Oldal 1/62
ENGLISHFRANÇAISESPAÑOL
IMPORTANT : Please read this operation manual before starting operating the equipment.
IMPORTANT : Veuillez lire ce mode d'emploi avant de commencer à utiliser l'appareil.
IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.
LC-40LE700UN
LC-46LE700UN
LC-52LE700UN
ENGLISHFRANÇAISESPAÑOL
OPERATION MANUAL
MODE D'EMPLOI
MANUAL DE OPERACIÓN
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO
ENGLISHFRANÇAISESPAÑOL
Dimensional Drawings
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
CAUTION:
1
LC-40LE700UN
LC-46LE700UN
LC-52LE700UN
OPERATION MANUAL
IMPORTANT:
To aid reporting in case of loss or theft, please record the
TV's model and serial numbers in the space provided. The
numbers are located at the rear of the TV.
Model No.:
Serial No.:
LIQUID CRYSTAL TELEVISION
ENGLISH
IMPORTANT INFORMATION
ENGLISH
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
DECLARATION OF CONFORMITY:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
TEL: 1-800-BE-SHARP
For Business Customers: URL http://www.sharpusa.com
“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.”
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded
cables and connectors for connections.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly
approved by the manufacturer could void the user's authority to operate this equipment.
2
IMPORTANT INFORMATION
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-40LE700UN/LC-46LE700UN/LC-52LE700UN
Trademarks
• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
• “HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
• Products that have earned the ENERGY STAR
® are designed to protect the environment through superior energy
effi ciency.
•
and LC logo mark are registered trademarks of SHARP Corporation.
This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly
displaying easy-to-read characters on LCD screens. However, other fonts are used for some screen pages, too.
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage
if improperly handled. This product has been engineered and manufactured with the highest priority on safety.
However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and cleaning the product. To ensure your safety
and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully
before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Information
15) Power Sources—This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery power, or other sources, refer to the
operating instructions.
16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a qualified technician
to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for service.
19) Replacement Parts—When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
4
• Outdoor Antenna Grounding — If an outside antenna is
connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base
can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product
on a wall, be sure to follow the manufacturer's instructions. Use only the mounting hardware recommended by the
manufacturer.
• Selecting the location — Select a place with no direct sunlight and good ventilation.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insuffi cient ventilation can cause overheating and/or shorten the life of the product. Do not place
the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not
designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer's instructions are followed.
• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the product is dropped or
applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifi ers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 2,073,600 pixels, giving you fi ne picture details.
Occasionally, a few non-active pixels may appear on the screen as a fi xed point of blue, green or red. Please note that
this does not affect the performance of your product.
• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to
the equipment due to lightning and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
• To prevent fi re, never place any type of candle or fl ames on the top or near the TV set.
• To prevent fi re or shock hazard, do not place the AC cord under the TV set or other heavy items.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• To prevent fi re or shock hazard, do not expose this product to dripping or splashing.
No objects fi lled with liquids, such as vases, should be placed on the product.
• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may
result in fi re or electric shock. Exercise special caution when using the product around children.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always
carry the TV by two people holding it with two hands — one hand on each side of the TV.
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Use a soft cloth and gently wipe the surface of the display panel. Using a hard cloth may
scratch the panel surface.
• Use a soft damp cloth to gently wipe the panel when it is really dirty.
(It may scratch the panel surface when wiped strongly.)
• If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To protect the panel, do not use a dirty cloth, liquid cleaners or chemical cloth to clean it, such materials may damage
the panel surface.
• To clean the outer cabinet, use the same method. Do not use liquid or aerosol cleaners.
IMPORTANT SAFETY INSTRUCTIONS
5
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger fl at panel
displays are popular purchases. However, fl at panel displays are not always supported
on the proper stands or installed according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, shelves,
desks, speakers, chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable
and safe.
TUNE INTO SAFETY
One size does NOT fi t all. Follow the manufacturer’s recommendations for the safe
installation and use of your fl at panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place fl at panel displays on furniture that can easily be used as steps, such as
a chest of drawers.
Remember that children can become excited while watching a program, especially
on a “larger than life” fl at panel display. Care should be taken to place or install the
display where it cannot be pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables connected to the fl at panel
display so that they cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT
PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display manufacturer and/or listed
by an independent laboratory (such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your fl at panel display,
contact your retailer about professional installation.
Make sure that the wall where you are mounting the display is appropriate. Some
wall mounts are not designed to be mounted to walls with steel studs or old cinder
block construction. If you are unsure, contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be
heavy.
Note: CEA is the preeminent trade association promoting growth in the $161 billion U.S.
consumer electronics industry. More than 2,200 companies enjoy the benefi ts of CEA
membership, including legislative advocacy, market research, technical training and education,
industry promotion and the fostering of business and strategic relationships.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
6
1 Confi rm that there are 12 screws (all the same size)
supplied with the stand unit.
2 1 Set the post for the stand unit onto the box.
2 Attach the base to the post.
3 Insert and tighten the 8 screws into the 8 holes
on the bottom of the base.
• Hold the stand unit securely with one hand, and then
tighten the screws.
FRONT
3
2
3
1
1
Screws
Attaching the Stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
QUICK REFERENCE
3 1 Insert the stand into the openings on the bottom
of the TV.
2 Insert and tighten the 4 screws into the 4 holes
on the rear of the TV.
1
1
2 2
Screws
Soft cushion
• To detach the stand, perform the steps in reverse order.
Supplied Accessories
• Always use the AC cord supplied with the TV.
• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.
• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are available
directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or
VISIT www.sharpusa.com/SharpDirect.
Make sure the following accessories are provided with the product.
Remote control unit
(g1)
Page 7
“AAA” size battery
(g2)
Page 8
AC cord
(g1)
Page 7
Stand unit
(g1)
Page 6
Cable clamp
(g1)
Page 7
Operation manual
(g1)
CAUTION
• Attach the stand in the correct direction.
• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
7
QUICK REFERENCE
Using the Remote Control Unit
Use the remote control unit by pointing it towards the
remote control sensor on the TV. Objects between the
remote control unit and the remote control sensor may
prevent proper operation.
Remote control sensor
30º 30º
30º
30º
17´ (5 m)
■ Cautions regarding the remote control unit
• Do not expose the remote control unit to shock. In addition,
do not expose the remote control unit to liquids, and do not
place in an area with high humidity.
• Do not install or place the remote control unit under direct
sunlight. The heat may cause deformation of the remote
control unit.
• The remote control unit may not work properly if the remote
control sensor on the TV is under direct sunlight or strong
lighting. In such cases, change the angle of the lighting
or the TV, or operate the remote control unit closer to the
remote control sensor.
IMPORTANT:
The POWER indicator on the television should light GREEN
indicating you have power to the television.
If the POWER indicator on the television still does not light up,
press on the remote control to turn the power on.TV POWER
IMPORTANT:
IF THE UNIT DOES NOT POWER ON - UNPLUG THE
TELEVISION FROM THE OUTLET AND REPEAT THE
INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT
US AT 1-800-BE-SHARP.
1 Attach your antenna to the back of the television.
(See page 8.)
2 Connect the AC plug for the television into the AC
outlet.
AC outlet
• Place the TV close to the AC outlet, and keep the power
plug within reach.
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT
TOUCH UN-INSULATED PARTS OF ANY CABLES
WITH THE AC CORD CONNECTED.
3 Bundle the cords properly with the cable clamp.
4 How to turn on the television for the fi rst time.
A) Press POWER on the television.
POWER
B) The POWER indicator on the front of the
television lights GREEN.
POWER indicator
• Speakers cannot be detached from the TV.
• TV angle cannot be adjusted.
QUICK INSTALLATION TIPS
8
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector,
plug it into the antenna terminal at the rear of the TV set.
1. A 75-ohm system is generally a round cable with F-type connector
that can easily be attached to a terminal without tools (Commercially
available).
F-type connector
300-ohm twin-lead cable (fl at)
F-type connector
75-ohm coaxial cable (round)
75-ohm coaxial cable
NOTICE
2. A 300-ohm system is a fl at “twin-lead” cable that can be attached
to a 75-ohm terminal through a 300/75-ohm adapter (Commercially
available).
When connecting the RF cable to the TV set, do not tighten F-type
connector with tools.
If tools are used, it may cause damage to your TV set. (The breaking
of internal circuit, etc.)
300-ohm twin-lead cable
75-ohm coaxial cable (round)
75-ohm coaxial cable
IN OUT
300-ohm
twin-lead cable
VHF
A
NTENNA
UHF
ANTENNA
Combiner
(commercially available)
300/75-ohm adapter
(commercially available)
300-ohm twin-lead cable (flat)
75-ohm coaxial cable (round)
Cable TV lead-In
Coaxial cable
(commercially available)
Coaxial cable
(commercially available)
Home Antenna
terminal (75-ohm)
Home Antenna
terminal (75-ohm)
or
or
F-type connector should be fi nger-tightened only.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage
in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a
rash. If you fi nd any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries from it.
1 Open the battery cover.
• Place the batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
2 Insert two “AAA” size batteries
(supplied with the product).
3 Close the battery cover.
Installing Batteries in the Remote Control Unit
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
Preparation
Connecting Antenna Cable
1 Cable without a CATV
converter
3 Combination VHF/
UHF antenna
4 Separate VHF/UHF
antenna
To TV antenna
terminal
2 VHF/UHF antenna
• Connect the antenna cable to the TV using one of the methods in the illustration as shown (
1, 2, 3 or 4).
9
Contents
IMPORTANT INFORMATION . . . . . . . . . . . . . . . . . . . . . 1
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DEAR SHARP CUSTOMER . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . 3-5
Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
QUICK REFERENCE
Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
QUICK INSTALLATION TIPS . . . . . . . . . . . . . . . . . . . 7
Using the Remote Control Unit . . . . . . . . . . . . . . . . . 7
Preparation
Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Batteries in the Remote Control Unit . . . 8
Part Names
TV (Front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TV (Rear/Side) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Remote Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connecting to External Equipment
Connecting Audiovisual Equipment . . . . . . . . . 12-13
Connecting a Speaker/Amplifi er . . . . . . . . . . . . . . . 13
Watching TV
Turning On/Off the Power . . . . . . . . . . . . . . . . . . . . . 14
Initial Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Direct Button Operation
Changing Channels . . . . . . . . . . . . . . . . . . . . . . . 15
Changing Volume . . . . . . . . . . . . . . . . . . . . . . . . . . 15
MUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
FLASHBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SURROUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
FREEZE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
AV MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
POWER SAVING . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Closed Captions and
Digital Closed Captions . . . . . . . . . . . . . . . . . . . 17
VIEW MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
On-Screen Display Menu
On-Screen Display Menu Operation . . . . . . . . . . . 19
Menu Operation Buttons . . . . . . . . . . . . . . . . . . . . . . 19
Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Picture Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-22
Audio Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Power Control Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-27
Option Menu .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29
Digital Setup Menu .. . . . . . . . . . . . . . . . . . . . . . . . 30-31
Enjoying photo and music playback
Viewing photos and listening to music . . . . . . . . . 32
USB memory device compatibility . . . . . . . . . . . . . 32
Photo Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Music Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
USB Menu .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-35
Other Viewing Options
Presetting Remote Control Function .. . . . . . . . . . 36
Operating the Connected Equipment . . . . . . . . . . 36
Using AQUOS LINK
Controlling HDMI Equipment
Using AQUOS LINK . . . . . . . . . . . . . . . . . . . . . . . 38-40
AQUOS LINK Menu 40-41. . . . . . . . . . . . . . . . . . . . . . . .
Using a PC
Connecting a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Displaying a PC image on the screen .. . . . . . . . . 43
Adjusting the PC Image . . . . . . . . . . . . . . . . . . . . . . . 44
Setting Audio Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
PC Compatibility Chart . . . . . . . . . . . . . . . . . . . . . . . . 44
RS-232C Port Specifi cations . . . . . . . . . . . . . . . . . . 45
Using the Internet
Internet Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Displaying the Sidebar Widget . . . . . . . . . . . . . . . . . 47
Entering Text (Software Keyboard) . . . . . . . . . . . . . 48
Using the Browser . . . . . . . . . . . . . . . . . . . . . . . . . . 49-52
Appendix
Removing the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Setting the TV on the Wall .. . . . . . . . . . . . . . . . . . . . 53
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Troubleshooting-Digital Broadcasting . . . . . . . . . . 54
Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Optional Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Information on the Software License for
This Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Dimensional Drawings
• The dimensional drawings for the LCD TV set are shown
on the inside back cover.
10
Part Names
TV (Front)
OPC sensor* (See page 21.)
POWER indicator (See page 14.)
Remote control sensor
OPC indicator (See page 21.)
TV (Rear/Side)
AC INPUT
terminal
INPUT 3
terminals
USB
terminal
INPUT 5
terminal
(HDMI)
*1
*2
*3
*1
RS-232C terminal
DIGITAL AUDIO
OUTPUT terminal
INPUT 7 terminal
(HDMI)
INPUT 8 terminal
(HDMI)
INPUT 6 terminal (HDMI)
INPUT 4 terminal (PC-IN)
AUDIO terminal (shared for INPUT 4 and INPUT 6) *4
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
AUDIO OUTPUT
terminals
ETHERNET terminal
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CHU/V)
Volume
buttons
(VOLk/
l)
*1 See pages 12, 13, 38 and 42 for external equipment connection.
*2 See page 19 for button operations.
*3 See page 7 for connecting the AC cord.
*4 See page 44 for details on the PC Audio Select function.
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• The examples used throughout this manual are based on the LC-46LE700UN model.
* OPC: Optical Picture Control
Blue Illumination LED (See page 25.)
11
3
2
1 18
5
6
4
9
21
19
20
22
23
7
24
11
10
25
12
14
13
27
28
29
16
15
17
31
26
30
8
Part Names
1 TV POWER: Switch the TV power on or enter standby. (See page
14.)
2 DISPLAY: Display the channel information.
3 SOURCE POWER: Turns the power of the external equipment
on and off.
4 External equipment operational buttons: Operate the external
equipment.
5 0 9: – Set the channel. (See page 15.)
6 • (DOT): (See pages 15 and 36.)
7 NET: Switches the display to the Sidebar Widget, TV
kWeb, Web
or TV screen. (See pages 46 to 52 for details.)
8 INPUT: Select a TV input source. (TV, INPUT 1, INPUT 2, INPUT 3,
INPUT 4, INPUT 5, INPUT 6, INPUT 7, INPUT 8, USB) (See page
15.)
9 VOL k/l: Set the volume. (See page 15.)
10 POWER SAVING: Select Power Saving settings. (See page 17.)
11 FREEZE: Set the still image. Press again to return to normal
screen. (See page 15.)
12 EXIT: Turn off the menu screen.
13 OPTION: Display the AQUOS LINK MENU screen. This button
will function only when AQUOS LINK is used. (See pages 38 to 41
for details.)
14 REC STOP: Stops one touch recording. This button will function
only when AQUOS LINK is used. (See pages 38 to 41 for details.)
15 SLEEP: Set the sleep timer. (See page 15.)
16 SURROUND: Select Surround settings. (See page 15.)
17 AUDIO: Selects the MTS/SAP or the audio mode during multi-
channel audio broadcasts. (See page 16.)
18 FUNCTION: Switches the remote control for TV, CBL/SAT, VCR,
BD/DVD and AUDIO operation. Indicator lights up for the current
mode. (See pages 36 to 37 for details.)
* To enter the code registration mode, you need to press
FUNCTION DISPLAY and at the same time.
19 LIGHT ': When this button is pressed, some buttons (for
example, VOLk/l and CHU/V) on the remote control unit will
light. The lighting will turn off if no operations are performed within
about 5 seconds. This button is used for performing operations in
low-light situations.
20 VIEW MODE: Select the screen size. (See pages 18 and 43.)
21 ENT: 0 9 Jumps to a channel after selecting with the – buttons.
22 FLASHBACK: Return to the previous channel or external input
mode. (See page 15.)
23 CH U/V: Select the channel. (See page 15.)
24 MUTE: Mute the sound. (See page 15.)
25 MENU: Display the menu screen.
26 a/b/c/d, Select a desired item on the screen.ENTER:
27 RETURN: Return to the previous menu screen.
28 FAVORITE CH
, , , Select 4 preset favorite channels in 4 different A B C D:
categories. (See page 29.)
While watching, you can toggle the selected channels by pressing
A B C D, , and .
29 FAVORITE: Set the favorite channels. (See page 29.)
30 CC: Display captions from a closed-caption source. (See page 17.)
31 AV MODE: Select an audio or video setting.
(When the input source is TV, INPUT 1, 2 or 3: STANDARD,
MOVIE, GAME, USER, INTELLIGENT, DYNAMIC (Fixed),
DYNAMIC. When the input source is INPUT 4, 5, 6, 7 or
8: STANDARD, MOVIE, GAME, PC, USER, INTELLIGENT,
DYNAMIC (Fixed), DYNAMIC) (See page 16.)
Remote Control Unit
• When using the remote control unit, point it at the TV.
12
Connecting to External Equipment
For connecting the TV to external equipment, use commercially available cables.
CAUTION
• To protect equipment, always turn off the TV before connecting any external equipment.
• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.
