USER GUIDE

WiFi HUMIDITY AND TEMPERATURE

SENSOR

H&T

Shelly® H&T by Allterco Robotics is intended to be placed

in a room/area in order to be aware of the humidity and tem-

perature. Shelly H&T is battery powered, with battery life up

to 18 months. Shelly may work as a standalone device or as

an accessory to a home automation controller.

Battery Type:

3V DC - CR123A

Battery Life:

Up to 18 months

Electrical consumption:

• Static ≤70uA

• Awake ≤250mA

Humidity measurement

range:

0~100% (±5%)

Temperature measurement range:

-40°C ÷ 60 °C (± 1°C)

Working temperature:

-40°C ÷ 60 °C

Dimensions (HxWxL):

35x45x45 mm

Radio protocol:

WiFi 802.11 b/g/n

Frequency:

2400 – 2500 MHz;

Operational range:

• up to 50 m outdoors

• up to 30 m indoors

Radio signal power:

1mW

Complies with EU stan-

dards:

• RE Directive 2014/53/EU

• LVD 2014/35/EU

• EMC 2004/108/WE

• RoHS2 2011/65/UE

Specication

Installation Instructions

CAUTION! Before beginning the installation please read

the accompanying documentation carefully and completely.

Failure to follow recommended procedures could lead to

malfunction, danger to your life or violation of the law.

Allterco Robotics is not responsible for any loss or damage

in case of incorrect installation or operation of this device.

CAUTION! Use the Device only with batteries which com-

ply with all applicable regulations. Inappropriate batteries

may cause a short circuit in the Device, which may damage it.

CAUTION! Do not allow children to play with the device,

especially with the Power Button. Keep the devices for re-

mote control of Shelly (mobile phones, tablets, PCs) away

from children.

Control your home with your voice

All Shelly devices are compatible with Amazons’ Alexa and

Googles’ assistant. Please see our step-by-step guides on:

https://shelly.cloud/compatibility/Alexa

https://shelly.cloud/compatibility/Assistant

Device „Wake Up“

To open the device, twist the top and bottom part of the

case counter clockwise.

Press the Button. The LED should ash slowly. This means

that Shelly is in AP mode. Press the Button again and the

LED will turn off and Shelly will be in „sleep“ mode.

LED States

• LED ashing quickly - AP Mode

• LED ashing slowly - STA Mode (No Cloud)

• LED still - STA Mode (Connected to Cloud)

• LED ashing quickly - FW Update (STA mode connected Cloud)

Factory Reset

You can return your Shelly H&T to its Factory Settings by

pressing and holding the Button for 10 seconds. Upon suc-

cessful factory reset the LED will ash slowly.

Additional Features

Shelly allows control via HTTP from any other device, home

automation controller, mobile app or server.For more infor-

mation about the REST control protocol, please visit:

www.shelly.cloud or send a request to developers@shelly.cloud

MOBILE APPLICATION FOR SHELLY

The Shelly Cloud mobile application

Shelly Cloud gives you opportunity to control and adjust all

Shelly® devices from anywhere in the world. The only thing

you need is connection to the Internet and our mobile appli-

cation, installed on your smartphone or tablet. To install the

application please visit Google Play or App Store.

Registration

The rst time you open the Shelly Cloud mobile app, you

have to create an account which can manage all your

Shelly® devices.

Forgotten Password

In case you forget or lose your password, just enter the

e-mail address you have used in your registration. You will

then receive instructions on how to change your password.

WARNING! Be careful when you type your e-mail address

during the registration, as it will be used in case you forgot

your password.

After registering, create your rst

room (or rooms), where you are

going to add and use your Shelly

devices. Shelly Cloud allows easy

control and monitoring using a mo-

bile phone, tablet or PC.

Device Inclusion

To add a new Shelly device, connect it to the power grid

following the Installation Instructions included with the

Device.

Step 1

Place your Shelly H&T in the room where you want to use it.

Press the Button - the LED should turn on and ash slowly.

WARNING: If the LED does not ash slowly, press and

hold the Button for at least 10 seconds. The LED should

then ash quickly. If not, please repeat or contact our cus-

tomer support at: support@shelly.cloud

Step 2

Choose “Add Device”.

In order to add more devices later, use the Menu at the top

right corner of the main screen and click “Add Device”.

Type the name and password for the WiFi network, to which

you want to add Shelly.

