2022

OWNER’S

MANUAL

RZR XP 1000 Tractor

For Maintenance and Safety

WARNING

Read this manual carefully. It contains important safety

information. This is an adult vehicle only.

Operation is prohibited for those under 16 years of age.

!WARNING

Read, understand, and follow all of the instructions and safety

precautions in this manual and on all product labels.

Failure to follow the safety precautions

could result in serious injury or death.

For videos and more information

about a safe riding experience with

your Polaris vehicle, scan this QR

Code® with your smartphone.

2022 Owner’s Manual

RZR XP 1000 Tractor

Unless noted, trademarks are the property of Polaris Industries Inc.

Recreational Off-Highway Vehicle Association® and ROHVA® are registered

trademarks of the Recreational Off-Highway Vehicle Association. Tread

Lightly® is a registered trademark of the United States Department of

Agriculture. BatteryMINDer® is a registered trademark of VDC Electronics

Inc. Loctite® is a registered trademark of Henkel Corporation. NYOGEL® is a

registered trademark of Nye Lubricants, Inc. WD-40® is registered to WD-40

Manufacturing Company. QR Code® is a registered trademark of DENSO

WAVE INCORPORATED. Sandisk® is a registered trademark of SANDISK

LLC. Google Play® is a registered trademark of Google, Inc. Apple® is a

registered trademark of Apple Inc. NGK® is a registered trademark of NGK

Spark Plug Co., Ltd. OSHA® is a registered trademark of the Occupational

Safety and Health Administration, U.S. Dept. of Labor. FOX® is a registered

trademark of Fox Factory Inc. Bluetooth® is a registered trademark of

Bluetooth Sig, Inc.

publication is based on the latest product information at the time of

publication. Due to constant improvements in the design and quality of

production components, some minor discrepancies may result between the

actual vehicle and the information presented in this publication. Depictions

and/or procedures in this publication are intended for reference use only. No

liability can be accepted for omissions or inaccuracies. Any reprinting or

reuse of the depictions and/or procedures contained within, whether whole or

in part, is expressly prohibited.

The original instructions for this vehicle are in English. Other languages are

provided as translations of the original instructions.

Printed in Czech Republic

9940196 R02

Thank you for purchasing a POLARIS vehicle, and welcome to our world-wide

family of POLARIS enthusiasts. Be sure to visit us online at www.polaris.com for

the latest news, new product introductions, upcoming events, career

opportunities and more.

Here at POLARIS we proudly produce an exciting line of utility and recreational

products. We believe POLARIS sets a standard of excellence for all utility and

recreational vehicles manufactured in the world today. Many years of experience

have gone into the engineering, design, and development of your POLARIS

vehicle, making it the finest machine we’ve ever produced.

For safe and enjoyable operation of your vehicle, be sure to follow the

instructions and recommendations in this owner’s manual. Your manual contains

instructions for minor maintenance, but information about major repairs is

outlined in the POLARIS Service Manual and can be performed by a factory

certified Master Service Dealer (MSD) technician.

Your POLARIS dealer knows your vehicle best and is interested in your total

satisfaction. Your POLARIS dealership can perform all of your service needs

during and after the warranty period.

For the most up-to-date owner’s manual visit https://www. polaris. com/en-us/

owners-manuals.

WELCOME

The following signal words and symbols appear throughout this manual and on

your vehicle. Your safety is involved when these words and symbols are used.

Become familiar with their meanings before reading the manual.

DANGER

DANGER indicates a hazardous situation which, if not avoided, WILL result in

death or serious injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, COULD result

in death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, COULD result

in minor to moderate injury.

NOTICE

NOTICE provides key information by clarifying instructions.

IMPORTANT

IMPORTANT provides key reminders during disassembly, assembly, and

inspection of components.

The Prohibition Safety Sign indicates an action NOT to take in

order to avoid a hazard.

The Mandatory Action Sign indicates an action that NEEDS to

be taken to avoid a hazard.

SAFETY SYMBOLS AND SIGNAL WORDS

Introduction . . . . . . . . . . . . . . . . . . . . 7

Safety . . . . . . . . . . . . . . . . . . . . . . 11

Features and Controls . . . . . . . . . . . . . . 31

Operation . . . . . . . . . . . . . . . . . . . . 63

Winch Guide. . . . . . . . . . . . . . . . . . . 83

Emission Control Systems . . . . . . . . . . . . . 93

Maintenance . . . . . . . . . . . . . . . . . . 95

Specifications . . . . . . . . . . . . . . . . . . 171

Polaris Products . . . . . . . . . . . . . . . . . 175

Troubleshooting . . . . . . . . . . . . . . . . . 177

Warranty . . . . . . . . . . . . . . . . . . . . 183

Maintenance Log . . . . . . . . . . . . . . . . 189

TABLE OF CONTENTS

INTRODUCTION

BEFORE YOU RIDE

WARNING

Failure to heed the warnings and safety precautions contained in this manual

can result in severe injury or death. Your POLARIS vehicle is not a toy and can

be hazardous to operate. This vehicle handles differently than cars, trucks or

other off-road vehicles. A collision or rollover can occur quickly, even during

routine maneuvers like turning, or driving on hills or over obstacles, if you fail to

take proper precautions.

• Read this owner’s manual and review the safety DVD that came with your

vehicle. A free extra copy of the DVD can be obtained by contacting your

local POLARIS dealer. Understand all safety warnings, precautions and

operating procedures before operating the vehicle. Keep this manual with

the vehicle.

• This vehicle is an ADULT VEHICLE ONLY. You MUST be at least age 16

and have a valid driver’s license to operate this vehicle.

• All riders must be able to sit with backs against the seat, both feet flat on the

floor and both hands on the steering wheel (if driving) or on a passenger

hand hold.

• Always use the cab nets (or doors) while riding in this vehicle. Always keep

hands, feet and all other body parts inside the vehicle at all times.

• Always wear a seat belt when riding in this vehicle. Always wear a helmet,

eye protection, gloves, long-sleeve shirt, long pants and over-the-ankle

boots.

• Never operate this vehicle under the influence of drugs or alcohol, as these

conditions impair judgement and the operator’s ability to react.

• Complete the steps described in the New Operator Driving Procedures

section. Never allow a guest to operate this vehicle until the guest has

completed the New Operator Driving Procedures.

INTRODUCTION

NEAR-FIELD COMMUNICATION (NFC)

(IF EQUIPPED)

Some Polaris vehicles come equipped with a near-field communication (NFC)

chip. The NFC chip is embedded in the Polaris emblem located at the front of

the vehicle and seamlessly connects you to a digital platform of vehicle

information and tools. See your dealer for more information.

IMPORTANT

Not all devices are equipped with an NFC reader. Additionally, some devices

require third party applications to access NFC content. For questions regarding

the NFC reader on your device, refer to the device’s user manual.

On models equipped with NFC, place your smartphone directly over the Polaris

emblem to do the following:

• View vehicle-specific

information

• Access your Polaris Garage

• Download and view the

owner’s manual

• View accessory instructions

• Watch how-to videos

• Access warranty information

• Check for service notifications

RIDE COMMAND WITH NFC

Additional NFC features are available when using the Ride Command mobile

app. To access these features, do the following:

1. Download the Ride Command mobile app from the Apple App Store® or

Google Play® store.

2. Create or log in to an existing account.

3. From the Ride Command mobile app home screen, select Add Vehicle.

4. On the vehicle, tap the NFC-enabled badge with the phone to scan the

vehicle.

5. Confirm information, name your vehicle, and tap add to garage.

SYSTEM REQUIREMENTS

Refer to device manufacturer’s instructions to verify NFC read capability, and/or

NFC-capable add-ons.

INTRODUCTION

VEHICLE IDENTIFICATION NUMBERS

Record your vehicle’s identification numberq, engine

serial number w, and key number ein the spaces

provided. Remove the spare key and store it in a safe

place. An ignition key can be duplicated only by

ordering a POLARIS key blank (using your key

number) and mating it with one of your existing keys.

The ignition switch must be replaced if all keys are

lost.

Vehicle Model Number:

Vehicle Identification Number:

Engine Serial Number:

Key Number:

INTRODUCTION

SAFETY

SAFETY TRAINING

Safety training is a top priority for POLARIS. POLARIS strongly encourages you

and any family members who will be riding this vehicle to take a training course.

For more information about safety, contact an authorized POLARIS dealer or

visit the POLARIS web site at www.polaris.com.

Your POLARIS vehicle is considered an on-road vehicle. Familiarize yourself

with all laws and regulations concerning the operation of this vehicle in your

area.

We strongly advise you to strictly follow the recommended maintenance

program outlined in your owner's manual. This preventive maintenance program

is designed to ensure that all critical components on your vehicle are thoroughly

inspected at specific intervals.

SAFETY

SAFE RIDING GEAR

Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants,

over-the-ankle boots and seat belt (if equipped) at all times. Protective gear

reduces the chance of injury.

RIDER COMFORT

Under certain operating conditions, heat generated by the engine and exhaust

system can elevate temperatures in the rider cab area. The condition occurs

most frequently when a vehicle is being operated in high ambient temperatures

at low speeds and/or high load conditions for an extended period of time. The

use of certain windshield, roof and/or cab systems may contribute to this

condition by restricting airflow.

Any discomfort due to heat buildup in

this area can be minimized by wearing

proper riding apparel and by varying

speeds to increase airflow.

qHelmet

wEye Protection

eLong Sleeves

rGloves

tLong Pants

yOver-the-Ankle Boots

SAFETY

HELMET

Wearing a helmet can prevent a severe head injury. Whenever riding this

POLARIS vehicle, always wear a helmet that meets or exceeds established

safety standards. Clasp the buckle and pull each strap tight to ensure the helmet

is properly secured to the head.

Parents and supervising adults should verify that young operators have a helmet

that fits, and should obtain one of proper size if it does not fit before allowing

operation.

Approved helmets in the USA and Canada bear a U.S.

Department of Transportation (DOT) label.

Approved helmets in Europe, Asia and Oceania bear

the ECE 22.05 label. The ECE mark consists of a

circle surrounding the letter E, followed by the

distinguishing number of the country which has

granted approval. The approval number and serial

number will also be displayed on the label.

EYE PROTECTION

Do not depend on eyeglasses or sunglasses for eye protection. Whenever riding

this POLARIS vehicle, always wear shatterproof goggles or use a shatterproof

helmet face shield. POLARIS recommends wearing approved Personal

Protective Equipment (PPE) bearing markings such as VESC 8, V-8, Z87.1, or

CE. Make sure protective eye wear is kept clean.

GLOVES

Wear gloves for comfort and for protection from sun, cold weather and other

elements.

BOOTS

Wear sturdy over-the-ankle boots for support and protection. Never ride a

POLARIS vehicle with bare feet or sandals.

CLOTHING

Wear long sleeves and long pants to protect arms and legs.