Connecting Audiovisual Equipment
You can connect many types of external equipment to your TV like a Blu-ray disc player, DVD player, VCR, Digital
TV tuner, HDMI equipment, game console or camcorder. To view external source images, select the input source
from on the remote control unit or on the TV. (See page 15.)INPUT
Analog Connection
COMPONENT OUT
AUDIO-L (White)
VIDEO (Yellow)
AUDIO-R (Red)
AUDIO-R (Red)
AUDIO-L (White)
AUDIO-R (Red)
AUDIO-L (White) P (Blue)B
Y (Green)
PR (Red)
When using S-VIDEO cable:
• Game console • Camcorder
• VCR
INPUT 2
When using component cable:
• Blu-ray disc player • DVD player • VCR
• Cable/Satellite set-top box
INPUT 1 or 2
When using composite cable:
• Blu-ray disc player • Game console • VCR
• DVD player • Camcorder
• Cable/Satellite set-top box
INPUT 1 or 3
Audio cable
Audio cable
S-VIDEO cable
AV cable
Component video cable
• To enjoy the AQUOS 1080p display capability, connect your external equipment using a component cable and set the
equipment to 1080p output.
• See page 13 for connecting a Blu-ray disc player, DVD player or a Cable/Satellite set-top box to the HDMI terminal.
• The COMPONENT terminals take priority over the VIDEO (INPUT 1) and S-VIDEO (INPUT 2) terminals.
13
Connecting to External Equipment
HDMI Connection
AUDIO
HDMI OUT
HDMI-certifi ed cable
HDMI-DVI conversion cable
INPUT 5, 6, 7 or 8
INPUT 6
Ø 3.5 mm stereo minijack cable
When using HDMI-DVI
conversion cable:
• When using an HDMI-DVI conversion cable, input the audio signal to the AUDIO terminal of INPUT 6.
When you input the audio signal via the AUDIO terminal with INPUT 6, set "PC Audio Select" to "Input 6 (HDMI)". (See page 44.)
• To enjoy the AQUOS 1080p display capability, connect your Blu-ray disc player or other external equipment using an HDMI-
certifi ed cable and set the equipment to 1080p output.
Connecting a Speaker/Amplifi er
DIGITAL AUDIO INPUT
OPTICAL
ANALOG AUDIO IN
AUDIO-L (White)
AUDIO-R (Red)
Audio cable
Optical fi ber cable
OUTPUT
DIGITAL AUDIO OUT PUT
Amplifi er with
analog audio input
Amplifi er with
digital audio input
It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 30 for details.) PCM audio
outputs from the terminal.
• Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI
connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz.
14
4 When Air is selected in Antenna setting:" "
Press c/d to select "Start", and then press .ENTER
When Cable is selected in Antenna setting:" "
Press a/b to select "Analog & Digital Search Start" to
search both analog and digital broadcasts, or to select
“Analog Search Start” to search only analog broadcasts,
and then press .ENTER
• The Channel search will start automatically.
• To exit the Channel search screen, select "Cancel", and
then press .ENTER
Language
TV Location
Air/Cable
CH Search
English
Español
Français
Analog & Digital Search Start
Cancel
Analog Search Start
Turning On/Off the Power
Press on the TV, or on the remote control unit to POWER TV POWER
turn the power on.
• POWER indicator (Green): The TV is on. (After a few seconds, a window
appears with sound.)
• The initial setup starts when the TV powers on for the fi rst time. If the TV has
been turned on before, the initial setup will not be invoked. For changing the
settings of the initial setup, perform EZ setup on the Setup menu on page 24.
Press on the TV, or on the remote control unit POWER TV POWER
again to turn the power off.
• The TV enters standby and the image on the screen disappears.
• The POWER indicator on the TV turns off.
• If you are not going to use this TV for a long period of time, be sure to remove
the AC cord from the AC outlet.
• Weak electric power is still consumed even when the TV is turned off.
Watching TV
Initial Setup
When you turn on the TV for the fi rst time, it will
automatically memorize the broadcasting channels
available in the region where you live. Perform the
following steps before you press on the TV POWER
remote control unit.
1. Insert the batteries into the remote control unit. (See page 8.)
2. Connect the antenna cable to the TV. (See page 8.)
3. Plug in the AC cord to the AC outlet. (See page 7.)
Language (Language setting)
Select from among 3 languages: English, French and Spanish.
1 Press a/b to select the desired language listed on the
screen, and then press .ENTER
CH Se Channel search)arch (
Channel auto search makes the TV look for all channels
viewable in the set area.
TV Location
Select "Home" or "Store" for the location where you plan to
install the TV. This product qualifi es for ENERGY STAR V3.0
in Home mode default setting.
2 Press c/d to select "Home" or "Store".
Press ENTER to enter the setting.
Home Store
• If no channel is found, confi rm the type of connection made
with your TV and try EZ Setup again.
(See page 24.)
• For changing the settings of the initial setup, perform EZ
setup on the Setup menu on page 24.
Air Cable
ENERGY STAR qualifi cation is based on AV MODE "STANDARD".
Air/Cable (Antenna setting)
Make sure what kind of connection is made with your TV
when selecting "Air" or "Cable".
3 Press c/d to select "Air" or "Cable".
Press ENTER to enter the setting.
Home: “Power Saving” is set to "Advanced", and AV
MODE is set to "STANDARD".
Store:
“Power Saving” is set to "Off" and AV MODE is set to
"DYNAMIC (Fixed)". Picture Reset and Feature Demo can
be set.
Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)"
regardless of whether Picture Reset is "On" or "Off". If you
select "On", AV MODE will be reset to "DYNAMIC (Fixed)" if
there is no operation for 30 minutes. When "Off" is selected,
AV MODE will be set to "DYNAMIC (Fixed)".
Feature Demo: When “On” is selected, after all the settings are
completed, the Feature Demo screen is displayed if there is
no operation for several minutes.
POWER
Start Cancel
TV POWER
(On/Standby)
15
Direct Button Operation
Sleep Timer
Allows you to set a time when the TV automatically
switches to standby.
Press . SLEEP
•
The remaining time displays when the sleep timer has been set.
• Each time you press , the remaining time switches SLEEP
as shown below.
Off 30 60 90 120
• When set, the time automatically starts counting down.
• If you want to adjust the sleep timer, you can press SLEEP
twice then change the time setting.
• When it is 5 minutes before the time expires, the remaining
time will start to keep appearing every minute.
• Select "Off" by pressing to cancel the sleep timer.SLEEP
•
The TV will enter standby when the remaining time reaches 0.
FLASHBACK
Press to switch to the previously tuned FLASHBACK
channel.
• Press again to switch back to the currently FLASHBACK
tuned channel.
• FLASHBACK will not work if no channel has been
changed after the TV is turned on.
SURROUND
The surround function produces Surround effect from
the speakers. Each time you press , the SURROUND
mode changes between On and Off.
On: Makes it possible to enjoy natural, realistic surround
sound.
Off: Outputs the normal sound.
• You can have the same settings by choosing "Surround"
on the menu items. (See page 23.)
FREEZE
Allows you to capture and freeze a moving image that
you are watching.
Press .FREEZE
• A moving image is captured.
• Press again to cancel the function.FREEZE
• When this function is not available, "No displaying still
image available." will display.
• The still image automatically goes out after 30 minutes.
• If you are using the freeze function and a broadcast
activates the V-CHIP BLOCK, the freeze function will be
canceled and a V-CHIP BLOCK message will appear.
INPUT
To view external source images, select the input
source
using on the remote control unit or on the TV.INPUT
1 Press .INPUT
A list of selectable sources appears.
2 Press INPUT again or press a/b to select the input
source.
An image from the selected source automatically displays.
Each time is pressed, the input source toggles.INPUT
If the corresponding input is not plugged in, you cannot change
the input. Be sure to connect the equipment beforehand.
• See pages 12, 13, 38 and 42 for external equipment
connection.
•
•
•
•
Changing Channels
You can change channels by pressing CHU/V or 0 9-,
• (DOT).
Examples:
To select a 1 or 2-digit channel number (e. g., Channel 5):
Press 5 ENT .
To select a 3-digit channel number (e. g., Channel 115):
Press 1 1 5 ENT .
To select a 4-digit channel number (e. g., Channel 22.1):
Press 2 2 (DOT) 1 ENT • .
• When selecting a 1-digit channel number, it is not
necessary to press before the number.0
• When you enter - only, channel selection will be made if 0 9
there is no operation within a few seconds.
• If you push "0" by itself, nothing will happen.
• Complete the above steps within a few seconds.
• When you enter - and • (DOT), channel selection will be 0 9
made if there is no operation within a few seconds.
Changing Volume
You can change the volume by pressing VOLk/l on
the TV or on the remote control unit.
• To increase the volume, press VOLk.
• To decrease the volume, press VOLl.
20
Audio status
Output device Output Select
Fixed Variable
Speaker Variable sound Mute
• When "Output Select" is set to "Variable", the indicator on
the screen changes as shown below.
60
• See page 28 for details on the Output Select function.
MUTE
Mutes the current sound output.
Press .MUTE
• " " will be displayed on the screen for 30 minutes, and
the sound is silenced.
• Within 30 minutes of pressing , mute can be MUTE
canceled by pressing VOLk/l or .MUTE
• Mute will be canceled after 30 minutes have passed.
However, the TV will not suddenly output a loud sound as
the volume level is set to 0 automatically.
16
AV MODE
AV MODE gives you several viewing options to choose
from to best match the surrounding environment of the
TV, which can vary due to factors like room brightness,
type of program watched or the type of image input
from external equipment.
Press . Current AV MODE displays.AV MODE
• Press again before the mode displayed on the AV MODE
screen disappears. The mode changes as shown below:
Example:
When the input source is TV, INPUT 1, 2 or 3 terminals
STANDARD MOVIE GAME USER [TV]
DYNAMIC DYNAMIC (Fixed) INTELLIGEN
T
Example:
When the input source is INPUT 4, 5, 6, 7 or 8
terminals
STANDARD MOVIE GAME PC USER[ ]
DYNAMIC DYNAMIC (Fixed) INTELLIGENT
STANDARD: For a highly defi ned image in a normal
lighting.
MOVIE: For a movie.
GAME: Lowers image brightness for easier viewing.
PC: For PC.
USER: Allows the user to customize settings as desired.
You can set the mode for each input source.
INTELLIGENT: Optimizes the image quality automatically
based on the room brightness and image signal.
DYNAMIC (Fixed): Changes the image and sound
settings to the factory preset values. No adjustments
are allowed.
DYNAMIC: For a clear-cut image emphasizing high
contrast, useful for sports viewing.
• You can select a different AV MODE item for each input
mode. (For example, select STANDARD for TV input and
DYNAMIC for INPUT 1.)
• When you play games, "GAME" is recommended for AV
MODE.
Direct Button Operation
AUDIO
■ MTS/SAP stereo mode
The TV has a feature that allows reception of sound
other than the main audio for the program. This feature
is called Multi-channel Television Sound (MTS). The TV
with MTS can receive mono sound, stereo sound
and Secondary Audio Programs (SAP). The SAP
feature allows a TV station to broadcast other
information, which could be audio in another language
or something completely different like weather
information.
You can enjoy Hi-Fi stereo sound or SAP broadcasts
where available.
• Stereo broadcasts: View programs like live sporting
events, shows and concerts in dynamic stereo sound.
• SAP broadcasts: Receive TV broadcasts in either MAIN
or SAP sound.
MAIN sound: The normal program soundtrack (either in
mono or stereo).
SAP sound: Listen to a second language, supplementary
commentary or other information. (SAP is mono sound.)
If stereo sound is diffi cult to hear.
• Obtain a clearer sound by manually switching to fi xed
mono-sound mode.
You can change MTS as shown below to match the television
broadcast signal.
Press to toggle between audio modes.AUDIO
Examples: when receiving MTS and SAP
STEREO mode: STEREO MONO
STEREO + SAP mode: ST(SAP) SAP(ST) MONO
MAIN + SAP mode: MAIN SAP
MONO mode: MONO
■ Digital broadcasting audio mode
The types of audio transmitted in a digital broadcast include
SURROUND as well as MONO and STEREO. In addition, it
is possible for multiple audio tracks to accompany a single
video track.
Press to toggle between audio modes.AUDIO
Example: when receiving Digital broadcasting
STEREO (Audio1) STEREO (Audio2)
SURROUND (Audio3)
• MTS only operates while in TV mode.
17
1/3 ENG 2/3 CC1 3/3 Text1 Off
POWER SAVING
Allows you to set the Power Saving level in order to
decrease the power consumption and increase the
backlight lifespan.
Press .POWER SAVING
• Each time you press POWER SAVING, the mode changes
as shown below.
Off Standard Advanced
• You can have the same settings by choosing "Power
Saving" on the menu items. (See page 23.)
Closed Captions and Digital Closed Captions
Your TV is equipped with an internal Closed Caption
decoder. It allows you to view conversations, narration
and sound effects as subtitles on your TV. Closed
Captions are available on some TV programs and on
some VHS home video tapes at the discretion of the
program provider.
Digital Closed Caption service is a new caption service
available only on digital TV programs (also at the
discretion of the service provider). It is a more fl exible
system than the original Closed Caption system,
because it allows for a variety of caption sizes and font
styles. When the Digital Closed Caption service is in
use, it will be indicated by the appearance of a 3-letter
abbreviation that also indicates the language of the
Digital Closed Captions: ENG (English), SPA (Spanish),
FRA (French) or other language codes.
Not all programs and VHS videotapes offer closed
captions. Please look for the “1” symbol to ensure
that captions will be shown.
In the Closed Caption system, there can be more than
one caption service provided. Each is identifi ed by its
own number. The “CC1” and “CC2” services display
subtitles of TV programs superimposed over the
program's picture.
In the Closed Caption system, the “Text1” or “Text2”
services display text that is unrelated to the program
being viewed (e.g., weather or news). These services
are also superimposed over the program currently
being viewed.
• Depending on the number of caption services in the
signal being received, you will see information such as
1/2 or 1/4 displayed.
1/2 means “the fi rst of two services”.
Example:
If a program has three services (Digital CC(ENG), CC1
and Text1), the closed caption display will toggle in this
sequence:
• The button keeps a record of the last service CC
selected in its memory.
If the last closed caption mode (e.g. 1/3 ENG) you
selected is not available for the next program, or on
another channel, the closed caption service that is
available is automatically selected, and this service
appears in parentheses, e.g. “1/3(CC1)”.
Closed Caption services that appear in parentheses
will not be stored in the button's memory as your CC
last selected service. Only services that you have
selected with the button are stored.CC
Examples:
In a case where there are two closed caption
services provided (for instance, Digital CC(ENG)
and CC1), and Digital CC(ENG) is displayed
as your current selection, if Digital CC(ENG) is
not broadcast for the next program, the other
closed caption service, CC1, will be displayed in
parentheses.
A closed caption service appears in parentheses
because the service you selected is not available
and a different service is displayed on your screen.
“1/1(CC1)” is displayed instead of “1/2/ENG”.
• When “Power Saving” is set to “Standard” or “Advanced”,
the Power Saving leaf icon appears on the channel
information window. See page 23 for details of Power
Saving settings.
• See page 29 for detailed closed caption settings.
• When the program contains no closed caption, “--”
displays in the closed caption information.
• If the language code, e.g. “ENG”, is not found on Digital TV
programs, “--” will be shown.
• Four kinds of closed caption service (CC1, CC2, Text1,
Text2) are potentially available, but a broadcast may
contain none or only some of these services at the
discretion of the program provider.
• When the Sidebar Widget, TV+Web or Web is displayed,
Closed Captions are not available.
Direct Button Operation
Press while the Closed Caption information is CC
still on the screen.
• Press repeatedly until you select the desired closed
caption service.
2
Closed Caption
information
22.1
Air DIGITAL
Audio : MONO
:
CC 1/2 CC1:
Video 1080i (16:9)
Ratings : NONE: NONE
Press .CC
• This will present the Closed Caption information
display.
1
18
Direct Button Operation
VIEW MODE
You can select the screen size.
1 Press VIEW MODE.
• The View Mode menu displays.
• The menu lists the View Mode options selectable for the type of video signal currently being received.
2 Press VIEW MODE or a/b while the View Mode menu is displayed to select a desired item on the menu.
• You can sequentially select a View Mode that has its own aspect ratio.
■ For 4:3 programs
Example: Screen size images
Side Bar S.Stretch (Smart stretch) Zoom Stretch
Suitable for viewing
conventional 4:3 programs in
their normal format.
Suitable for stretching 4:3
programs to fi ll the screen.
Suitable for viewing wide-
screen 2.35:1 anamorphic
DVDs in full screen.
This mode is useful for 1.78:1
DVDs. When viewing 1.85:1
DVDs, stretch mode will still show
very thin black bands at the top
and bottom of the screen.
■ For HD programs
Stretch: Suitable for viewing wide-screen 1.78:1 aspect ratio program, stretch mode will still show very thin black bands at
the top and bottom of the screen.
Dot by Dot (1080i/p only): Detects the resolution of the signal and displays an image with the same number of pixels on
the screen.
Full Screen (720p only): You can select "Full Screen" only when receiving a 720p signal.
S.Stretch (Smart stretch): Suitable for stretching 4:3 programs to fi ll the screen.
Zoom: Suitable for viewing wide-screen 2.35:1 aspect-ratio programs in full screen.
•
When using Dot by Dot or Full Screen, it is possible to see noise or bars around different outer portions of the screen. Please
change view mode to correct this.
19
ENTER
: Select : Enter MENU : Exit
RETURN
: Back
1 Item displayed in yellow
• This indicates the item currently selected.
• Press ENTER to go to the adjustment screen for this
item.
2 Item in brackets
• This indicates the current setting for the item.
3 Item displayed in white
• This indicates that the item can be selected.
4 Item displayed in gray
• This indicates that the item cannot be selected.
