Oldal 1/4
Installation & Operation
P1L 10" 12"
Single P1L-110 P1L-112
Dual P1L-210 P1L-212
P2L 10" 12"
Single P2L-110 P2L-112
Dual P2L-210 P2L-212
P1L & P2L - LOADED ENCLOSURES
SVC - SINGLE VOICE COIL UBWOOFERSS DVC - DUAL VOICE COIL UBWOOFERSS
INSTALLATION ENGLISH
CAUTION:
Run the speaker cable from the amp.
INSTALACIÓN ESPAÑOL
PRECAUCN:
Recorrido del Cable de Altavoz Desde el Amplificador.
INSTALLATION FRANÇAIS
MISE EN GARDE :
Branchement du câble du haut-parleur de l’amplificateur.
EINBAU DEUTSCH
VORSICHT:
Anschluß des Lautsprecherkabels.
INSTALLAZIONE ITALIANO
ATTENZIONE:
Far correre il cavo dell’altoparlante all’amplificatore.
Strip 5/8"
(16mm)
From
Amplifier
FEATURES
SPECIFICATIONS
Vented Enclosure Features
Proprietary High-Flow, Low-Noise Ports
High Current Binding Posts
Constructed with 5/8" MDF
Covered with High Density Carpet
Wired Exclusively with Connecting Punch
Specifications subject to change without notice
Speaker Features - P1L - SVC (Single Voice Coil)
High modulus closed conical polypropylene cone.
Tear & fatigue resistant poly-cotton spider.
High density compressed half-roll sealed poly-foam surround.
High temp voice coil with spun-laced Nomex insulating re-inforcment
collar.
Optimized motor magnetics with extended pole and bumped backplate.
Sturdy 16 guage compound bend frame geometry.
Proprietary spider venting/cooling technique.
Speaker Features - P2L - DVC (Dual Voice Coil)
Venturi-effect center pole dispersion venting/cooling system.
High modulus closed conical polypropylene cone.
Tear & fatigue resistant poly-cotton spider.
High density compressed half-roll sealed poly-foam surround.
High temp voice coil with spun-laced Nomex insulating re-inforcment
collar.
Optimized motor magnetics with extended pole and bumped backplate.
Double stack ferrite magnet structure.
Sturdy 16 guage compound bend frame geometry.
Proprietary spider venting/cooling technique.
Diamond cut cast aluminum motor cover for improved heat dissipation.
P1L-110 (Single 10" SVC)
P1L-210 (Dual 10" SVC)
P1L-112 (Single 12" SVC)
P1L-212 (Dual 12" SVC)
P2L-110 (Single 10" DVC)
P2L-210 (Dual 10" DVC)
P2L-112 (Single 12" DVC)
P2L-212 (Dual 12" DVC)