SAFETY

SAFETY LABELS AND LOCATIONS

Warning labels have been placed on the vehicle for your protection. Read and

follow the instructions of the labels on the vehicle carefully. If any of the labels

depicted in this manual differ from the labels on your vehicle, always read and

follow the instructions of the labels .on the vehicle

If any label becomes illegible or comes off, contact your POLARIS dealer to

purchase a replacement. Replacement labels are provided by POLARISsafety

at no charge. The part number is printed on the label.

qGeneral Alerts / Jacking Points Alert / Greasing Points Alert

wLoad / Passenger /Tire Pressure Alert

eClutch Cover Alert

rHitch Capacity Alert

tIntake Alert

SAFETY

GENERAL ALERT (7185803)

• Always read the owner’s manual.

• Never allow anyone under 16 years

of age to operate this vehicle.

• Never use alcohol or drugs before or

while driving or riding.

• This vehicle is approved for on-road

operation.

GENERAL ALERT (7183322)

• Always read the owner’s manual.

• Always use the cab nets or doors.

• Always wear seat belts.

GENERAL ALERT (7183307)

• Always read the owner’s manual.

• Wear approved helmet, goggles, and

protective clothing.

• Avoid exhibition driving.

• Avoid operating in a manner that

could result in a rollover.

JACKING POINTS ALERT (7184992)

Jacking positions are located beneath

the vehicle’s center points. Read the

owner’s manual.

SAFETY

GREASING POINTS ALERT (7185156)

Lubricate as recommended. Read

owner’s manual.

CLUTCH COVER ALERT (7181427)

Keep body parts away from belt.

Label Location: on the clutch cover.

INTAKE ALERT (7185975)

Use a Polaris approved air filter. The

use of a non-Polaris approved air filter

may cause engine damage. Before

installing filter ensure there is no dirt or

debris in the clean side of the intake

tube. The air filter must be properly

seated and the hinges fully inserted

when the lid is reinstalled. The intake

tube must also be fully seated on the air

box and throttle body. Inspect full

perimeter if serviced. Clamps at air box

and throttle body must be torqued to 5.5

N m (49 in-lbs) or severe engine⋅

damage may occur. Please reference

your owner’s manual for additional

information regarding the air filter

service.

Label Location: On the air box.

SAFETY

LOAD / PASSENGER / TIRE PRESSURE ALERT

(7191116)

WARNING

Never carry passengers in cargo

box. Passengers can be thrown off.

This can cause serious injury or

death. Read owner's manual.

NEVER carry fuel or other

flammable liquids on this vehicle.

Failure to follow this instruction

could lead to serious burn injuries or

death.

MAXIMUM CARGO BOX LOAD 136 kg

TIRE PRESSURE IN kPa / bar / PSI FRONT 110 / 1,1 / 16

REAR 110 / 1,1 / 16

MAXIMUM WEIGHT CAPACITY

INCLUDES WEIGHT OF OPERATOR,

PASSENGERS, CARGO AND ACCESSORIES

336 kg

Read Operation and Maintenance Manual for more detailed loading

information.

SAFETY

SAFETY WARNINGS

WARNING

Failure to operate this vehicle properly can result in a collision, loss of control,

accident or rollover, which may result in serious injury or death. Heed all safety

warnings outlined in this section of the owner’s manual and in the safety DVD

provided with your vehicle. See the OPERATION section of the owner’s

manual for proper operating procedures.

FUEL TRANSPORT WARNING

NEVER carry fuel or other flammable liquids on this

vehicle.

Failure to follow this instruction could lead to serious

burn injuries or death.

OPERATING WITHOUT INSTRUCTION

Operating this vehicle without proper

instruction increases the risk of an accident.

The operator must understand how to

operate the vehicle properly in different

situations and on different types of terrain. All

operators must read and understand the

Owner's Manual and all warning and

instruction labels before operating the

vehicle.

SAFETY

AGE RESTRICTIONS

This vehicle is an ADULT VEHICLE ONLY.

Operation is prohibited for anyone under 16 years of

age or anyone without a valid driver’s license.

All riders must be able to sit with backs against the

seat, both feet flat on the floor and both hands on

the steering wheel (if driving) or on a passenger

hand hold.

USING ALCOHOL OR DRUGS

Operating the vehicle after consuming

alcohol or drugs could adversely affect

operator judgment, reaction time, balance

and perception. Never drink alcohol or use

drugs or medications before or while

operating this vehicle.

ROLLOVERS

A rollover can result in serious injury or death. Avoid

operating in a manner that could result in a rollover.

SAFETY

PROTECTIVE APPAREL

Riding in this vehicle without wearing an

approved helmet and protective eyewear

increases the risk of a serious injuries in the

event of an accident. Operator and all

passenger always wear an approvedmust

helmet that fits properly and eye protection

(goggles or face shield).

SEAT BELTS

Riding in this vehicle without wearing the seat belt

increases the risk of serious injury in the event of

rollover, loss of control, other accident or sudden

stop. Seat belts may reduce the severity of injury in

these circumstances.

All riders wear seat belts at all times.must

CAB NETS AND DOORS

Riding in this vehicle without closed and latched cab doors increases the risk of

serious injury or death in the event of an accident or rollover.

Always make sure all cab doors are closed and latched while riding in this

vehicle. Cab doors are NOT intended to be used as arm rests.

Always keep hands and feet inside the vehicle at all times.

SAFETY

OPERATING ON PUBLIC ROADS

This vehicle is approved for on-road operation.

JUMPS AND STUNTS

Exhibition driving increases the risk of an accident

or rollover. DO NOT do power slides, “donuts”,

jumps or other driving stunts. Avoid exhibition

driving.

FAILURE TO INSPECT BEFORE OPERATING

WARNING

Failure to inspect and verify that the vehicle is in safe operating condition

before operating increases the risk of an accident. Always perform the Pre-

Ride Inspection outlined in the Operation chapter before each use of your

vehicle to make sure it's in safe operating condition. Always follow the

inspection and maintenance procedures and schedules described in this

owner’s manual. See the Periodic Maintenance section of the Maintenance

chapter.

SAFETY

CARRYING MULTIPLE PASSENGERS (RZR 2–

SEAT)

Never carry a passenger until you have

operated this vehicle for at least two hours

and have completed the steps in the New

Operator Driving Procedures section. A

passenger must always be seated in a

passenger seat with seat belt secured.

Carrying more than one passenger in a 2-

seat vehicle can affect the operator’s ability to

steer and operate the controls, which

increases the risk of loss of control and

accident or rollover. Never carry more than

one passenger in a 2-seat vehicle.

PASSENGERS IN THE CARGO BOX

Carrying a passenger in the cargo box could result in a

fall from the vehicle or contact with moving

components. Never allow a passenger to ride in the

cargo box. A passenger must always be seated in a

passenger seat with seat belt secured.

OPERATING ON PAVEMENT

This vehicle's tires are designed for off-road use, not for use on pavement.

Operating this vehicle on paved surfaces (including sidewalks, paths, parking

lots and driveways) may adversely affect the handling of the vehicle and may

increase the risk of loss of control and accident or rollover. Avoid operating the

vehicle on pavement. If it's unavoidable, travel slowly, travel short distances and

avoid sudden turns or stops.

SAFETY

OPERATING WITH A LOAD ON THE VEHICLE

The weight of both cargo and vehicle occupants impacts vehicle operation and

stability. For your safety and the safety of others, carefully consider how your

vehicle is loaded and how to safely operate the vehicle. Follow the instructions in

this manual for loading, tire pressure, gear selection and speed.

• The vehicle’s maximum weightDo not exceed vehicle weight capacities.

capacity is listed in the specifications section of this manual and on a label on

the vehicle. When more passenger weight is added, cargo weight may need

to be reduced accordingly.

• The recommended tire pressures are listed in the specifications section of this

manual and on a label on the vehicle.

Always follow these guidelines:

Under ANY of these conditions: Do ALL of these steps:

Passenger and/or cargo exceeds half the

maximum weight capacity

1. Slow down.

2. Verify tire pressure.

3. Use extra caution when

operating.

Operating in rough terrain

Operating over obstacles

Climbing an incline

Towing

OPERATING AT EXCESSIVE SPEEDS

Operating this vehicle at excessive speeds increases

the operator's risk of losing control. Always operate at

a speed that's appropriate for the terrain, the visibility

and operating conditions, your skills and experience

and any passenger’s skills and experience.

TURNING IMPROPERLY

Turning improperly could cause loss of traction, loss of control, accident or

rollover. Always follow proper procedures for turning as described in this owner's

manual.

Avoid sharp turns. Never turn while applying heavy throttle. Never make abrupt

steering maneuvers. Practice turning at slow speeds before attempting to turn at

faster speeds.

SAFETY

IMPROPER HILL CLIMBING

Improper hill climbing could cause loss of control or

rollover. Use extreme caution when operating on hills.

Always follow proper procedures for hill climbing as

described in this owner's manual. See the Driving

Uphill section for details.

DESCENDING HILLS IMPROPERLY

Improperly descending a hill could cause loss of

control or rollover. Always follow proper procedures for

traveling down hills as described in this owner’s

manual. See the Driving Downhill section for details.

CROSSING HILLSIDES

Driving on a sidehill is not recommended. Improper procedure could cause loss

of control or rollover. Avoid crossing the side of any hill unless absolutely

necessary.

If crossing a hillside is unavoidable, always follow proper procedures as

described in this owner's manual. See the Driving on a Sidehill (Sidehilling)

section for details.

STALLING WHILE CLIMBING A HILL

Stalling or rolling backwards while climbing a hill could cause a rollover. Maintain

a steady speed when climbing a hill.

If you lose all forward speed:

Apply the brakes gradually until the vehicle is fully

stopped. Place the transmission in reverse and slowly

allow the vehicle to roll straight downhill while applying

light brake pressure to control speed.

SAFETY

OPERATING IN UNFAMILIAR TERRAIN

Failure to use extra caution when operating on

unfamiliar terrain could result in an accident or rollover.

Unfamiliar terrain may contain hidden rocks, bumps, or

holes that could cause loss of control or rollover.

Travel slowly and use extra caution when operating on

unfamiliar terrain. Always be alert to changing terrain

conditions.

OPERATING IMPROPERLY IN REVERSE

Improperly operating in reverse could result in a

collision with an obstacle or person. Always follow

proper operating procedures as outlined in this

manual. See the Driving in Reverse section for details.

Before shifting into reverse gear, always check for

obstacles or people behind the vehicle. When it's safe

to proceed, back slowly.

IMPROPER TIRE MAINTENANCE

Operating this vehicle with improper tires or with improper or uneven tire

pressure could cause loss of control, accident or rollover.

Always use the size and type of tires specified for your vehicle. Always maintain

proper tire pressure as described in this owner's manual and on safety labels.

SKIDDING OR SLIDING

Failure to use extra caution when operating on excessively rough, slippery or

loose terrain could cause loss of traction, loss of control, accident or rollover. Do

not operate on excessively slippery surfaces. Always slow down and use

additional caution when operating on slippery surfaces.

Skidding or sliding due to loss of traction can cause loss of control or rollover (if

tires regain traction unexpectedly). Always follow proper procedures for

operating on slippery surfaces as described in this owner's manual. See the

Driving on Slippery Surfaces section for details.