There are various reasons why the items cannot be
selected, but the main reasons are as follows:
—Nothing is connected to the selected input terminal.
—The function is not compatible with the current input
signal.
1 Press c/d to select the desired item.
2 Press a/b to select the desired item.
3 Press c/d to adjust the item.
On-Screen Display Menu
On-Screen Display Menu Operation
MENU: Press to open or close the menu screen.
a/b/c/d: Press to select a desired item on the screen or
adjust a selected item.
ENTER: Press to go to the next step or complete the
setting.
RETURN: Press to return to the previous step.
The bar above is an operational guide for
the remote control. The bar will change in
accordance with each menu setting screen.
Example
Menu Operation Buttons
Using the control panel of the main unit
You can also operate the menu with the control panel
of the main unit.
Button operations on the control panel correspond to
the ones on the remote control as shown below.
Using the remote control
Use the following buttons on the remote control to
operate the menu.
MENU: MENU on the remote
control.
INPUT: ENTER on the remote
control.
CHU/V: Cursor a/b on the
remote control.
VOLk/l: Cursor c/d on the
remote control.
LCFONT:
• This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly displaying easy-
to-read characters on LCD screens.
• Menu options differ in the selected input modes, but the operating procedures are the same.
• The screens in the operation manual are for explanation purposes (some are enlarged, others cropped) and may vary slightly
from the actual screens.
LCFONT embedded Example
Contrast
OPC
Brightness
Color
Tint
Sharpness
Advanced
Reset
[ 30]b
[ 0]
[ 0]
[ 0]
[ 2]b
0
a30
a30
a30
a10
b40
b30
b30
b30
b10
Backlight [ 12] 16b a b16
Off On On : Display
Option
[No]Program Title Display
[On]Clear Voice
Auto Volume
Favorite CH
[Off]Operation Lock Out
Demo Mode
[No]Channel selecting effect
Caption Setup
Digital Caption Info.
Audio Only
Output Select [Fixed]
AQUOS LINK Setup
PC Audio Select [Input
4
(PC)]
[On]
20
On-Screen Display Menu
Menu Items
Setup Menu
EZ Setup ............................................Page 24 * 3
CH Setup ...........................................Page 24 * 3
Antenna Setup-DIGITAL .....................Page 24 * 3
Input Skip ...........................................Page 24
Auto Sync. ........................................Page 44 * 4
Input Label .........................................Page 24 * 1
Parental CTRL .............................Pages 25-27 * 3
Fine Sync. .........................................Page 44 *4
Position ..............................................Page 25 * 1
Language ...........................................Page 25
Blue Illumination .................................Page 25
Reset .................................................Page 25
Option Menu
AQUOS LINK Setup ...........................Page 35
Audio Only .........................................Page 28
Input Select ........................................Page 28 * 3
HDMI Setup .......................................Page 28 *4
PC Audio Select .................................Page 44
Auto Volume ......................................Page 28
Clear Voice .........................................Page 28
Output Select .....................................Page 28 *5
Color System .....................................Page 29 * 3
Caption Setup ....................................Page 29 * 3
Digital Caption Info. ............................Page 29 * 3
Program Title Display ..........................Page 29 * 3
Favorite CH ........................................Page 29 * 3
Game Play Time .................................Page 29 * 2
Operation Lock Out ............................Page 29
Channel selecting effect .....................Page 29
Demo Mode .......................................Page 29 *5
Digital Setup Menu
Audio Setup .......................................Page 30 * 3
Communication Setup ........................Page 47 * 3
Interactive Service ..............................Page 47 * 3
Identifi cation .......................................Page 30 * 3
Software Update .........................Pages 30-31 * 1
Picture Menu
OPC ...................................................Page 21
Backlight ............................................Page 21
Contrast .............................................Page 21
Brightness ..........................................Page 21
Color ..................................................Page 21
Tint .....................................................Page 21
Sharpness ..........................................Page 21
Advanced
C.M.S.-Hue ............................. Page 21 * 1
C.M.S.-Saturation ...................Page 21 * 1
C.M.S.-Value...........................Page 21 * 1
Color Temp. ...........................Page 21 * 2
Fine Motion Enhanced ............Page 22 *2
Active Contrast .......................Page 22 * 1
Gamma Adjustment ................Page 22 * 2
Black Level..............................Page 22 * 1
Film Mode ...............................Page 22 * 1
Digital Noise Reduction ...........Page 22 *1
3D-Y/C ...................................Page 22 * 3
Monochrome ..........................Page 22 * 1
Range of OPC .........................Page 22
Reset .................................................Page 21
Audio Menu
Treble .................................................Page 23
Bass ...................................................Page 23
Balance ..............................................Page 23
Surround ............................................Page 23
Bass Enhancer ...................................Page 23 * 2
Reset .................................................Page 23
Power Control Menu
Power Saving .....................................Page 23 * 2
No Signal Off ......................................Page 23 * 1
No Operation Off ................................Page 23
When AV MODE is set to "INTELLIGENT", part of the menu may not be displayed correctly or the setting range of the menu
may be changed.
Some menu items may not be displayed depending on the selected input source.
When confi guring a menu, be sure to select the input source according to the menu items to be confi gured. If a menu is not
displayed, check whether one of the following may be the source of the problem.
*1 The TV is connected to the Internet (HTML mode).
Photos or music on a connected USB memory device are being viewed or played back (USB mode).
*2 Photos or music on a connected USB memory device are being viewed or played back (USB mode).
*3 Audio and video are being inputted to the TV from external HDMI equipment or video is being inputted from a computer
(INPUT 4, 5, 6, 7, 8).
The TV is connected to the Internet (HTML mode).
Photos or music on a connected USB memory device are being viewed or played back (USB mode).
*4 A TV program is being viewed (TV).
Audio and video are being inputted from external analog equipment (INPUT 1, 2, 3).
The TV is connected to the Internet (HTML mode).
Photos or music on a connected USB memory device are being viewed or played back (USB mode).
*5 The TV is connected to the Internet (HTML mode).
•
•
•
21
On-Screen Display Menu
OPC Setting
Automatically adjusts the brightness of the screen.
Off: The brightness is fi xed at the value set in "Backlight".
On: Automatically adjusts.
On: Display: Displays the OPC effect on the screen while
adjusting the brightness of the screen.
• When set to "On", the Optical Picture Control (OPC)
senses the surrounding light and automatically adjusts
the backlight brightness. Make sure nothing obstructs
the OPC sensor, which could affect its ability to sense
surrounding light.
• When set to "On: Display", OPC effect displays on the
screen while the OPC adjusts the screen brightness.
• When set to "On" or "On: Display", the OPC indicator on
the TV lights green.
Advanced Picture Setting
This TV provides various advanced functions for
optimizing the picture quality.
C.M.S.
(Color Management System)
Color tone is managed using the six-color adjustment
setting.
C.M.S.-Hue: This is a standard to adjust the color either
more reddish or more bluish in tone.
C.M.S.-Saturation: Increases or decreases the
saturation of a selected color.
C.M.S.-Value: A higher value makes the image brighter.
A lower value makes the image darker.
•
For resetting all adjustment items to the factory preset
values, press
a/b
to select "Reset", and then press
ENTER
.
Color Temp.
(Color Temperature)
For a better white balance, use color temperature
correction.
High: White with bluish tone
Mid-High:
Middle:
Mid-Low:
Low: White with reddish tone
White balance can be adjusted between a maximum of
+30 and a minimum of –30 for each color temperature.
R Gain (LO/HI): –30 through +30
G Gain (LO/HI): –30 through +30
B Gain (LO/HI): –30 through +30
•
For resetting all adjustment items to the factory preset
values, press
a/b
to select "Reset", and then press
ENTER
.
Picture Menu
Adjusts the picture to your preference with the
following picture settings.
Contrast
OPC
Brightness
Color
Tint
Sharpness
Advanced
Reset
[ 30]b
[ 0]
[ 0]
[ 0]
[ 2]b
0
a30
a30
a30
a10
b40
b30
b30
b30
b10
Backlight [ 12] 16b a b16
Off On On : Display
Example
1 Press MENU to display the MENU screen, and then
press c/d to select "Picture".
2 Press a/b to select a specifi c adjustment item.
Select "Advanced" and then press to set ENTER
"C.M.S.-Hue", "C.M.S.-Saturation", "C.M.S.-Value",
"Color Temp.", "Fine Motion Enhanced", "Active
Contrast", "Gamma Adjustment", "Black Level",
"Film Mode", "Digital Noise Reduction", "3D-Y/C",
"Monochrome" or "Range of OPC".
3 Press a/b(or c/d) to select the desired setting,
and then press .ENTER
4 Press MENU to exit.
Selected item cbutton dbutton
Backlight The screen dims The screen
brightens
Contrast For less contrast For more contrast
Brightness For less
brightness
For more
brightness
Color For less color
intensity
For more color
intensity
Tint Skin tones
become reddish
Skin tones
become greenish
Sharpness For less
sharpness
For more
sharpness
• For resetting all Picture adjustment items to the factory
preset values, press a/b to select "Reset", press ENTER,
press c/d to select "Yes", and then press .ENTER
22
Fine Motion Enhanced
Use Fine Motion Enhanced to view fast-action video
more clearly.
On: For obtaining a clearer image.
Off: Normal image.
• Fine Motion Enhanced may cause image noise. If this
occurs, turn the function "Off".
Active Contrast
Automatically adjusts the image contrast according to
the scene.
On: Automatically adjusts the image contrast.
Off: No adjustment.
Gamma Adjustment
Adjusts the differences of picture tones between bright
parts and dark parts. The adjustment range of the
gamma can be set to a maximum of +2 and a minimum
of –2 by pressing c or d.
Black Level
Adjusts on-screen black level to your preferred level.
Low: The black level gets darker.
High: The black level gets brighter.
• "Black Level" is available for input signal from Composite
Video, S-Video, Component 480i and analog broadcasts
(air and cable).
Film Mode (3:2 pull-down)
Automatically detects a fi lm-based source (originally
encoded at 24 frames/second), analyzes it then recreates
each still fi lm frame for high-defi nition picture quality.
■ For LC-46LE700UN/LC-52LE700UN
Advanced(High)/Advanced(Low): Select a desired level
to remove jerkiness from fi lm contents.
Standard: Detects, analyzes, converts fi lm source.
Off: Normal viewing mode.
• "Film Mode" does not function when you set the "AV
Mode" to "Game".
• "Standard" does not function when channel display shows
an input signal resolution of 480p, 720p or 1080p.
• "Film Mode" is not available during PC format input.
■ For LC-40LE700UN
On: Detects, analyzes, converts fi lm source.
Off: Normal viewing mode.
• "Film Mode" does not function when you set the "AV
Mode" to "Game".
• "Film Mode" is not selectable when channel display shows
an input signal resolution of 480p, 720p, or 1080p.
On-Screen Display Menu
Digital Noise Reduction
Produces a clearer video image.
Auto: Automatically adjusts the level of noise reduction.
High/Middle/Low: Select a desired level for viewing a
clearer video image.
Off: No adjustment.
• "Digital Noise Reduction" is not available during PC format
input.
3D-Y/C
Provides high quality images with minimal dot crawl
and cross color noise.
Slow: For still images.
Standard: Normal adjustment.
Fast: For moving images.
• 3D-Y/C is available for input signal from Composite Video
and analog broadcasts (air and cable).
Monochrome
For viewing a video in monochrome.
On: For viewing in monochrome.
Off: Normal color.
Range of OPC
The brightness level range of the OPC sensor's automatic
adjustments can be set according to your preferences.
The adjustment range of the OPC sensor can be set to
a maximum of +16 and a minimum of –16.
Max.: –15 through +16
Min.: –16 through +15
• The range of OPC settings are active only when the OPC
is set to "On".
• The maximum setting cannot be set to a smaller number
than the minimum setting.
• The minimum setting cannot be set to a bigger number
than the maximum setting.
• Depending on the brightness of the surrounding light, the
OPC sensor might not operate if the adjustment range is
small.
23
On-Screen Display Menu
Audio Menu
You can adjust the sound quality to your preference
with the following settings.
Example
Audio
Treble
Bass
Balance
Surround
Bass Enhancer
Reset
[Off]
[On]
a15
L
b15
[ 0]
[ 0]
[ 0]
a15 b15
R
1 Press MENU to display the MENU screen, and then
press c/d to select "Audio".
2 Press a/b to select a specifi c adjustment item.
Select "Surround" or "Bass Enhancer" and then press
ENTER to set each item.
3 Press a/b (or c/d) to select the desired setting,
and then press .ENTER
4 Press MENU to exit.
Selected item c
button dbutton
Treble For weaker treble For stronger treble
Bass For weaker bass For stronger bass
Balance
Decrease audio from
the right speaker
Decrease audio from
the left speaker
• Audio menu is grayed out when Output Select is set to
"Variable". (See page 28.)
• For resetting all Audio adjustment items to the factory
preset values, press a/b to select "Reset", press ENTER,
press c/d to select "Yes", and then press .ENTER
Surround
Surround function allows you to enjoy realistic "live" sound.
On: Surround function is on.
Off: Normal sound.
• You can choose Surround by pressing on SURROUND
the remote control unit. (See page 15.)
• Audio menu is grayed out when Output Select is set to
"Variable". (See page 28.)
• For some discs, setup may be required on your DVD
player. In this case, please refer to the operation manual of
your DVD player.
Bass Enhancer
This function allows you to enjoy bass-enhanced sound.
On: Bass Enhancer function is on.
Off: Normal sound.
• Audio menu is grayed out when Output Select is set to
"Variable". (See page 28.)
•
Power Control Menu
Power control setting allows you to save energy.
Power Saving [Off]
No Signal Off [Disable]
No Operation Off [Disable]
Power Control
Example
1 Press MENU to display the MENU screen, and then
press c/d to select "Power Control".
2 Press a/b to select a specifi c adjustment item,
and then press .ENTER
3 Press a/b (or c/d) to select the desired setting,
and then press .ENTER
4 Press MENU to exit.
Power Saving
This function allows you to set the Power Saving level
in order to decrease the power consumption and
increase the backlight lifespan.
Standard: Optimizes power reduction based upon video
content. When set to "Standard", " " appears on the
screen.
Advanced: Optimizes power reduction based upon video
content and engages OPC. When set to "Advanced",
" " appears on the screen.
Off: This function does not work.
• "Power Saving" does not function when you set "AV
MODE" to "DYNAMIC (Fixed)".
• You cannot select a different Power Saving item for each
AV MODE.
When “Power Saving” is set, the “OPC” settings for all AV
Modes will automatically change.
—If you set “OPC” to “On” when “Power Saving” is set
to “Standard”, then the “Power Saving” setting will
change to “Advanced”.
—When you change the “Power Saving” setting from
“Advanced” to “Off” or to “Standard”, “OPC” will be set
to “Off”.
—“DYNAMIC (Fixed)” will remain set to “Off”.
• When "Power Saving" is set to "Standard" or "Advanced",
the Power Saving leaf icon appears to the left of "OPC" in
the Picture menu screen.
• You can select Power Saving by pressing POWER
SAVING on the remote control unit. (See page 17.)
No Signal Off
When set to "Enable", the power will automatically shut
down if there is no signal for 15 minutes.
• When it is 5 minutes before the power shuts down, the
remaining time will start to keep appearing every minute.
• "Disable" is the factory preset value.
•
When a TV program fi nishes, this function may not operate.
No Operation Off
When set to "Enable", the power will automatically shut
down if there is no operation for 3 hours.
• When it is 5 minutes before the power shuts down, the
remaining time will start to keep appearing every minute.
• "Disable" is the factory preset value.
24
Setup Menu
Example
CH Setup
Antenna Setup-DIGITAL
EZ Setup
Input Skip
Parental CTRL
Position
Language
Reset
[English]
Blue Illumination [On]
Setup
1 Press MENU to display the MENU screen, and then
press c/d to select "Setup".
2 Press a/b to select a specifi c adjustment item,
and then press .ENTER
When you select "EZ Setup", "CH Setup", "Parental
CTRL" or "Reset", you can enter the 4-digit secret
number here. See page 25 for setting a secret number.
3 Press a/b (or c/d) to select the desired setting,
and then press .ENTER
4 Press MENU to exit.
EZ Setup
You can run EZ Setup again, even after setting up the
preset channels.
Language: Select from among 3 languages (English,
French and Spanish).
TV Location: Select "Home" or "Store" for the location
where you plan to install the TV. This product qualifi es
for ENERGY STAR V3.0 in Home mode default setting.
Home: “Power Saving” is set to "Advanced", and AV MODE is
set to "STANDARD".
Store: “Power Saving” is set to "Off" and AV MODE is set to
"DYNAMIC (Fixed)". Picture Reset and Feature Demo can be
set.
Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)"
regardless of whether Picture Reset is "On" or "Off". If you
select "On", AV MODE will be reset to "DYNAMIC (Fixed)"
if there is no operation for 30 minutes. When "Off" is
selected, AV MODE will be set to "DYNAMIC (Fixed)".
Feature Demo: When “On” is selected, after all the settings
are completed, the Feature Demo screen is displayed if
there is no operation for several minutes.
ENERGY STAR qualifi cation is based on AV MODE
"STANDARD".
Air/Cable: Make sure what kind of connection is made
with your TV when selecting "Air" or "Cable".
CH Search: Channel auto search makes the TV look for
all channels viewable in the set area.
• See "Initial Setup" on page 14 for setting each item.
• If no channel is found, confi rm the type of connection
made with your TV and try EZ Setup again.
