Industrial VPN Security Router
IVR-100 & IVR-300 Series
Quick Installation Guide
Table of Contents
1. Package Contents ....................................................................................3
2 4.Connecting The Power Input ....................................................................
2.1 Upper Panel ......................................................................................4
2.2 Wiring the Power Inputs.....................................................................5
2.3 Grounding the Device ........................................................................7
2.4 Wiring the Fault Alarm Contact ...........................................................7
2.5 Wi-Fi Antenna Installation (IVR-300W) ................................................8
3. Hardware Installation ...............................................................................9
3.1 DIN-rail Mounting Installation .............................................................9
3.2 Wall-mount Plate Mounting .................................................................9
3.3 Side Wall-mount Plate Mounting .......................................................10
4. Setup of the VPN Gateway .....................................................................11
4.1 Requirements ..................................................................................11
4.2 Logging in to the VPN Gateway ........................................................11
5. RecoveringBacktoDefaultConguration ................................................14
5.1 IP Address has been changed or admin password has been forgotten 14
6. Appendix ..............................................................................................15
7. Customer Support .................................................................................16
3
1. Package Contents
Thank you for purchasing PLANET Industrial Security Gateway, IVR-100 and
IVR-300 series. The descriptions of these models are as follows
IVR-100 Industrial 5-Port 10/100/1000T VPN Security Gateway
IVR-300 Industrial 5-Port 10/100/1000T VPN Security Gateway with
Redundant Power
IVR-300W Industrial 5-Port 10/100/1000T + 802.11ax Wi-Fi VPN Security
Gateway
IVR-300FP Industrial 4-Port 10/100/1000T 802.3at PoE + 1-Port
10/100/1000T + 1-Port 1000X SFP VPN Security Gateway
Open the box of the Security Gateway and carefully unpack it. The box should
contain the following items:
Model
Item IVR-100 IVR-300 IVR-300W IVR-300FP
VPN Gateway x 1 x 1 x 1 x 1
QR Code Sheet x 1 x 1 x 1 x 1
CloudViewer QIG x 1 x 1 x 1 x 1
Wall-mount Kit x 1 x 1 x 1 x 1
Dust Cap x 5 x 5 x 5 x 5
SFP Cap x 1
RS485 3-pin Terminal Block x 1 x 1 x 1
Dual band Wi-Fi Antenna x 2
Antenna Dust Cap x 2
If any of the above items are damaged or missing, please contact your dealer
immediately.