SAFETY

OPERATING OVER OBSTACLES

Improperly operating over obstacles could cause loss

of control or rollover.

Before operating in a new area, check for obstacles.

Never attempt to operate over large obstacles such as

large rocks or fallen trees. Always follow the proper

procedures outlined in this manual when operating

over obstacles. See the Driving Over Obstacles

section for details.

OPERATING THROUGH WATER

Operating through deep or fast-flowing water can

cause loss of traction, loss of control, rollover or

accident. Never operate in fast-flowing water or in

water that exceeds the floor level of the vehicle.

Always follow proper procedures for operating in water

as described in this owner’s manual. See the Driving

Through Water section for details.

Wet brakes may have reduced stopping ability. After

leaving water, test the brakes. Apply them lightly

several times while driving slowly. The friction will help

dry out the pads.

OPERATING ON FROZEN BODIES OF WATER

Severe injury or death can result if the vehicle and/or

the operator fall through the ice. Never operate the

vehicle on a frozen body of water unless you have first

verified that the ice is sufficiently thick to support the

weight and moving force of the vehicle, you and any

passengers, and your cargo, together with any other

vehicles in your party.

Always check with local authorities and residents to

confirm ice conditions and thickness over your entire

route. Vehicle operators assume all risk associated

with ice conditions on frozen bodies of water.

OPERATING A DAMAGED VEHICLE

Operating a damaged vehicle can result in an accident. After any rollover or

other accident, have a qualified service dealer inspect the entire machine for

possible damage, including (but not limited to) seat belts, rollover protection

devices, brakes, throttle and steering systems.

SAFETY

IMPROPER CARGO LOADING

Overloading the vehicle or carrying cargo improperly may cause changes in

stability and handling, which could cause loss of control or an accident.

• Always follow the instructions in this owner’s manual for carrying cargo. See

the Hauling Cargo section for details.

• Never exceed the stated load capacity for this vehicle.

• Cargo should be properly distributed and securely attached. See the Hauling

Cargo section for details.

• Reduce speed when carrying cargo. Allow a greater distance for braking.

REFUELING

Gasoline is highly flammable and explosive under certain conditions.

• Always exercise extreme caution whenever handling gasoline.

• Always turn off the engine when refueling.

• Always refuel outdoors or in a well ventilated area free of any source of flame

or sparks.

• NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow

this instruction could lead to serious burn injuries or death.

• Do not smoke or allow open flames or sparks in or near the area where

refueling is performed or where gasoline is stored.

• Do not overfill the tank. Do not fill the tank neck.

• If gasoline spills on your skin or clothing, immediately wash it off with soap

and water and change clothing.

EXPOSURE TO EXHAUST

Engine exhaust fumes are poisonous and can cause loss of consciousness or

death in a short time. Never start the engine or let it run in an enclosed area.

Operate this vehicle only outdoors or in well-ventilated areas.

SAFETY

HOT EXHAUST SYSTEMS

WARNING

Exhaust system components are very hot during and after use of the vehicle.

Hot components can cause burns and fire. Do not touch hot exhaust system

components. Always keep combustible materials away from the exhaust

system.

Use caution when traveling through tall grass, especially dry grass and when

traveling through muddy conditions. Always inspect the underside of the

vehicle and areas near the exhaust system after driving through tall grass,

weeds, brush, other tall ground cover, and muddy conditions. Promptly remove

any grass, debris or foreign matter clinging to the vehicle and pay particular

attention to the exhaust system area.

UNAUTHORIZED USE OF THE VEHICLE

Leaving the keys in the ignition can lead to unauthorized use of the vehicle by

someone under the age of 16, without a drivers license, or without proper

training. This could result in an accident or rollover. Always remove the ignition

key when the vehicle is not in use.

LIGHTNING AND POWERLINES

Avoid operating this vehicle when lightning could occur or near powerlines.

Rubber tires, rubber handgrips, and a foam seat will not protect a rider from

lightning strikes or electrical surges. Always seek safe shelter when lightning is

imminent and keep a safe distance from powerlines.

SAFETY

EQUIPMENT MODIFICATIONS

Your POLARIS vehicle is designed to provide safe operation when used as

directed. Modifications to your vehicle may negatively impact vehicle stability.

Failure of critical machine components may result from operation with any

modifications, especially those that increase speed or power. This vehicle may

become less stable at speeds higher than those for which it is designed. Loss of

control may occur at higher speeds.

Do not install any non-POLARIS-approved accessory or modify the vehicle for

the purpose of increasing speed or power. Any modifications or installation of

non-POLARIS-approved accessories could create a substantial safety hazard

and increase the risk of bodily injury.

The POLARIS limited warranty on your POLARIS vehicle will be terminated if

any non-POLARIS-approved equipment and/or modifications have been added

to the vehicle that increase speed or power.

The addition of certain accessories, including (but not limited to) mowers,

blades, tires, sprayers, or large racks, may change the handling characteristics

of the vehicle. Use only POLARIS-approved accessories, and familiarize

yourself with their function and effect on the vehicle.

SAFETY

POSITION FUNCTION

OFF The engine is off. Electrical circuits are off, except

accessory 12V.

ACCESSORY

The engine is off. Powers the display, terminal block,

and front/rear accent lights. Check engine and power

steering warning indicators will appear on the display in

this mode but will turn off when the vehicle is started if

no issues are present.

ON Electrical circuits are on. Electrical equipment can be

used.

START

The vehicle must be in PARK or NEUTRAL before the

engine can start. To start the vehicle, press the brake

pedal, turn the key to the start position, and then

release. The engine will turn over for about 5 seconds

or until started.

HEADLIGHT SWITCH

Use the headlight switch to turn the lights on and off and to change the lights

from high beam to low beam. The ignition switch must be in the ON position to

operate the headlights.

Press the top of the rocker switch toward the dash to place the headlights on

high beam q. Move the rocker switch to the center position to place the

headlights on low beam w. Press the bottom of the rocker switch to turn off the

headlights.

If the headlight switch is ON when the ignition switch is turned off, the lights will

remain on for approximately 30 seconds.

FEATURES AND CONTROLS

HORN SWITCH

The horn switch is located on the turn

signal lever q. Press the tip of the turn

signal lever inward to sound the horn.

HAZARD LIGHT

The hazard light is controlled by the turn signal lever. To switch the hazard light

to ON position, push the lever forward. Pull the lever backward to switch the

hazard light to OFF position.

TURN SIGNAL LEVER

Before turning, activate a turn signal to alert others of your intentions. Check turn

signal lamps before each ride.

TIP

The key must be in the ON position to activate the turn signals.

Move the turn signal lever downwardq

to signal a left turn. The left turn signal

lamps in the taillight and below the front

headlight will flash. The turn signal

indicator in the gauge will also flash.

Move the lever upward wto signal a

right turn. The right signal lamps and

indicator will flash.

Return the lever to the center position to

end the signal.

FEATURES AND CONTROLS

DRIVELINE MODE SWITCH

The Driveline Mode Switch has three positions:

qAll Wheel Drive (AWD)

wTwo Wheel Drive (2WD)

eTurf Mode / Differential Unlocked (1WD)

See the All Wheel Drive (AWD) System section for operating instructions.

ELECTRONIC POWER STEERING (EPS)

Electronic power steering (if equipped) engages when the ignition key is turned

to the ON position. EPS remains engaged whether the vehicle is moving or idle.

The EPS warning indicator briefly illuminates when the key is turned to the ON

position. See the Indicator Lamps section for details.

To conserve battery power, the EPS will shut down 5 minutes after the engine is

stopped if the key remains in the ON position. The EPS warning indicator will

illuminate to indicate the EPS has shut down.

If the light remains on after starting the engine, the EPS system is inoperative.

See your POLARIS dealer, or another qualified person, as soon as possible for

repair. Continued operation could result in permanent damage to the EPS unit

and increased steering effort.

STEERING WHEEL

The steering wheel can be tilted upward

or downward for rider preference. Lift

and hold the steering wheel adjustment

lever qwhile moving the steering

wheel upward or downward. Release

the lever when the steering wheel is at

the desired position.

FEATURES AND CONTROLS

SEAT ADJUSTMENTS

The driver’s seat is equipped with an adjustment lever and adjustment knob for

optimal spacing.

• Pull the adjustment lever to the left to move the seat forward or rearward.

Once released, the lever will lock into place.

• Rotate the adjustment knob to move the seat forward upward or rearwardand

and downward.

Driver’s Seat

Up Position

Driver’s Seat

Down Position

To adjust the front passenger seat, loosen (do not remove) the four screws

located on the seat bottom. Slide the seat forward or rearward to the desired

position. Tighten the screws to 5.4 Nm (4 ft. lbs.). Do not overtighten.

FEATURES AND CONTROLS

PASSENGER HAND HOLD

Always adjust the hand hold to a comfortable position for your passenger before

operating. Make sure the adjustment pin and retainer are securely installed after

making adjustments.

1. Remove the retainer qfrom the end of the adjustment pinw.

2. Remove the pin from the post.

3. Slide the post inward or outward to the desired position.

4. Reinstall the pin through the post mounting holee, adapter bushing hole r,

both post adjustment holest, and lastly through the remaining bushing hole

and post mounting hole.

5. Reinstall the retainer to the pin.

FEATURES AND CONTROLS

CARGO BOX ACCESS PANEL

The cargo box access panel is located on the floor of the cargo box. Remove the

panel to access the engine oil fill cap, spark plugs and air filter.

CAB DOORS

Riding in this vehicle without closed and latched cab doors increases the risk of

serious injury or death in the event of an accident or rollover. Always make sure

all cab doors are closed and latched while riding in this vehicle. Cab doors are

NOT intended to be used as arm rests. Keep hands and feet inside the vehicle

at all times.

SEAT BELTS

This POLARIS vehicle is equipped with seat belts for all riders. Always make

sure the seat belts are secured for the operator and all passengers before riding.

The driver’s seat belt is equipped with a seat belt interlock. Vehicle speed will be

limited to 15 mph (24 km/h) if the seat belt is not secured.

3-POINT SEAT BELT

To wear the 3-point seat belt properly, follow this procedure:

1. Pull the seat belt latch downward and across your chest toward the buckle at

the inner edge of the seat. The belt should fit snugly across your hips and

diagonally across your chest. Make sure the belt is not twisted.

2. Push the latch plate into the buckle until it clicks. Pull up on the strap to

tighten.

3. Press the red release latch on the buckle to release the seat belt.

FEATURES AND CONTROLS

BRAKE AND THROTTLE PEDALS

BRAKE PEDAL

Depress the brake pedal qto slow or stop the vehicle. Apply the brakes while

starting the engine.

THROTTLE PEDAL

Push the throttle pedal wdown to increase engine speed. Spring pressure

returns the pedal to the rest position when released. Always check that the

throttle pedal returns normally before starting the engine.

TIP

If the throttle pedal and brake pedal are applied simultaneously, engine power

may be limited.