• If you select "Analog Search Start" and initiate the channel
search, the CH Memory for Cable Digital will be deleted.
•
•
CH Setup
If initial setup does not memorize all the channels in
your region, follow the instructions below to manually
memorize the channels.
Air/Cable: Make sure what kind of connection is made
with your TV when selecting "Air" or "Cable".
CH Search: Channel auto search makes the TV look for
all channels viewable in the set area.
CH Memory: You can select the channels to skip in each
ANALOG (Air), ANALOG (Cable), DIGITAL (Air) and
DIGITAL (Cable).
On: CHSkips channels. (Channel selection disabled using
U/V.)
Off: Does not skip channels. (Channel selection enabled using
CH U
/V.)
Remove Scrambled CH: This function makes the TV
look for and then delete digital cable channels that
are scrambled and so unavailable in the set area. The
process may take more than 20 minutes.
Yes: Starts to remove scrambled channels.
No: This function does not work.
• See "Initial Setup" on page 14 for setting each item.
• If no channel is found, confi rm the type of connection
made with your TV and try channel search again.
• If you select "Analog Search Start" and initiate the channel
search, the CH Memory for Cable Digital will be deleted.
Antenna Setup-DIGITAL
In order to receive digital air broadcasts, you need
a digital broadcast antenna. You can confi rm the
antenna confi guration through the "Antenna Setup-
DIGITAL" screen. If necessary, adjust the direction of
the antenna to obtain the maximum signal strength.
Signal Strength: The signal strength of DIGITAL channel
is displayed. The signal information is based on the
current channel.
Channel Strength: Input the 2-digit channel number
to check the signal strength of the selected channel.
Make sure the signal is strong enough for each
channel.
This function is available for DIGITAL (Air) only.
Input Skip
This setting allows you to skip the HDMI or PC-IN Input
("Input 4 (PC)", "Input 5 (HDMI)", "Input 6 (HDMI)",
"Input 7 (HDMI)" and "Input 8 (HDMI)") on the Input
Selection operation.
Yes: Skips the input.
No: Does not skip input.
Input Label
Lets you set the input terminal displayed when using
the INPUT SOURCE menu or channel display. Press
a/b/c/d to select the new name for the input
mode.
• Using the software keyboard, you can enter up to 10
characters for text. (See page 48.)
• You cannot change labels if the INPUT SOURCE is TV.
•
On-Screen Display Menu
25
Position
For adjusting a picture's horizontal and vertical
position.
H-Pos.: Centers the image by moving it to the left or
right.
V-Pos.: Centers the image by moving it up or down.
• For resetting adjustments to the factory preset values,
press a/b to select "Reset", and then press .ENTER
• When connecting a PC to the HDMI terminal, the image
position will be automatically adjusted. It cannot be
manually adjusted.
• The screen position variable ranges depend on the View
Mode or the signal type. The ranges can be seen on the
position-setting screen.
• Adjustments are stored separately according to input
source.
Language
You can also select a language from the Setup menu.
Select from among 3 languages: English, French and
Spanish.
Blue Illumination
When this function is set to "On", the LED on the front
of the TV turns on.
• "On" is the factory preset value. If you want to turn off the
LED, set the function to "Off".
Reset
If complex adjustments are made and the settings
cannot be restored to normal, you can reset the
settings to the factory preset values.
1 "Return to the factory preset values" displays on the
screen.
If you have already set the Secret No., input the 4-digit
secret number here.
2 Select "Yes".
"Now, TV will restart automatically. OK?" displays on the
screen.
3 Select "Yes".
"Now initializing..." displays on the screen and blinks.
After the reset has been completed, the power shuts off
and then comes back on. The screen will have returned
to its original settings.
• The Channel Setup settings will not be changed.
• The Language settings will not be changed.
• The Secret number settings will not be changed.
• The TV Location settings will not be changed.
•
•
•
Parental CTRL
(Parental Control Setting)
Secret No.
Allows you to use a secret number to protect certain
settings from being accidentally changed.
IMPORTANT:
Three conditions must be met to enable the V-Chip (see
pages 26 to 27):
1.
Secret No. is registered.
2.
V-Chip/V-Chip (DTV Only) settings have been made.
The “V-Chip (DTV Only)” will only be selectable when a new
rating system can be downloaded via digital broadcasting in the
U.S.
3. "
Status
"
is set to
"
On
"
.
■
New Secret No.
You can set and change the secret number by using
0 9- .
Input Secret No.: When you change the secret number,
enter the old 4-digit secret number here. The cursor
moves to "New Secret No.".
New Secret No.: When you set the new secret number,
enter the new 4-digit secret number here. The cursor
moves to "Reconfi rm".
Reconfi rm: Enter the same 4-digit number you set in
"New Secret No.".
■
Secret No. Clear
You can clear your secret number.
Yes: Your secret number is cleared.
No: Your secret number is not cleared.
• As a precautionary measure, make a note of your secret
number and keep it in a familiar place.
• If the secret number is cleared, the Status setting
automatically sets to "Off". "V-Chip" and "Status" will not
be selectable from the menu.
Status
Used to enable or disable the parental control function.
This function will not be selectable from the menu if
you do not fi rst confi gure your secret number.
On: Enables Parental CTRL.
Off: Disables Parental CTRL.
•
On-Screen Display Menu
26
On-Screen Display Menu
V-Chip
V-CHIP is an electronic fi ltering device built into your
TV. This tool gives parents a great degree of control
over broadcasts accessed by their children. It allows
parents to select programs judged suitable for child
viewing while blocking ones judged not suitable. It
does so automatically once you activate the V-CHIP
feature in your TV. "V-Chip" and "Status" will not be
selectable from the menu if you do not fi rst confi gure
your secret number.
• The U.S. has two rating systems for viewing content: TV
Parental Guidelines and movie ratings.
• The TV Parental Guidelines work in conjunction with the
V-CHIP to help parents screen out inappropriate television
shows from their children.
• Movie ratings are used for original movies rated by the
Motion Picture Association of America (MPAA) as watched
on cable TV and not edited for television. The V-CHIP can
also be set to block MPAA-rated movies.
• The setting automatically enters "Block" for any ratings
below your selection.
• If Status is not set to "On", the confi guration settings will
not work.
■
MPAA (Voluntary movie rating system)
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings PG-13
R
NC-17
X
NONE
PG
G
Press a/b to adjust the item to your desired position.
" " indicates the item is blocked. Press to exit.MENU
G: General audiences. All ages admitted.
PG: Parental guidance suggested. Some material may not be
suitable for children.
PG-13: Parents strongly cautioned. Some material may be
inappropriate for children under 13.
R: Restricted. Under 17 requires accompanying parent or
adult guardian (age varies in some jurisdictions).
NC-17: No one 17 and under admitted.
X: X is an older rating that is unifi ed with NC-17 but may be
encoded in the data of older movies.
• Voluntary movie rating system only uses an age-based
rating.
■ TV Parental Guidelines
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings L
S
V
FV
D
TV-G
TV-PG
TV-14
TV-MA
NONE
TV-Y7
TV-Y
Pressa/b to adjust the item to your desired position.
" " indicates the item is blocked. Press to exit.MENU
Suggested age
TV-Y: All children.
TV-Y7: Directed to older children.
TV-G: General audience.
TV-PG: Parental Guidance suggested.
TV-14: Parents strongly cautioned.
TV-MA: Mature audience only.
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings L
S
V
D
TV-G
TV-PG
TV-14
TV-MA
NONE
TV-Y7
TV-Y
FV
When setting an individual content-based rating item:
1 Press d or to access blocked content ENTER
items from the currently selected age-based rating
item.
2 Pressa/
b to select an individual item, and then
press to unblock it (" " is removed). Repeat ENTER
the same steps for the other items.
3 Press c or to register after all individual RETURN
content rating items are set.
Content
FV: Fantasy violence.
V: Violence.
S: Sexual situation.
L: Adult language.
D: Sexually suggestive dialog.
Rating
Content
FV V S L
D
Suggested
age
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
: The content rating can be set, but this rating is not
normally broadcast by TV stations.
: Content rating can be set.
27
■ Canadian French Ratings
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings 8ans+
13ans+
16ans+
18ans+
NONE
G
E
Press a/b to adjust the item to your desired position.
"" indicates the item is blocked. Press to exit.MENU
E: Exempt programming.
G: General: All ages and children, contains minimal direct
violence, but may be integrated into the plot in a humorous
or unrealistic manner.
8ans+: General but inadvisable for young children: May
be viewed by a wide public audience, but could contain
scenes disturbing to children under 8 who cannot
distinguish between imaginary and real situations.
Recommended for viewing with parent.
13ans+: Over 13 years: Could contain scenes of frequent
violent scenes and therefore recommended for viewing with
parent.
16ans+: Over 16 years: Could contain frequent violent scenes
and intense violence.
18ans+: Over 18 years: Only for adult viewing. Could contain
frequent violent scenes and extreme violence.
■ How to temporarily release the V-CHIP BLOCK
When the V-CHIP BLOCK is working and censors a
broadcast, "V-CHIP HAS BEEN ACTIVATED." displays.
1 Press ENTER while the V-CHIP is working, and
then the secret number setting menu displays.
2 Input the 4-digit secret number by using . At this 0 9–
time V-CHIP BLOCK temporarily releases.
■ Reactivating the temporarily released V-CHIP
BLOCK
You can reactivate the temporarily released V-CHIP
BLOCK as shown below.
• Select "Status" setting from the Parental CTRL menu to
reactivate BLOCK. (See page 25.)
• Select "V-Chip" setting ("MPAA", "TV Guidelines", "Can.
English Ratings" or "Can. French Ratings") from the
Parental CTRL to reactivate BLOCK. (See pages 25 to 26.)
• Switch off the TV power.
• Performing any of the three above will activate the V-CHIP
BLOCK.
On-Screen Display Menu
Canadian Rating Systems (Canadian English ratings
and Canadian French ratings)
• The TV rating systems in Canada are based on the
Canadian Radio-Television and Telecommunications
Commission (CRTC) policy on violence in television
programming.
• While violence is the most important content element to
be rated, the structure developed takes into consideration
other program content like language, nudity, sexuality and
mature themes.
• When setting the V-CHIP on the Canadian system you
can choose either the Canadian English ratings or the
Canadian French ratings.
■ Canadian English Ratings
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
E
C
C8+
G
PG
14+
18+
NONE
Press a/b to adjust the item to your desired position.
" " indicates the item is blocked. Press to exit.MENU
E: Exempt: Includes news, sports, documentaries and other
information programming; talk shows, music videos, and
variety programming.
C: Children: Intended for younger children under the age of 8
years. Pays careful attention to themes that could threaten
their sense of security and well-being.
C8+: Children over 8 years old: Contains no portrayal
of violence as the preferred, acceptable, or only way
to resolve confl ict; nor encourage children to imitate
dangerous acts which they may see on the screen.
G: General: Considered acceptable for all age groups.
Appropriate viewing for the entire family, contains very little
violence, physical, verbal or emotional.
PG: Parental Guidance: Intended for a general audience, but
may not be suitable for younger children (under the age of 8)
because it could contain controversial themes or issues.
14+: Over 14 years: Could contain themes where violence
is one of the dominant elements of the storyline, but it
must be integral to the development of plot or character.
Language usage could be profane and nudity present
within the context of the theme.
18+: Adults: Intended for viewers 18 years and older and
might contain depictions of violence, which while related to
the development of plot, character or themes, are intended
for adult viewing. Could contain graphic language and
portrayals of sex and nudity.
28
On-Screen Display Menu
Option Menu
Audio Only
PC Audio Select
Output Select
AQUOS LINK Setup
Caption Setup
Digital Caption Info.
Program Title Display
Favorite CH
Game Play Time
Operation Lock Out
[Input 4 (PC)]
[Fixed]
Clear Voice [On]
Auto Volume [On]
[No]
[Off]
[Off]
Demo Mode
Option
Channel selecting effect [No]
Example
1 Press MENU to display the MENU screen, and then
press c/d to select "Option".
2 Press a/b to select a specifi c adjustment item and
then press .ENTER
3 Press a/b (or c/d) to select the desired setting,
and then press .ENTER
4 Press MENU to exit.
Skip this step for "Audio Only".
Audio Only
When listening to music from a music program, you
can turn the screen off and enjoy audio only.
On: Audio is output without screen image.
Off: Both screen images and audio are output.
• The screen image will return to normal when a button
(except those for audio adjustment, such as , ,VOL MUTE
SURROUND AUDIO, ) is pressed.
Auto Volume
Different sound sources sometimes do not have the
same volume level, such as a program and its
commercial breaks. The Automatic Volume Control
(Auto Volume) reduces this problem by equalizing
levels.
Clear Voice
This function emphasizes speech against background
noise for greater clarity.
Input Select
•
Input Select
If the image does not come in clearly from the external
equipment connected to INPUT 1 or INPUT 2, you
may need to change the input signal type setting on
the "Input Select" menu.
■ INPUT 1
Select the input signal type from the list below:
Auto/COMPONENT/VIDEO
■ INPUT 2
Select the input signal type from the list below:
Auto/COMPONENT/S-TERMINAL
• If the selected signal type is incorrect, images are not
displayed at all or are displayed without any color.
• Refer to your external equipment operation manual for the
signal type.
• If you set INPUT 1 or 2 to Auto, the TV will automatically
select the input signal.
• Setting INPUT 1 or 2 signal selection to "Auto" when
other equipment is connected will result in the following
connection priority.
INPUT 1:
1 COMPONENT VIDEO
2 VIDEO
INPUT 2:
1 COMPONENT VIDEO
2 S-VIDEO
HDMI Setup
To watch an HDMI or PC-IN equipment image, select
"INPUT5", "INPUT6", "INPUT7" or "INPUT8" from
INPUT SOURCE menu using on the remote INPUT
control unit or on the TV.
Auto View:
Enable: To use View Mode based on signal
recognition, including an HDMI signal.
Disable: No function.
• Refer to your external equipment operation manual for the
signal type.
• When connecting an HDMI-DVI conversion adapter/cable
to the HDMI terminal, the image may not come in clearly.
Output Select
Allows you to select what controls the audio output.
Fixed: VOLSound via speaker is adjusted with k/l on
the remote control unit or VOLk/l on the TV.
Sound via the AUDIO OUTPUT terminal is not
adjustable and outputs at a consistent level.
Variable: Sound via the AUDIO OUTPUT terminal is
adjusted with VOLk/l on the remote control unit or
VOLk/l on the TV.
Sound via speaker is muted.
29
Color System
Select the video signal system compatible with your
equipment from the list below:
Auto/NTSC/PAL-M/PAL-N
• "Color System" can only be set for the INPUT 1 VIDEO,
INPUT 2 S-VIDEO and INPUT 3 VIDEO.
• If you have already set the Secret No., input the 4-digit
secret number here. See page 25 for setting a secret
number.
Caption Setup
This function allows you to adjust the closed
caption screen appearance to suit your preference.
You can adjust 7 items: "Caption Size", "Font
Style", "Foreground Color", "Foreground Opacity",
"Background Color", "Background Opacity" and
"Character Edge".
Example:
Selectable items available for "Font Style".
Default: The font specifi ed by broadcasting station or
default font.
Type 0: Proportional font used in the MENU screen.
Type 1: Monospaced with serifs.
Type 2: Proportionally spaced with serifs.
Type 3: Monospaced without serifs.
Type 4: Proportionally spaced without serifs.
Type 5: Casual font type.
Type 6: Cursive font type.
Type 7: Small capitals.
• For resetting adjustments to the factory preset values,
press a/b to select "Reset", and then press .ENTER
• The default value depends on the broadcasting station.
Digital Caption Info.
(Digital Caption Information)
This function allows viewing of digital closed caption
information for the digital broadcast program being
viewed.
• This list is not displayed for analog broadcasts or external
input audio/video.
• This information is not included in CC1, CC2, Text1, or
Text2, and is not displayed in a list.
Program Title Display
Select the CH display when changing channels for
digital broadcasting.
Yes: "Program Info." displays.
No: "Program Info." does not display.
Game Play Time
This function displays the elapsed game time so you
do not lose track of the time. To display the elapsed
time, select "GAME" for the AV MODE before starting
the game.
On: The elapsed time is displayed every 30 minutes when
you switch to GAME mode in external input mode.
Off: No adjustment.
On-Screen Display Menu
Operation Lock Out
This function locks the operation buttons on the TV
and the remote control.
Off: No adjustment.
RC Control Lock: All buttons on the remote control are
locked.
Button Control Lock: All buttons on the TV, except
POWER, are locked.
• To unlock the buttons on the remote control, press MENU
on the TV, and then select "Off" on the MENU screen.
• To unlock the buttons on the TV, press on the MENU
remote control, and then select "Off" on the MENU screen.
Favorite CH
(Favorite Channel Setting)
This function allows you to program 4 favorite
channels, in 4 different categories. By setting the
favorite channels in advance, you can select your
favorite channels easily.
To register your favorite channel:
Select "Register" and then press . Press ENTER a/b/c/
d to select the position in the category, and then press
ENTER to register.
To delete your favorite channel:
Select "1 Data Clear" and then press . Press ENTER
a/b/c/d to select the channel you want to delete, and
then press . Select "Yes" and then press .ENTER ENTER
To delete all the favorite channels, select "All Data Clear".
• Before setting the channel, select the channel you want to
register as a favorite channel.
• You can display the "Favorite CH" screen by pressing
FAVORITE on the remote control.
Channel selecting effect
You can select whether to use transition effects when
changing channels.
Yes: A transition effect is used when the channel is changed.
