m
velocity of propagation within 10…99% or 15…148.5 m/μs
output impulse 5 Vp-p for an open circuit
output impedance 25, 50, 75, 100, 125 and 200 Ω
impulse width 3 ns…3 μs (depending on the range)
scanning type up to 3 scans/s
or a single scan (ONCE mode)
generated acoustic signal 810...1100 Hz
operating time on a full battery up to 8 hours of continuous scanning
power supply 4 x alkaline batteries 1.5 V AA type or
4 x NiMH AA rechargeable batteries
auto-off function 1, 5, 10, 15 minutes or deactivated
display colour 3.5” LCD TFT, 320 x 240 pixels
overvoltage protection 400 V DC / 250 V AC
operating temperature -20...+70°C
storage temperature -30...+80°C
dimensions 220 x 98 x 58 mm
weight 487 g
electromagnetic compatibility
standards (EMC) EN 61326-1
ingress protection IP67
double-wire test
lead 0.6 m
WAPRZ0X6DZBB
4x alkaline
battery 1.5 V AA
M1 hanging straps
WAPOZSZE4
crocodile clip
red 1 kV 20 A
WAKRORE20K02
crocodile clip
black 1 kV 20 A
WAKROBL20K01
Standard accessories
M-6 carrying case
WAFUTM6