FEATURES AND CONTROLS

PARK BRAKE LEVER

Always apply the service brakes before engaging or releasing the park brake. To

help prevent the vehicle from rolling, set the park brake when parking the

vehicle. When the park brake is set and the park brake indicator is illuminated,

engine speed is limited. If the accelerator is applied, this limiting feature

prevents operation, which protects the park brake pads from excessive wear.

TIP

This feature will not operate properly if the park brake connector or switch

malfunctions or becomes disconnected, or if the switch has moved. Check for

disconnection, then see your dealer promptly if this feature fails to operate

properly.

1. To set the park brake, apply the brakes.

2. Pull the park brake lever qupward as far as possible.

3. To release the park brake, apply the brakes. Press the park brake releasew

inward and move the lever downward as far as possible.

FEATURES AND CONTROLS

HITCHES

WARNING

Whenever the vehicle is towing, always stay clear of the area between the

vehicle and the towed object.

REAR HITCH

NOTICE

After 1000 km of use, tighten the bolt holding the trailer ball to the hitch to 445

N m.⋅

Use the rear hitch for towing a trailer. See the Hauling Cargo section for details

and procedures.

The values given below pertain to factory-installed hitches and are provided for

informational purposes only.

IMPORTANT

For vehicle-specific trailering values, see the Specifications chapter.

The vehicle-specific values take precedent if they are lower than the

component values shown below.

REAR HITCH COMPONENT SPECIFICATIONS

Maximum Vertical Load (S) 85 kg

Maximum Towable Mass 2000 kg

Maximum Dynamic Force (D) 10,2 kN

Approval # E20 55R-01 4430

REAR HITCH CERTIFICATION LABEL

The hitch certification label is located on

the hitch bar.

FEATURES AND CONTROLS

HITCH REMOVAL / INSTALLATION

1. To remove the hitch (if equipped), remove the cotter pinqand hitch pin w.

Remove the hitch, then reinstall the hitch pinwand secure the cotter pin q.

2. To install the hitch, remove the cotter pinqfrom the hitch pin and remove

the hitch pin w.

3. Install the hitch to the receiver.

4. Reinstall the hitch pin (from the left side of the hitch) through the bore of both

the receiver and the hitch.

5. Reinstall the cotter pin. Make sure the hitch assembly is secure at that the

cotter pin is properly engaged over the hitch pin.

7-WAY TRAILER CONNECTOR

The 7-way trailer connector (if

equipped) qinstalled on your

vehicle meets the requirements of

European standard ISO 1724.

This connector uses all 7 pins on

newer model trailers. An older

model trailer may not be compatible

with this connector.

Improper electrical wiring changes

can result in damage to both vehicle

and trailer components. When in

doubt about your trailer connection,

please contact a qualified tow-bar

specialist for assistance.

FEATURES AND CONTROLS

ENGAGING AWD

The AWD switch may be turned on or off while the vehicle is moving. Initially, the

vehicle's electronic system will not enable the AWD until the engine RPM is

below 3100. Once enabled, the AWD remains enabled until the AWD switch is

turned off. If the switch is turned off while the demand drive unit is moving, it will

not disengage until the rear wheels regain traction.

Engage the AWD switch before getting into conditions where front wheel drive

may be needed. If the rear wheels are spinning, release the throttle before

switching to AWD.

NOTICE

Switching to AWD while the rear wheels are spinning or slipping may cause

severe drive shaft and gearcase damage. Always switch to AWD while the rear

wheels have traction or are at rest.

DISENGAGING AWD

Move the AWD switch to the center or bottom position to disengage AWD. If the

switch is turned off while the front hubs are driving, they will not release until the

rear wheels regain traction.

In some situations, the front gearcase may remain locked after turning the AWD

switch off. If this occurs, you may notice increased steering effort and some

vehicle speed restriction. Perform the following procedure to unlock the front

gearcase.

1. Stop the vehicle.

2. Operate in reverse for at least 10 ft (3 m).

3. Stop completely.

4. Shift into low gear and drive forward.

5. If the front gearcase remains locked after following these instructions, see

your dealer for service.

FEATURES AND CONTROLS

LOCKING/UNLOCKING THE DIFFERENTIAL

NOTICE

Damage to the differential can occur if it is engaged while the vehicle is

traveling at high speeds or while the rear wheels are spinning. Slow the vehicle

to nearly stopped before engaging the differential.

Locking the differential in slippery or low traction conditions helps improve

traction. Move the rocker switch to the center position (2WD) to lock the

differential and operate in rear wheel drive.

Press the bottom of the switch to unlock the differential and allow the rear drive

wheels to operate independently. This mode of operation is well suited to turf

driving or whenever aggressive traction is not required.

FEATURES AND CONTROLS

INSTRUMENT CLUSTER

NOTICE

High water pressure may damage components. Wash the vehicle by hand or

with a garden hose using mild soap. Certain products, including insect

repellents and chemicals, will damage the speedometer lens and other plastic

surfaces. Do not use alcohol to clean the instrument cluster. Do not allow

insect sprays to contact the lens. Immediately clean off any gasoline that

splashes on the instrument cluster.

qSpeedometer

wTachometer

eIndicator Lamps

rMode Button

tToggle Buttons

yRider Information Center

SPEEDOMETER

The speedometer displays vehicle speed in either miles per hour (MPH) or

kilometers per hour (km/h).

TACHOMETER

The tachometer displays engine speed in revolutions per minute (RPM).

MODE BUTTON

Press and hold the MODE buttonrto enter or exit the settings menu. Press

and release the MODE button to cycle through Area 1 modes and to select an

item.

FEATURES AND CONTROLS

TOGGLE BUTTONS

Press and release either toggle buttontto cycle through the options menu or

Area 2 modes. Press and hold either toggle button to reset an item. See page

57.

TIP

With the ignition key off, pressing the MODE button or either toggle button will

power up the Rider Information Center for 10 seconds to allow viewing of the

odometer and the clock.

INDICATOR LAMPS

LAMP INDICATES CONDITION

Vehicle Speed When standard mode is selected, speed displays in miles per

hour.

When metric mode is selected, speed displays in kilometers

per hour.

Over

Temperature

This lamp illuminates to indicate an overheated engine. If the

indicator flashes, the overheating condition remains, and the

system will automatically reduce engine power.

Electric Power

Steering (EPS)

Warning (if

equipped)

This indicator illuminates briefly when the key is turned to the

ON position. If the light remains on, the EPS system is

inoperative. See your POLARIS dealer, or other qualified

person, as soon as possible for repair. Continued operation

could result in permanent damage to the EPS unit and

increased steering effort.

Neutral This lamp illuminates when the transmission is in neutral and

the ignition key is in the ON position.

High Beam This lamp illuminates when the headlamp switch is set to high

beam.

Helmet/Seat Belt This lamp is a reminder to the operator to ensure all riders are

wearing helmets and seat belts before operating. The driver’s

seat belt is equipped with a seat belt interlock. Vehicle speed

will be limited to 15 MPH (24 km/h) if the seat belt is not

secured.

Check Engine This indicator appears if an Electronic Fuel Injection (EFI)

related fault occurs. Do not operate the vehicle if this warning

appears. Serious engine damage could result. Your dealer

can assist.

FEATURES AND CONTROLS

LAMP INDICATES CONDITION

Check Battery This warning usually indicates that the vehicle is operating at

an RPM too low to keep the battery charged. It may also

occur when the engine is at idle and high electrical load

(lights, cooling fan, accessories) is applied. Drive at a higher

RPM or recharge the battery to clear the warning.

Low Fuel This lamp illuminates when fuel level in the fuel tank is low.

Direction

Indicators

Direction indicators flash when a turn signal is active. Both

indicators flash when the hazard signal is active.

Brake Failure

Alarm

Lamp illuminates when Brake System (if Brake Failure Alarm

is equipped) detects low pressure in brake hydraulic system.

Park Brake Lamp illuminates when the Park Brake is applied.

Trailer Indicator The Turn Trailer Indicator is illuminating when the trailer turn

signals are active.

FEATURES AND CONTROLS

RIDER INFORMATION CENTER

qGear Indicator This indicator displays gear shifter position.

H = High Gear

L = Low Gear

N = Neutral

R = Reverse Gear

P = Park

– = Gear Signal Error (or shifter between gears)

wDriveline

Indicator

This indicator shows whether 2X4, Turf, or AWD is active.

eService

Indicator

A flashing wrench symbol alerts the operator that the preset

service interval has been reached. Your POLARIS dealer, or

other qualified person, can provide scheduled maintenance.

See page 60 for resetting instructions.

rFuel Gauge The segments of the fuel gauge show the level of fuel in the

fuel tank. When the last segment clears, a low fuel warning is

activated. The outline of the fuel display will flash. Refuel

immediately.

The rider information center is located

in the instrument cluster. All segments

will light up for one second at start-up.

If the instrument cluster fails to

illuminate, a battery over-voltage may

have occurred and the instrument

cluster may have shut off to protect the

electronic speedometer. If this occurs,

your POLARIS dealer, or other qualified

person, can provide proper diagnosis.

The information center is set to display

standard units of measurement and a

12-hour clock at the factory. To change

to metric and/or a 24-hour clock hold

the mode button and cycle to the clock

menu. Use the directional arrows to

change the clock settings.

FEATURES AND CONTROLS

ACCESSING MENUS AND OPTIONS

GAUGE SETTINGS MENU

Press and release the MODE button to cycle through the Area 1 modes until the

desired default mode displays. See the Mode Information Displays section for

details.

Press and hold the MODE button to enter the settings menu.

The OPTIONS screen will display for a few seconds.

1. Press and release either toggle

button to cycle to the desired option.

2. Press MODE to select the option.

3. Press either toggle button to cycle to

the desired setting.

4. Press MODE to save and exit to the

settings menu.

5. Press and hold the MODE button to

exit the settings menu.

BACKLIGHT COLOR

The information center backlight can be

set to either blue or red.

1. Press and hold the MODE button to

enter the settings menu.

2. Press either toggle button to cycle to

the “BL COLOR” option. Press

MODE to select.

3. Press either toggle button to cycle to

the desired setting.

4. Press MODE to save and exit to the

settings menu,

FEATURES AND CONTROLS

DISPLAY UNITS (STANDARD/METRIC)

1. Press and hold the MODE button to enter the settings menu.

2. Press either toggle button to cycle to the desired “UNITS” option (distance,

temperature or volume). Press MODE to select.

3. Press either toggle button to cycle to the desired setting.

4. Press MODE to save and exit to the settings menu.

TRIP METER

Use a trip meter to track the distance

traveled during a specific trip or period

of time. Reset the meter to zero before

traveling.

1. Press either toggle button to cycle to

the desired trip meter option (T1 or

T2).

2. Press and hold either toggle button

until the meter resets to zero.

TRIP TIME

Use a trip time meter to track the travel

time during a specific trip. Reset the

meter to zero before traveling.

1. Press either toggle button to cycle to

the trip time option (TT).

2. Press and hold either toggle button

until the meter resets to zero.