No: No function.
Demo Mode
You can select the image from several types of demo
mode.
120Hz Demo/LED Demo/Net/Feature Demo/
Auto Play
If you select "Auto Play", you need to set playback type.
Continuous: Play Demos continuously.
10 min.: Play Demos every 10 minutes.
20 min.: Play Demos every 20 minutes.
• This function will be canceled when you press on the EXIT
remote control unit.
• When "Demo Mode" is set to "Net" or "Feature Demo",
pressing pauses/restarts demo.FREEZE
• "Demo Mode" may not be selected depending on input
signal type.
• "Demo Mode" may be automatically canceled depending
on input signal type.
30
Digital Setup Menu
This setting allows you to optimize the settings of
Digital broadcasting.
Communication Setup
Interactive Service
Identification
Audio Setup
Software Update
[Yes]
[PCM]
Digital Setup
Example
On-Screen Display Menu
Software Update
This function allows software updates by inserting a
USB memory device with the update fi le into the USB
terminal on the TV.
To check for the availability of a software update, visit
www.sharpusa.com. If you have any questions, please
call 1-800-BE-SHARP (800-237-4277).
CAUTION
• Do not remove the USB memory device or unplug
the AC cord while the software is being updated.
• Be sure to properly follow the whole procedure
described below, step by step. Otherwise, for
example, the TV cannot read the data in the USB
memory device and software updating will fail.
Insert the USB memory device with the update fi le
into the USB terminal on the TV.
1
Press to display the MENU screen, and MENU
then press c/d to select “Digital Setup”.
2
Press a/b to select “Software Update”, and then
press .ENTER
• If you have already set the Secret No., go to step 4.
Audio Setup
Communication Setup
Software Update
Interactive Service
Identification
[PCM]
[Yes]
Digital Setup
3
Input the 4-digit secret number by using – .0 9
Digital Setup
Secret No. aaaa
4
1 Press MENU to display the MENU screen, and then
press c/d to select "Digital Setup".
2 Press a/b to select a specifi c adjustment item,
and then press .ENTER
3 Press a/b (or c/d) to select the desired setting,
and then press .ENTER
4 Press MENU to exit.
Audio Setup
You can output digital audio to an AV amplifi er or
similar device whose DIGITAL AUDIO INPUT terminal
is connected to the DIGITAL AUDIO OUTPUT terminal
on the TV. Please select an audio output format
compatible with the audio format of the program you
are watching and the equipment connected.
PCM: The optical output terminal outputs audio signal
in PCM form. If your digital audio system does not
support Dolby Digital, select "PCM".
Dolby Digital: The optical output terminal outputs audio
signal in Dolby Digital form. It reproduces sound from
surround program of digital.
Identifi cation
The current version of the TV software is displayed.
31
During the data checking, “Checking” blinks.
Checking
Now checking the data in the USB memory device.
• The current version of the TV software and the version
of the update fi le on the USB memory device are
displayed. To update the TV software with the update
fi le, select “Yes”, and then press .ENTER
Example
No
Current Version: UXXXXXX1
Software update file is detected
in the USB memory device.
Start update?
Update Version: UXXXXXX2
Yes
• If the USB memory device is not properly installed or
the correct update fi le cannot be found on the USB
memory device, an error message is displayed.
Check the fi le on the USB memory device, and then
reinsert the USB memory device correctly.
Software update file is not detected
in the USB memory device.
Confirm that you have transferred the file
to the USB memory device and retry software update.
OK
There is more than one software file
in the USB memory device.
Confirm that only the software update file is
in the USB memory device.
OK
6
Press to start updating.ENTER
• The screen becomes dark for a while until the update
screen can be displayed. Please wait for the update
screen to appear. Do not unplug the AC cord.
The picture will temporarily go dark until
the Software Update display appears.
Wait several minutes and do not unplug the AC cord.
OK
Example
30%
Now updating
Do not unplug AC cord.
Update Version UXXXXXX2
7
When the software is successfully updated, a
screen is displayed indicating that the update
process is completed.
After this screen is displayed, the TV automatically
turns off and then turns on again.
Example
Update Version UXXXXXX2
Software update is complete.
• If the update has failed, check the fi le in the USB
memory device and try Software Update again.
Failed to complete update.
Retry Software Update.
If system Update fails again,
contact the customer service center.
8
After the screen shown below is displayed, press
ENTER.
OK
System software was
successfully updated.
Remove the USB memory device.
9
Remove the USB memory device.
10
Press to start checking the data in the ENTER
USB memory device.
Insert the USB memory device containing
the software update file.
OK
5
CAUTION
• Do not remove the USB memory device or unplug
the AC cord while the software is being updated.
On-Screen Display Menu
32
Enjoying photo and music playback
You can enjoy viewing photos and listening to music from external USB memory devices.
Depending on the USB memory device, the TV may not be able to recognize the recorded data.
Use only alphanumeric characters for naming fi les.
File names over 80 characters (may vary depending on character set) may not be displayed.
Do not remove a USB memory device or memory card from the TV while transferring fi les, using the slide show function, or
switching screens, or before you exit "USB" from the INPUT SOURCE menu.
Do not insert and remove a USB memory device to and from the TV repeatedly.
•
•
•
•
•
Insert the USB memory device with recorded photos
or music into the USB terminal on the TV.
The display varies depending on the type of data recorded
in the USB memory device.
•
■When the USB memory device contains both
photos and music fi les
Thumbnails of the photos are displayed.
When there are multiple folders on the USB memory
device, the data in the folder in which the fi rst photo is read
is displayed.
To play back a music fi le, select "Change to Music Mode"
on the USB MENU screen. (See page 34.)
•
•
Displaying data with the INPUT SOURCE
menu screen
You cannot enter this mode when a USB memory device is
not inserted into the TV.
"VIEW MODE" is fi xed during this mode.
"USER (USB)" is the default value for the "AV MODE"
setting. Each time you press , the mode AV MODE
changes between "USER (USB)", "DYNAMIC (Fixed)",
"DYNAMIC" and "STANDARD".
•
•
•
USB memory device compatibility
USB memory
device
USB Memory, USB card reader (Mass
Storage class)
File system FAT/FAT32
Photo fi le
format
JPEG (.jpg) (DCF2.0 compliant)
Music fi le
format
MP3 (.mp3)
Bitrate: 32k, 40k, 48k, 56k, 64k, 80k,
96k, 112k, 128k, 160k, 192k, 224k,
256k, 320kbps
Sampling frequency: 32k, 44.1k, 48kHz
Progressive format jpeg fi les are not supported.
Music fi les in USB 1.1 devices may not be played properly.
Operation using USB hubs is not guaranteed.
•
•
•
1 Press to display the INPUT SOURCE menu MENU
screen.
2 Press again or press INPUT a/b to select "USB".
• The display varies depending on the type of data
recorded in the USB memory device.
Sample
Viewing photos and listening
to music
■When the USB memory device contains only
music fi les
An error message is displayed.
To play back a music fi le, select "Change to Music Mode"
on the USB MENU screen. (See page 34.)
•
33
Enjoying photo and music playback
Photo Mode
When there are invalid photo fi les, the mark will be X
displayed for the fi le.
You can see the fi le name, shooting date, fi le size and pixel
size of the selected photo in the lower-left corner of the
screen (shooting date is only available in the EXIF fi le format).
•
•
Viewing Thumbnails
Buttons Description
ENTER When selecting the folder icon with the
mark: Go back to the parent directory.
When selecting a folder icon: Enter this
directory.
When selecting a photo thumbnail: Display
the photo in full screen.
a/b/c/dSelect a desired item.
A (red) Go back to the previous page.
B (green) Go to the next page.
C (blue) Start the slide show.
D (yellow) Display the USB MENU screen.
Viewing Photos in Full Screen
The photo selected on the thumbnail selection screen
is displayed in full screen.
Buttons Description
c/dGo to the previous/next photo in the same
directory.
RETURN Return to the thumbnail selection screen.
A (red) Rotate the photo by 90 degrees to the left.
B (green) Rotate the photo by 90 degrees to the right.
C (blue) Reveal/hide the Guide Display.
D (yellow) Display the USB MENU screen.
Rotating photos only applies to the temporarily selected
item and this setting is not saved.
•
Music Mode
When there are invalid music fi les, the mark will be X
displayed for the fi le.
The displayed play time may differ slightly from the actual
play time depending on the fi les.
•
•
Buttons Description
ENTER When selecting the folder icon with the
mark: Go back to the parent directory.
When selecting a folder icon: Enter this
directory.
When selecting a music fi le: Play music.
a/bSelect a desired item.
dPage up.
cPage down.
A (red) Stop music.
B (green) Play/Pause music.
D (yellow) Display the USB MENU screen.
Sample
Select Music
ROOT
CLASSIC
SONG_01.MP3
SONG_02.MP3
SONG_03.MP3
SONG_04.MP3
SONG_05.MP3
SONG_06.MP3
SONG_07.MP3
SONG_08.MP3
Slide Show
The photos displayed on the thumbnail selection
screen are displayed as a slide show.
Buttons Description
RETURN Return to the thumbnail selection screen.
C (blue) Reveal/hide the Guide Display.
D (yellow) Display the USB MENU screen.
The selected BGM is played repeatedly.
The slide show continues until you press .RETURN
For setting the slide show speed, select "Slide Show
Interval" on the USB MENU screen. (See page 34.)
•
•
•
34
Enjoying photo and music playback
USB Menu
* The display varies depending on the selected mode.
When Photo mode is selected, "Change to Music Mode" is
displayed.
When Music mode is selected, "Change to Photo Mode" is
displayed.
Change to Photo Mode/Music Mode
Change the mode.
1 Press to display the USB MENU screen.D
2 Press a/b to select "Change to Photo Mode"/
"Change to Music Mode", and then press .ENTER
• The display varies depending on the selected mode.
When Photo mode is selected, "Change to Music
Mode" is displayed.
When Music mode is selected, "Change to Photo
Mode" is displayed.
• Each time is pressed, the setting changes ENTER
between Photo Mode and Music Mode.
Select USB Drive
If the inserted USB memory device contains multiple
drives, select the drive you want to display or play
back.
1 Press to display the USB MENU screen.D
2 Press a/b to select "Select USB Drive", and then
press .ENTER
3 Press a/b/c/d to select the drive, and then press
ENTER.
Up to 16 drives can be displayed.•
Slide Show Interval
Specify the length of time before the next image
appears.
1 Press to display the USB MENU screen.D
2 Press a/b to select "Slide Show Interval", and
then press .ENTER
3 Press a/
b to select the length of time, and then
press .ENTER
Select Slide Show Image
Select the images to be displayed.
1 Press to display the USB MENU screen.D
2 Press a/b to select "Select Slide Show Image",
and then press .ENTER
• The image selection screen is displayed.
3 Press a/
b/c/d to select the images, and then
press .ENTER
• Checkmarks are added to the selected images.
4 Press to start the slide show. C
All of the images are selected by default.
If no images have been selected, "No Images" is displayed
and the slide show does not start.
•
•
Change to Music Mode
Select USB Drive [Drive1]
Slide Show Interval [10sec]
Select Slide Show Image
Select Slide Show BGM
Select Auto Play Music
USB MENU
Drive1 Drive2 Drive3 Drive4
Drive5 Drive6
Sample
*
35
Enjoying photo and music playback
Select Slide Show Background Music
You can select the music to be played in the
background while the slide show is being displayed.
1 Press to display the USB MENU screen.D
2 Press a/b to select "Select Slide Show BGM",
and then press .ENTER
• The list screen is displayed.
3 Select the music.
• Checkmarks are added to the selected music.
• Use the following buttons to select the music.
Buttons Description
ENTER When selecting the folder icon with the
mark: Go back to the parent directory.
When selecting a folder icon: Enter this
directory.
When selecting a music fi le: Play music.
a/bSelect a desired item.
dPage up.
cPage down.
D (yellow) Display the USB MENU screen.
4 Press C to start the slide show and the background
music.
All of the music fi les are selected by default.•
Select Auto Play Music
You can select the music to be played back
1 Press to display the USB MENU screen.D
2 Press a/b to select "Select Auto Play Music", and
then press .ENTER
• The list screen is displayed.
3 Select the music.
• Checkmarks are added to the selected music.
Buttons Description
ENTER When selecting the folder icon with the
mark: Go back to the parent directory.
When selecting a folder icon: Enter this
directory.
When selecting a music fi le: Play music.
a/bSelect a desired item.
dPage up.
cPage down.
D (yellow) Display the USB MENU screen.
4 Press to play back the selected music.C
All of the music fi les are selected by default.
If no music fi les have been selected, "No Playable Files" is
displayed and the music is not played back automatically.
•
•
Select BGM
ROOT
CLASSIC
SONG_01.MP3
SONG_02.MP3
SONG_03.MP3
SONG_04.MP3
SONG_05.MP3
SONG_06.MP3
SONG_07.MP3
SONG_08.MP3
36
Presetting Remote Control Function
You can operate the connected AV products (AV
receiver, cable box, SAT tuner, DTV, VCR, DVD, LD)
using the presetting manufacturer function of your
remote control unit.
Presetting manufacturer codes
After the LED for your device lights up, press
FUNCTION DISPLAY and at the same time to
enter the code registration mode. The LED will
blink.
Press until the LED for your device FUNCTION
lights up.
After registering the code, the LED will stop blinking
then turn off after one second. (If you perform an
incorrect operation, the LED will blink quickly then
turn off.)
Press to enter the manufacturer code. (See 0–9
page 37.)
• Preset mode is fi nished once the LED no longer lights
up.
1
2
4
3
Operating the Connected Equipment
To operate the connected equipment, press
FUNCTION to select the LED for your device. (VCR,
AUDIO, CBL/SAT (cable converter) or BD/DVD.) The
LED lights up, and the remote control unit button will
function as follows.
• When you operate VCR or DVD, press to select the INPUT
terminal connected to your device.
• CABLE and SAT cannot be selected at the same time.
1 SOURCE POWER
• Turns the connected equipment power on and off.
2 *
• Rewinds the tape and allows picture search. (VCR)
• Hold down to go in reverse. (BD/DVD)
3 REC
• Starts recording. (VCR)
4 .
• Pressing quickly once takes you to the start of the chapter
currently playing. Each time you press it, you move back
to the start of the previous chapter. (BD/DVD)
5 0– (CBL/SAT), (DOT) (SAT)9 •
• Press a button (or buttons) that corresponds to the
channel that you wish to watch.
6 ,
• Starts playback. (VCR, BD/DVD)
7 -
• Rapidly advances the tape and allows picture search.
(VCR)
• Hold down to fast forward. (BD/DVD)
8 )
• Sets pauses and still pictures. (VCR, BD/DVD)
9 +
• Stops the tape transport. (VCR)
• Playback stops when pressed. With some DVD players,
pressing the button twice may open the disc tray. (BD/
DVD)
10 /
• Pressing quickly once takes you to the start of the next
chapter. Each time you press it, you move ahead to the
start of the next chapter. (BD/DVD)
11 FLASHBACK
• Press to switch between the current channel and the
channel you were watching immediately before. Some
manufacturers do not preset FLASHBACK. (CBL)
12 CHU/V
• Press CHU or CHV to tune in to a higher or lower
channel. (CBL)
• Press to select the channel of the TV tuner on the VCR.
(VCR)
13 MENU
• When this button is pressed, the DVD menu will display.
14 a/b/c
/d, ENTER
• a/b/c/
d: Press the button to select items on the SAT
GUIDE screen or SAT MENU screen. (SAT). Press the
button to select items on the DVD MENU screen. (BD/
DVD)
• Press to activate the selected function. (SAT, ENTER:
BD/DVD)
2
3
44
5
16
7
8
9
10
12
11
13
14
Other Viewing Options
37
Manufacturer codes
REMOTE CONTROL CODE
NUMBER
Other Viewing Options
VCR BRAND REMOTE CONTROL CODE
NUMBER
DVD/BD/LD BRAND
REMOTE CONTROL CODE
NUMBER
CATV/SAT BRAND
• Numbers marked with * are SAT codes, all others are
CATV codes.
AUDIO BRAND REMOTE CONTROL CODE
NUMBER
38
Using AQUOS LINK
Controlling HDMI Equipment Using AQUOS LINK
What’s AQUOS LINK?
• Using the HDMI CEC (Consumer Electronics Control) protocol, with AQUOS LINK you can interactively operate
compatible system equipment (Blu-ray disc equipment, AV amplifi er, DVD).
• By connecting AQUOS LINK-compatible devices with HDMI-certifi ed cables to the TV, you can control a
recorder or AV amplifi er using the remote control of the TV.
• AQUOS LINK allows you to operate the HDMI-connected equipment with one remote control.
Point the remote control toward the TV, not to connected HDMI equipment.
Video noise may occur depending on the type of HDMI cable used. Make sure to use an HDMI-certifi ed cable.
Up to 3 pieces of HDMI recording equipment and one AV amplifi er can be connected using this system.
These operations affect the HDMI equipment selected as the current input source. If the equipment does not operate, turn on
the equipment and select the appropriate input source using .INPUT
•
•
•
•
You can operate AQUOS LINK-compatible devices with the remote control
unit when the of the remote control unit is set to TV. FUNCTION
REC STOP OPTION and buttons will function only when AQUOS LINK is
used.
■One Touch Play
While the TV is in standby mode, it automatically turns on and plays back the
image from the HDMI source.
■One Touch Recording
Press while you are viewing a broadcast received with the AQUOS REC
LINK-compatible recorder. The AQUOS LINK automatically recognizes the
connected HDMI device and starts recording.