Step 3

- If using iOS: you will see the following screen (g. 4)

On your iOS device open Settings > WiFi and connect to the

WiFi network created by Shelly, e.g. ShellyHT-35FA58.

- If using Android (g. 5) your phone will automatically

scan and include all new Shelly devices in the WiFi network,

that you dened.

Upon successful Device Inclusion to the WiFi network you

will see the following pop-up:

Step 4:

Approximately 30 seconds after discovery of any new de-

vices оn the local WiFi network, а list will be displayed by

default in the “Discovered Devices” room.

Step 5:

Select Discovered Devices and choose the Shelly device you

want to include in your account.

Step 6:

Enter a name

for the De-

vice. Choose

a Room, in

which the de-

vice has to be

po sitio ned.

You can choose an icon or upload a picture to make it easier

to recognize. Press “Save Device”.

Step 7:

To enable connection to the Shelly Cloud service for remote

control and monitoring of the Device, press “yes” on the

following pop-up.

The Embedded Web Interface

Even without the mobile app Shelly can be set and con-

trolled through a browser and connection of a mobile phone

or tablet.

Abbreviations used:

Shelly-ID – consists of 6 or more characters. It may include

numbers and letters, for example 35FA58.

SSID – the name of the WiFi network, created by the device,

for example ShellyHT-35FA58.

Access Point (AP) – in this mode in Shelly creates its own

WiFi network.

Client Mode (CM) – in this mode in Shelly connects to an-

other WiFi network.

Installation/Initial inclusion

Step 1

Place Shelly in the room where you want to use it. Open it

and press the Button. The LED should ash slowly.

To open the device, twist the top and bottom part of the

case counter clockwise.

CAUTION! If the LED does not ash slowly, press and

hold the Button for 10 seconds. Upon successful factory

reset, the LED will ash slowly.

Step 2

When the LED is ashing slowly, Shelly has created a WiFi

network, with name such as ShellyHT-35FA58. Connect to it.

Step 3

Type 192.168.33.1 into the address eld of your browser to

load the web interface of Shelly.

General - Home Page

This is the home page of the

embedded web interface. Here

you will see information about:

• Current Temperature

• Current Humidity

• Current battery percentage

• Connection to Cloud

• Present time

• Settings

Sensor Settings

Temperature Units: Setting for change of the temperature units.

• Celsius

• Fahrenheit

Send Status Period: Dene the period (in hours), in which

Shelly H&T will report its’ status. The value must be between

1 and 24.

Temperature Threshold: Dene the temperature Threshold

in which Shelly H&T will “wake up” and send status. The val-

ue can be from 1° up to 5° or you can disable it.

Humidity Threshold: Dene the humidity Threshold in which

Shelly H&T will “wake up” and send status. The value can be

from 0.5 up to 50% or you can disable it.

Internet/Security

WiFi Mode-Client:

Allows the device to connect to an available

WiFi network. After typing the details in the elds, press Connect.

WiFi Mode-Acess Point: Congure Shelly to create a Wi-Fi

Access point. After typing the details in the elds, press

Create Access Point.

Restrict Login: Restrict the web interface of Shely with a

Username and Password. After typing the details in the re-

spective elds, press Restrict Shelly.

Advanced Developer Settings: Here you can change the

action execution:

• Via CoAP (CoIOT)

• Via MQTT

ATTENTION: To reset the device, press and hold the But-

ton for at least 10 seconds. Upon successful factory reset,

the LED will ash slowly.

Settings

Time Zone and Geo-location: Enable or Disable the auto-

matic detection of Time Zone and Geo-location. If Disabled

you can dene it manually.

Firmware Upgrade: Shows present rmware version. If a

newer version is available, you can update your Shelly by

clicking Upload to install it.

Factory reset: Return Shelly to its factory settings.

Device Reboot: Reboots the device.

Shelly Devices Settings

After your Shelly de-

vice is included in the

app, you can control

it, change its settings

and automate the

way it works.

To switch the device

on and off, use the

Power button.

To enter the details

menu of the device,

click on it’s name.

From there you may control the device, as well as edit its

appearance and settings.

Send Status Period: Dene the period (in hours), in which

Shelly H&T will report its’ status. Possible range: 1 ~ 24 h.

Temperature Threshold: Dene the temperature Threshold

in which Shelly H&T will “wake up” and send status. The val-

ue can be from 1° up to 5° or you can disable it.