FEATURES AND CONTROLS

PROGRAMMABLE SERVICE INTERVAL

The service interval counter is programmed to 25 hours at the factory. As hours

of engine operation increase, the counter decreases. The wrench icon will flash

for about 10 seconds when the counter reaches zero (0), and each time the key

is turned on thereafter, until the counter is reset.

When this feature is enabled, it provides a convenient reminder to perform

routine maintenance. Refer to the Periodic Maintenance Chart for recommended

service intervals.

Use the following procedure to reset or change the service interval.

1. Press and hold the MODE button to

enter the settings menu.

2. Press either toggle button to cycle to

the “Service Hours” option. Press

MODE to select.

3. Press MODE to reset the existing

value and exit, or press either toggle

button to change the value. Press

MODE to save and exit to the

settings menu.

FEATURES AND CONTROLS

ENGINE ERROR CODES

The error screen displays only when the CHECK ENGINE indicator is on or

when it goes on and off during one ignition cycle. Error codes are not stored.

When the key is turned OFF, the code and message is lost, but will reappear if

the fault reoccurs after restarting the engine.

If the CHECK ENGINE lamp or the EPS lamp illuminates, retrieve the active

error codes from the display.

qFailure Mode Indicator (FMI)

wSuspect Parameter Number (SPN)

eCode Count

1. Press and hold the MODE button to enter the settings menu.

2. Press either toggle button to cycle to the “DIAGCODE” option. Press MODE

to select.

3. More than one diagnostic code may be present. Press the toggle UP button

to see if more codes are present. Press MODE to select a code.

NOTICE

If the displayed code is an engine fault code, the CHECK ENGINE lamp will

blink. If the displayed code is an EPS fault code, the EPS lamp will blink.

4. Record the three (3) numbers displayed.

5. Press MODE to exit to the settings menu.

FEATURES AND CONTROLS

OPERATION

IMPORTANT INFORMATION

WARNING

Failure to operate the vehicle properly can result in a collision, loss of control,

accident or rollover, which may result in serious injury or death. Read and

understand all safety warnings outlined in the safety section of this owner’s

manual.

VEHICLE BREAK-IN PERIOD

The break-in period for your new POLARIS vehicle is the first 25 hours of

operation, or the time it takes to use the first two tanks full of gasoline. Clutch

and drive belt break-in periods vary depending on operating conditions.

No single action on your part is as important as a proper break-in period. Careful

treatment of a new engine and drive components will result in more efficient

performance and longer life for these components. Perform the following

procedures carefully.

NOTICE

Excessive heat build-up during the first three hours of operation will damage

close-fitted engine parts and drive components. Do not operate at full throttle

or high speeds during the first three hours of use.

Use of any improper oils may cause serious engine damage. POLARIS

Premium 4 Synthetic Oil is specifically formulated for your 4-cycle engine

OPERATION

ENGINE AND DRIVETRAIN BREAK-IN

1. Fill the fuel tank with the recommended fuel. See the Refueling section for

details. Always exercise extreme caution whenever handling gasoline.

2. Check the oil level. See the Oil Check section for details. Add the

recommended oil as needed to maintain the oil level in the safe operating

range.

3. Complete the steps in the New Operator Driving Procedures section.

4. Avoid aggressive use of the brakes.

5. Vary throttle positions. Do not operate at sustained idle.

6. Perform regular checks on fluid levels, controls and areas outlined on the

daily pre-ride inspection checklist.

7. Carry only light loads.

8. During the break-in period, change both the oil and the filter at 25 hours or

one month.

9. Check fluid levels of transmission and all gearcases after the first 25 hours of

operation and every 100 hours thereafter.

BRAKE SYSTEM BREAK-IN

Apply only moderate braking force for the first 50 stops. Aggressive or overly

forceful braking when the brake system is new could damage brake pads and

rotors.

PVT BREAK-IN (CLUTCHES / BELT)

A proper break-in of the clutches and drive belt will ensure a longer life and

better performance. If a belt fails, always clean any debris from the duct and

from the engine compartment.

Standard Break-in

Drive at slower speeds for the first 50 miles (80 km) of operation. Carry only light

loads. Avoid aggressive acceleration, high-speed operation and prolonged

operation at a specific RPM during this period.

Sand / Dune Break-in

Drive in low gear for the first 5 miles (8 km) of operation. Avoid prolonged low

speed operation at high throttle. Avoid aggressive acceleration, high-speed

operation and prolonged operation at a specific RPM during this period.

OPERATION

ITEM REMARKS REF

Cab Doors Check doors and latches for wear

or damage. page 42

Grass and Leaves Remove grass, leaves, foreign

matter, and other flammable

material or debris, especially near

the exhaust system.

SAFE OPERATION PRACTICES

1. Visit the Recreational Off-Highway Vehicle Association® web site (rohva.org)

and take the free on-line training course. Complete the steps in the New

Operator Driving Procedures section.

2. Do not allow anyone under 16 years of age or without a valid driver’s license

to operate this vehicle.

3. Never carry a passenger on a 1-seat vehicle. Never carry more than one

passenger in a 2-seat vehicle. Never carry more than three passengers in a

4-seat vehicle. Never allow a passenger to ride in the cargo box.

4. Engine exhaust fumes are poisonous. Never start the engine or let it run in

an enclosed area.

5. Never operate with accessories not approved by POLARIS for use on this

vehicle.

6. Operate this vehicle off-road only. Never operate the vehicle on pavement or

on any public street, road or highway, including dirt and gravel roads.

7. Drive in a manner appropriate for your skills and operating conditions. Never

operate at excessive speeds. Never attempt wheelies, jumps, or other

stunts. Keep both hands on the steering wheel during operation.

8. Never consume alcohol or drugs before or while operating this vehicle.

9. Always use the size and type of tires specified for your vehicle. Always

maintain proper tire pressure.

10. Never operate a damaged vehicle. After any rollover or accident, have a

qualified service dealer inspect the entire machine for possible damage.

11. Never operate the vehicle on a frozen body of water unless you have first

verified that the ice is sufficiently thick to support the weight and moving force

of the vehicle, you and any passengers, and your cargo, together with any

other vehicles in your party.

OPERATION

NOTICE

Operating the vehicle immediately after starting could cause engine damage.

Allow the engine to warm up for several minutes before operating the vehicle.

STOPPING THE ENGINE

WARNING

A rolling vehicle can cause serious injury. Always place the transmission in

PARK and engage the park brake (if equipped) when stopping the engine.

1. Release the throttle pedal completely and brake to a complete stop.

2. Place the transmission in PARK.

3. Turn the engine off.

4. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle.

5. Engage the park brake (if equipped).

BRAKING

1. Release the throttle pedal completely.

TIP

When the throttle pedal is released completely and engine speed slows to near

idle, the vehicle has no engine braking.

2. Press on the brake pedal evenly and firmly.

3. Practice starting and stopping (using the brakes) until you're familiar with the

controls.

PARKING THE VEHICLE

To park the vehicle, do the following:

1. Apply the brakes. Stop the vehicle on a level surface.

2. When parking inside a garage or other structure, be sure that the structure is

well ventilated and that the vehicle is not close to any source of flame or

sparks, including any appliance with pilot lights.

3. Place the transmission in PARK.

4. Engage the park brake.

OPERATION

5. Turn the engine off.

6. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle

7. Remove the ignition key to prevent unauthorized use.

NEW OPERATOR DRIVING PROCEDURES

1. Read and understand the owner’s manual and all warning and instruction

labels before operating this vehicle.

2. Take a training course.

3. Perform the pre-ride inspection. See the Pre-Ride Inspection section for

details.

4. Do not carry a passenger until you have at least two hours of driving

experience with this vehicle.

5. Do not carry cargo during this period.

6. Select an open area that allows room to familiarize yourself with vehicle

operation and handling.

7. The driver and passenger must wear helmet, eye protection, gloves, long-

sleeve shirt, long pants, over-the-ankle boots and seat belt at all times.

8. Always make sure all cab doors are closed and latched when riding in this

vehicle.

9. Sit in the driver’s seat and fasten the seat belt.

10. Place the transmission in PARK.

11. Start the engine.

12. Apply the brakes and shift into low gear.

13. Check your surroundings and determine your path of travel.

14. Release the park brake.

15. Keeping both hands on the steering wheel, slowly release the brakes and

depress the throttle with your right foot to begin driving.

16. Drive slowly at first. On level surfaces, practice starting, stopping, turning,

maneuvering, using the throttle and brakes and driving in reverse. Learn how

the vehicle handles when making both left and right turns at a slow speed.

17. Increase speed only after mastering all maneuvers at a slow speed.

18. After you become skilled at making turns and begin to operate at faster

speeds, follow these precautions:

OPERATION

• Avoid sharp turns.

• Never turn while applying heavy throttle.

• Never make abrupt steering maneuvers.

• Operate at speeds appropriate for your skills, the conditions and the

terrain.

• DO NOT do power slides, “donuts”, jumps or other driving stunts.

DRIVING WITH PASSENGERS

1. Complete the steps in the New Operator Driving Procedures section.

2. Perform the pre-ride inspection.

3. Do not carry more than one passenger in a 2-seat vehicle. Do not carry more

than three passengers in a 4-seat vehicle. Additional passengers can affect

the operator’s ability to steer and operate the controls.

4. All riders must be able to sit with backs against the seat, both feet flat on the

floor and both hands on the steering wheel (if driving) or on a passenger

hand hold.

5. The driver and all passengers must wear helmet, eye protection, gloves,

long-sleeve shirt, long pants, over-the-ankle boots and seat belt at all times.

See the Safe Riding Gear section for details.

6. Always make sure all cab doors are closed and latched when riding in this

vehicle.

7. Allow a passenger to ride only in a passenger seat.

OPERATION

8. Slow down. Always travel at a speed appropriate for your skills, your

passengers’ skills and operating conditions. Avoid unexpected or aggressive

maneuvers that could cause discomfort or injury to a passenger.

9. Vehicle handling may change with passengers and/or cargo on board. Allow

more time and distance for braking.

10. Always follow all operating guidelines as outlined on safety labels and in this

manual.

DRIVING ON SLIPPERY SURFACES

When driving on slippery surfaces such as wet trails, loose gravel, or ice, be

alert for the possibility of skidding and sliding.

Follow these precautions when encountering slippery conditions:

1. Slow down before entering slippery areas.

2. Maintain a high level of alertness, reading the trail and avoiding quick, sharp

turns, which can cause skids.

3. Engage all-wheel drive before wheels begin to lose traction.

NOTICE

Severe damage to the drive train may occur if the AWD is engaged while the

wheels are spinning. Always allow the wheels to stop spinning before engaging

AWD.

4. Correct a skid by turning the steering wheel in the direction of the skid. Never

apply the brakes during a skid.

OPERATION

DRIVING ON A SIDEHILL (SIDEHILLING)

Driving on a sidehill is not recommended. Improper procedure could cause loss

of control or rollover. Avoid crossing the side of any hill unless absolutely

necessary.