■Single remote control
The AQUOS LINK automatically recognizes the connected HDMI device and
you can control the TV and the devices as if using a universal remote control.
■Control the AQUOS LINK-compatible audio system
Set the volume of AQUOS LINK-compatible audio system.
The above description is an example of the AQUOS LINK function.
The steps in “AQUOS LINK Setup” on page 39 need to be completed beforehand.
Refer to this operation manual and the operation manual of the AQUOS LINK device to be used with this TV.
•
•
•
Example*
TV
AQUOS LINK-compatible
Audio system
Connecting AQUOS
BD Player via AQUOS
LINK-compatible
Audio system
AQUOS BD Player
HDMI-certified cable
(commercially available)
HDMI-certified cable
(commercially available)
Optical fiber cable
(commercially available)
* You can use the INPUT 5,
6, 7 or 8 terminal.
39
AQUOS LINK Setup
1 Press MENU to display the MENU screen, and then
press c/d to select "Option".
2 Press a/b to select “AQUOS LINK Setup”, and
then press .ENTER
3 Press a/b to select a specifi c item, and then press
ENTER.
4 Press a/b (or c/d ) to select the desired setting,
and then press .ENTER
5 Press to exit.MENU
AQUOS LINK Control
Select AQUOS LINK Control to disable AQUOS LINK
function even when an AQUOS LINK-compatible HDMI
device is connected to the TV. This function prevents
the device from starting to operate unexpectedly.
Enable: You can operate AQUOS LINK-compatible
equipment.
Disable: AQUOS LINK function does not work.
Selecting Recorder
Auto Power On
AQUOS LINK Control
Enable Disable
Auto Power On
If this is activated, the One Touch Play function is
enabled.
Yes: While the TV is in standby mode, it automatically
turns on and plays back the image from the HDMI
source.
No: This function does not work.
Selecting Recorder
Auto Power On
AQUOS LINK Control
Yes No
Using AQUOS LINK
Selecting Recorder
When multiple AQUOS LINK-compatible devices are
connected, this function allows you to set the recorder
for recording when you press on the TV’s remote REC
control unit.
Press a/b to select the recorder for recording.
Example
INPUT5
INPUT6
[1.0.0.0]
[2.0.0.0]
Input Location
Selecting Recorder
Auto Power On
AQUOS LINK Control
Example : when connecting AQUOS LINK-compatible
recorder via AQUOS LINK-compatible Audio
system
When an AQUOS LINK-compatible audio system or
other equipment is connected between the TV and
recorder, “Sub” is displayed.
5WDINPUT5
INPUT6
[1.1.0.0]
[2.0.0.0]
Input Location
Selecting Recorder
Auto Power On
AQUOS LINK Control
One Touch Recording
This function allows easy one-touch recording of the
program being viewed on the TV to AQUOS LINK-
compatible equipment with a recording function by
simply pressing on the remote control.REC
Prepare the connected AQUOS LINK-compatible
recorder for recording. Check the following items.
Make sure that the antenna cable is connected.
Check that there is suffi cient available space on the
recording media (HDD, DVD, etc.).
On the TV, use “AQUOS LINK Setup” and “Selecting
Recorder” to select the equipment for recording.
By default, the recorder connected to INPUT 5 is selected
for recording.
1 Press to start recording.REC
When you are viewing a broadcast received with
the AQUOS LINK-compatible recorder selected in
"Selecting Recorder", recording to the AQUOS recorder
of the broadcast being viewed starts.
When you are viewing a broadcast received with
equipment other than the AQUOS LINK-compatible
recorder selected in "Selecting Recorder" or other
external input equipment, pressing on the remote REC
control does not start recording.
2 Press to stop recording.REC STOP
•
•
•
•
•
•
40
AQUOS LINK Menu
Recorder EPG
Top menu/title list
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup menu
Model select
AQUOS LINK
Timer Recording
You can call up the AQUOS LINK-compatible
recorder’s EPG and preset timer recordings using the
TV’s remote control.
1 Press to display the AQUOS LINK MENU OPTION
screen.
2 Press a/b to select “Recorder EPG”, and then
press .ENTER
The recorder’s EPG is displayed.
3 Select the program to record.
• You can use a/b/c/d, ENTER RETURN EXIT, , and
the coloured buttons.
This function works only when an AQUOS LINK-compatible
recorder is connected.
Refer to the operation manual of the recorder for details.
•
•
•
Using AQUOS LINK
One Touch Playback
AQUOS LINK allows you to operate the HDMI-
connected equipment with one remote control.
Press d to start playing back a title.
The last played program is played back. You can use the
following buttons during broadcast viewing.
Buttons Description
SOURCE
POWER
Turns the power of the HDMI connected
devices on and off.
*Hold down to go in reverse.
,Starts playback.
-Hold down to fast forward.
+Playback stops.
)Sets pauses and still pictures.
7
Pressing quickly once takes you to the start
of the chapter currently playing. Each time
you press it, you move back to the start of
the previous chapter.
8
Pressing quickly once takes you to the start
of the next chapter. Each time you press
it, you move ahead to the start of the next
chapter.
You can use 7/8 only when the model BD-HP21U is
connected.
The buttons 7/8 do not function with the following
BD players currently available.
- BD-HP20U, BD-HP50U
•
•
•
41
Playback of Titles Using AQUOS LINK
This section explains how to play back a title in the
AQUOS LINK-compatible equipment.
1 Power on the AQUOS LINK-compatible equipment,
and select appropriate external input.
2 Press to display the AQUOS LINK MENU OPTION
screen.
3 Press a/b to select “Top menu/title list”, and then
press .ENTER
The title list data from the connected AQUOS LINK-
compatible equipment displays.
4 Select the title with a/b/c/d, and then press d
to start playback.
This function works only when AQUOS LINK-compatible
equipment is connected.
Selecting Media Type for AQUOS LINK-
Compatible Recorder
You can switch the media (HDD or DVD) for playback
or recording on the AQUOS LINK-compatible recorder.
1 Press to display the AQUOS LINK MENU OPTION
screen.
2 Press a/b to select “Media change”, and then
press .ENTER
3
Select the desired media such as DVD or HDD.
The Media type toggles each time you press in ENTER
“Media change”.
Select the media to be operated by the player.
Listening with the AQUOS AUDIO Speaker System
You can select to listen to the TV sound only from the
AQUOS LINK-compatible audio system and manually
change its sound mode.
1 Press to display the AQUOS LINK MENU OPTION
screen.
2 Press a/b to select “By AQUOS AUDIO SP”, and
then press .ENTER
The sound from the TV speaker is muted and only the
sound from the AQUOS LINK-compatible audio system
is audible.
You can use VOLk/l and .MUTE
Select “By AQUOS SP”, and then press to ENTER
listen to the TV sound.
•
•
•
•
•
•
Manually Changing AQUOS AUDIO Speaker
System’s Sound Mode
1 Press to display the AQUOS LINK MENU OPTION
screen.
2 Press a/b to select “Sound mode change”, and
then press .ENTER
The sound mode changes each time you press ENTER.
Refer to the operation manual of the AQUOS LINK-
compatible audio system for details.
Displaying the Setup Menu of AQUOS
LINK-Compatible Equipment
You can call up a setup menu from the connected
AQUOS LINK-compatible equipment.
1 Press to display the AQUOS LINK MENU OPTION
screen.
2 Press a/b to select "Setup menu", and then press
.ENTER
The setup menu of the AQUOS LINK-compatible
equipment is displayed.
Depending on the status of the equipment (recording or in
standby mode, etc), the setup menu will not be displayed.
This function works only when the model BD-HP21U or
BD-HP50U is connected.
The setup menu will not be displayed with the player
BD-HP20U currently available.
HDMI Device Selection
If multiple HDMI devices are connected in a daisy
chain, you can specify which device to control here.
1 Press to display the AQUOS LINK MENU OPTION
screen.
2 Press a/b to select “Model select”, and then
press . The HDMI device toggles each time ENTER
you press .ENTER
•
•
•
•
•
•
Using AQUOS LINK
42
Using a PC
When using HDMI cable:
AUDIO
HDMI OUT
AUDIO
HDMI-certifi ed cable
HDMI-DVI conversion cableI
INPUT 6
Ø 3.5 mm stereo minijack cable
When using analog RGB cable:
When using RS-232C serial control cable:
• When connecting a PC to the INPUT 4, set "PC Audio Select" to "Input 4 (PC)". (See page 44.)
• When connecting a PC to the INPUT 6, set "PC Audio Select" to "Input 6 (HDMI)". (See page 44.)
• The HDMI terminals only support digital signal.
• Refer to page 44 for a list of PC signals compatible with the TV.
Ø 3.5 mm stereo minijack cable
RGB cable
INPUT 4
RS-232C serial control cable (cross type)
RS-232C
INPUT 5, 6, 7 or 8
Connecting a PC
43
VIEW MODE
You can select the screen size.
1 Press .VIEW MODE
The View Mode menu displays.
The menu lists the View Mode options selectable for the type of video signal currently being received.
2 Press or VIEW MODE a/b while the View Mode menu is displayed to select a desired item on the menu.
You can sequentially select a View Mode that has its own aspect ratio.
Connect the PC before making adjustments. (See page 42.)
Selectable screen size may vary with input signal type.
Example: Screen size images
Input signal Normal Zoom Stretch Dot by Dot
4:3 Keeps the original
aspect ratio in a full
screen display.
For viewing
widescreen
programs. The top
and bottom of the
image is cropped.
An image fully fi lls the
screen.
Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
Input signal Stretch Dot by Dot
16:9 An image fully fi lls the
screen.
Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
•
•
•
•
•
Using a PC
Displaying a PC image on the screen
44
Using a PC
1 Press MENU to display the MENU screen, and then
press c/d to select the Setup or Option menu.
For adjusting "Auto Sync." or "Fine Sync.", select the
Setup menu.
For setting "PC Audio Select", select the Option menu.
2 Press a/b to select a specifi c adjustment item,
and then press to set each item.ENTER
3 Press a/b (or c/d) to select or adjust the desired
setting, and then press .ENTER
Adjusting the PC Image
Auto Sync.
(for Analog PC Input Mode Only)
For automatically adjusting the PC image.
Yes: Auto Sync. starts and "Now adjusting the image."
displays.
No: This function does not work.
When Auto Sync. is successful, "Completed" displays. If
not, Auto Sync. failed.
Auto Sync. may fail even if "Completed" displays.
Auto Sync. may fail if the computer image has low
resolution, has unclear (black) edges, or is moved while
executing Auto Sync.
Be sure to connect the PC to the TV and switch it on before
starting Auto Sync.
Fine Sync.
Ordinarily you can easily adjust the picture as
necessary to change image position using Auto Sync.
In some cases, however, manual adjustment is needed
to optimize the image.
H-Pos.: Centers the image by moving it to the left or
right.
V-Pos.: Centers the image by moving it up or down.
Clock: Adjust when the image fl ickers with vertical
stripes.
Phase: Adjust when characters have low contrast or
when the image fl ickers.
For resetting all Fine Sync. adjustment items to the factory
preset values, press a/b to select "Reset", and then press
ENTER.
It is not necessary to adjust the "Clock" or "Phase" when a
digital signal is being input, so it cannot be selected.
The default cursor position may not be in the center,
because the screen position variable ranges may be
asymmetrical.
The screen position variable ranges depend on the View
Mode or the signal type. The ranges can be seen on the
position-setting screen.
•
•
•
•
•
•
•
•
•
•
Setting Audio Input
PC Audio Select
Determines whether the AUDIO terminal is used for
INPUT 4 (PC-IN) or INPUT 6 (HDMI).
Input 4 (PC): Select this item when the audio signal is
input via the INPUT 4 (PC-IN) terminal using an analog
RGB cable.
Input 6 (HDMI): Select this item when the audio signal is
input via the INPUT 6 (HDMI) terminal using an HDMI-
DVI conversion cable.
When "PC Audio Select" is set to "Input 6 (HDMI)", sound
will not be produced if you use only an HDMI-certifi ed
cable to connect HDMI-compatible equipment. To produce
sound, you should make an analog audio connection.
If you want to connect HDMI-compatible equipment using
only an HDMI-certifi ed cable, set "PC Audio Select" to
"Input 4 (PC)".
•
•
PC Compatibility Chart
It is necessary to set the PC correctly to display XGA
and WXGA signal.
VGA and XGA are registered trademarks of International
Business Machines Corp.
31.5 kHz
31.5 kHz
37.9 kHz
37.5 kHz
35.1 kHz
37.9 kHz
48.1 kHz
46.9 kHz
48.4 kHz
56.5 kHz
60.0 kHz
47.7 kHz
640 x 480
720 x 400
VGA
800 x 600SVGA
XGA 1024 x 768
WXGA 1360 x 768
70 Hz
60 Hz
72 Hz
75 Hz
56 Hz
60 Hz
72 Hz
75 Hz
60 Hz
70 Hz
75 Hz
60 Hz
O
O
O
O
O
O
O
O
O
O
O
64.0 kHzSXGA 1280 x 1024 60 Hz O
65.3 kHzSXGA+ 1400 x 1050 60 Hz O
75.0 kHzUXGA 1600 x 1200 60 Hz O
Horizontal
Frequency
VESA
Standard
Resolution
Vertical
Frequency
45
■ PC control of the TV
• Attach an RS-232C cable cross-type (commercially
available) to the supplied Din/D-Sub RS-232C for the
connections.
This operation system should be used by a person who is
accustomed to using computers.
■ Communication conditions
Set the RS-232C communication settings on the PC to
match the TV's communication conditions.
The TV's communication settings are as follows:
•
■ Communication procedure
Send the control commands from the PC via the RS-
232C connector.
The TV operates according to the received command
and sends a response message to the PC.
Do not send multiple commands at the same time.
Wait until the PC receives the OK response before
sending the next command.
■ Parameter
Input the parameter values, aligning left, and fi ll with
blank(s) for the remainder. (Be sure that 4 values are
input for the parameter.)
When the input parameter is not within an adjustable
range, “ERR” returns. (Refer to “Response code format”.)
Any numerical value can replace the “x” on the table.
a3 0
0 0 0 9
0
? ? ? ?
?
When “?” is input for some
commands, the
present setting
value responds.
■ Command format
Eight ASCII codes e CR
Command 4-digits Parameter 4-digits Return code
C1 C2 C3 C4 P1 P2 P3 P4
Command 4-digits: Command. The text of four characters.
Parameter 4-digits: Parameter 0–9, x, blank, ?
Baud rate: 9,600 bps
Data length: 8 bits
Parity bit: None
Stop bit: 1 bit
Flow control: None
■ Command table
• Commands not indicated here are not guaranteed to operate.
■ Response code format
Normal response
Return code (0DH) Return code (0DH)
Problem response (communication
error or incorrect command)
O K
E R R
If an underbar (_) appears in the parameter column, enter a space.
If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.
Any numerical value can replace the “x” on the table.
•
•
•
CONTROL ITEM COMMAND
PARAMETER
CONTROL CONTENTS
POWER ON COMMAND SETTING
POWER SETTING
The Power On command rejected.
It input-switches by the toggle. (It is the same as an input change key)
It input-switches to TV. (A channel remains as it is. (Last memory))
It input-switches to INPUT1~INPUT8.
An input change is also included.
Although it can choose now, it is toggle operation in inside.
The screen position variable ranges depend on the View Mode or the
signal type. The ranges can be seen on the position-setting screen.
0: Although it can choose now, it is toggle operation in inside.
1: Only available when 4:3 signal is being input.
5, 6: Only available when 4:3 signal is being input.
8: [PC] Available except when UXGA is being input.
[AV] Only available when 1080i/p is being input.
9: Only available when 720p is being input.
(Toggle)
Input terminal number (1–8)
0: Auto, 1: VIDEO, 2: COMPONENT
0: (Toggle), 1: STANDARD, 2: MOVIE, 3: GAME, 4: USER,
5: DYNAMIC (Fixed), 6: DYNAMIC, 7: PC, 100: INTELLIGENT
Volume (0–60)
Only PC mode. (0–180)
Only PC mode. (0–40)
0: (Toggle) [AV], 1: Side Bar [AV], 2: S.Stretch [AV]
3: Zoom [AV], 4: Stretch [AV], 5: Normal [PC]
6: Zoom [PC], 7: Stretch [PC],
8: Dot by Dot [PC] [AV], 9: Full Screen [AV]
An input change is included if it is not TV display.
In Air, 2–69ch is effective.
In Cable, 1–135ch is effective.
If it is not TV display, it will input-switch to TV. (same function as CH )U
If it is not TV display, it will input-switch to TV. (same function as CH )V
Toggle operation of a closed caption.
0: (Toggle), 1: On, 2: Off
0: Off, 1: OFF TIMER – 30 MIN., 2: OFF TIMER – 60 MIN.,
3: OFF TIMER – 90 MIN., 4: OFF TIMER – 120 MIN.
