22” VARIABLE SPEED
SCROLL SAW
#10-622VS
Operator’s Manual
Record the serial number and date of purchase in your manual for future reference.
The serial number can be found on the specification label on the rear of your machine.
Serial Number: Date of purchase: ________________________ _________________
For technical support or parts questions, email techsupport@rikontools.com
or call toll free at (877) 884-5167.
www.rikontools.com
10-622VSM1
TABLE OF CONTENTS
Specifications ........................................................................................ 2
Safety ............................................................................................... 3 - 7
Key Parts Overview ............................................................................... 8
Attachment Parts ................................................................................... 9
Assembly ......................................................................................... 9, 10
Adjustments .................................................................................. 10 - 13
Operation ...................................................................................... 11 - 13
Maintenance ........................................................................................ 14
Troubleshooting ................................................................................... 15
Parts Diagram ...................................................................................... 16
Parts List ........................................................................................ 17, 18
Notes ................................................................................................... 18
Warranty .............................................................................................. 19
SPECIFICATIONS
Motor Amps, Volts, Hertz .......................................... 1.6A, 120V, 60Hz
Electronic Variable Speed (SPM) ....................................... 550 - 1,550
Pinless Blade Length .......................................................... 5” / 130mm
Maximum Cutting Height ...................................................... 2“ / 50mm
Stroke ................................................................................ 3/4” / 20mm
Throat Depth .................................................................... 22” / 560mm
Table Size (LxW) ...............................25-5/8” x 13-3/4” / 650 x 350mm
Table Tilting ...................................................... 30° Left, 0°, 45° Right
Base to Table Height .................................................. 7-9/16“ / 192mm
Dust Port Diameter (O.D.) ............................................. 1-3/8” / 35mm
Maximum Sound Level (at 0.3m / 11.8“) .................................... <80dB
Overall Size (LxWxH)............ 34"x14-1/8"x16-9/16" / 865x360x420mm
Base Size (approx. LxW) .................. 18-5/8” x 13-1/4” / 475 x 335mm
Net Weight ................................................................................. 68 lbs.
NOTE: The specifications, photographs, drawings and information in this manual represent the
current model when the manual was prepared. Changes and improvements may be made at any time,
with no obligation on the part of Rikon Power Tools, Inc. to modify previously delivered units.
Reasonable care has been taken to ensure that the information in this manual is correct, to provide
you with the guidelines for the proper safety, assembly and operation of this machine.
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body
is earthed or grounded.
3. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
4. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
5. When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is unavoidable, use a ground fault
circuit interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of
electric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
2. Use personal protective equipment. Always wear eye protection. Protective
equipment such as a respiratory mask, non-skid safety shoes and hearing
protection used for appropriate conditions will reduce the risk of personal injury.
3. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energizing power tools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
WARNING
!
3
SAFETY INSTRUCTIONS