If crossing a hill is , follow these precautions:unavoidable

1. Engage all-wheel drive.

2. Never operate in TURF mode (if equipped) while operating on a hill or other

irregular terrain. Always move the AWD switch to AWD before ascending or

descending a hill.

3. Drive slowly and use extreme caution.

4. If the vehicle begins to roll over, or if it feels as if it may roll over, immediately

turn downhill.

5. Avoid obstacles and changes in terrain that may lower or raise one side of

the vehicle or cause the vehicle to slide.

6. If the vehicle begins to slide downhill, immediately turn downhill to stop the

slide, or stop the vehicle and maneuver slowly and carefully until the vehicle

can be driven straight downhill.

OPERATION

DRIVING DOWNHILL

Whenever descending a hill, follow these precautions:

1. Avoid excessively steep hills.

2. Slow down. Never travel down a hill at high speed.

3. Always check the terrain carefully before descending a hill. Never drive on

hills with excessively slippery or loose surfaces.

4. Always descend a hill with the transmission in forward gear. Never descend

a hill with the transmission in neutral.

5. Avoid traveling down a hill at an angle, which would cause the vehicle to lean

sharply to one side. Travel straight downhill.

6. Apply the brakes to aid in slowing.lightly

OPERATION

DRIVING OVER OBSTACLES

Follow these precautions when operating over obstacles:

1. Always check for obstacles before operating in a new area.

2. Look ahead and learn to read the terrain. Be constantly alert for hazards

such as logs, rocks and low hanging branches.

3. Travel slowly and use extra caution when operating on unfamiliar terrain. Not

all obstacles are immediately visible.

4. Avoid operating over large obstacles such as large rocks and fallen trees. If

unavoidable, use extreme caution and operate slowly.

5. Always have any passengers dismount and move away from the vehicle

before operating over an obstacle that could cause a rollover.

OPERATION

DRIVING IN REVERSE

Follow these precautions when operating in reverse:

1. Always check for obstacles or people behind the vehicle.

2. Apply the throttle lightly. Never open the throttle suddenly.

3. Back slowly.

4. Apply the brakes for stopping.lightly

5. Avoid making sharp turns.

OPERATION

DRIVING THROUGH WATER

WARNING

The large tires on your vehicle may cause the vehicle to float in deep or fast-

flowing water, which could result in loss of traction, loss of control, rollover or

accident.

NOTICE

Major engine damage can result if the vehicle is not thoroughly inspected after

operation in water. Perform the services outlined in the Maintenance Chart

section. Give special attention to engine oil, transmission oil, demand drive

fluid, rear gearcase oil, and all grease fittings.

If your vehicle becomes immersed or is operated in water that exceeds the

floor level, Your POLARIS dealerservice is required before starting the engine.

can provide this service. If it's impossible to bring the vehicle in before starting

the engine, perform the service outlined on page 158, and take the vehicle in

for service at the first opportunity.

Your vehicle can operate through water

with a maximum recommended depth

equal to floor level. Follow these

precautions when operating through

water:

1. Determine the water depth and

current before entering the water.

2. Choose a crossing where the water

level is lowest and where both banks

have gradual inclines. Never

operate in water that exceeds the

maximum recommended depth

(floor level) q.

3. Wet brakes may have reduced

stopping ability. After leaving water,

test the brakes. Apply them lightly

several times while driving slowly.

The friction will help dry out the

pads. Avoid applying brake and

throttle at the same time.

OPERATION

PARKING ON AN INCLINE

A rolling vehicle can result in serious injury. Avoid parking on an incline. If

parking on an incline is , follow these precautions:unavoidable

1. Apply the brakes.

2. Place the transmission in PARK.

3. Engage the park brake.

4. Turn the engine off.

5. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle

6. Block the rear wheels on the downhill side.

OPERATION

HAULING CARGO

WARNING

NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow

this instruction could lead to serious burn injuries or death.

Overloading the vehicle or carrying cargo improperly can alter vehicle handling

and may cause loss of control or brake instability. Always follow these

precautions when hauling cargo:

Never exceed the stated load capacity for this vehicle.

REDUCE SPEED AND ALLOW GREATER DISTANCES FOR BRAKING

WHEN HAULING CARGO.

NEVER EXCEED THE MAXIMUM WEIGHT CAPACITY of the vehicle. When

determining the weight you are adding to the vehicle, include the weight of the

operator, passengers, accessories and loads in the rack or box. The combined

weight of these items must not exceed the maximum weight capacity.

Always load the cargo box with the load as far forward and as low as possible.

When operating over rough or hilly terrain, reduce speed and cargo to maintain

stable driving conditions.

Always operate the vehicle with extreme care when hauling cargo. Slow down

and drive in the lowest gear available.

WARNING

Carrying a passenger in the cargo box could result in a fall from the vehicle or

contact with moving components. Never allow a passenger to ride in the cargo

box. A passenger must always be seated in a passenger seat with seat belt

secured.

OPERATION

WARNING

SECURE ALL LOADS BEFORE OPERATING. Unsecured loads can create

unstable operating conditions, which could result in loss of control of the

vehicle.

OPERATE ONLY WITH STABLE AND SAFELY ARRANGED LOADS. When

handling off-centered loads that cannot be centered, securely fasten the load

and operate with extra caution.

HEAVY LOADS CAN CAUSE BRAKING AND CONTROL PROBLEMS. Use

extreme caution when applying brakes with a loaded vehicle. Avoid terrain or

situations that may require backing downhill.

USE EXTREME CAUTION when operating with loads that extend over the

rack sides. Stability and maneuverability may be adversely affected, causing a

rollover.

DO NOT TRAVEL FASTER THAN THE RECOMMENDED SPEEDS. Vehicle

should never exceed 10 MPH (16 km/h) while cornering or while ascending or

descending a hill.

Your POLARIS vehicle has been designed to carry a specific capacity. Reduce

speed and allow a greater distance for braking when carrying cargo.

Loads should be centered and carried as low as possible in the box. For stability

on rough or hilly terrain, reduce both speed and cargo. Exercise caution if the

cargo load extends over the side of the box.

Always read and understand the load distribution warnings listed on warning

labels and in this manual. Never exceed the maximum capacities specified for

your vehicle.

BELT LIFE

To extend belt life, use low gear in the following conditions:

• when hauling or towing heavy cargo.

• when consistently operating at speeds less than 35 MPH (56 km/h) in hard-

pulling terrain, such as mud, rocks or sand/dune environments.

OPERATION

TOWING

WARNING

Towing improperly can alter vehicle handling and may cause loss of control or

brake instability.

This vehicle can tow vehicles ONLY of equal or lesser size and weight.RZR

When towing a disabled vehicle, place the disabled vehicle’s transmissionRZR

in neutral. Do not operate the vehicle faster than 16 km/h (10 MPH) when

towing.

IMPORTANT

When using a trailer or machine-mounted trailer, always strictly follow the

instructions outlined in the trailer’s operator’s manual before towing. Never tow

trailers unless all respective instructions have been followed.

TOWING A RZR

Towing this vehicle is not recommended. Always transport the vehicle on a

trailer or flatbed with all four wheels off the ground. See the Transporting the

Vehicle section for details.

If towing a disabled vehicle is unavoidable, place the disabled vehicle’s

transmission in neutral. Tow the shortest distance possible. Do not operate

faster than 16km/h (10MPH).

qFront Tow Loop

OPERATION

WINCH GUIDE

WINCH SAFETY

These safety warnings and instructions apply if your vehicle came equipped with

a winch or if you choose to add an accessory winch to your vehicle.

WARNING

Improper winch use can result in SEVERE INJURY or DEATH. Always follow

all winch instructions and warnings in this manual.

Your winch may have a cable made of either wire rope or specially designed

synthetic rope. The term “winch cable” will be used for either unless noted

otherwise.

WINCH SAFETY PRECAUTIONS

1. Read all sections of this manual.

2. Never use alcohol or drugs before or while operating the winch.

3. Never allow children under 16 years of age to operate the winch.

4. Always wear eye protection and heavy gloves when operating the winch.

5. Always keep body, hair, clothing and jewelry clear of the winch cable, fairlead

and hook when operating winch.

6. Never attempt to “jerk” a load attached to the winch with a moving vehicle.

See the section on page 91.Shock Loading

7. Always keep the area around the vehicle, winch, winch cable, and load clear

of people (especially children) and distractions while operating the winch.

8. Always turn the vehicle ignition power OFF when it and the winch are not

being used.

9. Always be sure that at least five (5) full turns of winch cable are wrapped

around the winch drum at all times. The friction provided by this wrapped

cable allows the drum to pull on the winch cable and move the load.

10. Always apply your vehicle’s park brake and/or park mechanism to hold the

vehicle in place during winching. Use wheel chocks if needed.

11. Always align the vehicle and winch with the load directly in front of the

vehicle as much as possible. Avoid winching with the winch cable at an angle

to the winching vehicle’s centerline whenever possible.

WINCH GUIDE

12. If winching at an angle is unavoidable, follow these precautions:

a. Look at the winch drum occasionally. Never let the winch cable “stack” or

accumulate at one end of the winch drum. Too much winch cable at one

end of the winch drum can damage the winch and the winch cable.

b. If stacking occurs, stop winching. Follow step 15 of Winch Operation to

feed and rewind the cable evenly before continuing the winch operation.

13. Never winch up or down at sharp angles. This can destabilize the winching

vehicle and possibly cause it to move without warning.

14. Never attempt to winch loads that weigh more than the winch’s rated

capacity.

15. The winch motor may become hot during winch use. If you winch for more

than 45 seconds, or if the winch stalls during operation, stop winching and

permit the winch to cool down for 10 minutes before using it again.

16. Never touch, push, pull or straddle the

winch cable while winching a load.

17. Never let the winch cable run through

your hands, even if wearing heavy gloves.

18. Never release the clutch on the winch

when the winch cable is under load.

19. Never use the winch for lifting or

transporting people.

20. Never use the winch to hoist or suspend a

vertical load.

21. Always inspect your winch and winch cable before each use.

22. Never winch the hook fully into the winch. This can cause damage to winch

components.

23. Unplug the remote control from the vehicle when the winch is not in use to

prevent inadvertent activation and use by unauthorized persons.

24. Never grease or oil the winch cable. This will cause the winch cable to collect

debris that will shorten the life of the cable.

WINCH GUIDE

WINCH OPERATION

Read the Winch Safety Precautions in the preceding pages before using your

winch.

TIP

Consider practicing the operation and use of your winch before you actually

need to use it in the field.

WARNING

Improper winch use can result in SEVERE INJURY or DEATH. Always follow

all winch instructions and warnings in this manual.

Each winching situation is unique.

• Take your time to think through the winching you are about to do.

• Proceed slowly and deliberately.

• Never hurry or rush during winching.

• Always pay attention to your surroundings.

• You may need to change your winching strategy if it is not working.

• Always remember that your winch is very powerful.

• There are simply some situations that you and your winch will not be able to

deal with. Do not be afraid to ask others to help when this happens.