The channel number of TV
The channel number of TV +1
The channel number of TV
–
1
(Toggle)
(1–135)
R S P W
I T G D
I T V D
I A V D
I N P 1
INPUT SELECTION A TOGGLE
INPUT SELECTION B
AV MODE SELECTION
VOLUME
POSITION
VIEW MODE
SURROUND
SLEEP TIMER
CHANNEL
CC
DIRECT
(ANALOG)
(DIGITAL)
CH UP
CH DOWN
CHANNEL
H-POSITIONH-POSITION
V-POSITION
CLOCK
PHASE
INPUT 1
A V M D
V O L M
H P O S
V P O S
C L C K
P H S E
A C S U
O F T M
D C C H
C H U P
C H D W
C L C P
W I D E
0
x
0
*
*
*
*
*
*
*
*
*
*
*
x
x
x
*
*
_
_
_
_
_
_
*
*
*
*
*
_
_
_
_
_
_
*
_
_
_
_
_
_
*
*
*
*
_
_
_
_
_
_
_
_
DIGITAL Air (Two-Part numbers, 2-digit plus 2-digit)(0100-9999)
(1-999)
(0-999)
(0-9999)
(0-6383)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit)
Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel)
Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel)
DIRECT
CHANNEL
D A 2 P * * * *
D C 2 U * * * _
D C 2 L * * * _
DIGITAL Cable (One-Part numbers, 5-digit, less than 10,000)
D C 1 0 * * * *
DIGITAL Cable (One-Part numbers, 5-digit, more than 10,000)D C 1 1 * * * *
_
_
_
_
(Toggle)
AUDIO SELECTION A C H A x _ _ _
_
0: (Toggle), 1: On, 2: Off
MUTE M U T E * _ _ _
_
_
_
_
_
_
_ Off
The Power On command accepted.1 _ _ _ On
Power On1 _ _ _ Power On
It shifts to standby.P O W R 0 _ _ _ Power Off
_
_
_
_
0: Auto, 2: COMPONENT, 3: S-TERMINALI N P 2INPUT 2 * _ _ _
_
TV
INPUT1-8
RS-232C Port Specifi cations
Using a PC
46
Up to four devices can be connected to the HN-VA400U
adapter.
Internet
Model number Number of ports
HN-VA401SU 4 +1
HN-VA400U 4
HN-VA100U 1
Using the Internet
By connecting your TV to a broadband system, you can access the Internet from the TV.
Display the “Sidebar Widget” on the screen to check out the latest Internet information and access a range of
useful information for AQUOS users from the original home page*.
About the original home page
The original home page is a website set up specifi cally for AQUOS owners.
The website is worth visiting as it provides a range of useful information, including tips on using your AQUOS
and a frequently asked questions section.
Internet Setup
+Connecting to the Internet
To connect your TV to the Internet, you must have a broadband Internet connection.
Use an ETHERNET cable (commercially available) to connect the ETHERNET terminal on the TV to your
broadband router (commercially available).
If you do not have a broadband Internet connection, consult the store where you purchased your TV or ask your
Internet service provider or telephone company.
+Checking your Internet connection
Press twice or three times to switch to the TV+Web or Web screen. When NET
the original home page appears, now you are connected to the Internet.
If you have failed to connect to the Internet in the above operation, then an
error message will appear. In this case, press to return to the normal TV EXIT
screen and check the relevant settings (see page 47).
If you still cannot connect to the Internet, please consult your Internet service
provider or telephone company.
+Information on the PLC adapter
The SHARP PLC adapter kit (sold separately) lets you use the existing electrical wiring in your house to create a
•
•
*
•
•
•
•
•
•
•
•
home network.*1
Simply plug the adapters into electrical outlets at the
desired locations, and then connect your computer
and other devices to the adapters with LAN cables (two
LAN cables are provided).
If you have Broadband Internet service, connect your
router to one of the adapters to allow all your network
devices to access the Internet.
Data can be exchanged at speeds of up to 85 Mbps*2
on your network.
*1: PLC does not have router function. To connect
to the Internet via network, Broadband Internet
connection and related devices such as router etc
is required.
*2: The actual communication speed may be affected
by power line conditions, other electrical appliances
and network conditions.
Internet
ETHERNET cable
(commercially available)
47
Using the Internet
+If you cannot connect to the Internet
Perform the procedures below to check your TV's
network settings.
Ethernet Setup
1 Press to display the normal TV screen.EXIT
2 Press to display the MENU screen, and then MENU
press c/d to select “Digital Setup”.
3 Press a/b to select “Communication Setup”, and
then press .ENTER
4 Press a/b to select “Ethernet Setup”, and then
press .ENTER
Check that numbers are displayed for each setting.
If there are any settings without numbers, specify the
numbers by following the on-screen instructions.
For information on how to enter text, see page 48.
5 Press to exit.MENU
Setting the Zip Code
1 Repeat steps 1 to 3 in .Ethernet Setup
2 Press a/b to select “Zip Code”, and then press
ENTER. After “Change” is highlighted, press
ENTER again.
3 Press c/d to select “US/Mexico” or “Canada”,
and then press .ENTER
4 Enter your zip code.
The U.S. and Mexico use 5-digit zip codes. Canada
uses 6-digit codes.
For the U.S and Mexico, use - on the remote control 0 9
unit to enter your zip code. For Canada, use the
software keyboard.
5 After “Complete” is highlighted, press .ENTER
6 Press to exit.MENU
Interactive Service
If you do not want other people to connect to the
Internet in your absence, you can make settings to
keep the TV away from the Internet.
1 Press to display the MENU screen, and then MENU
press c/d to select “Digital Setup”.
2 Press a/b to select “Interactive Service”, and then
press .ENTER
Input the 4-digit secret number by using – .0 9
3 Press c/d to select “No”, and then press .ENTER
If you want to allow Internet connection, select “Yes”,
and then press ENTER.
4 Press to exit.MENU
•
•
•
•
•
•
•
Displaying the Sidebar Widget
Perform the steps below to display the Sidebar Widget
on the screen and view the latest Internet information.
1 Press repeatedly to display the Sidebar NET
Widget.
Each time you press , the screen image toggles as NET
shown below:
Sidebar Widget TV+Web Web T
V
When you are not connected to the Internet, a network
function explanation screen is displayed.
The services displayed vary depending on
circumstances.
2 Press a/b to select a title, and then press
ENTER.
The web page for the selected title is displayed.
The service details vary depending on circumstances.
3 Press to return to the normal TV screen.EXIT
If you start up the Sidebar Widget while a Closed Caption
is displayed, the Closed Caption is automatically hidden.
Web page appearances may differ depending on the type
of screen (TV+Web or Web).
When a still image is displayed, the Sidebar Widget does
not appear even if you press .NET
•
•
•
•
•
•
•
EN T ER E X I T
:Deta il :Exit
48
Entering Text (Software Keyboard)
When you are editing an input screen or specifying the
Ethernet settings used for accessing the Internet, enter
text from the software keyboard.
You can enter up to 128 characters for text.•
Buttons Description
aMoves the focus up. When the focus is at the top edge, this moves the focus to
the opposite edge (bottom edge).
bMoves the focus down. When the focus is at the bottom edge, this moves the
focus to the opposite edge (top edge).
c
Moves the focus left. When the focus is at the left edge, this moves the focus to
the opposite edge (right edge).
When the focus is on “Character Set”, this selects the character type (moving
backwards).
When the focus is in an input box, this moves the cursor in the input box to the left.
d
Moves the focus right. When the focus is at the right edge, this moves the focus to
the opposite edge (left edge).
When the focus is on “Character Set”, this selects the character type (moving
forwards).
When the focus is in an input box, this moves the cursor in the input box to the
right.
ENTER Performs the processing for the button currently in the focus.
EXIT
Closes the software keyboard without applying the original input elements for the
entered text.
Erases the text in the input box where the cursor is currently located.
RETURN When the cursor is at the end of a sentence, this acts as a backspace.
0-9 Directly enters the single-byte number for that button.
A (red) Directly enters prediction candidate 1.
B (green) Directly enters prediction candidate 2.
C (blue) Directly enters prediction candidate 3.
D (yellow) Enters a space.
Caps Off Caps On Caps Lock/ /
If “alphabet” is selected in “Character Set”, this switches
characters between uppercase and lowercase.
Each time you press , the character type switches as ENTER
shown below:
Caps Off: all the characters are lowercased
Caps On: only the fi rst character is uppercased
Caps Lock: all the characters are uppercased
Done
Applies the entered information and closes the software
keyboard.
Quit
Closes the software keyboard without applying the entered
information.
You can also close the software keyboard by pressing
EXIT on the remote control unit.
Displays the icon “ ”, indicating that a new line has been
inserted.
Clear
Erases the character string.
When the cursor is somewhere in a line: the character
string to the right of the cursor will be erased.
When the cursor is at the right end of a line: the entire line
will be erased.
Delete
If the cursor is at the right end of a line, this erases text one
character at a time.
You can also delete text by pressing RETURN on the
remote control unit.
•
•
•
•
Using the Internet
The text you enter is displayed as you type it in.
To move the cursor (the current input position), use
“ ” or “ ” on the software keyboard.
Press c/d to select the type of characters entered:
alphabet, number or sign.
(The selectable types depend on the input source.)
While you are entering text, likely input conversion candidates
are displayed based on what you typed in.
You can also enter text by pressing , or on the remote A B C
control unit.
•
Enters a space.
49
Using the Browser
ENTER, a/b/c/d
• Press a/b/c/d to select a link that you want to jump,
and then press .ENTER
EXIT
• Press the button to return to the TV screen.
RETURN
• Press the button to return to the previous page.
Example : The image shown below, which is only for
explanation, is subject to change.
About links
Web pages on the Internet often include “links” that
allow you to jump to other web pages (or sites).
“Links” can take various forms, including words
or images, but they always work in the same way
letting you jump to the link destination when you
select them.
Selected items (such as links of text input fi elds) are
enclosed in a yellow frame.
You can jump from a “link” to the corresponding link
destination.
CAUTION
If the power is cut due to a power failure or the TV being
unplugged while you are using the Internet, information
such as bookmarks or cookies may not be saved correctly.
When a security notifi cation window is displayed:
Press
ENTER to close the window.
This window appears when you visit a web page that has
security protection, or when you move from a protected
page to an unprotected page.
In “Security Settings” you can set whether or not this
window is displayed. (See page 52.)
When a cookie confi rmation window appears:
Choose whether or not to accept the cookie (see page 52),
and then press ENTER.
In “Cookies” settings you can set whether or not this
window is displayed. You can also opt to delete all the
cookies at once. (See page 52.)
To users who access the Internet from a PC
When you access the Internet from this TV, the
procedures may not be the same as regular
browser-based access on a PC.
You cannot download fi les.
You cannot view a history of the pages you have
visited.
You cannot change the startup page displayed
when you press .NET
Pop-up windows appear in separate tabs.
On some pages, video and audio cannot be
played, and text or images may not be displayed
correctly.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
When “z” is displayed in a page:
The page failed to load successfully, or it contains images
with formats that cannot be displayed on the TV. Try
reloading the page by selecting “ ” (see page 50) in the
toolbar.
•
Using the Internet
Photo Player
P
P
P
Ph
h
h
ho
o
o
ot
t
t
to
o
o
o
P
P
P
Pl
l
l
la
a
a
ay
y
y
ye
e
e
er
r
r
r
:To ol
:
:
:
:T
T
T
To
o
o
oo
o
o
ol
l
l
l
:Scr o ll
:
:
:
:S
S
S
Sc
c
c
cr
r
r
ro
o
o
ol
l
l
ll
l
l
l
AQUOS
A
A
A
AQU
QU
QU
QUO
O
O
OS
S
S
S
C
C
C
CCo
o
o
oo n
n
n
nn s
s
s
sso
o
o
oo l
l
l
lle
e
e
ee
Click this but t on to go to
AQUOS Network.
Page 1
o f 3
Ad d Wid gets
Ad
Ad
Ad
Add
d
d
d
Wi
Wi
Wi
Wid
d
d
dge
ge
ge
get
t
t
ts
s
s
s
Legal
Le
Le
Le
Leg
g
g
ga
a
a
al
l
l
l
AQUOS
AQU
AQU
AQU
AQUOS
OS
OS
OS Ce
Ce
Ce
Ce Cen
n
n
nnt
t
t
tte
e
e
ee r
r
r
rr
AQUOS
A
A
A
AQ
Q
Q
QU
U
U
UO
O
O
OS
S
S
S
Network
N
N
N
Ne
e
e
et
t
t
tw
w
w
wor
or
or
ork
k
k
k
What’s New
Wha
Wha
Wha
What’s
t’s
t’s
t’s Ne
Ne
Ne
New
w
w
w
F
F
F
FF
ea
e
e
e
ea
a
a
at
t
t
tt
ured C
u
u
u
ur
r
r
re
e
e
ed
d
d
d
C
C
C
Co
o
o
oon
n
n
nnt
t
t
tte
e
e
een
n
n
nnt
t
t
tt
Sports
S
S
S
Sp
p
p
po
o
o
ort
rt
rt
rts
s
s
s
Entertainment
E
E
E
En
n
n
nt
t
t
te
e
e
er
r
r
rt
t
t
ta
a
a
ai
i
i
in
n
n
nm
m
m
me
e
e
en
n
n
nt
t
t
t
AQUOS
AQUOS
AQUOS
AQUOSAQUOS
G
G
G
GG
allery
all
all
all
allery
ery
ery
ery
CONSOLE
Monday
M
M
M
Mon
on
on
ond
d
d
day
ay
ay
ay
Today
T
T
T
Tod
od
od
oda
a
a
ay
y
y
y
Wednesday
W
W
W
Wed
ed
ed
edn
n
n
nes
es
es
esd
d
d
da
a
a
ay
y
y
y
Tuesday
T
T
T
Tue
ue
ue
ues
s
s
sda
da
da
day
y
y
y
AQUARIUS
A
A
A
AQU
QU
QU
QUA
A
A
ARI
RI
RI
RIU
U
U
US
S
S
S
GE MI NI
G
G
G
GEM
EM
EM
EMI
I
I
INI
NI
NI
NI
PISCES
P
P
P
PIS
IS
IS
IS C
C
C
CES
ES
ES
ES
ARI E S
A
A
A
ARI
RI
RI
RIE
E
E
ES
S
S
S
D
D
D
D
Pages with security protection are
clearly shown as such.
If content on a page is continued on another page,
directions to that page are shown clearly.
You can use a/b/c/d to go to the continuation of a
page.
Where there is link text or a link image in the
direction pressed, the text or image is selected fi rst.
If this happens, press the same direction button
several times.
•
Tab
50
Using the Toolbar
You can use the toolbar to control the browser and to
specify settings.
1 Press on the remote control unit to display the D
toolbar.
2 Press c/d to select a function, and then press
ENTER.
Selected item Description
Displays the linked page in a new tab.
Displays the Tab menu.
Returns to the previous page.
Goes back to the original page when you
have viewed the previous page.
Refreshes the page.
Interrupts a page while it is loading.
Displays the original home page.
Select this to open a bookmark.
Adds the current page to your bookmarks.
Displays the Browser menu.
Using Tabs
You can use tabs to view up to 3 web pages at the
same time. Each page appears in a separate tab, and
you can switch between the tabs.
1 Press on the remote control unit to display the B
Tab menu.
You can also display the Tab menu by clicking “ ” in
the toolbar.
Selected item Description
Select This Displays the web page in the
selected tab.
Close This Tab Closes the selected tab.
You can also press on the C
remote control unit to close a
tab.
•
Close Other Tabs Closes the other (unselected) tabs.
Create New Tab Creates a new tab.
You can also press on the A
remote control unit to create a
tab.
•
2 Press c/d to select a tab.
3 Press a/b to select the item you want to use, and
then press .ENTER
•
Using the Internet
51
Saving the URL of the Current Page
Adding a web page to your bookmarks allows you to
return to that page later by simply selecting it from your
list of bookmarks.
1 Display the page that you want to bookmark.
2 Press on the remote control unit to display the D
toolbar.
3 Press c/d to select “ ” in the toolbar, and then
press .ENTER
4 Select “Yes”, and then press .ENTER
The page is added to your bookmarks.
Opening a Bookmarked Page
1 Press on the remote control unit to display the D
toolbar.
2 Press c/d to select “ ” in the toolbar, and then
press .ENTER
Your bookmarks list is displayed.
3 Press a/b/c/d to select the page you want to
access, and then press .ENTER
The selected page is displayed.
If you have bookmarked 11 or more web pages, press
c/d to scroll through your bookmarks list.
When opening a bookmark in a new tab:
1
Press instead of . A ENTER
The Bookmarks menu appears.
2
Select “Open in New Tab”, and then press
ENTER.
•
•
•
•
•
Editing Bookmarks
You can rearrange or delete the bookmarks.
Switching between the URL and title name
1 Press on the remote control unit to display the D
toolbar.
2 Press c/d to select “ ” in the toolbar, and then
press . ENTER
Your bookmarks list is displayed.
3 Press a/b to select the title you want to edit from
the bookmarks list, and then press on the remote A
control unit.
The Bookmarks menu appears.
4 Select “Display by Address” or “Display by Title” in
the Bookmarks menu, and then press .ENTER
Rearranging displayed items
1 Press on the remote control unit to display the D
toolbar.
2 Press c/d to select “ ” in the toolbar, and then
press .ENTER
Your bookmarks list is displayed.
3 Press a/b to select the title you want to display
in a different position from the bookmarks list, and
then press on the remote control unit.A
The Bookmarks menu appears.
4 Press a/b to select “Move Up” or “Move Down”,
and then press .ENTER
Deleting bookmarks
1 Press on the remote control unit to display the D
toolbar.
2 Press c/d to select “ ” in the toolbar, and then
press .ENTER
Your bookmarks list is displayed.
3 Press a/b to select the title you want to delete,
and then press on the remote control unit.A
The Bookmarks menu appears.
4 Press a/b to select “Delete”, and then press
ENTER.
To delete all the bookmarks, select “Delete All”.
5 Press c/d to select “Yes”, and then press
ENTER.