Humidity Threshold: Dene the humidity Threshold in which

Shelly H&T will “wake up” and send status. The value can be

from 0.5 up to 50% or you can disable it.

Internet/Security

WiFi Mode - Client: Allows the device to connect to an avail-

able WiFi network. After typing the details in the respective

elds, press Connect.

WiFi Mode - Access Point: Congure Shelly to create a Wi-

Fi Access point. After typing the details in the respective

elds, press Create Access Point.

Restrict Login: Restrict the web interface (IP in the Wi-Fi

network) of Shely with a Username and Password. After typ-

ing the details in the respective elds, press Restrict Login.

Settings

Firmware Update

Update the rmware of Shelly, when a new version is re-

leased.

Time Zone and Geo-location

Enable or Disable the automatic detection of Time Zone and

Geo-location.

Factory Reset

Return Shelly to its factory default settings.

Device Information

Here you can see the:

• Device ID - Unique ID of Shelly

• Device IP - The IP of Shelly in your Wi-Fi network

Edit Device

From here you can edit:

• Device Name

• Device Room

• Device Picture

When you are done, press Save Device.

Alarms

Low Temperature Alarm:

Receive a notication when

the temperature is less than

a predened value. Possible

range: -20 ~ 60°C

High Temperature Alarm:

Receive a notication when

the temperature is greater

than a predened value. Pos-

sible range: -20 ~ 60°C

Low Humidity Alarm:

Receive a notication when

the humidity is less than a

predened value.

Possible range: 1 ~ 100%

High Humidity Alarm:

Receive a notication when

the humidity is greater than a

predened value.

Possible range: 1 ~ 100%

Sensor settings

Temperature Units

Setting for change of the tem-

perature units.

• Celsius

• Fahrenheit

Battery Life Recommendations

For the best battery life we recommend you the following

settings for Shelly H&T:

Sensor settings

• Send Status Period: 6 h

• Temperature Threshold: 1°

• Humidity Threshold: 10%

Set a static IP address in the Wi-Fi network for Shelly from

the ebmedded web interface. Go to Internet/Security ->

Sensor settings Set static IP address and press on . After

typing the details in the respective elds, press Connect.

Keep Shelly at the best distance possible to the Wi-Fi router.

H&T

Developers support

Our Facebook support group:

www.facebook.com/groups/1686781668087857

Our support e-mail:

support@shelly.cloud

Our website:

www.Shelly.cloud

You can nd the latest PDF version of this user

guide here:

( o rective)R HSII Di

Termékspecifikációk

Márka:	Shelly
Kategória:	okos otthon
Modell:	H&T

Szüksége van segítségre?

Ha segítségre van szüksége Shelly H&T, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek

Az Ön neve*

Az Ön e-mail címe*

Írja ide kérdését

Útmutatók okos otthon Shelly

Shelly BLU Button 1 Útmutató

27 Március 2025

Shelly Qubino Wave 1PM Mini Útmutató

1 Október 2024

Shelly Wave Shutter Útmutató

1 Szeptember 2024

Shelly Wave i4 Útmutató

1 Szeptember 2024

Shelly Wave Pro 2 Útmutató

1 Szeptember 2024

Shelly Plus Un Útmutató

1 Szeptember 2024

Shelly Pro Dimmer 1PM Útmutató

1 Szeptember 2024

Shelly Wave Pro 1PM Útmutató

1 Szeptember 2024

Shelly Wave Pro 2PM Útmutató

1 Szeptember 2024

Shelly Pro Dimmer 2PM Útmutató

1 Szeptember 2024

Útmutatók okos otthon

Legújabb útmutatók okos otthon

Busch-Jaeger 6151-0-0217 Útmutató

29 Március 2025

Busch-Jaeger 6151-0-0218 Útmutató

29 Március 2025

Tesla MS360 Útmutató

29 Március 2025

Sommer SOMweb Útmutató

19 Március 2025

EZVIZ T33 Útmutató

18 Március 2025

Niko 350-20071 Útmutató

15 Január 2025

WiZ Smart Útmutató

14 Január 2025

EZVIZ DL03 Útmutató

14 Január 2025

EZVIZ DL04 Pro Útmutató

14 Január 2025

EZVIZ CP5 Útmutató

14 Január 2025