1. Always inspect the vehicle, winch, winch cable and winch controls for any

signs of damage or parts in need of repair or replacement before each use.

Pay particular attention to the first 3 feet (1 meter) of winch cable if the winch

is being used (or has been used) for lifting an accessory plow assembly.

Promptly replace any worn or damaged cable.

2. Never operate a winch or a vehicle in

need of repair or service.

3. Always apply your vehicle’s park brake

and/ or park mechanism to hold the

vehicle in place during winching. Use

wheel chocks if needed.

4. Always use the hook strap when handling

the hook.

WINCH GUIDE

WARNING

Never put your fingers into the hook. This could lead to SEVERE INJURY.

• Attach the hook itself onto the load or use a tow strap or chain to secure the

load to the winch cable.

TIP

A “tow strap” is NOT intended to stretch. A “recovery strap” is designed to

stretch.

WARNING

Never use a recovery strap when winching due to the excessive energy that

can be released if the winch cable breaks. This can result in SEVERE INJURY

or DEATH. See the section on page 91.Shock Loading

• Never hook the winch cable back onto itself. This will damage the winch cable

and may result in winch cable failure.

WARNING

Replace the winch cable at the first sign of damage to prevent SEVERE

INJURY or DEATH in the event of failure. For your safety, always replace

POLARIS winch parts (including the cable) with genuine POLARIS

replacement parts available at your authorized POLARIS dealer, or other

qualified dealer.

WINCH GUIDE

• If possible, keep the winch cable aligned with the centerline of the winching

vehicle. This will help the spooling of the winch cable and reduce the load on

the fairlead.

• If freeing a stuck vehicle by attaching to a tree, use an item such as a tow

strap to avoid damaging the tree during winch operation. Sharp cables and

chains can damage and even kill trees. Please remember to TreadLightly®

(treadlightly.org).

• Before operating the winch, be sure that the safety latch on the winch cable

hook is fully seated when the load is attached.

• Never operate your winch with a damaged hook or latch. Always replace

damaged parts before using the winch.

5. Never remove the hook strap from the hook.

6. Release the winch clutch and pull out the winch cable.

7. Pulling out as much cable as possible maximizes the winch’s pulling

capacity. Always be sure that at least five (5) full turns of winch cable are

wrapped around the winch drum at all times. The friction provided by this

wrapped cable allows the drum to pull on the winch cable and move the load.

8. Read and adhere to the following information for winch damping to ensure

safe winch use.

a. In order to absorb energy that could be released by a winch cable failure,

always place a “damper” on the winch cable. A damper can be heavy

jacket, tarp, or other soft, dense object. A damper can absorb much of the

energy released if a winch cable breaks when winching. Even a tree limb

can help as a damper if no other items are available to you.

b. Lay the damper on top of the mid-point of the winch cable length that is

spooled out.

WINCH GUIDE

c. On a long pull, it may be necessary to stop winching so that the damper

can be repositioned to the new mid-point of the winch cable. Always

release the tension on the winch cable before repositioning the damper.

d. Avoid being directly in line with the winch cable whenever possible. Also,

never permit others to stand near or in line with the winch cable during

winch operation.

9. Never hook the winch cable back onto itself. This will damage the winch

cable and may result in winch cable failure.

10.Never use straps, chains or other rigging items that are damaged or worn.

11. The ONLY time a winch-equipped vehicle should be moving when using the

winch is when that vehicle itself is stuck. The winch equipped vehicle should

NEVER be in motion to “shock” load the winch cable in an attempt to move a

second stuck vehicle. See the Shock Loading section on page 91. For your

safety, always follow these guidelines when winching a vehicle free:

a. Release the winch clutch and spool out the necessary length of winch

cable.

b. Align the winch cable as close as possible to the winching vehicle’s

centerline.

c. Attach the winch cable hook to the anchor point or the stuck vehicle’s

frame following instructions in this manual.

d. Re-engage the clutch on the winch.

e. Slowly winch in the slack in the winch cable.

f. Select the proper vehicle gear to propel the stuck vehicle in the direction

of winching.

g. Shift to the lowest gear available on the stuck vehicle.

h. Slowly and carefully apply vehicle throttle and winch together to free the

vehicle.

i. Stop winching as soon as the stuck vehicle is able to propel itself without

the help of the winch.

j. Detach the winch cable hook.

k. Rewind the winch cable evenly back onto the winch drum following the

instructions in this manual.

12.Never attempt to winch another stuck vehicle by attaching the winch cable to

a suspension component, brush guard, bumper or cargo rack. Vehicle

damage may result. Instead, attach the winch to a strong portion of the

vehicle frame or hitch.

WINCH GUIDE

13.Extensive winching will run down the battery on the winching vehicle. Let the

winching vehicle’s engine run while operating the winch to prevent the

battery from running low if winching for long periods.

14.The winch motor may become hot during winch use. If you winch for more

than 45 seconds, or if the winch stalls during operation, stop winching and

permit the winch to cool down for 10 minutes before using it again.

15.After winching is complete, especially if winching at an angle, it may be

necessary to re-distribute the winch cable across the winch drum. You will

need an assistant to perform this task.

a. Release the clutch on the winch.

b. Feed out the winch cable that is unevenly bunched up in one area.

c. Re-engage the winch clutch.

d. Have an assistant pull the winch cable tightly with about 100 lbs. (45 kg)

of tension using the hook strap.

e. Slowly winch the cable in while your assistant moves the end of the winch

cable back and forth horizontally to evenly distribute the winch cable on

the drum.

f. Doing this reduces the chances of the winch cable “wedging” itself

between lower layers of winch cable.

WINCH GUIDE

WINCH CABLE CARE

WARNING

Use of worn or damaged cable could lead to sudden failure and SEVERE

INJURY.

For your safety, always replace POLARIS winch parts (including the cable) with

genuine POLARIS replacement parts available at your authorized POLARIS

dealer, or other qualified person.

1. Always inspect your winch before each use. Inspect for worn or loose parts

including mounting hardware. Never use the winch if any part needs repair or

replacement.

2. Always inspect your winch cable before each use. Inspect for worn or kinked

winch cable.

A kinked winch cable made of wire rope

is shown at right. Even after being

“straightened out,” this cable has

already been permanently and severely

damaged. Promptly discontinue use of

a winch cable in this condition.

A kinked winch cable made of wire rope

that has been “straightened out” is

shown at right. Even though it may look

usable, the cable has been permanently

and severely damaged. It can no longer

transmit the load that it could prior to

kinking. Promptly discontinue use of a

winch cable in this condition.

A winch cable made of synthetic rope

should be inspected for signs of fraying.

Replace the cable if fraying is observed

(shown below). Promptly discontinue

use of a winch cable in this condition.

Also replace the winch cable if there are

fused or melted fibers. Such an area of

the synthetic rope will be stiff and

appear smooth or glazed. Promptly

discontinue use of a winch cable in this

condition.

WINCH GUIDE

SHOCK LOADING

WARNING

Your winch cable is very strong but it is NOT designed for dynamic, or “shock”

loading. Shock loading may tension a winch cable beyond its strength and

cause the cable to break. The end of a broken winch cable under such high

loading can cause SEVERE INJURY or DEATH to you and other bystanders.

Winch cables are designed to NOT absorb energy. This is true of both wire-rope

and synthetic-rope winch cables.

1. Never attempt to “jerk” a load with the winch. For example, never take up

slack in the winch cable by moving the winching vehicle in an attempt to

move an object. This is a dangerous practice. It generates high winch cable

loads that may exceed the strength of the cable. Even a slowly moving

vehicle can create large shock loads in a winch cable.

WARNING

SEVERE INJURY or DEATH can result from a broken winch cable.

2. Never quickly turn the winch ON and OFF repeatedly (“jogging”). This puts

extra load on the winch, winch cable, and generates excessive heat from the

motor. This is a form of shock loading.

3. Never tow a vehicle or other object with your winch. Towing an object with a

winch produces shock loading of the cable even when towing at slow

speeds. Towing from a winch also positions the towing force high on the

vehicle. This can cause instability of the vehicle and possibly lead to an

accident.

4. Never use recovery straps with your winch. Recovery straps are designed to

stretch and can store energy. This stored energy in the recovery strap is

released if a winch cable fails making the event even more hazardous.

Similarly, never use elastic “bungie” cords for winching.

5. Never use the winch to tie down a vehicle to a trailer or other transportation

vehicle. This type of use also causes shock loading that can cause damage

to the winch, winch cable, or vehicles used.

Your winch cable is designed and tested to withstand the loads produced

by the winch motor when operated from a stationary vehicle. Always

remember that the winch and winch cable are NOT designed for shock

WINCH GUIDE

WINCH MAINTENANCE AND SERVICE SAFETY

WARNING

Improper or lack of winch maintenance and service could lead to SEVERE

INJURY or DEATH. Always follow all winch instructions and warnings in this

manual.

1. Always inspect your winch before each use. Inspect for worn or kinked winch

cable. Also inspect for worn or loose parts including mounting hardware.

2. Permit your winch motor to cool down prior to servicing your winch.

3. Never work on your winch without first disconnecting the battery connections

to prevent accidental activation of the winch.

4. For your safety, always replace POLARIS winch parts (including the cable)

with genuine POLARIS replacement parts available at your authorized

POLARIS dealer, or other qualified person.

5. Some winch models use wire rope as the winch cable. Other winches use a

specially designed synthetic rope as the winch cable.

6. Never replace a synthetic-rope winch cable with a consumer-grade polymer

rope such as can be purchased in a hardware store. Although they may look

similar, they are NOT alike. A polymer rope not designed for winch use will

stretch and store excessive energy when winching.

WARNING

Failure of a stretched rope under winching conditions will release all of the

stored energy. This will increase the chances of SEVERE INJURY or DEATH.

WINCH GUIDE

EMISSION CONTROL SYSTEMS

NOISE EMISSION CONTROL SYSTEM

Do not modify the engine, intake or exhaust components, as doing so may affect

compliance with governmental noise level requirements.

CRANKCASE EMISSION CONTROL SYSTEM

This engine is equipped with a closed crankcase system. Blow-by gases are

forced back to the combustion chamber by the intake system. All exhaust gases

exit through the exhaust system.

EXHAUST EMISSION CONTROL SYSTEM

Exhaust emissions are controlled by engine design. An electronic fuel injection

(EFI) system controls fuel delivery. The engine and EFI components are set at

the factory for optimal performance and are not adjustable.

The emissions label is located on the left front frame of the vehicle.

ELECTROMAGNETIC INTERFERENCE

This vehicle complies with the EMC requirements of EU regulation No. 2015/208

Annex XV.

Non-ionizing Radiation: This vehicle emits some electromagnetic energy.

People with active or non-active implantable medical devices (such as heart

monitoring or controlling devices) should review the limitations of their device

and the applicable electromagnetic standards and directives that apply to this

vehicle.

EMISSION CONTROL SYSTEMS

MAINTENANCE

ELEVATING THE VEHICLE FOR SERVICE

Some service procedures require that the vehicle be elevated. Before

proceeding, remember to:

• Always position the vehicle on a firm, level surface before elevating.