■
•
•
■
•
•
■
•
•
•
Using the Internet
52
Browser Settings
You can check or modify your browser settings from
the Browser menu.
The Browser menu includes a display settings menu
and a security settings menu.
1 Press to display the toolbar.D
2 Press c/d to select “ ” in the toolbar, and then
press .ENTER
3 Press c/d to select the settings menu you want to
access.
4 Press a/b to select and confi rm the item you want
to set.
5 Press a/b/c/d to specify the required setting,
and then press .ENTER
6 Press to exit.D
View Settings
Zoom In/Out:
Zoom in: Displays content enlarged to 200%.
Normal: Displays content at 100%.
Zoom out: Displays content reduced to 75%.
Encoding: Selects the desired encoding from the list below:
Western (ISO-8859-1)/Unicode (UTF-8)
Page Information: Displays information about the currently
displayed page.
Reset:
Yes: Resets the browser settings.
No: Does not reset the browser settings.
“Reset” does not reset the certifi cation enable/disable and
Encoding settings.
•
Security Settings
Security:
Save Setting: If you select this option, a message is
displayed when you move from a protected page to an
unprotected page.
To change this setting, remove the tick, select “Save
Setting” and then press .ENTER
Root Certifi cates/CA Certifi cates: Displays the list of
certifi cates. To disable a certifi cate, select the certifi cate
to be disabled and press to display the sub-menu. A
Select “Disable”, and then press .ENTER
Disabled certifi cates are shown unticked in the
certifi cate list screen.
Cookies:
Accept all: Select this option to accept all cookies.
Reject all: Select this option when you do not want to
accept cookies.
Prompt before accepting: When you open a page
that uses cookies, this option displays a confi rmation
message.
Delete All Cookies: Deletes all your cookies.
Server Certifi cates: Displays certifi cates for the connected
server.
Browser Information: Displays browser information.
• This product contains NetFront Browser of
ACCESS CO., LTD.
• ACCESS, the ACCESS logo and NetFront
are registered trademarks or trademarks of
ACCESS CO., LTD. in the United States,
Japan and/or other countries.
© 2009 ACCESS CO., LTD. All rights
reserved.
• This software is based in part on the work of
the Independent JPEG Group.
•
Using the Internet
53
Appendix
Removing the Stand
•
Before detaching (or attaching) the stand, unplug the AC cord from the AC INPUT terminal.
CAUTION
• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
Before attaching/detaching the stand
• Before performing work, make sure to turn off the TV.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
• To attach the stand, perform the above steps in reverse order.
Unfasten the four screws used to secure the stand in
place.
Detach the stand from the TV. (Hold the stand so it
will not drop from the edge of the base area.)
1 2
• Detach the cable clamp on the rear of the TV when using the optional mount bracket.
• Due to the terminal confi guration on this TV, when you wall-mount this model, make sure there is enough space between the
wall and the TV for the cables.
• To use this TV mounted on a wall, remove the covers at the 4 locations on the rear of the TV, and then use the screws
supplied with the wall mount bracket to secure the bracket to the rear of the TV.
Setting the TV on the Wall
CAUTION
LC-40LE700UN
• This TV should be mounted on the wall with both the AN-37AG2 (SHARP) wall mount bracket and the AN-37P30
(SHARP) attachment of the wall mount bracket. The TV cannot be mounted when with only the AN-37AG2 wall
mount bracket. The use of other wall mount brackets may result in an unstable installation and may cause
serious injuries.
LC-46LE700UN/LC-52LE700UN
• This TV should be mounted on the wall only with the wall mount bracket AN-52AG4 (SHARP). The use of other
wall mount brackets may result in an unstable installation and may cause serious injuries.
• Installing the TV requires special skill that should only be performed by qualifi ed service personnel. Customers
should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or
mounting that results in accident or injury.
Using an optional bracket to mount the TV
•
You can ask a qualifi ed service professional about using an optional AN-37AG2 or AN-52AG4 bracket to mount the
TV on the wall.
• Carefully read the instructions that come with the bracket before beginning work.
Hanging on the wall
AN-37AG2 or AN-52AG4
wall mount bracket.
(See the bracket instructions for details.)
About setting the TV angle
Vertical mounting Angular mounting
0/5/10/15/20°
AN-37AG2 + AN-37P30
LC-40LE700UN
•
The center of the display:
1
9
/
64
inches (29.05 mm) under the “B” position.
AN-52AG4
LC-46LE700UN
• The center of the display:
1/16 inch (1.2 mm) under the “b” position.
LC-52LE700UN
• The center of the display:
5
/
64
inch (1.75 mm) under the “b” position.
•
Refer to the operation manual of
AN-37AG2/AN-37P30 or AN-52AG4 for details.
54
Appendix
Troubleshooting
Problem Possible Solution
No power• Check if you pressed on the remote control unit. TV POWER Page 14
If the indicator on the TV does not light up, press on the TV.POWER
Is the AC cord disconnected? Page 7
Has the power been turned on? Page 14
•
•
•
Unit cannot be operated.• External infl uences such as lightning, static electricity, may cause improper
operation. In this case, operate the unit after fi rst turning off the power of the TV or
unplugging the AC cord and replugging it in after 1 or 2 minutes.
•
Remote control unit does not
operate.
• Is the set correctly? Set it to the TV setting position.FUNCTION
Are batteries inserted with polarity (
e, f) aligned? Page 8
Are batteries worn out? (Replace with new batteries.)
Are you using it under strong or fl uorescent lighting?
Is a fl uorescent light illuminated near the remote control sensor?
•
•
•
•
•
Picture is cut off/with sidebar
screen.
• Is the image position correct? Page 25
Are screen mode adjustments such as picture size made correctly? Pages 18 and 43
•
•
Strange color, light color, or color
misalignment
• Adjust the picture tone. Pages 21 and 22
Is the room too bright? The picture may look dark in a room that is too bright.
•
•
Power is suddenly turned off.• Is the sleep timer set? Page 15
Check the power control settings. Page 23
The unit's internal temperature has increased. Remove any objects blocking vent or
clean.
•
•
•
No picture• Is connection to other components correct? Pages 12, 13, 38 and 42
Is correct input signal source selected after connection? Page 28
Is the correct input selected? Page 28
Is picture adjustment correct? Pages 21 and 22
Is “On” selected in “Audio Only”? Page 28
Is a non-compatible signal being input? Page 44
•
•
•
•
•
•
No sound• Is the volume too low? Page 15
Is “Variable” selected in “Output Select”? Page 28
Have you pressed on the remote control unit? MUTE Page 15
•
•
•
The TV sometimes makes a
cracking sound.
• This is not a malfunction. This happens when the cabinet slightly expands and
contracts according to change in temperature. This does not affect the TV's
performance.
•
• The original home page cannot
be displayed.
• Is the ETHERNET cable connected correctly? Page 46
• Check the settings of "Communication Setup" and "Interactive Service". Page 47
• Some Internet functions used on
a PC are not available from the
TV.
• The TV has only limited functions compared with regular PC browsers. Page 48
Troubleshooting-Digital Broadcasting
The error message about reception of broadcast
The example of an error message
displayed on a screen Error code Possible Solution
Failed to receive broadcast.• Check the antenna cable. Check that the antenna is correctly E202
setup.
•
No broadcast now.• Check the broadcast time in the program guide.•E203
Item Model: LC-40LE700UN Model: LC-46LE700UN Model: LC-52LE77UN
LCD panel
40o Class (40o Diagonal)
Advanced Super View &
BLACK TFT LCD
46o Class (45
63
/
64
o Diagonal)
Advanced Super View &
BLACK TFT LCD
52o Class (52
1
/
32
o Diagonal)
Advanced Super View &
BLACK TFT LCD
Resolution 2,073,600 pixels (1,920 g 1,080)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Backlight 100,000 hours (at Backlight Standard position)
Audio out 10W g 2
Terminals
Rear
INPUT 1 AV in, COMPONENT in
INPUT 2 COMPONENT in, S-VIDEO in
INPUT 4 ANALOG RGB (PC) in (15-pin mini D-sub female connector), Audio in (Ø 3.5 mm jack)
INPUT 6 HDMI in with HDCP, Audio in (Ø 3.5 mm jack)
INPUT 7 HDMI in with HDCP
INPUT 8 HDMI in with HDCP
ANT/CABLE 75 q Unbalance, F Type g 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO Audio in (Ø 3.5 mm jack)
DIGITAL AUDIO OUTPUT
Optical Digital audio output g 1 (PCM/Dolby Digital)
ETHERNET Network connector
OUTPUT Audio out
RS-232C 9-pin D-sub male connector
Side
INPUT 3 AV in
INPUT 5 HDMI in with HDCP
USB Photo/Music mode, Software update
OSD language English/French/Spanish
Power Requirement AC 120 V, 60 Hz
Power Consumption 160 W
(0.5 W Standby with AC 120 V)
200 W
(0.5 W Standby with AC 120 V)
250 W
(0.5 W Standby with AC 120 V)
Weight TV + stand 30.9 lbs./14.0 kg 47.4 lbs./21.5 kg 57.3 lbs./26.0 kg
TV only 26.5 lbs./12.0 kg 40.8 lbs./18.5 kg 50.7 lbs./23.0 kg
Dimension*2
(W g H g D)
(inches)
TV + stand
37 61/64 g 26 3/16 g 12 3/8
43
9/32
g 29
11/64
g 13
61/64
48
3/4
g 32
13/64
g 13
61/64
TV only
37 61/64 g24 3/32 g 3 41/64
43
9/32
g 27
3/32
g 3
45/64
48
3/4
g 30
1/8
g 3
43/64
Operating temperature e32°F to e104°F (0°C to e40°C)
*1 Emergency alert messages via Cable are unreceivable.
*2 The dimensional drawings are shown on the inside back cover.
• As part of policy of continuous improvement, SHARP reserves the right to make design and specifi cation changes for
product improvement without prior notice. The performance specifi cation fi gures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
Optional Accessory
The listed optional accessory is available for the Liquid
Crystal Television. Please purchase it at your nearest shop.
• Additional optional accessories may be available in the near
future. When purchasing, please read the newest catalogue for
compatibility and check the availability.
Part name Model number
Wall mount
bracket AN-37AG2 (for LC-40LE700UN)
Attachment AN-37P30 (for LC-40LE700UN)
Wall mount
bracket
AN-52AG4
(for LC-46LE700UN/LC-52LE700UN)
55
Specifi cations
Appendix
56
• As a precautionary measure, make a note of your secret number above, cut it from this manual, and keep it in a safe place.
The secret number is .
Information on the Software License for This Product
Software composition
The software included in this product is comprised of various software components whose individual copyrights
are held by SHARP or by third parties.
Software developed by SHARP and open source software
The copyrights for the software components and various relevant documents included with this product that
were developed or written by SHARP are owned by SHARP and are protected by the Copyright Act, international
treaties, and other relevant laws. This product also makes use of freely distributed software and software
components whose copyrights are held by third parties. These include software components covered by a GNU
General Public License (hereafter GPL), a GNU Lesser General Public License (hereafter LGPL) or other license
agreement.
Obtaining source code
Some of the open source software licensors require the distributor to provide the source code with the executable
software components. GPL and LGPL include similar requirements. For information on obtaining the source code
for the open source software and for obtaining the GPL, LGPL, and other license agreement information, visit the
following website:
http://www.sharpusa.com/gpl
We are unable to answer any questions about the source code for the open source software. The source code for
the software components whose copyrights are held by SHARP is not distributed.
Acknowledgements
The following open source software components are included in this product:
• linux kernel/busybox/uClibc/zlib/libpng/libjpeg/libiconv/DirectFB/OpenSSL/XMLRPC-EPI
Software Copyrights
XMLRPC-EPI
Copyright 2000 © Epinions, Inc.
libjpeg
This software is copyright © 1991-1998, Thomas G. Lane.
Portions of this software are based in part on the work of the Independent JPEG Group.
OpenSSL
Copyright © 1998-2001 The OpenSSL Project.
This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit. (http://www.openssl.org)
SSLeay
Copyright © 1995-1998 Eric Young (eay@cryptsoft.com)
This product includes cryptographic software written by Eric Young (eay@cryptsoft.com).
Cautions regarding use in high and low temperature environments
When the unit is used in a low temperature space (e.g. room, offi ce), the picture may leave trails or appear slightly delayed.
This is not a malfunction, and the unit will recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a
heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: f4°F to e140°F (f20°C to e60°C)
•
•
CLEARING THE SECRET NUMBER
If you forget the secret number, clear the secret number using the following procedure.
1 Select an item from the list below to display the secret number input screen. (For operating the on-screen
display menu, see page 19.)
• “EZ Setup”, “CH Setup”, “Parental CTRL” or “Reset” on the Setup menu.
• “Color System” on the Option menu.
• “Software Update” on the Digital Setup menu.
2 Press and hold both CHU and VOLk on the TV simultaneously until the message appears on the screen.
■
■
■
■
■
Appendix
Termékspecifikációk
| Márka: | Sharp |
| Kategória: | televízió |
| Modell: | LC-40LE700UN |
Szüksége van segítségre?
Ha segítségre van szüksége Sharp LC-40LE700UN, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók televízió Sharp
9 Április 2025
6 Április 2025
28 Március 2025
27 Március 2025
18 Március 2025
18 Március 2025
13 Január 2025
13 Január 2025
13 Január 2025
13 Január 2025
Útmutatók televízió
- televízió Samsung
- televízió Sony
- televízió Yamaha
- televízió Beko
- televízió Fujitsu
- televízió Acer
- televízió Nedis
- televízió LG
- televízió Grundig
- televízió Marantz
- televízió Philips
- televízió Pioneer
- televízió SilverCrest
- televízió Panasonic
- televízió JVC
- televízió AEG
- televízió Nokia
- televízió Lenovo
- televízió Casio
- televízió Toshiba
- televízió Oppo
- televízió Hyundai
- televízió Hisense
- televízió BenQ
- televízió SunBriteTV
- televízió Siemens
- televízió Medion
- televízió TCL
- televízió Xiaomi
- televízió GoGen
- televízió Insignia
- televízió Infiniton
- televízió Dell
- televízió Strong
- televízió VOX
- televízió Vivax
- televízió Thomson
- televízió Polaroid
- televízió Aiwa
- televízió Orima
- televízió V7
- televízió Clatronic
- televízió PEAQ
- televízió Qilive
- televízió Haier
- televízió Mitsubishi
- televízió Cecotec
- televízió Sencor
- televízió GPX
- televízió Küppersbusch
- televízió Innoliving
- televízió AOC
- televízió Citizen
- televízió Westinghouse
- televízió Hitachi
- televízió Continental Edison
- televízió Telefunken
- televízió Nevir
- televízió Monster
- televízió Roadstar
- televízió Optoma
- televízió CHiQ
- televízió Viewsonic
- televízió Nextbase
- televízió Denver
- televízió Bush
- televízió Trevi
- televízió Albrecht
- televízió Daewoo
- televízió Funai
- televízió Tesla
- televízió Smart Tech
- televízió Muse
- televízió Energy Sistem
- televízió OK
- televízió SVAN
- televízió Loewe
- televízió RevolutionHD
- televízió Polar
- televízió Manhattan
- televízió Kogan
- televízió Horizon
- televízió Intenso
- televízió Furrion
- televízió Teac
- televízió Aspes
- televízió Digihome
- televízió Manta
- televízió Blaupunkt
- televízió Sagem
- televízió Jay-Tech
- televízió Logik
- televízió Finlux
- televízió Peerless-AV
- televízió Abus
- televízió AG Neovo
- televízió Bang & Olufsen
- televízió Iiyama
- televízió AKAI
- televízió TechniSat
- televízió Seiki
- televízió Jensen
- televízió Pyle
- televízió Emerson
- televízió Sanyo
- televízió Kemo
- televízió Salora
- televízió Lenco
- televízió Schneider
- televízió Philco
- televízió ECG
- televízió Uniden
- televízió Technika
- televízió NEC
- televízió Element
- televízió Soundmaster
- televízió Alphatronics
- televízió AYA
- televízió MBM
- televízió Krüger&Matz
- televízió Dual
- televízió Brandt
- televízió Wharfedale
- televízió Allview
- televízió RCA
- televízió OKI
- televízió Orion
- televízió SereneLife
- televízió Schaub Lorenz
- televízió Luxor
- televízió Metz
- televízió ILive
- televízió Graetz
- televízió Tatung
- televízió Packard Bell
- televízió EasyMaxx
- televízió Orava
- televízió Arçelik
- televízió Planar
- televízió Zenith
- televízió Doffler
- televízió QBell Technology
- televízió SYLVOX
- televízió Majestic
- televízió Reflexion
- televízió FFalcon
- televízió Megasat
- televízió Sogo
- televízió United
- televízió Techwood
- televízió Newstar
- televízió Matsui
- televízió Alden
- televízió Aldi
- televízió Airis
- televízió Aristona
- televízió Apex
- televízió Icy Box
- televízió Lexibook
- televízió Palsonic
- televízió Walker
- televízió Saba
- televízió Antarion
- televízió Kernau
- televízió Tevion
- televízió Proscan
- televízió Vestel
- televízió Tucson
- televízió Sunstech
- televízió Nabo
- televízió Sylvania
- televízió Sunny
- televízió Marquant
- televízió Nordmende
- televízió AudioAffairs
- televízió Magnum
- televízió Audiosonic
- televízió Kubo
- televízió Proline
- televízió Coby
- televízió Seg
- televízió Vivo
- televízió Daitsu
- televízió Terris
- televízió Changhong
- televízió Alba