• Only use an appropriate sized lift or jack.

• Refrain from positioning a jack or jack stand under any components other

than the vehicle frame.

• Refrain from allowing the vehicle to remain elevated on a floor jack for an

extended period of time.

PLACING ONTO JACK STANDS

1. Place the floor jack directly beneath the center of the vehicle (either front or

rear).

2. This vehicle is not equipped with dedicated jacking points. Make sure that

the floor jack only makes contact with the vehicle only while lifting.frame

3. After vehicle is elevated to desired height, place jack stands under the

vehicle on both sides of the floor jack, then lower the vehicle until theframe

jack stands come into contact with the vehicle .frame

MAINTENANCE

PERIODIC MAINTENANCE CHART

Any qualified repair shop or person may maintain, replace or repair the emission

control devices or systems on your vehicle. An authorized POLARIS dealer can

perform any service that may be necessary for your vehicle. POLARIS also

recommends POLARIS parts for emissions-related service, however equivalent

parts can be used.

It is a potential violation of the Clean Air Act if a part supplied by an aftermarket

parts manufacturer reduces the effectiveness of the vehicle’s emission controls.

Tampering with emission controls is prohibited by federal law.

Owners are responsible for performing the scheduled maintenance identified in

this owner’s manual.

Careful periodic maintenance will help keep your vehicle in the safest, most

reliable condition. Inspection, adjustment and lubrication of important

components are explained in the periodic maintenance chart.

Inspect, clean, lubricate, adjust and replace parts as necessary. When

inspection reveals the need for replacement parts, genuine POLARIS parts are

available from your POLARIS dealer. Equivalent parts may be used for

emissions-related service.

Service and adjustments are important for proper vehicle operation. If you're not

familiar with safe service and adjustment procedures, a qualified dealer can

perform these operations.

Vehicles subjected to heavy or severe use patterns must be inspected and

serviced more frequently.

SEVERE USE DEFINITION

• Frequent immersion in mud, water or sand

• Racing or race-style high RPM use

• Prolonged low speed, heavy load operation

• Extended idle

• Frequent short trip operation in cold weather (engine frequently does not

operate long enough to reach full operating temperature)

Pay special attention to the oil level. A rise in oil level during cold weather can

indicate contaminants collecting in the oil sump or crankcase. Change oil

immediately if the oil level begins to rise. Monitor the oil level, and if it continues

to rise, discontinue use and determine the cause. Your POLARIS dealer or other

authorized person can assist.

MAINTENANCE

50 HOUR / 500 MILE (800 KM) SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU General Lubrication Lubricate all fittings, pivots, cables, etc.

D Throttle Pedal Inspect; replace if it sticks

Throttle Body Intake

Ducts/Flange Inspect ducts for proper sealing / air leaks

Shift Cable / Linkage Inspect; adjust as needed

DSteering Lubricate (if applicable)

XU Front / Rear Suspension Lubricate (if applicable)

DCooling System Inspect coolant strength seasonally; pressure

test system yearly

D Drive Belt Inspect; replace as needed

DClutches (Drive and

Driven) Inspect; clean; replace worn parts

XU Engine Oil Lines/

Fasteners Inspect for leaks and loose fittings

XU Spray Suppression

Valances Clean regularly

XU Seat Adjuster Lubricate long threaded bolt and all pivot pins

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

MAINTENANCE

75 HOUR / 750 MILE (1200 KM)SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Engine Oil & Filter

Change

Change oil and filter, inspect used oil for

contaminants

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

MAINTENANCE

100 HOUR / 1000 MILE (1600 KM) SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU General Lubrication Lubricate all fittings, pivots, cables, etc.

D Throttle Pedal Inspect; replace if it sticks

Throttle Body Intake

Ducts/Flange Inspect ducts for proper sealing / air leaks

Shift Cable / Linkage Inspect; adjust as needed

DSteering Lubricate (if applicable)

XU Front / Rear Suspension Lubricate (if applicable)

DCooling System Inspect coolant strength seasonally; pressure

test system yearly

D Drive Belt Inspect; replace as needed

XU Engine Oil Lines/

Fasteners Inspect for leaks and loose fittings

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension as needed

XU Front Gearcase

Lubricant Change lubricant

XU Transmission Lubricant

(AGL) Change lubricant

DFuel System Check for leaks at fill cap, fuel line / rail, and

fuel pump.

DSpark Plug Inspection Inspect; replace as needed; torque to

specification

XU Radiator Inspect; clean external surfaces

XU Cooling Hoses Inspect for leaks; pressure test system

XU Engine Mounts Inspect, torque to specification

Exhaust Silencer / Pipe Inspect

100

MAINTENANCE

ITEM REMARKS

XU Wiring Inspect for wear, routing, security; inspect

connectors subjected to water, mud, etc.

DClutches (Drive and

Driven) Inspect; clean; replace worn parts

DFront Wheel Bearings Inspect; replace as needed

XU Shocks Visually inspect shock seals; change oil and

seals if leaking

Cam Chain Tensioner Inspect/clean; replace as needed

XU Spray Suppression

Valances Clean regularly

XU Seat Adjuster Lubricate long threaded bolt and all pivot pins

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

101

MAINTENANCE

125 HOUR / 1250 MILE (2000 KM) SERVICE

ITEM REMARKS

XU /

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

XU /

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Engine Oil & Filter

Change

Change oil and filter, inspect used oil for

contaminants

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

102

MAINTENANCE

150 HOUR / 1500 MILE (2400 KM) SERVICE

ITEM REMARKS

XU /

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

XU /

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU General Lubrication Lubricate all fittings, pivots, cables, etc.

D Throttle Pedal Inspect; replace if it sticks

Throttle Body Intake

Ducts/Flange Inspect ducts for proper sealing / air leaks

Shift Cable / Linkage Inspect; adjust as needed

DSteering Lubricate (if applicable)

XU Front / Rear Suspension Lubricate (if applicable)

DCooling System Inspect coolant strength seasonally; pressure

test system yearly

D Drive Belt Inspect; replace as needed

DClutches (Drive and

Driven) Inspect; clean; replace worn parts

XU Engine Oil Lines/

Fasteners Inspect for leaks and loose fittings

XU Spray Suppression

Valances Clean regularly

XU Seat Adjuster Lubricate long threaded bolt and all pivot pins

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

103

MAINTENANCE

175 HOUR / 1750 MILE (2800 KM) SERVICE

ITEM REMARKS

XU /

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

XU /

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Engine Oil & Filter

Change

Change oil and filter, inspect used oil for

contaminants

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

104

MAINTENANCE

200 HOUR / 2000 MILE (3200 KM) SERVICE

ITEM REMARKS

XU /

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

XU /

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU General Lubrication Lubricate all fittings, pivots, cables, etc.

D Throttle Pedal Inspect; replace if it sticks

Throttle Body Intake

Ducts/Flange Inspect ducts for proper sealing / air leaks

Shift Cable / Linkage Inspect; adjust as needed

DSteering Lubricate (if applicable)

XU Front / Rear Suspension Lubricate (if applicable)

DCooling System Inspect coolant strength seasonally; pressure

test system yearly

D Drive Belt Inspect; replace as needed

DClutches (Drive and

Driven) Inspect; clean; replace worn parts

XU Engine Oil Lines/

Fasteners Inspect for leaks and loose fittings

XU /

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension as needed

XU Front Gearcase

Lubricant Change lubricant

XU Transmission Lubricant

(AGL) Change lubricant

DFuel System Check for leaks at fill cap, fuel line / rail, and

fuel pump.

DSpark Plug Inspection Inspect; replace as needed; torque to

specification

XU Radiator Inspect; clean external surfaces

XU Cooling Hoses Inspect for leaks; pressure test system

105

MAINTENANCE

ITEM REMARKS

XU Engine Mounts Inspect, torque to specification

Exhaust Silencer / Pipe Inspect

XU Wiring Inspect routing and for wear; inspect

connectors subjected to water/mud.

DFront Wheel Bearings Inspect; replace as needed

XU /

DShocks Change shock oil and inspect seals

D Brake Fluid Change every two years (DOT 4)

Spark Arrestor Clean daily if driven in mud / water; replace a

damaged arrestor before operating

Cam Chain Tensioner Inspect/clean; replace as needed

D Valve Clearance Inspect; adjust as needed

XU Spray Suppression

Valances Clean regularly

XU Seat Adjuster Lubricate long threaded bolt and all pivot pins

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

106

MAINTENANCE

250 HOUR / 2500 MILE (4000 KM) SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU General Lubrication Lubricate all fittings, pivots, cables, etc.

D Throttle Pedal Inspect; replace if it sticks

Throttle Body Intake

Ducts/Flange Inspect ducts for proper sealing / air leaks

Shift Cable / Linkage Inspect; adjust as needed

DSteering Lubricate (if applicable)

XU Front / Rear Suspension Lubricate (if applicable)

DCooling System Inspect coolant strength seasonally; pressure

test system yearly

D Drive Belt Inspect; replace as needed

DClutches (Drive and

Driven) Inspect; clean; replace worn parts

XU Engine Oil Lines/

Fasteners Inspect for leaks and loose fittings

XU Spray Suppression

Valances Clean regularly

XU Seat Adjuster Lubricate long threaded bolt and all pivot pins

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

108

MAINTENANCE

275 HOUR / 2750 MILE (4400 KM) SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Engine Oil & Filter

Change

Change oil and filter, inspect used oil for

contaminants

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

109

MAINTENANCE

ITEM REMARKS

XU Engine Mounts Inspect, torque to specification

Exhaust Silencer / Pipe Inspect

XU Wiring Inspect for wear, routing, security; inspect

connectors subjected to water, mud, etc.

DFront Wheel Bearings Inspect; replace as needed

XU Shocks Visually inspect shock seals; change oil and

seals if leaking

Cam Chain Tensioner Inspect/clean; replace as needed

XU Spray Suppression

Valances Clean regularly

XU Seat Adjuster Lubricate long threaded bolt and all pivot pins

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

111

MAINTENANCE

325 HOUR / 3250 MILE (5200 KM) SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Engine Oil & Filter

Change

Change oil and filter, inspect used oil for

contaminants

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

112

MAINTENANCE

475 HOUR / 4750 MILE (7600 KM) SERVICE

ITEM REMARKS

/ D

Brake Pads / Parking

Brake Pads (INT’L)

Inspect pad wear; replace if worn beyond

service limit

Fuel System Turn key on to pressurize fuel pump; check

lines / fittings for leaks and abrasion

/ D

Parking Brake Cable

Adjustment (INT’L) Inspect; adjust tension if necessary

XU Engine Breather Inspect; clean

Battery Check terminals; clean; test

XU Engine Oil & Filter

Change

Change oil and filter, inspect used oil for

contaminants

XU Front Gearcase

Lubricant Inspect / add lubricant if needed

XU Transmission Lubricant

(AGL) Inspect / add lubricant if needed

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Polaris dealer perform these services.

119

MAINTENANCE
